Living & Co YL-B18 Series User manual

- 1 -
OIL FILLED RADIATOR
USER INSTRUCTIONS
Model no.: YL-B18-11AU
TECHNICAL CHARACTERISTICS
RATED VOLTAGE RANGE: AC220-240V 50Hz
11FINS OIL FILLED RADIATOR 2000-2400W

- 2 -
INDOOR HOUSEHOLD USE ONLY
WARNING: PLEASE READ THIS INSTRUCTION MANUAL CAREFULLY BEFORE USE
When using an electrical appliance, basic safety precautions should always be observed, including the
following:
1. This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
2. Children should be supervised to ensure that they do not play with the appliance.
3. Connect the appliance to single phase AC supply of the voltage specified on the rating plate.
4. In order to avoid overheating, do not cover the heater.
5. Never leave the heater unattended while it is in use.Always turn the product to the OFF position and
unplug it from the electrical outlet when not in use.
6. Extreme caution is necessary when any heater is used by or near children, invalids or elderly person
and whenever the heater is left operating and unattended.
7. The heater must not be located immediately below an electrical socket-outlet.
8. Do not run cord under carpeting and do not cover cord with throw rugs, runners or the like.Arrange
cord away from traffic area and where it will not be tripped over.
9. Do not operate the heater with a damaged cord or plug, or after the heater malfunctions, has been
dropped, or damaged in any manner.
10. If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a
similarly qualified person to avoid a hazard.
11. Avoid the use of an extension cord as this may overheat and cause a risk of fire.
12. Use the heater in a well-ventilated area. Do not insert or allow objects to enter any ventilation or
exhaust opening. To prevent a possible fire, do not block air intakes or exhaust openings in any manner.
Do not use on soft surfaces, like a bed, where openings may become blocked. Use the heater on flat, dry
surfaces only.
13. Do not place this heater near flammable materials, surfaces or substances, as there may be a risk of
fire. Keep the above flammable materials, surfaces or substances at least 1m from the front of the
product and keep them away from the sides and rear.
14. Do not use the heater in any areas where petrol, paint or other flammable liquids are stored e.g.
Garages or workshops as a hot, arcing or sparking parts inside the heater.
15. Don’t use this heater in the immediate surroundings of a bath, a shower or a swimming pool. Never
locate the heater where it may fall into bathtub or other water container.
16. This heater is hot when in use. To avoid burns and personal injury, do not let bare skin touch hot
surfaces. If provided, use handles when moving the product.
17. Be sure that no other appliances are in use on the same electrical circuit as your product as an
overload can occur.
18. This heater is filled with a precise quantity of special oil.
19. Repair requiring opening of the oil container are only to be made by the manufacturer or his service
agent who should be contacted if there is an oil leakage.
20. Regulations concerning the disposal of oil when scrapping the appliance have to be followed.
21. The heater should not be used in a room, of which the floor area is less than 5 M2.
22. The cord shouldn’t be placed nearby the hot surface of the appliance.
23. NOTE: It is normal when the heaters are turned on for the first time or when they are turned on after

- 3 -
having not been used for a long period of time the heaters may have noise inside,This will disappear
when the heater has been on a short while.
YL-B18 series
ASSEMBLY INSTRUCTIONS
The heater is packaged with the feet unattached. You must attach them before operating the heater.
WARNING: Do not operate without feet attached. Do operate the heater only in upright position
(feet on the bottom, controls on the top), any other position could create a hazardous situation.
1. Place the radiator body upside-down on a scratch-free location, make sure it is stable and will not fall.
2. Screw off the wing nuts from the U-shaped bolt provided, attach the U-shaped bolt to the U-facing
flange between first and second fins (near the front cover).
3. To attach the castor mounting plate to the radiator body, you should insert the threaded ends of the U
bolt in the holes on the castor mounting plate.
4. Screw the wing nuts back to the U bolt and fasten the wing nut properly.
Note: do not over tighten, which may cause the damage of radiator flange.
5、Screw off spherical nut from the castor, align the shaft to the hole of the castor mounting plate, insert in,
and screw on the spherical nut.
6、Repeat 2, 3, 4 and 5 on the rear of radiator for mounting of the rear castors.
Note: the rear castors must be mounted between the end two fins.
1. Carry handle
4. Cord storage
2. Power switch
5. Radiant fins
3. Thermostat knob
6. Castor
1
5
2
6
3
4

- 4 -
INSTRUCTIONS FOR USE
1. Before using the heater, make sure that it is on a flat and stable surface. Damage may occur if it is
placed on an incline or decline.
2. Set all the controls to OFF position and insert the plug into a socket-outlet with well grounded. Be sure
that plug fits firmly.
3. Rotate the thermostat knob clockwise to MAX position and switch the heater on as follow: the switch I
for low heat, the switch II for medium heat and both switches on for high heat.
4. When your room reaches the desired temperature, now slowly rotate the thermostat knob counter
clockwise until the pilot light goes out. The thermostat can now be left at this setting. As soon as the room
temperature has dropped below the set temperature, the unit will switch it self on automatically until the
set temperature has been reached again. In this way the room temperature remains constant with the
most economical use of electricity.
5. If you want to change the room temperature setting, rotate the thermostat knob clockwise to raise the
temperature, or counter clockwise to lower it.
6. This heater includes an overheat protection system that shuts off the heater when parts of the heater
are getting excessively hot.
7. To completely shut the heater off, turn all the controls to OFF, and remove plug from the socket-outlet.
MAINTENANCE
1. Always remove the plug from the socket-outlet and allow the radiator to cool down before clean the
heater.
2. Wipe radiator with a soft damp (not wet) cloth.
WARNING:
Do not immerse the heater in water.
Do not use any cleaning chemicals such as detergents and abrasives.
Do not allow the interior to get wet as this could create a hazard.
3. To store away the heater, wind the cable round bobbin and store the heater in a clean dry place.
4. In case of malfunction or doubt, do not try to repair the radiator yourself, it may result in a fire hazard or
electric shock.
CONFORMITY WITH DIRECTIVES
This product is CE marked to denote conformity with Directives 2006/95/EC (Low Voltage) and the EMC
directive (2004/108/EC), as amended.
Correct Disposal of this product
This marking indicates that this product should not be disposed with other
household wastes throughout the EU. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse of material resources. To return
your used device, please use the return and collection systems or contact the
retailer where the product was purchased. They can take this product for
environmental safe recycling.
