1
Cordless Rechargeable
BATTERY PACK
For Reclining Furniture
By Living Spaces
Go Cord-Free
Owner’s Manual
for
LS2500 Rechargeable Battery Pack
LS5000 Rechargeable Battery Pack
LS7500 Rechargeable Battery Pack

2
Your battery purchase includes:
(1) Rechargeable Battery Pack
(1) Charger
(1) AC Cord
Optional accessories not included:
PB – Universal bracket for attaching a battery pack
Y1 – Kit allows you to connect two independent reclining modular pieces (less than 3’ apart)
Y2 – Kit allows you to connect two independent reclining modular pieces (more than 3’ apart).
Y3 – Kit allows you to connect three independent reclining modular pieces
Please be aware:
1. Battery must be fully charged before initial use to ensure maximum battery life.
2. Do not allow battery to completely discharge.
a. A complete discharge may cause battery failure, which is a common characteristic of
Lithium Ion batteries.
b. This battery is equipped with a twenty-minute audible low battery warning signal. You can
use your recliners while the battery is charging.
3. Power reclining furniture with LED lights, speakers, USB ports, etc., will significantly reduce
battery life.
a. Many USB ports draw power even when not in use, requiring frequent charging of your
battery.
b. Ask Living Spaces for more information on the type of USB your furniture is equipped with.
4. If your furniture is equipped with an on/off USB switch, and you are not continuously plugged into
an outlet, it is recommended that you keep USB off at all times.
a. Using a battery to charge another electronic device will transfer the stored energy from the
battery to the electronic device and require frequent recharging of your battery.

3
Charging Instructions
Normal charging procedure (Scenarios A and B)
1. Press the Yellow power indicator button to display estimated remaining power when battery is not
plugged into charger.
2. Connect charger to battery pack. Only use charger provided.
3. Connect the AC power cord to charger, then plug AC power cord into electrical outlet.
4. The LED light will turn bright red, which indicates battery is charging.
5. When the LED light turns blue, battery pack is fully charged.
Normal charging procedure (Scenario C)
1. Press the Yellow power indicator button to display estimated remaining power when battery is not
plugged into charger.
2. Connect charger to Power Port in the rear, right side of your furniture. Only use charger provided.
3. Connect the AC power cord to charger, then plug AC power cord into electrical outlet.
4. The LED light on the Power Port will turn bright red, which indicates built-in battery is charging.
5. When the LED light on Power Port turns blue, built-in battery pack is fully charged.
Low Battery warning – This battery pack includes an audible warning feature. Battery will beep
continuously for 20 minutes when the remaining power is below 10%. It is recommended that you connect
charger immediately. You may continue to operate your recliner(s) while charging.
Caution: If your furniture is equipped with LED lights, speakers, USB ports, etc., the battery may
require frequent charging as some of these features are always active and continuously consume
power. In this case, it is important to charge battery every month. If your furniture has these features
listed above, and you anticipate the recliner will not be used for more than one month, it is
recommended that you disconnect your battery pack from motor. When battery pack is not in use for
extended period, please store in a safe place and ensure the battery pack has at least 50% power.
During charging, the LED light of corresponding remaining
power will flash. All four LED lights will become solid once
fully charged.
Red light indicates charging, Blue light indicates fully charged.
Press the power indicator button to display remaining power.

4
Installation Instructions
Scenario A (floor install without PB bracket)
Battery pack sits on floor underneath reclining mechanism and attaches to motor cable underneath
recliner. When connecting multiple independent recliners, please refer to additional instructions included
in your purchase of Y1, Y2 or Y3 cables.
Scenario B (installation behind backflap with purchase of PB bracket)
(Option #1) Battery pack is mounted behind the backflap of recliner using option PB bracket (Please refer
to PB bracket installation instructions). Battery attaches to motor cable under recliner. When connecting
multiple independent recliners, please refer to additional instructions included in your purchase of Y1, Y2
or Y3 cables.
(Option #2) If your recliner includes “Battery Ready” feature, the motor connection will be behind the
backflap. When connecting multiple independent recliners, please refer to additional instructions included
in your purchase of Y1, Y2 or Y3 cables.
Scenario C – Your recliner was manufactured to include a built-in battery pack. Battery is located inside
the left arm when you are facing the front of your furniture. The power port is located on the back of this
arm. Open zipper on bottom of left arm facing and connect battery to motor cable. Proceed to charging
instructions for scenario C in next section of owner’s manual.

5
Other Important Information
1. Should your battery remain unused for an extended period, it may require several charging cycles before
reaching peak performance.
2. Fully charged and unused mobile power sources are recommended to be recharged every 6 months.
The storage temperature should remain between 32-100 degrees Fahrenheit (0-38 ℃). Absolute
humidity should remain between 45%-85%.
3. For optimum performance, battery pack should be used in at room temperatures ranging from 50-86
degrees Fahrenheit (10-30℃).
4. Safety instructions:
Please check battery casing for cracks or other damage before use.
Should a malfunction be suspected when in first use, such as an odor, stop using it immediately
and return battery pack to the seller. Battery pack should be protected from exposure to direct
sunlight to avoid overheating, discoloration, warping, poor performance or shortened life.
This battery pack has been developed for use in power reclining furniture. Choosing to use battery
pack for other equipment than its intended use will void the warranty. Ensure that the technical
specifications of this battery pack, such as high current, fast charging, special applications and
other functions, meet the requirements of another manufacturer’s equipment before use.
The battery pack has a built-in protection circuit to prevent various accidents. Do not use the
battery pack in places where static electricity is available. Static electricity (above 1000V) can
easily damage the battery casing, causing the battery pack to heat up, deform, smoke or ignite.
When in use, the battery pack should be kept away from heat or high pressure. Do not drop the
battery pack.
Do not touch the contacts or disassemble the battery pack by yourself. Tampering with battery pack
may be harmful and will void warranty.
Never leave the battery pack in a damp place. Avoid getting the battery pack wet. Doing so may
cause damage to the internal protection circuit, causing it to heat up, smoke, deform or burn.
Dispose of the discarded battery pack properly. Do not put it in fire or in water.
The battery pack’s positive and negative pin connectors must not be touched by metal or foreign
object. Doing so may cause a short-circuit, the current will be amplified, and the battery pack will
be damaged, causing it to heat up, smoke, deform or burn.
Do not use the battery pack near fire sources, ovens, or where environment temperature exceeds
100 degrees Fahrenheit (38℃) or in high pressure. This may cause a short circuit and battery pack
to heat up, smoke, deform or burn.
CAUTION
Should battery pack malfunction and cause a hazard by leaking, do not come in
contact with leakage. In the event of accidental contact, rinse with water
immediately and consult a doctor.
CAUTION
Battery pack should always remain out of the reach of children or those who
have reduced physical or sensory ability.

6
Troubleshooting
1. For your safety, battery pack includes short circuit and overload protection systems. Should the
system experience either a short circuit or overload situation, power will be cut automatically.
Unplug the battery pack from motor, wait 3 minutes, then fully charge battery pack before
reconnecting to motor.
2. If the red light flashes rapidly (0.3 second intervals), it indicates a problem with the battery pack
which may include voltage overload, temperature overload, power loss, etc. Please stop charging
and/or using battery pack immediately until red light stops flashing rapidly. Please note that red light
flashing slowly (2 second intervals) is normal and reminds the user that the battery pack is low and
should be charged as soon as possible.
3. Only a qualified technician may repair battery pack. Tampering with battery pack casing will void
warranty.
4. My battery is connected, and furniture does not recline?
a. Ensure that the battery is properly installed and plugged in as instructed above. Specifically, ensure
that the cord from the battery is connected to the motor cord from the power recliner mechanism
and not the cord for the power headrest or power lumbar.
b. Follow the charging instructions if the red-light is flashing slowly (2 second intervals).
c. Verify that your furniture reclines when connected directly to the wall plug without the battery
installed. This will help determine if the issue is with the recliner, battery connection, or the battery.
5. One or more of the power features (i.e. power lumbar or headrest if included) of the furniture do not
function.
a. Ensure that the power cables for each feature are connected according to your furniture’s instruction
manual.
b. Ensure that the cables are attached to the recliner power cord according to the directions above.
c. Verify that the power feature operates when connected directly to the wall plug without the battery
installed. This will help determine if the issue is with the furniture, battery connection, or the battery.
