ZOOM AM1808 EVM
2 QuickStart Guide
Table of Contents
1Introduction 4
1.1 Scope of Document 4
1.2 Zoom AM1808 EVM Development Kit Contents 4
1.3 Unpack the System 5
1.4 Baseboard Connection Diagram 6
2 Development Kit Set-up 8
2.1 Connect the SOM-M1 to the Baseboard 8
2.2 Connect 4.3” WQVGA LCD 9
2.3 Ready for Demo Mode 10
3 Next Steps 13
3.1 Register your Development Kit 13
3.2 User Manuals and Getting Started Guides 13
4 Support & Product Ordering Information 14
4.1 Documentation and Software Downloads 14
4.2 Frequently Asked Questions 14
4.3 Technical Discussion Group 14
4.4 Warranty Statement 14
4.5 Additional Support Services Available from Logic 15
4.6 Product Ordering Information 15
4.7 Optional Zoom Display Kits 15
5 Product Notices 16
6 Troubleshooting 17

ZOOM AM1808 EVM
QuickStart Guide 3
List of Figures
Figure 1.1 – Kit Hardware Contents 5
Figure 1.2 –Connection Diagram for the Baseboard 6
Figure 2.1 –Align the SOM-M1 over the Baseboard 8
Figure 2.2 –Connect the SOM-M1 to the Baseboard 9
Figure 2.3 – Connect LCD to Baseboard 10
Figure 2.4 –Proper SD Card Positioning 10
Figure 2.5 – Insert SD Card 11
Figure 2.6 –Connect Power Supply and Adapter 11
Figure 2.7 –Connect Power to the Baseboard 12
Figure 2.8 –Switch Power On 12

ZOOM AM1808 EVM
4 QuickStart Guide
1 Introduction
Congratulations on your purchase of the Zoom™ AM1808 EVM Development Kit. This Zoom
Development Kit provides a product-ready hardware and software platform for evaluating the
functionality of the Texas Instruments™ (TI) Sitara™ AM1808 processor and the Logic
System on Module (SOM).
1.1 Scope of Document
This QuickStart Guide will list the contents of the development kit, point out the features of
the major components, and provide the instructions necessary to verify your development kit
is in working order. Any additional usage instructions or details fall outside the scope of this
document; additional documentation resources will be listed at the conclusion of this
QuickStart Guide.
1.2 Zoom AM1808 EVM Development Kit Contents
Boards
+AM1808 SOM-M1
+Application baseboard
+User Interface (UI) board
Display
+4.3” WQVGA TFT LCD with touchscreen
Cables and Accessories
+Blackhawk USB100v2 JTAG Controller
+Serial cable (null-modem)
+5 volt power supply with power adapters for the US, UK, Japan, and Europe
+Ethernet crossover cable
+USB A to mini-B cable
+Three screws and nuts
Software DVDs & SD Card
+Linux demo image on SD card
+AM1808 SW Tools DVD contains:
+Code Composer Studio (CCS) v4.1.1 IDE
+Board Support Library (BSL) sample programs
+TI AM1808 Linux Software Development Kit (SDK) contains:
+Open source Linux system tools and target file system
+Code Sourcery G++ Lite and Commercial Tools - Evaluation DVD

ZOOM AM1808 EVM
QuickStart Guide 5
1.3 Unpack the System
Once you have verified that all the development kit items are present, carefully remove the
boards from their protective anti-static bags. Check the boards for any visible damage and
ensure that there are no broken, damaged, or
missing parts.
NOTE: Use ESD precautions when handling the
boards.
Figure 1.1 – Kit Hardware Contents
Not shown: Software DVDs, SD Card, Screws & Nuts
AM1808
Regulated 5 volt
Power Supply
Null-modem
Serial Cable
Ethernet
Crossover Cable
Application Baseboard
Power Adapters
(only US cord
shown)
User Interface (UI) Board
USB Cable
SOM-M1
4.3” WQVGA LCD Blackhawk USB100v2
JTAG Controller

ZOOM AM1808 EVM
6 QuickStart Guide
1.4 Baseboard Connection Diagram
Figure 1.2 – Connection Diagram for the Baseboard
BADEF
G
H
J
LMNO
K
I
PQRS
T
U
V
C

ZOOM AM1808 EVM
QuickStart Guide 7
Connection Diagram Details
A – RS232 serial debug port
B – Line-in stereo 3.5 mm jack
C – SD/MMC card slot (on bottom of board)
D – Line-out stereo 3.5 mm jack
E – Three 100-pin board-to-board (BTB) socket connectors for SOM-M1
F – 60-pin header for integrated LCD, touch, backlight, connector power
G – USB On-the-Go mini-AB port (USB0)
H – USB host Type A port (USB1)
I – RJ45 Ethernet jack with magnetics (for use with MII PHY only)
J – Power-in from 5 volt regulated power supply
K– Poweron/offswitch
L – Video port interface (VPIF) BTB expansion connector (UI board connector)
M – System reset button
N – System user button
O – SATA connector
P – External memory interface (EMIF) BTB expansion connector (UI board connector)
Q – Boot mode / FET mux DIP switches (S7)
R – General purpose user DIP switches (S2)
S – Expansion connector
T – JTAG header for TI processor
U – Expansion connector
V – JTAG header for ARM core (used with the Blackhawk USB100v2 JTAG Controller)

ZOOM AM1808 EVM
8 QuickStart Guide
2 Development Kit Set-up
2.1 Connect the SOM-M1 to the Baseboard
The AM1808 EVM Development Kit comes with the AM1808 SOM-M1 that connects to the
baseboard via three board-to-board (BTB) socket connectors.
1. Align the SOM-M1 over the three BTB socket connectors in the center of the
baseboard. See Figure 2.1.
Figure 2.1 – Align the SOM-M1 over the Baseboard
2. Press straight down on the SOM-M1, applying even pressure over the baseboard
BTB socket connectors. See Figure 2.2.
