Logitech NuLOOQ navigator Guide

Welcome to Logitech NuLOOQ navigator
Congratulations on acquiring your new Logitech NuLOOQ navigator control device. This innovative
new device is truly your mouse's best friend. Off
load navigation and many other actions from the
mouse onto the NuLOOQ navigator. To get the
most from your device, you can use this help
system. It offers ideas on how you can use your
device's features when you are working, playing,
and communicating. It provides details on
customizing your device to suit you. And it gives
instructions on how to carry out your daily tasks
with your device.
Use this help system to work smarter, play more,
and communicate better with your Logitech
NuLOOQ navigator.
Select a task... (Click on link below)
●Configuring Adobe Photoshop CS2 for 1st Time Use
●Quickly Getting Started using your NuLOOQ navigator
●Installing / Uninstalling NuLOOQ navigator
●Using NuLOOQ navigator with Adobe Photoshop CS2
●Using NuLOOQ navigator with Adobe Photoshop Elements 4
●Other Applications
●Configuring NuLOOQ navigator for other apps
●Support
© 2006 Logitech. All rights reserved. Logitech, the Logitech logo and other Logitech marks are owned by Logitech and may be registered.
All other trademarks are the property of their respective owners.

Configuring Adobe Photoshop CS2 for 1st Time Use
Before NuLOOQ navigator can be used with Adobe Photoshop CS2, you must first configure Adobe Photoshop CS2 and then restart CS2
for proper operation. To get started, first ensure that the NuLOOQ navigator driver has been installed on your system and your system has
been restarted, if required.
Once up and running, start Adobe Photoshop CS2. After a first time install, you'll get a dialog box saying that you need to configure
Adobe Photoshop CS2.
Click on OK and once in Photoshop, go to "Keyboard Shortcuts..." menu. This menu is available from the "Edit" menu item.

A dialog box appears with options on configuring shortcut keys for virtually any command in Photoshop.
Click on "File" menu command. This will expand all the "File" menu commands. Scroll down the list till you fine "NuLOOQ Plug-in...".
Click under shortcut column next to "NuLOOQ Plug-in..." row and enter a shortcut command. Note, this shortcut command can be
anything, you'll not be typing this shortcut key at anytime, so make it as complicated as possible. This is required for our
Photoshop plug-in and once configured, you'll never have to use it again.

Click on OK once complete and then exit out of Photoshop. You may now start Photoshop and start using NuLOOQ navigator. No other
configuration changes are required from within the NuLOOQ navigator panel.
If you change your workspace or load a different workspace, you may need to reconfigure the shortcut key for NuLOOQ Plug-in.
© 2006 Logitech. All rights reserved. Logitech, the Logitech logo and other Logitech marks are owned by Logitech and may be registered. All other trademarks are the property of their
respective owners.

Getting Started
Logitech NuLOOQ navigator is a powerful device with a great deal of functionality and flexibility. Click on links below
to quickly get to a different section.
●NuLOOQ navigator components
●Placing the device on the desk
●Properly holding your NuLOOQ navigator
●Using the navring
●Using the tooltuner dial
●Using the triggerpoints
●Configuring NuLOOQ navigator
NuLOOQ navigator components
The NuLOOQ navigator is composed of a number of moveable and touch sensitive parts:
●navring: The gray moveable ring encircling the device.
●tooltuner dial: The touch sensitive circular surface located on top. (Also referred to as tooltuner.)

●click triggerpoints: The 4 triggerpoints within the tooltuner dial groove. Triggerpoints labeled I, III and the circle
and square buttons are click triggerpoints.
●touch triggerpoint: The single button located in the center labeled triggerpoint II.
Back to top >
Placing the device on the desk
The NuLOOQ navigator is not a mouse, but rather works with your mouse, trackball or tablet and keyboard. If you use
your mouse or tablet with the right hand, the NuLOOQ navigator should be placed on the left hand side. And vice versa if
you use your mouse or tablet on the left hand side. Picture below is an example of how NuLOOQ navigator is used on the
left hand and the mouse on the right hand.
Back to top >
Properly holding the NuLOOQ navigator
The NuLOOQ navigator is composed of a moveable ring, called the navring and also a touch sensitive surface located on
top of the device called the tooltuner dial or tooltuner. The most practical way to hold the device is to gently place your
thumb and middle or index finger on the gray ring and rest your arm on its side next to the navigator. This allows you to
move the navring as well as the tooltuner dial with minimal hand movement. See picture below for an example of the left
hand can be placed on the NuLOOQ navigator. We don't recommend placing your hand over the top the device as that

limits your access to the tooltuner dial and the built-in triggerpoints.
Back to top >
Using the navring
The navring is a gentle moveable gray ring encircling the device. This ring can be moved in all horizontal directions and
twisted, as shown in animated image below. Keep in mind that the device is not intended to move. Only the navring
slides, while the device is stationary.

In most applications, the navring is used to pan and zoom around documents and images. However in timeline based apps,
such as video editing or audio applications, the navring can be configured to navigate the timeline, such as moving forward
or backwards or adjusting resolution.
Back to top >
Using the tooltuner dial
The tooltuner dial is a flat touch-sensitive surface located on the top of your NuLOOQ navigator. To use the tooltuner dial,
just gently glide your finger on the surface within the groove in a clockwise or counter clockwise direction as shown in the
picture below.
The tooltuner dial is typically used to adjust brush size or text attributes in applications like Adobe Photoshop and Adobe
InDesign. However the tooltuner dial can be configured for many uses, including adjusting volume or navigating
timelines.
Back to top >

Using the triggerpoints
The surface of the tooltuner dial also contains five triggerpoints; 4 triggerpoints require a click to activate, while one is
touch sensitive.
All 5 triggerpoints are fully programmable and configurable. Triggerpoint II is touch sensitive and doesn't require a
click to activate. Just resting your finger on the surface of triggerpoint II will activate the button. The triggerpoints can be
configured to execute shortcut commands or even act as a modifier key. The NuLOOQ navigator control panel can be used
to configure the triggerpoints by application.
Please note that in applications such as Adobe Photoshop and Adobe InDesign, to adjust the brush size or text attributes
using tooltuner dial, a button needs to be configured to enable that mode. By default the button at the top (looks like a
square) is configured to enable tooltuner dial to adjust brush size. In other applications, all 5 buttons are programmable.
Back to top >
Configuring NuLOOQ navigator
The NuLOOQ navigator control panel can be used to quickly configure NuLOOQ navigator for your custom needs. The
control panel can be opened by either right clicking on navigator icon on system tray and opening panel or opening control
panel window and then double clicking on NuLOOQ navigator icon.

Back to top >
© 2006 Logitech. All rights reserved. Logitech, the Logitech logo and other Logitech marks are owned by Logitech and may be registered. All other trademarks are the
property of their respective owners.

Installing / Uninstalling Logitech NuLOOQ
navigator
In the Package
The package containing NuLOOQ navigator contains the control device, an installation CD and other
marketing collateral. The CD contained in the package is the latest version of software available at that
time. Please visit http://www.logitech.com/ for any newer drivers that may have been released since the
CD.
Plugging in NuLOOQ navigator
First plug your NuLOOQ navigator into any available USB port on your system or hub. The NuLOOQ
navigator does not require any unique USB port. Any available port will work for NuLOOQ navigator.
Once you plug-in the hardware, Microsoft Windows XP may attempt to auto configure the device. You
may see a message in the system tray indicating the system is attempting to configure the new
hardware. Let Microsoft Windows complete this process. Upon completion of this process, Microsoft
may require you to reboot the system. Please reboot at this time. However note the NuLOOQ
navigator driver hasn't yet been installed.
Installing the Driver
Place the install CD into your CD-ROM drive. If the CD doesn't auto start, open Windows Explorer and
open the setup file to start the install process. You'll see a sequence of screens guiding you through the
installation process.

The first screen above asks you to confirm the license agreement. Check next to "Yes" if you agree with
the agreement and then click on "Next>" to proceed to next screen.

The second screen above allows you to confirm location of driver. We recommend selecting the default
location. If you desire the driver to be installed at another location, type in the new location in the text
box or select browse to bring up the "Select Folder" window to select the folder. Once complete, click
on "Next>" to proceed to next screen. You may be asked for confirmation to place NuLOOQ navigator
files into the specified directory.

The last screen confirms your installation configuration. Once you click on "Next>" the installation for
NuLOOQ navigator will begin.

The installation will take between 10-30 seconds depending on your processor speed. Once complete
you'll be ready to use NuLOOQ navigator. No reboot is required after installation of Logitech driver.
To confirm that your NuLOOQ navigator is installed the button lights on top of your device will be
glowing blue and a NuLOOQ navigator icon should appear in the system tray.
Uninstalling NuLOOQ navigator
There are two ways
to uninstall NuLOOQ
navigator driver and
plug-ins. The fastest way is to find NuLOOQ navigator from within the Start menu. Under that menu
item, you'll see "Uninstall NuLOOQ navigator". Select that option to start the Uninstall program for
NuLOOQ navigator.

The above screen offers two options, one to uninstall and the other to repair. Select Uninstall and then
"Next>" to continue the uninstall process

.
The above confirmation screen asks you to reconfirm uninstall of NuLOOQ navigator. Note when you
uninstall NuLOOQ navigator, only driver and plug-in files will be deleted. All user configuration files
will NOT be deleted from your system. After you click on "Next>", the uninstall process will start and
be completed in a few seconds.
You don't need to restart the system. You can unplug your NuLOOQ navigator at anytime.
Repairing NuLOOQ navigator
If NuLOOQ navigator isn't functioning properly or if you've upgraded your Adobe applications, you
may need to repair NuLOOQ navigator installation to ensure required plug-ins are installed in the right
directory. At this time plug-ins are installed for Adobe Photoshop CS2, Adobe InDesign CS2 and
Adobe Photoshop Elements 4. If any of those applications are reinstalled, installed for first time or
uninstalled, you may need to run repair NuLOOQ navigator to ensure proper operation.

Select Repair NuLOOQ navigator from screen above to start repair process. And then click on "Next>"
to continue to next screen.

The repair process will reinstall drivers and plug-ins. Note any configuration files will not be removed
in the process. Click "Next>" to start process. The repair process will take about 10-30 seconds and
NuLOOQ navigator will be fully functional upon completion of the process.
© 2006 Logitech. All rights reserved. Logitech, the Logitech logo and other Logitech marks are owned by Logitech and may be registered.
All other trademarks are the property of their respective owners.

Using NuLOOQ navigator with Adobe Photoshop
CS2
Let's get started using NuLOOQ navigator in Adobe Photoshop CS2. Click on any link to quickly get to
see how you can use the navring, tooltuner and triggerpoints in Adobe Photoshop CS2. If you haven't
yet configured a shortcut command within Adobe Photoshop CS2 after your install, please click here to
configure Adobe Photoshop CS2 for proper operation.
●Pan and Zoom Navigation using navring
●Adjusting Brush Size and other Options using tooltuner
●Quick Shortcut Command / Modifier key access using triggerpoints
