Logitech Z906 User's Guide User manual

Logitech®
Surround Sound Speakers Z906
User’s Guide

2
Logitech®Surround Sound Speakers Z906
Contents
English 3
Deutsch 14
Français 25
Italiano 36
Español 47
Português 58
Nederlands 69
Svenska 80
Dansk 91
Norsk 102
Suomi 113
Ελληνικά 124
По-русски 135
Magyar 146
Česká verze 157
Po polsku 168
Eesti 179
Latviski 190
Lietuvių 201
Hrvatski 212
Srpski 223
Slovenščina 234
Slovenčina 245
Română 256
Български 267
Українська 278
Türkçe 289
310

English 3
Logitech®Surround Sound Speakers Z906
Thank you
Thank you for purchasing Logitech® Surround Sound Speakers Z906—designed to let you hear
every detail, all around you, with theater-quality 5.1 sound for your movies, games and music.
Dolby® Digital
Dolby Digital is the universal standard for 5.1
digital sound. Onboard 5.1 digital decoding
enables detailed surround sound—from the roar
of the crowd to the footsteps right behind you—
in your Dolby Digital soundtracks.
THX® Certified
THX certification is the seal of approval for
speaker quality. The Z906 speakers have
met strict performance standards to achieve
THX certification—so you can be sure that
your entertainment will sound the way it was
meant to.
DTS Digital Surround™
DTS is dedicated to making digital entertainment exciting, engaging and effortless by providing
state-of-the-art audio decoding. Blu-ray Disc technology adoption of DTS means you’ll get the
highest quality surround sound—in all of your DTS digital surround soundtracks.
For information about safety, compliance, and warranty,
please see the Important Information document.

4English
User’s guide
1. Four satellite speakers
2. Subwoofer
3. Center satellite speaker
4. Remote control
5. Control console
6. Five lengths of standard 18-guage speaker wire:
• Two 7.6-meter lengths for rear satellite
speakers
• Three 4.6-meter lengths for front and center
satellite speakers
7. 6-channel direct input cable
8. Three AAA alkaline batteries (remote control)
9. User documentation
Important information
Safety, compliance, and warranty
Logitech
®
Surround Sound Speakers Z906
User’s Guide

English 5
Logitech®Surround Sound Speakers Z906
Speaker placement
Before you position your speakers, take a look
around your room and figure out the best setup
(see diagram to the right). It’s easiest to place
all your speakers in the desired locations before
attaching any cables.
Satellite speakers – Place the two front
satellite speakers on either side of your
computer monitor or television, about the same
distance from each other as they are from your
listening position (e.g., the couch). Angle them
to face you. Place the two rear speakers behind
you and about the same distance apart as
the front speakers. You may want to mount
these speakers on the wall (see Wall mounting).
Center satellite speaker – Place your center
satellite speaker on your desk, or in front of
your monitor or television; you may also
wall-mount it.
Subwoofer – You can place the subwoofer
anywhere in relation to the other speakers.
To get the strongest bass, place your subwoofer
near a wall or corner, or under a desk. Make sure
that nothing is closer than 16 cm to the driver
or the bass port because it will affect your
sound. It’s also important to have adequate
ventilation around the subwoofer.
Control console –Place the control console
where it’s easy to reach. And make sure the IR
window is in plain view so the remote control
can communicate with it.
Subwoofer
Couch

6English
User’s guide
Subwoofer
Inputs
1. 6-channel direct
(PC sound card)
2. RCA (stereo)
3. Digital optical
4. Digital optical
5. Digital coaxial
Console
6. DB-15 pin connector
Speakers
7. Rear left
8. Rear right
9. Front left
10. Front right
11. Center
Power
12. Cable
Subwoofer back panel
SPEAKERS
FRONT RIGHT
FRONT LEFT
CENTER
REAR RIGHT
REAR LEFT
INPUTS
CONSOLE
2
34 5
1
SPEAKERS
FRONT RIGHT
FRONT LEFT
CENTER
REAR RIGHT
REAR LEFT
INPUTS
CONSOLE
1
34 5
2
12

English 7
Logitech®Surround Sound Speakers Z906
Connecting your speaker cables
The Z906 comes with five speaker cables: two 7.6-meter
cables for the rear satellites and three 4.6-meter cables
for the front and center satellites. When connecting
your speakers, the control console, and your audio source,
make sure the power to the system is off.
Connect the speaker cables –Connect your satellites
to the subwoofer using the speaker cables. Push the tab
on the spring clip, insert the wire into the connector,
and release the tab. Be sure that you match the wire
color (red or black) to the spring clip colors on both the
subwoofer and the satellite.
Connect the control console DB-15 cable – Connect
the control console DB-15 cable to the corresponding DB-
15 pin connector jack on the subwoofer.
SPEAKERS
FRONT RIGHT
FRONT LEFT
CENTER
REAR RIGHT
REAR LEFT
SPEAKERS
FRONT RIGHT
FRONT LEFT
CENTER
REAR RIGHT
REAR LEFT

8English
User’s guide
1. Power On/Off
2. Input indicator
3. Decode indicator
4. Volume/Level indicator
5. Volume/Level adjust: Use this to adjust the main
volume, subwoofer, rear satellites, and center
channel levels.
6. Speaker indicator
7. IR remote window
8. Level select: Use this to select subwoofer, rear
satellites, center channel, or main volume levels.
9. Mute: Mutes the whole system.
10. Effect select: When a stereo source is present,
use this to select your desired sound effect:
• Stereo 3D – Provides a 3D surround sound
effect through all speakers
• Stereo 4.1 - Plays stereo through both front
and both rear satellites, plus the subwoofer
• Stereo 2.1 – Plays stereo through both the
front satellites and the subwoofer
11. Input select: Use this to select your audio source
(6-channel direct, stereo, optical, coax, and Aux).
12. Headphone jack (side of console): When you plug
your headphones in, all other outputs will be
automatically muted.
13. Aux input (side of console)
INPUT
1
2
3
3D
4.1
2.1
4
5
AUX
DECODE
STEREO
MUTE
INPUT EFFECT LEVEL
12
13
Control console

English 9
Logitech®Surround Sound Speakers Z906
1. Battery door: Install the three AAA batteries
2. Power On/Off
3. Input select: Use this to select your audio source
(6-channel direct, stereo, optical, coax, and Aux).
4. Mute: Mutes the whole system.
5. Level select: Use this to select subwoofer, rear
satellites, center channel, or main volume levels.
6. Volume/Level up: Use this to adjust the main
volume, subwoofer, rear satellites, and center
channel levels
7. Effect select: When a stereo source is present,
use this to select your desired sound effect:
Stereo 3D, Stereo 4.1, and Stereo 2.1.
8. Volume/Level down: Use this to adjust the main
volume, subwoofer, rear satellites, and center
channel levels
9. Test: See Testing your system for more information
about this mode.
Remote control
Control your listening experience without ever getting off the couch.
INPUT MUTE
LEVEL
EFFECT

10 English
User’s guide
Connect the subwoofer
power cable
Plug the subwoofer power cable into an
electrical outlet.
Adjust volume
Set volume to the nine o’clock position to test;
adjust thereafter as needed.
Turning on your system
Press the POWER ON/OFF button on the remote
control or control console to turn on your Z906.
Testing your system
To test whether you have correctly set up
your speakers, press and hold the INPUT button
on the remote control or control console for
5 seconds to put your system into test mode.
In test mode, the system cycles through each
speaker, playing an audible test signal. The test
signal comes from only one speaker at a time,
in 5-second intervals, in the following order:
left front, center, right front, right rear, left rear,
and subwoofer.
As a channel is tested, its corresponding LED
lights up on the front panel of the control
console. The test signal cycles through each
speaker one time and stops. To re-enter test
mode, press and hold the INPUT button on
the remote or control console for 5 seconds.
INPUTS
CONSOLE
2
34 5
1
INPUTS
CONSOLE
1
34 5
2
Subwoofer back panel
Connect the audio source cable
Turn off speakers
Connect your audio source (e.g., TV, DVD,
computer) to the appropriate input jack on
your subwoofer.
•For computer sound cards, use the 6-channel
input (cable included).
•For stereo devices, use the Stereo RCA input
(cable not included).
•For digital devices, use the digital inputs
(cable not included).
