Lorex LNC104 Installation and operation manual

WIRELESS NETWORK CAMERA
www.lorextechnology.com
•View & record anytime, anywhere
•Control with Smartphone / Tablet App
•Dual lens for enhanced day & night video
•Event Push notifications
•Easy 3-step set-up
RECORD, PLAYBACK & SHARE.
Record directly to the camera, your smartphone, tablet, PC or Mac. Multiple recording options, no
recurring fees.*
DUAL MOTION DETECTION.
Advanced audio & motion sensors with smart video motion detection for improved alert accuracy.
EXPAND YOUR VIEW.
Watch over multiple locations simultaneously. Your home, your office or your vacation property, all in
one screen.6
QUICK SETUP.
Activate your camera by simply scanning a QR code with your smartphone or tablet.
STAY CONNECTED -
ANYWHERE YOU GO
LNC104 Series
PING
iPhone®iPad®
AWAY
FROM HOME*
HOME
WPS
SD
WWW
Wi-Fi
(OR)
Wired

FEATURES
www.lorextechnology.com
• iOS, Android, PC and Mac compatible *
• Wi-Fi & wired internet connectivity
•Easy connection to Wi-Fi networks with WPS 1
• Night vision up to 30ft with single high-power IR LED 2
• microSD recording & playback supported 3
• Dual motion detection : PIR & video
• Sound activated alerts
• Push notification of events & email alerts with snap shot
attachment
• Bandwidth-efficient VGA (640x480) resolution
• H.264 video compression
• Supports up to 20 simultaneous users 4
• Two-way audio supported 5
• Flexible indoor mounting (counter, wall, ceiling)
• Expandable up to 4 cameras
PC Viewing Application. (PC not included)
WIRELESS NETWORK CAMERA
LNC104 Series
PING
Mobile Application - iPad, iphone & Android App shown.
(tablet and mobile phones not included)

©2012 Lorex Technology Inc.
As our product is subject to continuous improvement, Lorex Technology & subsidiaries
reserve the right to modify product design, specifications & prices without notice and
without incurring any obligation. E&OE
901 Elkridge Landing Road, Suite 100
Linthicum, Maryland 21090
USA
Lorex Technology Inc.
250 Royal Crest Court
Markham, Ontario L3R 3S1
Canada
3-18102012
www.lorextechnology.com
Mode: Day & Night
Power: DC 5V, 1A (USB)
Processors: RISC CPU, hardware video processing and compression.
Network interface: Ethernet 10BaseT/100BaseTX, Auto-MDIX, RJ-45
Wireless interface: IEEE 802.11n 90 - 150 Mbps
IEEE 802.11g 6 - 54 Mbps
IEEE 802.11b 1 - 11 Mbps
Transmit power: 14.5dBm typically @ 802.11g
17.5dBm typically @ 802.11b
Receiver sensitivity: 54Mbps: Typical -73dBm @ 10% PER
11Mbps: Typical -86dBm @ 10% PER
Antenna gain: 0.01 dBi
Image sensor: RGB VGA 1/4 inch CMOS
Day and night separate sensorsAutomatic exposure control,
automatic white balance, automatic gain control, automatic
brightness control.
PIR sensor: Effective distance – 7 meters
Light sensitivity: 0.2 Lux ( IR LED off )
0 Lux (with 9 meters IR LED on)
Automatically turn on the IR LED on low light environment.
Lens: 3.2 mm, F2.0, viewing angle: 60.3°, fixed iris.
focus range: 30 cm to infinity
Day and night separate lens
Buttons: One reset button, to factory default settings
One WPS button for automatic WiFi setup
Indicators: One LED for Internet connection status indication
One LED for Ethernet connection indication
One LED for SD card recording indication
Video compression: H.264, baseline profile level 3.1
Video streaming: Separate frame rate/resolution/bandwidth settings for PC and
mobile.
Resolution: VGA(640x480), QVGA(320x240), QQVGA(160x120)
Bandwidth: 64k, 128k, 256k, 512k, 768k, 1M, 1.2M, 1.5M bps
Frame rate: 1~5, 10, 15, 20, 25, 30 fps
Audio: Built-in microphone for audio monitoring
Speaker jack for external speaker
Audio compression: G.711
• SPECIFICATIONS
MODEL CONFIGURATION PACKAGE W x D x H WEIGHT CUBE UPC Code
LNC104 Wireless Network
Camera
Retail
Giftbox
162 x 89 x 162mm/
6.4 x 3.5 x 6.4”
0.45 kg/1 lbs 0.0025 CBM x 0.086 CBF 7-78597-10400-4
LNC104F Wireless Network
Camera
Universal
Giftbox
162 x 89 x 162mm/
6.4 x 3.5 x 6.4”
0.45 kg/1 lbs 0.0025 CBM x 0.086 CBF 7-78597-10401-1
Includes: IP Camera, Camera Bracket, Ethernet cable, Power adapter, User Manual, Quick Start Guide, CD
• PRODUCT INFORMATION
Dimensions:
75mm/
3.0" 35mm/
1.4"
128mm/
5.1"
WIRELESS NETWORK CAMERA
Security: Web management username/password protection
Video display ID/password protection
WiFi WEP and WPA/WPA2 security mode
Installation, management and maintenance:
Plug & play by ID/password.
Video management software-L-View for video access and multi-
camera management
Firmware upgrades Push Notification
L-View SW upgrade Push Notification
Web browsing: Built-in web server for standard web browser access
Video display on IE browser
Video snapshot on any browser
Supported protocols: IPv4, HTTP, TCP, ICMP, RTSP, RTP, UDP, RTCP, SMTP, SNTP, FTP,
DHCP, ARP, DNS, PPPoE, etc.
Accessories: Power adaptor, camera bracket, RJ45 Ethernet cable,
quick installation guide, CD with installation software and
User’s Manual.
Video management software:
Surveillance software for viewing and archiving up to 4
cameras
Users Up to 20 simultaneous unicast users (depends on video
settings and internet bandwidth)
Alarm and event management:
Events triggered by PIR and sound detection
Email/ftp alarm message
Push notification on supported mobile devices.
Dimensions: 75 x 35 x 128mm/3.0 x 1.4 x 5.1"
(W x D x H)
Weight: 0.28kg/0.62lbs
(including camera bracket)
Approvals: EMC - CE, FCC Part 15 Subpart B Class B
Wireless RF - CE, FCC Part 15 Subpart C
Power supply: CE, FCC, UL, EN 60950
Operating conditions 0-50 °C
Humidity 20 – 80% RH (non-condensing)
1. Compatible with WPS enabled routers (not included).
2. Infrared illumination range under ideal conditions. Actual range and clarity may vary depending on scene/object reflection and camera application.
3. microSD Card not included (supports up to 32GB).
4. Connection speed may vary depending on internet bandwidth.
5. External speaker required, not included.
6. Up to 4 simultaneous camera views available on PC, Mac and tablets. Selectable single camera viewing on smartphones.
