Lorex SG7550 User manual

LOREX Technology Inc.
Copyright © 2008 LOREX Technology Inc. As our
products are subject to continuous improvement,
LOREX and its subsidiaries reserve the right to mod-
ify product design, specifications and prices, without
notice and without incurring any obligation. E&OE
Quick Set-up Guide
It’s all on the web
Product Information
User Manuals
Quick Start Guides
Specification Sheets
Software Upgrades
Firmware Upgrades
VISIT
www.lorexcctv.com
4. Camera Specifications H O M E & B U S I N E S S S E C U R I T Y
HIGH RESOLUTION INDOOR/
OUTDOOR COLOR CAMERA
with Night Vision
Specifications:
Dimensions:
Model: SG7550 Series
Image Sensor 1/4” Advanced Color
Lens / Lens Mount
Video Format / Pixels
Horizontal Resolution
Minimum Illumination
Termination
IR / Night Vision Range
FOV (diagonal)
S/N Ratio
Sync. & Scan. Systems
Video Output
Power Consumption
NTSC: 656(H) x 492 (V)
480 TVL
0.6 LUX @ F1.2 (IR Off)
0 LUX (IR LEDs ON)
Video: BNC Female
Power: Barrel Female
30IRLED/850nm/75’(23m)
50 Degree
> 48dB
Internal; 2:1 Internlace
Comp. 1.0 Vpp @ 75ohm
220mA or 3W max
Operating Temp.
Dimensions
(H x D x Dia)
14°F ~ 122°F
(-10°C ~ 50°C)
5.0mm F2.8/ Fixed
Iris & Shutter Speed AES; 1/60 ~ 1/50,000 sec.
Power Requirement 12V DC ±10%
Weight (with stand) 10.4 oz / 294.8 g
3.9” x 2.7” x 3.2”
100mm x 68mm x 80mm
English Version 2.0

1. Package Contents 2. Installing the Video Camera
1 x 60 ft. extension cable
1 x BNC to RCA Adaptors
1 x AC Power Adaptor
1 x High Resolution
Indoor / Outdoor Color
Camera with Night Vision
1 x Mounting Bracket /
Stand
1. Attach the camera to the supplied stand at either
of the two connection points.
2. Mount the camera stand to the desired mounting
surface
3. Connect the 60ft Extension cable to the camera:
The mounting stand is designed to permanently
mount the camera to a surface.
Features:
• Advanced Image Sensor (AIS) provides High
Resolution image (480 TV Lines)
• Auto Mechanical IR Cut Filter removal function
ensures accurate color reproduction
• Durable Weatherproof Indoor/Outdoor camera*
• Enhanced Night Vision Capability - up to 75 ft **
• Easily connects to any TV, VCR or DVR
• Ceiling and wall mounting bracket included
* Not recommended for submersion in water
** IR Illumination range of 75 ft. (23m) under ideal conditions.
Objects at or beyond this range may be partially or completely
obscured, depending on the camera application.
WARNING - REGULATED 12V DC 500mA power supply is RE-
QUIRED for use with this camera. Use of a non-regulated, non-con-
forming power supply can damage this product and will void the
warranty.
BNC (VIDEO)
(Yellow Connector)
POWER
(Black Connector)
CAMERA
CONNECTIONS:
Connect the BNC and
Power cables to the
Camera
VIDEO INPUT
CONNECTIONS:
Connect the BNC cable to
the video input of the
monitor, and connect the
power adaptor to an outlet.
3. Connecting the Camera
4. Connect the BNC end of the 60ft Extension Cable
to the DVR / Observation System or to a TV/VCR.
5. Connect the A/C Power Adaptor to the 60ft Exten-
sion cable (Black connector). Plug the Power
adaptor to a wall outlet
Setup Diagram:
Connect the BNC to RCA Adaptor as needed to
allow for proper connectivity.
NOTE - This Camera includes a Mechanical Auto IR Cut Filter. When
the camera changes between Day/Night Lighting, an audible clicking
noise may be heard coming from the camera. This clicking is normal,
and indicates that the Camera filter is working.
NOTE - This camera does not support Audio. For a full line of audio
enabled cameras, visit us on the web at http://www.lorexcctv.com
