LORUS Y704 User manual

■CHARACTERISTICS
1. Time display: Hour, minutes and sec-
onds.
2. Calendar display: Month, date and day
of the week.
3. Automatic calendar adjustment: Cal-
endar adjusts automatically for odd and
even months except February of leap years.
4. Time indication: Changeover between
12-hour and 24-hour indications is pos-
sible.
5. Stopwatch: 24 hour stopwatch with 1/
100 second readout up to 30 minutes and
with 1 second readout after the first 30
minutes. Split time measurement is avail-
able.
6. Alarm: The alarm rings at the desig-
nated hour and minute for 1 minute.
7. Snooze function: The alarm starts ringing
again 5 minutes after it is stopped.
8. Hourly time signal: Can be set to ring
every hour on the hour with a single “beep”.
Button B : • Calendar (month, date and day)
display in the time display.
• Start/stop in the stopwatch func-
tion.
• Setting the digits in the alarm
setting and the time/calendar
setting functions.
• Activating the snooze function
while the alarm is ringing.
Button C : • Alarm display in the time dis-
play.
• Split/Split release/Reset in the
stopwatch function.
• Selection of the digits to be ad-
justed in the alarm setting and
the time/calendar setting func-
tions.
• Stopping the alarm in any dis-
play.
Minutes Seconds
1 Depress button “A” to show the stopwatch
display. (The stopwatch indicator starts
flashing.)
The stopwatch can measure up to 24 hours
and is displayed in minutes, seconds, and
1/100 seconds up to 30 minutes, and in
hours, minutes, and seconds after the first
30 minutes. (The 1/100 second indicator
flashes during the first 30 minutes.)
When the measurement is over 24 hours,
the stopwatch will be reset to “0:00oo”
and start counting again.
2 Reset the digits to “0:00oo” before using
the stopwatch. When the split and the
stopwatch indicators are flashing, depress
button “B” to check that the stop indicator
starts flashing, and then depress button
“C” twice to reset the digits to zero.
3 When measuring a long period of time,
return the stopwatch to the time display
after the stopwatch starts to prevent any
possible mistaken operation.
* When button “B” or “C” is depressed in the
stopwatch display, a single “beep” sounds
to confirm the operation.
■HOW TO USE THE STOPWATCH
Button B while keeping button C depressed:
Engagement and disengagement
of the alarm in the time display
Button A while keeping button C depressed:
Turning on and off of the hourly
time signal in the time display
Buttons B & C:
Alarm test in the time display while
keeping the buttons depressed.
Button A : • Selection of the display.
The selection is made in the following order:
A
A
Time display
Stopwatch display
Alarm setting
▲
A
▲
▼
Time/calendar setting
Seconds
Stopwatch
indicator
Hour
Minutes
1/100 second
indicator
Split indicator Stop indicator
1/100 second
INSTRUCTION MANUAL
CAL. Y704 (R23 SERIES)
NREY704A 10-98
CB
STOPWATCH
AM/PM
mark
A
Day Alarm mark
■ DISPLAY AND BUTTON OPERATION
▼
A
A
C: Split/Split
release/
Reset
B: Start/
Stop

Accumulated elapsed time measurement
Start Stop Restart ResetStop
BB B BC
1 Depress button “A” to activate the alarm
setting function. (The alarm set indicator
starts flashing.)
2 Depress button “C” to activate the “Hour”
or “Minute” setting. The display changes
in the following order with each depres-
sion of button “C”.
3 One digit (flashing) is advanced with each
depression of button “B”. The digits are
advanced quickly by keeping button “B”
depressed.
4 After all the adjustments are completed,
depress button “A” to return to the time
display.
(The display returns directly to the time
display and not to the time/calendar set-
ting.)
Note: When setting the hour digits, be sure
to check that the “A” (AM)/“P” (PM)
mark is correctly set.
▲ ▼
C
Restart and stop can be repeated by
depressing button “B”.
Measurement between two competitors
Split time measurement
Start
BC BC
Split Split release Stop Reset
C
Finish (First runner)
BCBCC
Finish (Second runner)
Start Finish time
of 2nd
competitor
ResetStop
Measurement and release of split time
can be repeated by depressing button “C”.
Finish
time of 1st
competitor
Alarm set indicator
■HOW TO SET THE ALARM
■HOW TO ENGAGE AND DISENGAGE
THE ALARM
Alarm display
1 Depress button “C” in the time display to
show the alarm display. The alarm dis-
play is shown while button “C” is kept
depressed.
2 With each depression of button “B” while
keeping button “C” depressed, the engagement
and disengagement of the alarm are made
alternately.
■ HOW TO SET THE TIME/CALENDAR
Time/calendar setting
indicator
1 Depress button “A” to activate the time/
calendar setting function. (The time/calen-
dar setting indicator and the second digits
start flashing.)
2 Selection of the digits to be adjusted (flash-
ing) is made in the following order by
depressing button “C”.
3 One digit (flashing) is advanced with each
depression of button “B”. (The digits ex-
cept seconds are advanced quickly by keep-
ing button “B” depressed.)
•Second setting
Depress button “B” in accordance with
a time signal. The seconds are reset to
“00” and start immediately.
When the seconds count any number
from “30” to “59” and button “B” is de-
pressed, one minute is added and the
seconds are immediately reset to “00”.
4 After all the adjustments are completed,
depress button “A” to return to the time
display.
Note: When setting the hour digits in the
12-hour indication, be sure to check
that the AM/PM mark is correctly set.
In the 24-hour indication, there is no
indication.
Seconds Minutes DateHour
Day
→→→
Month
[Alarm engaged] [Alarm disengaged]
Hour Minutes “A” (AM)
A
“A” (AM)
▲
▲
Hour setting Minute setting
The alarm rings at the designated time for 1
minute and stops. However, the alarm can be
stopped manually by depressing button “C”
in any display.
■HOW TO STOP THE ALARM
While the alarm is ringing, depress button
“B”. It stops but starts ringing again after 5
minutes. In the same manner, the snooze
function can be activated repeatedly as many
times as necessary thereafter.
■HOW TO USE THE SNOOZE FUNCTION
■ALARM TEST
The alarm can be tested with a beeping sound
by depressing buttons “B” and “C” at the
same time in the time display.
■HOW TO TURN ON AND OFF THE
HOURLY TIME SIGNAL
1 Depress button “C” in the time display to
show the alarm display. The alarm dis-
play is shown while button “C” is kept
depressed.
2 While the alarm display is shown, depress
button “A”. With each depression of the
button, the day marks appear and disap-
pear alternately.
The hourly time signal is turned on while
the day marks are shown and is turned off
while they are not.
▲
▲
[Time signal disengaged][Time signal engaged]
Day mark
Alarm mark
AB
C
B
C
Minutes
Hour
BC A
←
↑←

■BATTERY CHANGE
The miniature battery MAXELL SR44W, which
powers your watch should last approximately
3 years. However, because it is inserted at
the factory, the actual life of the battery once
in your possession may be less than the specified
period. Be sure to replace the battery to
prevent any possible malfunction as soon as
it runs down. To replace the battery, we
recommend taking the watch to a local watch
repair shop.
■CARE OF YOUR LORUS WATCH
• BATTERY
• WATER RESISTANT
No
indication
WATER
RESISTANT
WATER
RESISTANT
(50 M/5 BAR)*
WATER
RESISTANT
100 M/
10 BAR or
above
Condition
of use
Accidental
contact with
water, such
as splashes
and rain
Swimm-
ing and
taking a
shower
Skin
diving
Scuba
diving
Indica-
tion on
the dial/
case back
NO NO NO NO
YES YES NO NO
YES NO NO NO
YES YES YES NO
()
*
CAUTION
Do not expose the old battery to
fire or recharge it. Keep it at a
place beyond the reach of chil-
dren. If a child swallows it, consult
a doctor immediately.
* If your watch is 200 M/20 BAR, 100 M/10
BAR or 50 M/5 BAR water resistant, it is so
indicated on the dial/case back.
•Do not operate the buttons when the watch
is wet.
•If the watch is exposed to salt water, rinse
it in fresh water and then wipe it thoroughly
dry.
Caution:
Leather straps are not water resistant except
so indicated, even if the watch head is water
resistant.
• ALLERGIC REACTION
Because the case and band touch the skin
directly, it is important to clean them
regularly. If not, shirt sleeves may be
stained and those with delicate skin may
develop a rash. Please wear the watch
with some play to avoid any possible allergic
reaction. If you develop a rash on your
wrist, stop wearing and consult a physician.
• MAGNETISM
Your watch will not be affected by mag-
netism generated by household electric
appliances.
• SHOCKS AND VIBRATIONS
Your watch may be worn for normal sports
activities, but be careful not to drop it or
hit it on hard surfaces.
• TEMPERATURE
Your watch is preadjusted so that constant
accuracy may be insured at normal tem-
perature.
■SERVICE
When your LORUS watch requires repair
or servicing, please see the enclosed
WARRANTY/GUARANTEE.
Printed in Hong Kong
■LUMIBRITE WATCH
(dial, hands, buttons, case, bezel,
strap, etc.)
✩If your watch is a LORUS LUMIBRITE watch,
it has following features.
LORUS LUMIBRITE watches absorb and store
light energy from natural and artificial light
sources and emit light in the dark. They are
made of environmentally friendly material,
and therefore, are harmless to human beings
and the environment.
• With a full charge, LORUS LUMIBRITE
watches glow in the dark hours longer than
conventional luminous watches of this type.
If exposed to a light of more than 500 lux
(i.e., the brightness of a typical office) for
approximately 10 minutes, or direct sunlight
for 2 minutes, they will glow for hours.
• Since LORUS LUMIBRITE watches emit
the light they store, the brightness will
decrease gradually over time. The length
of time they will glow may also differ slightly
depending on such factors as the brightness
of and distance from the light source used
to charge the watch.
