LS ELECTRIC SV-iS7 Series User manual

LS ELECTRIC strives to maximize your profits in gratitude for choosing us as your partner.
AC Variable Speed Drive
0.75-75kW[200V] 0.75-375kW[400V]
SV-iS7 series
User’s Manual

•SV-iS7 is the official name for the iS7 series inverters.
•This operation manual is intended for users with basic knowledge of electricity and electric
devices.
•Keep this manual near the product for future reference whenever setting change, maintenance
or service is required.
•Ensure that the field operators and service engineers can easily access this manual.
•For detailed information about the optional extension boards, including the specifications and
the requirements for installation and operation, refer to the instruction manuals that are
supplied with the products.

ii
Safety Information
Safety Information
Read and follow all safety instructions in this manual precisely to avoid unsafe operating
conditions, property damage, personal injury, or death.
Safety symbols in this manual
Indicates an imminently hazardous situation which, if not avoided, will result in severe injury or
death.
Indicates a potentially hazardous situation which, if not avoided, could result in injury or death.
Indicates a potentially hazardous situation which, if not avoided, could result in minor injury or
property damage.
Safety information
•Do not open the cover of the equipment while it is on or operating. Likewise, do not operate the
inverter while the cover is open. Exposure of the high voltage terminals or the charging area to
the external environment may result in an electric shock. Do not remove any covers or touch
the internal circuit boards (PCBs) or electrical contacts on the product when the power is on or
during operation. Doing so may result in serious injury, death, or serious property damage.
•Do not open the cover of the equipment, even when the power supply to the inverter has been
turned off, unless it is necessary for maintenance or regular inspection. Opening the cover may
result in an electric shock even when the power supply is off.
•The equipment may hold a charge long after the power supply has been turned off. Use a
multi-meter to make sure that the remaining voltage is below 30 VDC before working on the
inverter, motor, or motor cable.

iii
Safety Information
•This equipment must be grounded for safe and proper operation.
•Do not supply power to a faulty inverter. If you find that the inverter is faulty, disconnect the
power supply and have the inverter professionally repaired.
•The inverter becomes hot during operation. Avoid touching the inverter until it has cooled to
avoid burns.
•Do not allow foreign objects, such as screws, metal chips, debris, water, or oil, to get inside the
inverter. Allowing foreign objects inside the inverter may cause the inverter to malfunction or
result in a fire.
•Do not operate the inverter with wet hands. Doing so may result in electric shock.
•Do not modify the interior workings of the inverter. Doing so will void the warranty.
•Do not use cables with damages or cracks on the protective insulation when wiring the inverter.
Damaged insulation may cause misoperation, an electric shock or a fire.
•Do not place heavy objects on top of electric cables. Doing so may damage the cable and result
in an electric shock.

iv
About This Manual
Note
[English]
The maximum allowed prospective short-circuit current at the input power connection is defined in
IEC 60439-1 as 100 kA. The drive is suitable for use in a circuit capable of delivering not more than
100 kA RMS at the drive’s maximum rated voltage, depending on the selected MCCB. RMS
symmetrical amperes for recommended MCCB are the following table.
[French]
Le courant maximum de court-circuit présumé autorisé au connecteur d’alimentation électrique est
défini dans la norme IEC 60439-1 comme égal à 100 kA. L’entraînement convient pour une utilisation
dans un circuit capable de délivrer pas plus de 100 kA RMS à la tension nominale maximale de
l’entraînement. Le tableau suivant indique le MCCB recommandé selon le courant RMS symétrique
en ampères.
Working
Voltage
UTE100
(E/N)
UTS150
(N/H/L)
UTS250
(N/H/L)
UTS400
(N/H/L)
240V(50/60Hz)
50/65kA
65/100/150kA
65/100/150kA
65/100/150kA
480V(50/60Hz)
25/35kA
35/65/100kA
35/65/100kA
35/65/100kA
Working
Voltage
ABS33c
ABS53c
ABS63c
ABS103c
ABS203c
ABS403c
240V(50/60Hz)
30kA
35kA
35kA
85kA
85kA
75kA
480V(50/60Hz)
7.5kA
10kA
10kA
26kA
26kA
35kA

v
About This Manual
About This Manual
This operation manual describes the specifications of the SV-iS7 series inverters and provides
detailed information required for the installation, operation, and maintenance of the products.
This operation manual is intended for users with a basic knowledge of electricity and electric
devices. Read this manual carefully to install, operate, and maintain the products safely and
properly.
The following table lists the chapters in this manual, and brief descriptions of the information
provided:
Chapter
Chapter name
Information provided
1
About the Product
Basic information about the product that is required for safe
installation and operation
2
Technical Specifications
Product ratings and I/O types
3
Installing the Inverter
Information required for the installation of the product,
including considerations for installation locations and
operation environment
4
Connecting the Cables
Information required for connecting power supply and signal
cables
5
Peripheral Devices
Information about the peripheral devices that can be
connected to the input and output terminals of the product
6
Using the Keypad
Information about the keypad display and the operation keys
on the keypad
7
Basic Functions
Information about configuring the inverter to run the basic
functions
8
Learning Advanced
Features
Information about configuring the inverter for advanced
system application
9
Using Monitor
Functions
Information about monitoring the inverter for operation
statuses and trip conditions
10
Using Protection
Features
Information about the functions to protect the motor and the
inverter
11
Communication
Function
Specifications for the RS-485 network communication
between inverters and other devices
12
Troubleshooting and
Maintenance
Information about identifying the failures and anomalies
during operation and resolving them
13
Table of Functions
Table of all functions with brief descriptions
14
Functional Safety
Information about the products compliant with the safety
standards, and the safety functions
15
Classified Product
Information about the products approved for marine
application
16
Using a Single Phase
Power Source
Considerations for operating the inverter with a single phase
power source

Table of contents
vi
Table of Contents
1 About the Product ........................................................................................................1
1.1 Preparing for Installation and Operation...................................................... 1
1.1.1 Identifying the Product .................................................................................1
1.1.2 Checking the Product for Defects or Damage..........................................3
1.1.3 Preparing the Product for Installation and Operation ...........................3
1.1.4 Installing the Product ....................................................................................3
1.1.5 Connecting the Cables...................................................................................3
1.2 Part Names.......................................................................................................... 4
1.2.1 Interior and Exterior View (IP 21 Model Types Less than 22 kW [200 V]
/ Less than 75 kW [400 V])............................................................................4
1.2.2 Interior and Exterior View (IP 54 Model Types Less than 22 kW
[200/400 V]).....................................................................................................5
1.2.3 Interior and Exterior View (Model Types 30 kW and up [200 V] / 90
kW and up [400 V])........................................................................................6
2 Technical Specifications..............................................................................................7
2.1 Input and Output Specifications 200 V Class (0.75–22 kW) ....................... 7
2.2 Input and Output Specifications 200 V Class (30–75 kW)........................... 8
2.3 Input and Output Specifications 400 V Class (0.75–22 kW) ....................... 9
2.4 Input and Output Specifications 400 V Class (30–160 kW) ......................10
2.5 Input and Output Specifications 400 V Class (185–375 kW)....................11
2.6 Product Specification Details .........................................................................13
2.6.1 Control ........................................................................................................... 13
2.6.2 Operation ...................................................................................................... 13
2.6.3 Protection Function..................................................................................... 15
2.6.4 Structure and Operating Environment Control .................................... 15
3 Installing the Inverter.............................................................................................. 17
3.1 Installation Considerations ............................................................................17
3.2 Selecting and Preparing a Site for Installation...........................................18
3.3 Exterior and Dimensions (UL Enclosed Type 1, IP21 Type)......................22
3.4 Exterior and Dimensions (UL Enclosed Type 12, IP54 Type) ...................36
3.5 Frame Dimensions and Weight (UL Enclosed Type 1, IP 21 Type).........40
3.6 Frame Dimensions and Weight (UL Enclosed Type 12, IP54 Type)........42
3.7 Installation Procedures for UL Enclosed Type12 and IP54 Type Products
..............................................................................................................................43

Table of contents
vii
3.7.1 Disassembling the Keypad Cover and Keypad...................................... 43
3.7.2 Disassembling the IP54 Front Cover ....................................................... 44
3.7.3 Mounting the Inverter................................................................................ 45
3.7.4 Connecting the Power Cables................................................................... 46
3.7.5 Reassembling the IP54 Front Cover and the Keypad .......................... 47
4 Connecting the Cables.............................................................................................. 49
4.1 Removing the Front Cover for Cable Connection......................................49
4.1.1 IP 21 Type Products..................................................................................... 49
4.1.2 IP 54 Type Products..................................................................................... 51
4.1.3 90–375 kW, 400 V and 30–75 kW, 200 V Products ................................ 52
4.2 Activating and Deactivating the Built-in EMC Filter...................................53
4.2.1 Up to 7.5 kW Inverters................................................................................ 53
4.2.2 11–22 kW Inverters...................................................................................... 55
4.3 Precautions for Wiring the Inverter..............................................................57
4.4 Ground Connection .........................................................................................58
4.5 Terminal Wiring Diagram ...............................................................................59
4.5.1 Up to 7.5 kW Inverters................................................................................ 59
4.5.2 11–22 kW Inverters...................................................................................... 59
4.5.3 30–75 kW Inverters...................................................................................... 59
4.5.4 90–160 kW Inverters ................................................................................... 59
4.5.5 185–220 kW Inverters................................................................................. 60
4.5.6 280–375 kW Inverters................................................................................. 60
4.6 Connecting Cables to the Power Terminal Block ......................................61
4.6.1 0.75–22 kW (200 V/400 V)........................................................................... 61
4.6.2 30–75 kW (200 V/400 V).............................................................................. 62
4.6.3 90–160 kW (400 V)........................................................................................ 63
4.6.4 185–220 kW (400 V)..................................................................................... 64
4.6.5 280–375 kW (200 V/400 V).......................................................................... 65
4.7 Specifications of the Power Terminal Block and Exterior Fuse...............66
4.7.1 Cable Length between the Inverter and the Motor ............................. 67
4.7.2 Protective Measures for the Inverter and the Motor........................... 68
4.8 Control Terminal Wiring for iS7 Inverters Rated for Up To 22 kW.........69
4.8.1 NPN Mode (Sink).......................................................................................... 70
4.8.2 PNP Mode (Source) ..................................................................................... 70
4.8.3 0.75–22 kW (Basic I/O) ................................................................................ 71
4.9 Control Terminal Wiring for iS7 Inverters Rated for 30 kW or More.....72
4.10 Terminal Inputs for Inverter Operation.......................................................73
4.11 Cable Specifications for Control Block Wiring ............................................75

Table of contents
viii
4.12 Control Terminal Wiring for iS7 Extension I/O (Optional).....................76
4.13 Terminal Inputs for Inverter Operation.......................................................77
4.14 Cable Specifications for Control Block Wiring ............................................78
4.15 Setting the Built-in Surge Filter......................................................................79
4.16 Activating or Deactivating the Surge Filter .................................................80
4.16.1 iS7 30–75KW (400 V) Inverters .................................................................. 80
4.16.2 iS7 90–375 kW (400V) Inverters ................................................................ 80
4.17 Post-Installation Checklist...............................................................................82
4.18 Test Run..............................................................................................................83
4.18.1 Entering Easy Start Mode........................................................................... 83
4.18.2 Setting the Basic Parameters in Easy Start Mode................................. 84
4.18.3 Checking the Inverter Operation ............................................................. 85
5 Peripheral Devices..................................................................................................... 86
5.1 Wiring Switch, Electronic Contactor, and Reactor Specifications...........87
5.1.1 Wiring Switch, Short Circuit Switch, and Electronic Contactor........... 87
5.1.2 Reactors......................................................................................................... 89
5.1.3 Dynamic Braking Unit (DBU) and Resistor ............................................. 92
5.1.4 DB Unit Dimensions.................................................................................... 96
5.1.5 Indicators on the DB unit......................................................................... 102
5.1.6 DB Resistors................................................................................................ 102
5.1.7 DB Resistor Dimensions........................................................................... 105
5.1.8 Keypad Extension Cable for Remote Control (Optional) ................... 106
6 Using the Keypad..................................................................................................... 109
6.1 About the Keypad...........................................................................................109
6.1.1 Dimensions.................................................................................................109
6.1.2 Key Functions ............................................................................................. 110
6.1.3 Display Items.............................................................................................. 111
6.1.4 Display Item List......................................................................................... 111
6.2 Menu Items......................................................................................................114
6.2.1 Parameter Mode........................................................................................ 115
6.2.2 User & Macro Mode.................................................................................. 116
6.3 Navigating Modes ..........................................................................................117
6.3.1 Mode Navigation at the Factory Default............................................... 117
6.3.2 Mode Navigation with User/Macro Mode and Trip Mode................ 118
6.4 Navigating Modes and Parameters ...........................................................120
6.4.1 Group Navigation in Parameter mode ................................................. 120
6.4.2 Group Shift in User & Macro Mode........................................................ 122
6.5 Navigating through Codes (Function Items) ............................................123

Table of contents
ix
6.5.1 Code Navigation in Monitor Mode ........................................................ 123
6.5.2 Code Navigation (function items) in Other Modes and Groups ...... 124
6.5.3 Code Navigation Using Jump Code........................................................ 125
6.6 Setting Parameters ........................................................................................127
6.6.1 Parameter Settings in Monitor Mode.................................................... 127
6.6.2 Parameter Settings in Other Modes and Groups............................... 128
6.7 Monitoring Operating Status.......................................................................129
6.7.1 Using Monitor Mode................................................................................. 129
6.7.2 Monitoring Items....................................................................................... 130
6.7.3 Using the Status Display........................................................................... 131
6.8 Monitoring Faults ...........................................................................................132
6.8.1 Faults during Inverter Operation ........................................................... 132
6.8.2 Multiple Faults at a Time during Inverter Operation ......................... 133
6.8.3 Saving and Monitoring the Fault Trip History...................................... 133
6.9 Initializing Parameters ..................................................................................135
7 Basic Functions......................................................................................................... 137
7.1 Setting Frequency References.....................................................................137
7.1.1 Keypad as the Source (KeyPad-1 setting) ............................................. 138
7.1.2 Keypad as the Source (KeyPad-2 setting) ............................................. 138
7.1.3 V1 Terminal as the Source ....................................................................... 138
7.1.4 Setting a Frequency Reference Using an I/O Expansion Module
(Terminal V2/I2) ........................................................................................ 148
7.1.5 Setting a Frequency with Pulse Input (with an optional encoder
module) ...................................................................................................... 150
7.1.6 Setting a Frequency Reference via RS-485 Communication............. 152
7.2 Frequency Hold by Analog Input ................................................................153
7.3 Changing the Displayed Units (Hz↔Rpm).................................................154
7.4 Setting Multi-Step Frequency.......................................................................154
7.5 Command Source Configuration................................................................157
7.5.1 The Keypad as a Command Input Device ............................................ 157
7.5.2 The Terminal Block as a Command Input Device (Fwd/Rev run
commands)................................................................................................ 158
7.5.3 The Terminal Block as a Command Input Device (Run and Rotation
Direction Commands) ............................................................................. 159
7.5.4 RS-485 Communication as a Command Input Device....................... 160
7.6 Local/Remote Mode Switching....................................................................160
7.7 Forward or Reverse Run Prevention ..........................................................162
7.8 Power-on Run..................................................................................................163

Table of contents
x
7.9 Reset and Restart ...........................................................................................164
7.10 Setting Acceleration and Deceleration Times ..........................................165
7.10.1 Acc/Dec Time Based on Maximum Frequency.................................... 165
7.10.2 Acc/Dec Time Based on Operation Frequency.................................... 167
7.10.3 Multi-Step Acc/Dec Time Configuration................................................ 168
7.10.4 Configuring Acc/Dec Time Switch Frequency...................................... 169
7.11 Acc/Dec Pattern Configuration....................................................................171
7.12 Stopping the Acc/Dec Operation.................................................................174
7.13 V/F (Voltage/Frequency) Control .................................................................175
7.13.1 Linear V/F Pattern Operation .................................................................. 175
7.13.2 Square Reduction V/F Pattern Operation............................................. 176
7.13.3 User V/F Pattern Operation..................................................................... 177
7.14 Torque Boost...................................................................................................179
7.14.1 Manual Torque Boost............................................................................... 179
7.14.2 Auto Torque Boost .................................................................................... 180
7.14.3 Advanced Auto Torque Boost.................................................................180
7.15 Output Voltage Setting..................................................................................182
7.16 Start Mode Setting .........................................................................................183
7.16.1 Acceleration Start....................................................................................... 183
7.16.2 Start After DC Braking .............................................................................. 183
7.17 Stop Mode Setting..........................................................................................184
7.17.1 Deceleration Stop...................................................................................... 184
7.17.2 Stop after DC Braking............................................................................... 185
7.17.3 Free Run Stop ............................................................................................. 186
7.17.4 Power Braking............................................................................................ 187
7.18 Frequency Limit ..............................................................................................188
7.18.1 Frequency Limit Using Maximum Frequency and Start Frequency 188
7.18.2 Frequency Limit Using Upper and Lower Limit Frequency Values .188
7.18.3 Frequency Jump......................................................................................... 191
7.19 2nd Operation Mode Setting.........................................................................192
7.20 Multi-function Input Terminal Control.......................................................194
7.21 Expanded I/O Control with an Optional I/O Expansion Module..........195
8 Learning Advanced Features................................................................................ 196
8.1 Operating with Auxiliary References..........................................................196
8.2 Jog Operation ..................................................................................................201
8.2.1 Jog Operation 1-Forward Jog via Multi-function Terminal ................ 201
8.2.2 Jog Operation 2-Forward/Reverse Jog via Multi-function Terminal 202
8.2.3 Jog Operation via Keypad Input ............................................................. 203

Table of contents
xi
8.3 Up/down Operation.......................................................................................204
8.4 3-Wire Operation............................................................................................208
8.5 Safe Operation Mode ....................................................................................209
8.6 Dwell Operation..............................................................................................210
8.7 Slip Compensation Operation .....................................................................212
8.8 PID Control.......................................................................................................215
8.8.1 PID Basic Operation .................................................................................. 215
8.8.2 Pre-PID Operation..................................................................................... 222
8.8.3 PID Sleep Mode.......................................................................................... 223
8.8.4 PID Switching (PID Openloop) ................................................................ 224
8.9 Auto Tuning .....................................................................................................224
8.10 V/F Operation Using Speed Sensor ............................................................229
8.11 Sensorless-1 Vector Control.........................................................................230
8.12 Sensorless-2 Vector Control.........................................................................232
8.13 Vector Control Mode Operation..................................................................237
8.14 Torque Control................................................................................................242
8.15 Droop Control .................................................................................................244
8.16 Speed / Torque Control Switching..............................................................244
8.17 Kinetic Energy Buffering ...............................................................................245
8.18 Energy Saving Operation..............................................................................248
8.18.1 Manual Energy Saving Operation .......................................................... 248
8.18.2 Automatic Energy Saving Operation..................................................... 249
8.19 Speed Search Operation...............................................................................250
8.20 Auto Restart Settings.....................................................................................253
8.21 Operational Noise Settings (Carrier Frequency Settings) ......................255
8.22 2nd Motor Operation ....................................................................................258
8.23 Supply Power Transition ...............................................................................260
8.24 Cooling Fan Control .......................................................................................261
8.25 Input Power Frequency Settings.................................................................262
8.26 Input Power Voltage Settings ......................................................................263
8.27 Read, Write, and Save Parameters .............................................................263
8.28 Parameter Initialization.................................................................................264
8.29 Parameter Viewing and Lock Options .......................................................266
8.29.1 Parameter View Lock ................................................................................ 266
8.29.2 Parameter Lock.......................................................................................... 267
8.29.3 Changed Parameter Display ................................................................... 268

Table of contents
xii
8.30 User Group ......................................................................................................268
8.31 Macro Selection ..............................................................................................270
8.32 Easy Start..........................................................................................................271
8.33 Config (CNF) Mode .........................................................................................272
8.34 Timer Settings .................................................................................................273
8.35 Auto Sequence Operation............................................................................274
8.36 Traverse Operation........................................................................................278
8.37 Brake Control ..................................................................................................279
8.38 Multi-function Output On/Off Control.......................................................282
8.39 MMC function..................................................................................................282
8.39.1 Basic MMC Operation............................................................................... 285
8.39.2 Auto Change Operation........................................................................... 287
8.39.3 Interlock Operation................................................................................... 289
8.39.4 Bypass Operation (Regular Bypass)....................................................... 291
8.40 Press Regeneration Prevention (To evade control operation in the
status of regeneration during press) .........................................................292
8.41 Anti-Hunting Regulator.................................................................................293
8.42 Fire Mode .........................................................................................................294
8.43 Dynamic Braking (DB) Resistor Operation Reference Voltage .............296
8.44 kW/HP Unit Selection.....................................................................................297
8.45 Output Voltage Drop Prevention................................................................297
9 Using Monitor Functions ....................................................................................... 299
9.1 Monitoring the Operating Status via the Keypad....................................299
9.1.1 Selecting Monitor Mode Display ............................................................ 299
9.1.2 Displaying Output Power......................................................................... 301
9.1.3 Selecting Load Speed Display ................................................................. 302
9.1.4 Selecting Hz/Rpm Display........................................................................ 302
9.1.5 Selecting Status Display ........................................................................... 303
9.1.6 Monitoring Output Frequency................................................................ 303
9.2 Monitoring Fault Status Using Keypad ......................................................304
9.2.1 Monitoring Current Fault Status............................................................. 304
9.2.2 Monitoring Fault Trip History.................................................................. 305
9.3 Analog output .................................................................................................306
9.3.1 Voltage Output (0–10 V) ........................................................................... 306
9.3.2 Current Output (4–20 mA) ....................................................................... 309
9.3.3 Voltage Output (-10–+10V) Using an I/O Expansion Module ........... 312
9.3.4 Current Output (4–20 mA/0–20 mA) Using an I/O Expansion Module

Table of contents
xiii
...................................................................................................................... 313
9.4 Relay Output and Multi-function Output Terminal Settings.................314
9.5 Fault trip output using multi-function output terminals and relays....320
9.6 Output Terminal Delay Time and Terminal Types ..................................321
9.6.1 Output Terminal Delay Time................................................................... 321
9.6.2 Setting the Output Terminal Type.......................................................... 321
9.7 Operation Time Monitor...............................................................................322
9.8 Setting the Keypad Language .....................................................................323
10 Using Protection Features..................................................................................... 324
10.1 Motor Protection ............................................................................................324
10.1.1 Electrothermal Motor Overheating Prevention (ETH)........................ 324
10.1.2 Overload Early Warning and Trip........................................................... 326
10.1.3 Stall Prevention and Flux Braking .......................................................... 327
10.1.4 Motor Overheat Sensor Input.................................................................331
10.2 Inverter and Sequence Protection..............................................................333
10.2.1 Open-phase Protection ............................................................................ 333
10.2.2 External Trip Signal.................................................................................... 335
10.2.3 Inverter Overload Protection (IOLT) ...................................................... 335
10.2.4 Keypad Command Loss ........................................................................... 336
10.2.5 Speed Command Loss.............................................................................. 338
10.2.6 Dynamic Braking (DB) Resistor Configuration .................................... 340
10.2.7 Underload Warning and Failure............................................................. 341
10.2.8 Overspeed Fault......................................................................................... 343
10.2.9 Speed Deviation Fault............................................................................... 343
10.2.10 Speed Sensor (Encoder) Fault Detection............................................... 343
10.2.11 Fan Fault Detection ................................................................................... 344
10.2.12 Low Voltage Fault Trip .............................................................................. 344
10.2.13 Output Block via the Multi-Function Terminal..................................... 345
10.2.14 Trip Status Reset ........................................................................................ 346
10.2.15 Operation Mode On Optional Expansion Module Fault Trip............ 346
10.2.16 No Motor Trip............................................................................................. 347
10.2.17 Low Voltage Fault Trip 2 During Operation ......................................... 347
10.3 List of Faults and Warnings..........................................................................348
11 Communication Function...................................................................................... 351
11.1 Introduction.....................................................................................................351
11.2 Specifications...................................................................................................352
11.3 Communication System Configuration .....................................................353
11.4 Basic Settings ..................................................................................................354

Table of contents
xiv
11.5 Setting Operation Command and Frequency..........................................355
11.6 Command Loss Protection...........................................................................355
11.7 Setting Virtual Multi-Function inputs..........................................................356
11.8 Saving Parameters Defined by Communication .....................................357
11.9 Communication Frame Monitoring............................................................358
11.10 Special communication Area Settings .......................................................358
11.11 Parameter Group for Periodical Data Transmission...............................359
11.12 Parameter Group for Transmission of Macro Group and User Group at
U&M Mode.......................................................................................................361
11.13 Communication Protocol..............................................................................361
11.13.1 LS INV 485 Protocol................................................................................... 361
11.13.2 Modbus-RTU protocol .............................................................................. 367
11.13.3 iS7/iS5/iG5/iG5A Compatible Common Area Parameter .................. 369
11.13.4 Expansion Common Area Parameter ................................................... 373
12 Troubleshooting and Maintenance .................................................................... 387
12.1 Protection Functions......................................................................................387
12.1.1 Protection from Output Current and Input Voltage .......................... 387
12.1.2 Abnormal Circuit Conditions and External Signals............................. 388
12.1.3 Keypad and Optional Expansion Modules ........................................... 390
12.2 Warning Messages.........................................................................................391
12.3 Troubleshooting Fault Trips.........................................................................392
12.4 Replacing the Cooling Fan............................................................................395
12.4.1 Products Rated below 7.5 kW .................................................................395
12.4.2 Products Rated at 11-15 kW 200 V/400 V and 18.5-22 kW 400 V..... 395
12.4.3 Products Rated at more than 30 kW (200 V) / 90 kW (400 V), and 18.5–
22 kW (200 V) / 30–75 kW (200/400 V).................................................. 396
12.5 Daily and Regular Inspection Lists..............................................................397
13 Table of Functions ................................................................................................... 400
13.1 Parameter Mode –DRV Group (DRV).....................................................400
13.2 Parameter Mode –Basic Function Group (BAS) ..................................403
13.3 Parameter Mode –Expansion Function Group (PARADV).................407
13.4 Parameter Mode –Control Function Group (CON).............................411
13.5 Parameter Mode –Input Terminal Block Function Group (IN) ........417
13.6 Parameter Mode –Output Terminal Block Function Group (OUT) .421
13.7 Parameter Mode –Communication Function Group (COM)............425
13.8 Parameter Mode –Applied Function Group (APP)..............................428

Table of contents
xv
13.9 Parameter Mode –Auto Sequence Operation Group (AUT).............431
13.10 Parameter Mode –Option Module Function Group (APO)...............434
13.11 Parameter Mode –Protective Function Group (PRT)..........................437
13.12 Parameter Mode –2nd Motor Function Group (M2)..........................440
13.13 Trip Mode (TRP Current (or Last-x)) ............................................................441
13.14 Config Mode (CNF) .........................................................................................441
13.15 User/Macro Mode –Draw Operation Function GroupMC1..............445
13.16 User/Macro mode –Traverse Operation Function Group (MC2).....446
14 Safety Funtion STO(Safe Torque Off) .................................................................. 447
14.1 Safety Standard Product...............................................................................447
14.2 About the Safety Function ............................................................................447
14.2.1 Safety Function Wiring Diagram ............................................................ 448
14.2.2 Installing the Safety Board to 0.75–160 kW Product.......................... 449
14.2.3 Installing the Safety Board to 185–375 kW Product........................... 449
14.2.4 Safety Function Terminal Description ................................................... 450
14.2.5 Cable Specification for Signal Terminal Block Wiring......................... 450
15 Marine Certification................................................................................................ 451
15.1 DNV (Det Norske Veritas) Marine Certification Details...........................451
15.2 Bureau Veritas (Marine & Offshore Division) Marine Certification Details
............................................................................................................................451
15.3 ABS Marine Certification Details..................................................................451
15.4 KR Marine Certification Details ..................................................................452
15.5 Marine Certification Models for SV-iS7 Products.....................................452
16 Using a Single Phase Power Source .................................................................... 454
16.1 Single Phase Rating........................................................................................454
16.2 Power(HP), Input Current and Output Current........................................455
16.3 Input Frequency and Voltage Tolerance ...................................................456
16.4 Wiring and Peripheral Device ......................................................................457
16.5 Other Considerations ....................................................................................460
17 Storage and Disposal .............................................................................................. 461
17.1 Storage .............................................................................................................461
17.2 Disposal ............................................................................................................461
Product Warranty............................................................................................................ 465
Index................................................................................................................................... 468

About the Product
1
1 About the Product
This chapter provides details on product identification and part names. To install the inverter
correctly and safely, carefully read and follow the instructions.
1.1 Preparing for Installation and Operation
1.1.1 Identifying the Product
Check the product name, open the packaging, and then confirm that the product is free from
defects. Contact your supplier if you have any issues or questions about your product.
The iS7 inverter is manufactured in a range of product groups based on drive capacity and
power source specifications. The product name and specifications are detailed on the rating
plate. Check the rating plate before installing the product and make sure that the product
meets your requirements.

2
About the Product
Note1) Optional conduit parts are available for the Enclosed UL Type 1 models (0.75–75 kW
products).
Note2) Optional built-in DCR is available for the Web application models (0.75–375 kW / type
2/4 products).
Note3) To use safety function, please buy 0.75-160kW product including safety option. However
185-375kW product users have to buy safety option and apply to standard products because
safety option is not included.
Note
The iS7 75/90 kW, 400 V inverters satisfy the EMC standard EN61800-3 without the installation of
optional EMC filters.

About the Product
3
1.1.2 Checking the Product for Defects or Damage
If you suspect that the product has been mishandled or damaged in any way, contact the LS
ELECTRIC Customer Support center with the phone numbers listed on the back cover of this
manual.
1.1.3 Preparing the Product for Installation and Operation
Preparation steps for installation and operation may slightly vary by product type and
application. Refer to the manual and prepare the product accordingly.
1.1.4 Installing the Product
Refer to the installation section of this manual and install the product correctly considering the
installation and operating conditions at the installation location, such as installation clearances,
to prevent premature deterioration or performance loss.
1.1.5 Connecting the Cables
Connect the power input/output and signal cables to the terminal block according to the
instructions provided in this manual. Ensure that all the cables are connected correctly before
supplying power to the product. Incorrect cable connections may damage the product.
