LS ELECTRIC L7NH Series User manual

AC SERVO DRIVE
Xmotion
L7NH Series

Introduction
1
Introduction
Hello. Thank you for choosing LS ELECTRIC L7NH Series.
This user manual describes how to use this product safely and efficiently.
Failure to comply with the guidelines outlined in this manual may cause personal injury or damage to
the product. Be sure to read this manual carefully before using this product and follow all guidelines
contained therein.
The contents of this manual are subject to change without notice.
The reproduction of part or all of the contents of this manual in any form, by any means or for
any purpose is strictly prohibited without the explicit written consent of LS ELECTRIC.
LS ELECTRIC retains all patents, trademarks, copyrights and other intellectual property rights to
the material in this manual. The information contained in this manual is only intended for use
with LS ELECTRIC products.
Safety precautions are categorized as either Warnings or Cautions, depending on the severity
of the precaution.
Precautions
Meaning
Danger Failure to comply with these guidelines may cause serious injury or death.
Caution Failure to comply with these guidelines may cause personal injury or property
damage.
Precautions listed as Cautions may also result in serious injury.
Electric Safety Precautions
Danger
Before wiring or inspection tasks, turn off the power. Wait 15 minutes until the charge lamp
goes off, and then check the voltage.
Ground both the servo drive and the servo motor.
Only specially trained technicians may perform wiring on this product.
Install both the servo drive and servo motor before performing any wiring.
Do not operate the device with wet hands.
Do not open the servo drive cover during operation.
Do not operate the device with the servo drive cover removed.
Even if the power is off, do not remove the servo drive cover.
Fire Safety Precautions
Caution
Install the servo drive, the servo motor, and the regenerative resistor on non-combustible
materials.
Disconnect the input power if the servo drive malfunctions.

Introduction
2
Installation Precautions
Store and operate this product under the following environmental conditions.
Environment Conditions
Servo Drive
Servo Motor
Ambient
temperature 0 ~ 50
℃
0 ~ 40
℃
Storage
temp. -20 ~ 65
℃
-10 ~ 60
℃
Ambient
humidity Below 90% RH (no condensation) 20~80% RH(no condensation)
Storage
humidity
Altitude Up to 1000m
Spacing
When installing 1 unit:
More than 40 mm at the top and bottom
of the control panel
More than 10 mm on the left and right
sides of the control panel
When installing 2 or more units:

More than 40 mm at the top of the
control panel
More than 40 mm at the bottom of the
control panel
More than 30 mm on the left and right
sides of the control panel
More than10 mm between units

Refer to Section 2.2.1, "Wiring the
Control Panel."
Etc
Ensure the installation location is free from dust, iron, corrosive gas, and
combustible gas.
Ensure the installation location is free from
vibrations or the potential for hard
impacts.
Caution
Install the product with the correct orientation.
Do not drop the product or expose it to hard impact.
Install this product in a location that is free from water, corrosive gas, combustible gas, or
flammable materials.
Install this product in a location capable of supporting the weight of this product.
Do not stand on the product or place heavy objects on top of it.
Always maintain the specified spacing when installing the servo drive.
Ensure that there are no conductive or flammable debris inside the servo drive or the servo
motor.
Firmly attach the servo motor to the machine.
Install the servo motor with a correctly oriented decelerator.
Do not touch the rotating unit of the servo motor during operation.
Do not apply excessive force when connecting the couplings to the servo motor shaft.
Do not place loads on the servo motor shaft that exceed the specified amount.

Introduction
3
Wiring Precautions
Caution
Be sure to useAC power for the input power of the servo drive.
Always use an AC 380-480 V power input for the servo drive.
Do not connect commercial power directly to the servo motor.
Do not connect commercial power directly to the U, V, W output terminals of the servo drive.
Connect the U, V, W output terminals of the servo drive directly to the U, V, W input terminals
of the servo motor, but do not install magnetic contactors between the wires.
Always use pressurized terminals with insulation tubes when connecting the servo drive power
terminal.
When wiring, be sure to separate theU, V, andW cables for the servomotor power andencoder
cable.
Always use the robot cable if the motor moves.
Before you perform power line wiring, turn off the input power of the servo drive, and then wait
until the charge lamp goes off completely.
Note3) The N terminal is used to connect an external capacitor. Connecting the power used to
the N terminal will damage the product. If you need to connect an external capacitor, be sure
to contact the customer service center or dealer.
Startup Precautions
Caution
Check the input voltage (AC 380-480 V) and power unit wiring before supplying power to the
device.
The servo must be in the OFF mode when you turn on the power.
Before you turn on the power, check the motor's ID and the encoder pulse for L7NHB □□□.

Set the motor ID[0x2000], encoder type[0x2001] and the encoder pulse [0x2002] for
L7NHB□□□ first after you turn on the power.
After you complete the above settings, set the drive mode for the servo drive that is connected
to the upper level controller in [0x6060].
Refer to ‘Chapter 2.5 Input/Output Signal Wiring’ and perform I/O wiring of the servo drive for
each operation mode.
You can check the ON/OFF state for each input terminal of I/O at [0x60FD].
Handling and Operating Precautions
Caution
Check and adjust each parameter before operation.
Do not touch the rotating unit of the motor during operation.
Do not touch the heat sink during operation.
Be sure to attach or remove the I/O and ENCODER connectors when the power is off.
Extreme change of parameters may cause system instability.

Introduction
4
Usage Precautions
Caution
Install an emergency cut-off switch which immediately stops operation in an emergency.
Reset the alarm when the servo is off. Be warned that the system restarts immediately if the
alarm is reset while the servo is on.
Use a noise filter or DCreactorto minimize electromagnetic interference.This prevents nearby
electrical devices from malfunctioning due to interference.
Only use approved servo drive and servo motor combinations.
The electric brake on the servo motor stops operation. Do not use it for ordinary braking.
The electric brake may malfunction if the brake degrades or if the mechanical structure is
improper (for example, if the ball screw and servo motor are combined via the timing belt).
Install an emergency stop device to ensure mechanical safety.
Malfunction Precautions
Caution
Install a servo motor with an electric brake or separate the brake system for use during
emergencies or device malfunctions.

After solving the problem and ensuring safe operation, deactivate the alarm and resume
operation.
Do not approach the machine until the problem is solved.
Repair/Inspection Precautions
Caution
Before performing servicing tasks, turn off the power. Wait 15 minutes until the charge lamp
goes off, and then check the voltage. Enough voltage may remain in the condenser after the
power is off to cause an electric shock.
Only authorized personnel may repair and inspect the device or replace its parts.
Do not modify this device in any way.
General Precautions
Caution
This user manual is subject to change due to product modification or changes in standards. If
such changes occur, we issue a new user manual with a new product number.
Product Application
Caution
This product is not designed or manufactured for machines or systems intended to sustain
human life.
This product is manufactured under strict quality control conditions. Nevertheless, install safety
devices if installing the device in a facility where product malfunctions may result in a major
accident or a significant loss.

Introduction
5
EEPROM Lifespan
Caution
The EEPROM is rewritable up to 4 million times for the purpose of recording parameter
settings and other information. The servo drive may malfunction if the total number of the
following tasks exceeds 4 million, depending on the lifespan of the EEPROM.
EEPROM recording as a result of parameter changes
EEPROM recording as a result of an alarm

Table of Contents
6
Table of Contents
1. Product configuration.................................................1-1
1.1 Product Verification................................................................1-1
1.2 Product Specifications...........................................................1-2
1.3 Part Names............................................................................1-4
1.3.1 Servo Drive Parts..................................................................................... 1-4
1.3.2 Servo Motor Parts.................................................................................. 1-15
1.4 System configuration example.............................................1-16
2. Encoder cable Servo Motor........................................2-1
2.1 Servo Motor...........................................................................2-1
2.1.1 Outline drawing...................................................................................... 2-31
2.1.2 Motor type and ID................................................................................... 2-41
2.2 Servo Drive..........................................................................2-44
2.2.1 Product feature ...................................................................................... 2-44
2.2.2 Outline drawing...................................................................................... 2-48
2.3 Options and Peripheral Devices ..........................................2-54
3. Wiring and Connection...............................................3-1
3.1 Installation ofServo Motor......................................................3-1
3.1.1 Operating Environment ........................................................................... 3-1
3.1.2 Preventing Impact................................................................................... 3-1
3.1.3 Motor Connection ................................................................................... 3-1
3.1.4 The Load Device Connection .................................................................. 3-2
3.1.5 Cable Installation ..................................................................................... 3-2
3.2 Installation of Servo Drive.....................................................3-3
3.2.1 Installation and Usage Environment ....................................................... 3-3
3.2.2 Installtion in the Control panel ............................................................... 3-4
3.3 Internal Block Diagram of Drive ...........................................3-5
3.3.1 Block Diagram (100W~400W/200[V])...................................................... 3-5
3.3.2 Block Diagram of L7NH (800W~3.5kW/200[V])....................................... 3-6
3.3.3 Block Diagram of L7NH (5kW~7.5kW/200[V])........................................ 3-7
3.3.4 Block Diagram of drive (15kW / 200[V])................................................... 3-8
3.3.5 Block Diagram of L7NH (1kW~3.5kW/400[V])........................................ 3-9

Table of Contents
7
3.3.6 Block Diagram of L7NH (5kW~7.5kW/400[V]) ......................................3-10
3.3.7 Block Diagram of L7NH (15kW/400[V]).................................................3-11
3.4 Power Supply Wiring ..........................................................3-12
3.4.1 Power Supply Wiring 100[kW]~3.5[kW](200/400[V]) ............................3-13
3.4.2 Power supply sequence .........................................................................3-16
3.4.3 Power circuit Electrical Components......................................................3-17
3.4.4 Regenerative resistance option spec. ....................................................3-29
3.5 Wiring for Input/Output Signals.........................................3-31
3.5.1 Names and Functions of Digital Input/Output Signals............................3-32
3.5.2 Names and Functions of Analog Input/Output Signals........................3-34
3.5.3 Examples of Connecting Input/Output Signals.....................................3-35
3.5.4 Connection diagram of I/O Signal...........................................................3-38
3.6 Wiring of Encoder Signal (ENCODER) ................................3-39
3.6.1 Quadrature Encoder Signaling Unit Wiring...........................................3-39
3.6.2 Serial Encoder Signaling Unit Wiring......................................................3-41
3.6.3 Multi-Turn Encoder Signaling Unit Wiring............................................3-43
3.6.4 Tamagawa Encoder Signaling Unit Wiring............................................3-45
3.6.5 EnDat 2.2 Encoder Signaling Unit Wiring .............................................3-45
3.7 Wiring for Safety Function Signals (STO) ...........................3-46
3.7.1 Names and Functions of Safety Function Signals.................................3-46
3.7.2 Example of Connecting Safety Function Signals...................................3-47
3.7.3 Bypass Wiring of Safety Function Signal...............................................3-48
3.8 Wiring for EtherCAT Communication Signals.....................3-49
3.8.1 Names and Functions of EtherCAT Communication Signals ................3-49
3.8.2 Example of Drive Connection ................................................................3-50
4. EtherCAT Communication..........................................4-1
4.1 Structure of CANopen over EtherCAT...................................4-1
4.1.1 EtherCAT State Machine ..........................................................................4-2
4.2 Status LED .............................................................................4-4
4.3 Data Type ..............................................................................4-6
4.4 PDO allocation ......................................................................4-7

Table of Contents
8
4.5 Synchronization Using the DC (Distributed Clock).............4-10
4.6 Emergency Messages..........................................................4-11
5. CiA402 Drive Profile....................................................5-1
5.1 State machine........................................................................5-1
5.2 Operation mode....................................................................5-4
5.3 Position Control Modes ........................................................5-5
5.3.1 Cyclic Synchronous Position Mode......................................................... 5-5
5.3.2 Profile Position Mode.............................................................................. 5-8
5.4 Velocity Control Mode ........................................................5-13
5.4.1 Cyclic Synchronous Velocity Mode....................................................... 5-13
5.4.2Profile Velocity Mode ............................................................................ 5-16
5.5 Torque control mode ..........................................................5-19
5.5.1 Cyclic Synchronous Torque Mode ........................................................ 5-19
5.5.2 Profile Torque Mode ............................................................................. 5-22
5.6 Homing................................................................................5-25
5.6.1 Homing Method .................................................................................... 5-26
5.7 Touch Probe Function .........................................................5-40
6. Drive Application Function.........................................6-1
6.1 Drive Front Panel...................................................................6-1
6.1.1 7-Segment for indicating servo status...................................................... 6-1
6.2 Input/Output Signals Setting..................................................6-4
6.2.1 Assignment of Digital Input Signals.......................................................... 6-4
6.2.2 Assignment of Digital Output Signals....................................................... 6-6
6.2.3 Assignment of Analog Output Signals...................................................... 6-8
6.2.4 Use of User I/O...................................................................................... 6-11
6.3 Electric Gear Setup..............................................................6-15
6.3.1 Electric Gear.......................................................................................... 6-15
6.3.2 Example of Electric Gear Setup............................................................. 6-17
6.3.3 Calculation of speed and acceleration/deceleration when using electronic gear
6-18
6.4 Settings Related to Speed Control.......................................6-20

Table of Contents
9
6.4.1 Smooth Acceleration and Deceleration..................................................6-20
6.4.2 Servo-lock Function................................................................................6-21
6.4.3 Signals Related to Speed Control ..........................................................6-21
6.5 Settings Related to Position Control....................................6-22
6.5.1 Position Command Filter........................................................................6-22
6.5.2 Signals Related to Position Control........................................................6-23
6.6 Settings Related to Torque Control......................................6-24
6.6.1 Speed Limit Function..............................................................................6-24
6.7 Positive/Negative Limit Settings..........................................6-25
6.8 Setting the Brake Output Signal Function............................6-26
6.9 Torque Limit Function..........................................................6-28
6.10 Gain switching function........................................................6-31
6.10.1 Gain group switching..............................................................................6-31
6.10.2 P/PI Control Switching............................................................................6-33
6.11 Motor Overload Protection...................................................6-35
6.11.1 Algorithm protection..........................................................................6-35
6.11.2 Protection by motor thermal time constant.............................................6-36
6.12 Dynamic brake ....................................................................6-37
6.13 Regeneration Brake Resistor Configuration........................6-39
6.13.1 Use of Internal Regenerative Resistor....................................................6-40
6.13.2 Use of External Regenerative Resistor ..................................................6-42
6.13.3 Other Considerations .............................................................................6-43
6.14 Configuration of Drive Node Address (ADDR).....................6-44
7. Safety Functions..........................................................7-1
7.1 Safety standard products.......................................................7-1
7.2 Safe Torque Off (STO) Function............................................7-1
7.3 External Device Monitor (EDM).............................................7-4
7.4 Example of Using Safety Function.........................................7-4
7.5 How to Verify Safety Function ...............................................7-5
7.6 Precautions for Using Safety Function ..................................7-5
8. Tuning ..........................................................................8-7
8.1 Off-line Auto Gain Tuning ......................................................8-7
8.2 On-line Auto Gain Tuning ......................................................8-9

Table of Contents
10
8.3 Manual Gain Tuning.............................................................8-12
8.3.1 Gain Tuning Sequence .......................................................................... 8-12
8.4 Vibration Control..................................................................8-13
8.4.1 Notch Filter............................................................................................. 8-13
8.4.2 Adaptive Filter........................................................................................ 8-14
8.4.3 Vibration Control (Damping) Filter.......................................................... 8-15
9. Procedure Function ....................................................9-1
9.1 Manual JOG Operation..........................................................9-1
9.2 Programmed Jog Operation ..................................................9-2
9.3 Alarm history reset.................................................................9-3
9.4 Index Pulse Search................................................................9-4
9.5 Absolute encoder reset..........................................................9-5
9.6 Instantaneous Maximum Torque Initialization........................9-5
9.7 Phase current offset tuning....................................................9-6
9.8 Software reset........................................................................9-6
9.9 Commutation.........................................................................9-6
10. Object Dictionary ......................................................10-1
10.1 General Objects...................................................................10-1
10.2 Manufacturer Specific Objects...........................................10-18
10.3 CiA402 Objects..................................................................10-81
11. Maintenance and Inspection ....................................11-1
11.1 Maintenance and Inspection................................................11-1
11.1.1 Caution................................................................................................... 11-1
11.1.2 What to Inspect...................................................................................... 11-1
11.1.3 Replacing Parts...................................................................................... 11-2
11.2 Diagnosing and TroubleshootingAbnormalities...................11-4
11.2.1 Servo Motor ........................................................................................... 11-4
11.2.2 Servo Drive ............................................................................................ 11-5
11.2.3 Overload Operating Characteristic Curve ............................................ 11-13
12. Test operation ...........................................................12-1
12.1 Preparation for Operation....................................................12-2
12.2 Test Drive Using TwinCAT System Manager .......................12-4

Table of Contents
11
12.3 Test Drive Using LS ELECTRIC PLC (XGT + PN8B)........12-13
12.4 Test Drive Using LS Mecapion MXP Series.......................12-19
13. Appendix i (Update)...................................................13-1
13.1 Firmware Update.................................................................13-1
13.1.1 Use of USB OTG....................................................................................13-1
13.1.2 Use of FoE (File access over EtherCAT)................................................13-2
13.1.3 Use of Drive CM.....................................................................................13-6
14. Appendix ⅱ(L7N → L7NH exchange) .....................14-1
14.1 Notes on capacity selection.................................................14-1
14.1.1 Review of drive selection........................................................................14-1
14.1.2 When selecting a product.......................................................................14-1
14.1.3 Comparison according to servo drive type .............................................14-1
14.2I/O PinMap comparison.......................................................14-2
14.2.1 I/O Pin Map via wiring example..............................................................14-2
14.3 Control detailed data ...........................................................14-3
14.3.1 Input point (CN1)....................................................................................14-3
14.3.2 Output point (CN1).................................................................................14-4
14.3.3 Analog signal (CN1)...............................................................................14-4
14.3.4 Analog output signal (Analog monitoring connector)..............................14-5
14.3.5 Safety (STO, Safety Toque Off) .............................................................14-5
14.4 Parameter setting................................................................14-6

Table of Contents
12

1. Product configuration
1-1
1. Product configuration
1.1 Product Verification
1. Check the name tag to verify that the product received matches the model ordered
Does the servo driver's name plate match?
Does the servo motor's name plate match?
2. Check the product components and options.
Are the type and length of cables correct?
Does the regenerative resistor conform to the required standard?
Is the shape of the shaft correct?
Are there any abnormalities after mounting the oil seal or brake?
Are the gearbox and the gear ratios correct?
Is the encoder format correct?
3. Check the exterior of the device.
Are there any foreign substances or humidity in the device?
Is there any discoloration, contaminant, damage or disconnected wire?
Are the bolts tightly fastened to the joints?
Is there any abnormal sound or excessive friction during operation?

1. Product configuration
1-2
1.2 Product Specifications
L7NH Series Product Type
L7 NH B 010 U AA
Input voltage
A: 200Vac
B: 400Vac
Option
Blank: Standard
Marked: Exclusive
Encoder
U: Universal
Series Name
L7 Series
Capacity
001 : 100W
002 : 200W
004 : 400W
008 : 750W
010 : 1kW
020 : 2kW
035 : 3.5kW
050 : 5.0kW
075 : 7.5kW
110 : 11.0kW
150 : 15kW
Communication
/Drive Type
S: Standard I/O
N: network
NH: Network type &
All-in-One Type
P: Standard I/O &
Index

1. Product configuration
1-3
Servo Motor Product Format
APM – S E P 10 D E K 1 G1 03
Motor Shape
S: Real Axis
H: Hollow Shaft
B: Assembly
Servo Motor
Flange Size
A: 40 Flange
B: 60 Flange
C: 80 Flange
D: 100 Flange
E: 130 Flange
F: 180 Flange
G: 220 Flange
Gearbox Classification
03: 1/3
10: 1/10
Gearbox Spec.
Non-existent: No gearbox
G1: For general industrial purposes
G2: For general industrial purposes
G3: Precise Gearbox
Oil Seal, Brake Existence
Non-existent: Noneincluded
1: Oil Seal attached
2: Brake attached
3: Oil Seal and Brake
Motor
R3: 30[W]
R5: 50[W]
01: 100[W]
02: 200[W]
03: 300[W]
04: 400[W]
06: 550/600[W]
07: 650[W]
08: 750/800[W]
10: 1[kW]
15: 1.5[kW]
20: 2[kW]
35: 3.5[kW]
50: 5[kW]
75: 7.5[kW]
150: 15[kW]
220: 22[kW]
300: 30[kW]
370: 37[kW]
RatedRPM
A: 3000[rpm]
D: 2000[rpm]
G: 1500[rpm]
M: 1000[rpm]
Encoder Type
Quadrature(Pulse type)
A: Inc. 1024[ppr]
B: Inc. 2000[ppr]
C: Inc. 2048[ppr]
D: Inc. 2500[ppr]
E: Inc. 3000[ppr]
F: Inc. 5000[ppr]
G: Inc. 6000[ppr]
Serial BiSS
(Communication type)
N : 19bit SingleTurn
M : 19bit MultiTurn
Shaft Shape
N: Straight
K: One-sidedround key
(Standard))
C: C Cut
D: D Cut
T: Taper Shape
R: Double-sided
H: Hollow Shaft
Input
Blank: 200Vac
P: 400Vac

1. Product configuration
1-4
1.3 Part Names
1.3.1 Servo Drive Parts
100W, 200W, 400W (200[V])
Display
This displays numerical values such as the
L7NH state and alarm number
State LEDs
These LED indicate the current EtherCAT state
Main power connectors (L1, L2, and L3)
These terminals connect to the main circuit power
input.
DC Reactor connectors (PO,PI)
These terminals connect to the DC reactor to
suppress high-frequency power(PO-PI)
Short circuit these when not in use
Regenerative resistance connectors(B+,B,BI)
These terminal connect to be external regenerative
resistor
-Short B and BI for basic installations
-If you are using an external resistor, connect it to
the B+ and B terminals
Control power terminals (C1,C2)
These terminals and for the control power input
Servo motor connecting terminal (U,V,W)
These terminals connects to the main circuit
cable(power cable) of the servo motor
Connector for Analog monitor
Connector for Analog output signal
Node address setting switch
This switch is to set the node address of the
drive. You can set the node addresses from
0 to 99.
USB Connector
This port communicates with a personal
computer
Ether CAT Communication port(IN)
EtherCAT Communication port(OUT)
Safety connector
connector connects safety devices.
-If you are not using any safety devices, be sure
to install the safety jump connector on the L7NH
Input/output signal connector
This connector is for sequence input/output
signals.
Encoder connector
This connects to the encoder installed on the
servo motor
CHARGE lamp
This turns on when the main circuit power is on
Ground terminal
The ground terminal prevents electric shock

1. Product configuration
1-5
750W, 1kW (200[V])
Display
This displays numerical values such as the
L7NH state and alarm number
CHARGE lamp
This turns on when the main circuit power is on
Main power connectors (L1, L2, and L3)
These terminals connect to the main circuit power
input.
DC Reactor connectors (PO,PI)
These terminals connect to the DC reactor to
suppress high-frequency power(PO-PI)
Short circuit these when not in use
Regenerative resistance connectors(B+,B,BI)
These terminal connect to be external
regenerative resistor
-Short B and BI for basic installations
-If you are using an external resistor,
connect it to the B+ and B terminals
Control power terminals (C1,C2)
These terminals and for the control power input
Servo motor connecting terminal (U,V,W)
These terminals connects to the main circuit
cable(power cable) of the servo motor
Connector for Analog monitor
Connector for Analog output signal
Node address setting switch
This switch is to set the node address of the
drive. You can set the node addresses from
0 to 99..
USB Connector
This port communicates with a personal
computer
Ether CAT Communication port(IN)
EtherCAT Communication port(OUT)
Safety connector
This connector connects safety devices.
-If you are not using any safety devices, be sure
to install the safety jump connector on the L7NH
Input/output signal connector
This connector is for sequence input/output signals.
Encoder connector
This connects to the encoder installed on the
servo motor
State LEDs
These LED indicate the current EtherCAT state
Ground terminal
The ground terminal prevents electric shock

1. Product configuration
1-6
2kW, 3.5kW (200[V])
Display
This displays numerical values such as the
L7NH state and alarm number
CHARGE lamp
This turns on when the main circuit power is on
Main power connectors (L1, L2, and L3)
These terminals connect to the main circuit power
input.
DC Reactor connectors (PO,PI)
These terminals connect to the DC reactor to
suppress high-frequency power(PO-PI)
Short circuit these when not in use
Regenerative resistance
connectors(B+,B,BI)
These terminal connect to be external
regenerative resistor
-Short B and BI for basic installations
-If you are using an external resistor,
connect it to the B+ and B terminals
Control power terminals (C1,C2)
These terminals and for the control power input
Servo motor connecting terminal (U,V,W)
These terminals connects to the main circuit
cable(power cable) of the servo motor
Connector for Analog monitor
Connector for Analog output signal
Node address setting switch
This switch is to set the node address of the
drive. You can set the node addresses from
0 to 99..
USB connector
This port communicates with a personal
computer
EtherCAT Communication port(IN)
EtherCAT Communication port(OUT)
Safety connector
This connector connects safety devices.
-If you are not using any safety devices, be
sure to install the safety jump connector on
the L7NH
Input/output signal connector
This connector is for sequence input/output
signals.
Encoder connector
This connects to the encoder installed on
the servo motor
State LEDs
These LED indicate the current EtherCAT state
Ground terminal
The ground terminal prevents electric shock

1. Product configuration
1-7
5KW(200[V])
Display
It shows drive status, alarms, etc.
Connector for analog monitors
It is a connector for checking the analog
output signal.
Status LED
It indicates the current state of
EtherCAT communication.
Node address setting switch
This switch is to set the node address of
the drive.
You can set the node addresses from 0
to 99.
USB connector (USB)
This connector is to communicate with a
PC.
EtherCAT communication input
EtherCAT communication input port
(ECAT OUT)
Safety connector (STO)
This connector connects safety devices.
-If a safety device is not used, be sure
to install the safety jump connector
before use.
Input/output signal connector (I/O)
This connector is for sequence
input/output signals.
Encoder connector (ENCODER)
This connector connects to the encoder
installed in the servo motor.
CHARGE lamp
This turns on when the main circuit
power is on.
Ground terminal
It is a ground terminal to prevent
electric shock.
Servo motor connection terminals
(U,V,W)
These terminals connect to the main
circuit cable (power cable) of the servo
motor.
Control power terminals (C1
and C2)
DC reactor connector (PO, PI)
These terminals connect to the
DC reactor to suppress high-
frequency power.
* It is not a connector for
connection (N)
Main power connectors (L1,
L2, and L3)
These terminals connect to the
main circuit power input.
Regenerative resistance connector (B+, B)
These terminals connect to the external
regenerative resistor.
-For basic installations: Short-circuit B+ and
B terminals.
-For external resistor installations : After
attaching internal resistor wiring to the
internal resistor fixing hole “NC” of the case,
connect the external resistor to B+ and B
terminals.
