LS iP5A User manual

iP5A Modbus/TCP Manual
1
Thank you for purchasing LS Modbus/TCP Option board.
Safety Instruction
To prevent injury and danger in advance for safe and correct use of the product,
be sure to follow the Safety Instructions.
The instructions are divided as ‘WARNING’and ‘CAUTION’which mean as follow.
WARNING
CAUTION
The meaning of each symbol in this manual and on your equipment is as
follows.
This is the safety alert symbol.
This is the dangerous voltage alert symbol.
After reading the manual, keep it in the place that the user always can
Contact easily.
Read carefully this manual to use the communication option function of
SV-iP5A Series Inverter safely and correctly.
WARNING
Be cautious about dealing with CMOS elements of option board.
It can cause malfunction by static electricity.
Connection changing like communication wire change must be
Done with power off.
It can cause communication faulty or malfunction.
Be sure to connect exactly between Inverter and option board.
It can cause communication faulty or malfunction.
Check parameter unit when setting parameter.
It can cause communication faulty
This symbol indicates the possibility of death or
serious injury.
This symbol indicates the possibility of injury
or damage to property.

iP5A Modbus/TCP Manual
2
1. Introduction
Modbus/TCP communication board make SV-iP5A inverter be connected to Ethernet
network. Controlling and monitoring inverter can be done by PLC sequence program or any
Master Module. Since Ethernet which constitutes Internet has been used and IPV4 has been
supported, wherever Internet can be done, controlling and monitoring is possible. But,
Ethernet network of the factory has to be connected to Internet through Gateway.
With simple wiring, installation time can be reduced and maintenance becomes easier.
2. Modbus/TCP Technical features
3. Product Constituents
-. Modbus TCP communication board : 1 ea
-. Supporting pole : 3 ea
-. The manual : 1 ea
Transmission Speed
10Mbps, 100Mbps
Transmission method
Baseband
Max. extended distance
between nodes.
100m (Node-Hub)
Max. node number
Hub connection
Auto Negotiation
Supported
Max. Frame size
1500 byte
Communication zone access
method
CSMA/CD
Frame error checking method
CRC32
Recommended
connecting channel
3 channel

iP5A Modbus/TCP Manual
3
4. Modbus/TCP Appearance and Installation
Installing communication card to iP5A inverter

iP5A Modbus/TCP Manual
4
5. Network Connection
Communication cable connecting terminal
※Make sure that cables connected to Pin1 and 2 are twisted together.
※Make sure that cables connected to Pin3 and 6 are twisted together.
Pin No.
Signal
Description
Cable color
1
TX+
Transmitting data Plus
White / Yellow
2
TX-
Transmitting data Minus
Yellow
3
RX+
Receiving data Plus
White / Green
4
NONE
Not used
Blue
5
NONE
Not used
White / Blue
6
RX-
Receiving data Minus
Green
7
NONE
Not used
White / Brown
8
NONE
Not used
Brown
1
8

iP5A Modbus/TCP Manual
5
6. Network Cable Standard
(1) Used Frequency band
Category 5 is used. Transmitting speed of category 5 is 100MHz and possible
up to 100Mbps.
(2) Twisted Pair cable type
Classification
Detail
Used
UTP (U.UTP)
High speed signal cable
with no cover
Maximum 200MHz
Voice + Information(Data)+
Low-grade Video signal
FTP (S.UTP)
Cable core covered only
Maximum 100MHz
Electromagnetic interruption (EMI) or
electric stability considered
Voice+ Information (Data) +
Low-grade Video signal
STP (S.STP)
Double-covered,
separately covered Pair
with cable core
covered
Maximum 500MHz
Voice +Information(Data)+
Video signal
75Ωcoaxial cable replacement

iP5A Modbus/TCP Manual
6
7. Modbus/TCP related Keypad parameter
Inverter parameters below display Modbus/TCP related information.
iP5A Modbus/TCP related Keypad parameter
Code
number
Parameter
name
Initial
value
Setting
value
Description
COM-01
Opt B/D
-
-
Communication card installed
in inverter is displayed.
(If Modbus/TCP comm. Card
is installed, “Modbus/TCP”is
displayed)
COM-02
Opt mode
None
None
Command
Freq
Cmd +Freq
set method for drive and freq.
command of communication
card
COM-03
Opt Version
-
-
The version of Communication
card installed in inverter is
displayed.
COM-61
IP Addr Hi
C0:A8 HEX
00:00 HEX
~
FF:FF HEX
Set IP Address.
COM-62
IP Addr Lo
64:0A HEX
00:00 HEX
~
FF:FF HEX
COM-63
Subnet Hi
FF:FF HEX
00:00 HEX
~
FF:FF HEX
Set Subnet Mask.
COM-64
Subnet Lo
FF:00 HEX
00:00 HEX
~
FF:FF HEX
COM-65
Gateway Hi
C0:A8 HEX
00:00 HEX
~
FF:FF HEX
Set Gateway Address.
COM-66
Gateway Lo
64:01 HEX
00:00 HEX
~
FF:FF HEX
COM-67
Comm Update
Communication related
Keypad parameter is Updated.

iP5A Modbus/TCP Manual
7
(1) Opt B/D (Option card information, COM-01)
The type of communication card installed in inverter is displayed automatically.
If iP5A Modbus/TCP communication card is installed, “Modbus/TCP”message
is displayed automatically.
(2) Opt mode (drive and freq. command setting mode, COM-02)
Set the method for drive and freq. setting command of communication card.
(3) Opt Version (Option version information, COM-03)
Version of communication card installed in inverter is displayed automatically.
(4) Modbus/TCP IP, Subnet Mask, Gateway Address (COM-61~66)
IP version that Modbus/TCP option supports is v4.
All the addresses and masks are expressed as decimal number. decimal
number. decimal number. decimal number and a number between 0 and 255
is input for each decimal number.
In Modbus/TCP option, all decimal number is supposed to changed into
hexadecimal number. Also input dividing 2 higher hexadecimal numbers and
2 lower numbers
EX) For setting IP Address 196.168.10.131
Change 196.168.10.131 into hexadecimal numbers. C0.A8.0A.83
For COM-61 IP Addr Hi, input C0:A8 HEX.
ForCOM-62 IP Addr Lo, input 0A:83 HEX.
(5) Comm UpDate (COM-67)
For COM-61 ~ 66 parameters, when power inputs for the first time, the values
set in Option are expressed. But if you set, the setting is not reflected at once.
If Comm Update is set as Yes, the value is reflected to Modbus/TCP
communication card and only Modbus/TCP communication card operates again.
In the case of Parameter initialization, the values of COM-61 ~ 66 are
changed into initial values even though they aren’t reflected to actual option
board. So also in this case, Comm. UpDate has to be done.

iP5A Modbus/TCP Manual
8
8. Inverter communication address
Refer to iP5A manual appendix C - built-in comm. Parameter list
9. Modbus/TCP Frame
(1) Modbus/TCP Frame structure
Generally, Ethernet uses Ethernet II Frame.
MODBUS Application Protocol Header (MBAP Header)
MBAP Header structure is as below.
Protocol Data Unit (PDU)
AS an actual Data of Modbus TCP, consists of Function Code and Data.
Detail information will be given at “(2) Function Code Description.”
MBAP Header( 7 bytes)
PDU (5 bytes ~)
Region
Length
Description
Transaction Identifier
2 Bytes
As an identified transmitting number,
is increased by 1 each time Data Frame
is send to Server from Client.
Protocol Identifier
2 Bytes
Fixed as 0.
Length
2 Bytes
Modbus Data Frame length.
From MBAP Header to Unit Identifier,
Byte-unit length can be expressed.
Unit Identifier
1 Bytes
When Modbus TCP and Modbus RTU
are connected with Gate, Slave number
is written. When Modbus TCP is only used,
it is fixed as 0xFF.

iP5A Modbus/TCP Manual
9
(2) Function Code Description
Modbus TCP can be divided into Client and Server. Client gives the command
and Server responds to the command. Generally, as Client, there are PLC, HMI,
PC so on, and Server means inverter.
①Read Multiple Registers
It is a function for reading Data from Inverter (Server).
Frame Constitution that Client requires Server
Frame Constitution that Server responds to Master
②Write Single Register
The function is used when modifying 1 Data of Inverter (Server).
Frame Constitution that Client requires Server
Required Frame
Length
Value
Function Code
1 Bytes
0x03
Comm. Address
2 Bytes
0x0000 ~ 0xFFFF
Required Data number
2 Bytes
1~16
(by LSIS Inverter standard)
Responded Frame
Length
Value
Function Code
1 Bytes
0x03
Comm. Address
1 Bytes
2 x Data required number
Required Data number
Data required
number x 2 Bytes
Required number of Data
from comm. address
Required Frame
Length
Value
Function Code
1 Bytes
0x06
Comm. Address
2 Bytes
0x0000 ~ 0xFFFF
Data Value
2 Bytes
0x0000 ~ 0xFFFF

iP5A Modbus/TCP Manual
10
Frame Constitution that Server responds to Master
③Write Multiple Register
The function is used when modifying consecutive Data from 1 up to 16 of
inverter (Server).
Frame Constitution that Client requires Server
Frame Constitution that Server responds to Master
Responded Frame
Length
Value
Function Code
1 Bytes
0x06
Comm. Address
2 Bytes
0x0000 ~ 0xFFFF
Data Value
2 Bytes
0x0000 ~ 0xFFFF
Required Frame
Length
Value
Function Code
1bytes
0x10
Comm. Address
2bytes
0x0000 ~ 0xFFFF
Modifying Data number
2byte
1~16 (by LSIS inverter
standard )
Byte Count
1byte
2 X Data number
Data value to be
modified
Data number
x 2 bytes
Data for modifying
Responded Frame
Length
Value
Function Code
1 Bytes
0x10
Comm. Address
2 Bytes
0x0000 ~ 0xFFFF
Modifying Data
number
2 Bytes
1~16 (by LSIS inverter
standard)

iP5A Modbus/TCP Manual
11
(3) Except Frame
Except Frame is for responding from Server if Error happens performing the
required Frame when Client sends required Frame to Server.
Exception Frame Structure
Exception Code Type
Error Frame
Length
Value
Error Code
1bytes
0x80 + Function Code that
Client requires
Exception Code
1bytes
0x0000 ~ 0xFFFF

iP5A Modbus/TCP Manual
12
10. LED Information
In Modbus/TCP communication card, 4 LEDs which indicate the Modbus/TCP state
to the user are installed. In iP5A Modbus/TCP communication card, LEDs are
displayed as below.
Type
Code
Description
ILLEGAL FUNCTION
0x01
If non-supported Function is
Required, this massage is displayed.
ILLEGAL DATA ADDRESS
0x02
If Data of not used address is
required or to be modified, this
massage is displayed.
ILLEGAL DATA VALUE
0x03
If you try to modify Data with the
Value that is against the permitted
Data range, this massage is
displayed.
SLAVE DEVICE FAILURE
0x04
If there is error in Server
(CAN Comm. ERROR with inverter,
Option initialization ERROR, failure
of DATA comm. with inverter), this
massage is displayed.
SLAVE DEVICE BUSY
0x06
If Server can’t respond due to other
process (such as Inverter parameter
initialization or option initialization
setting), this massage is displayed.
READ ONLY ADDRESS
0X14
If you try to save address that is
only for reading value, this massage
is displayed.
WRITE PERMITION ERROR
0x20
This Code only exists at LS inverter.
If you try to modify modifying
prohibited parameter value this
massage is displayed.
Green
Speed
Green
Link
Red
Error
Green
CPU

iP5A Modbus/TCP Manual
13
LED name
Color
Function
CPU
Green
BLINK –It means Modbus/TCP communication card
CPU is operating normally when the power is well
supplied to iP5A Modbus/TCP.
ERROR
Red
OFF –It means Modbus/TCP communication card is
normal without Error.
CPU, ERROR Flashing by turns
–If IP Address is set as 0x00.0x00.0x00.0x00 or
0xFF.0xFF.0xFF.0xFF. Using special IP like 0.0.0.0 or
255.255.255.255 is not recommended
Twice of CPU Blinking period time Flashing
–It means IP Address Setting is being tried.
If you set Com update as Yes, LED is off as IP Address
set in keypad is reflected to option board.
CPU, ERROR Flashing at the same time–
It means Comm. Option board can not recognize inverter.
Replace the board.
ON –It means Modbus/TCP option EEPRom is faulty.
Replace the board.
Speed
Green
ON –means Comm. Speed is 100Mbps.
OFF –means Comm. Speed is 10Mbps.
Link
Green
ON –means it is ready to do communication.
OFF –If communication cable wiring is incorrect, Link
LED becomes OFF. Check communication Cable.
