LST IND-200W-UVC User manual

NB: READ THIS MANUAL CAREFULLY BEFORE USE OR MAINTENANCE. KEEP THIS MANUAL FOR FUTURE REFERENCE.
UV indUction steriliser Unit
100W - 400W
INSTRUCTION MANUAL

FEATURES
HOW TO OPERATE
• Destroys&preventsregenerationofviruses
andbacteria
• Highpower,highintensity
• UV-CDeepwavelengthultra-violettechnology
• Dual-purposesteriliser
• FixedorMobile
• Fast&convenientdisinfection
Hoistingring
UVelectrodelesslight
Stainlesssteellampguard
Infraredsensor
Electricalbox
Wheelswithbrake
1. Removeallprotectivepackaging.
2. Undothestainlesssteelhoistingringandremovethestainless
steelguard.
3. Connecttomainspower.
4. Setthetimerforthedesiredsterilisationtime(Seepage2).
Thedefaulttimeis30minutes.
5. Replacethestainlesssteelguardandreplaceandtightenthe
stainlesssteelhoistingring.
6. Placethesteriliserinthecentreoftherequiredsterilisationspace
andlockthecasterwheelsinplace.
7. Ensure that the infrared sensor faces the  entrance of the
sterilisationspace.
8. Whentheindicatorlightisonthesteriliserisoperational.
9. CAUTION!Leavethesterilisationareawithin30secondsto
avoidUVexposure.
NEVER expose your eyes or skin to direct ulraviolet light!
10. Theunitwillturnoffautomaticallyafterthepresetsterilisation
timeiscompleted.
11. Theareamustbeventilatedfor30minutes(orassuggestedin
thefollowingsection)afterdisinfection.
12. If someone enters the room during disinfection, the unit will
turn off automatically. To continue sterilisation, turn off the
powerswitchandturnonagainafter30seconds.Leavethe
areaimmediately.
13. For the most effective sterilisation ensure that the regular
lightingintheareatobedisinfectedisswitchedoffwhilstthe
disinfectionisunderway.
14. After the sterilisation unit has switched off it is important to
ventilate the area before allowing normal occupancy of the
particularworkarea.
On-Offswitch
ACPowerSupplyCord
Germicidal Efficacy (185-253.7nm)
Micro-organism
(Bacteria/ viruses)
UV sterilisation reference (99.999%)
Required flux
(µW sec/cm2)
Time required (s)
5mw 100mw
Anthraxspores 46,200 35 1.75
Escherichiacoli 6,600 50.25
Clostridiumtetanus 22,000 16.7 0.83
Diptheriaclub 6,510 4.93 0.25
Typhoidfever 4,100 3.1 0.16
Mycobacteriumtuberculosis 10,000 7.6 0.38
Gonococcus 8,500 6.4 0.32
Salmonella 7,600 5.8 0.29
ParatyphoidofSalmonellatyphimurium 6,100 4.6 0.23
Dysentery 4,200 3.2 0.16
Vibriocommacholera 6,500 4.9 0.25
Infectioushepatitis 8,000 6.2 0.31
Inuenza 6,600 50.25
Poliomyelitis 6,600 50.25
COVID-19 6,600 60.3

MODEL DIMENSIONS
(LxWxH) VOLTAGE INPUT FREQUENCY WATTAGE WAVELENGTH
(nm)
PEAK
WAVELENGTH
UV
SPECTRAL
IRRADIANCE
UV
SPECTRAL
FLUX
N.W.
IND-200W-UVC 300x300x815mm 120-227V 2.2A 50/60HZ 210W 253.7nm-400nm 253.7nm 947.3µw/cm248W 8.7kg
IND-200W-UVC-O 300x300x815mm 120-227V 2.2A 50/60HZ 210W 185nm-400nm 253.7nm 947.3µw/cm248W 8.7kg
IND-250W-UVC 300x300x815mm 120-227V 2.6A 50/60HZ 260W 253.7nm-400nm 253.7nm 1200µw/cm262W 8.7kg
IND-250W-UVC-O 300x300x815mm 120-227V 2.6A 50/60HZ 260W 185nm-400nm 253.7nm 1200µw/cm262W 8.7kg
IND-300W-UVC 300x300x884mm 120-227V 3.2A 50/60HZ 310W 253.7nm-400nm 253.7nm 1300µw/cm294W 9.6kg
IND-300W-UVC-O 300x300x884mm 120-227V 3.2A 50/60HZ 310W 185nm-400nm 253.7nm 1300µw/cm294W 9.6kg
IND-400W-UVC 300x300x1080mm 120-227V 4.2A 50/60HZ 420W 253.7nm-400nm 253.7nm 1515µw/cm2116W 11.3kg
IND-400W-UVC-O 300x300x1080mm 120-227V 4.2A 50/60HZ 420W 185nm-400nm 253.7nm 1515µw/cm2116W 11.3kg
SPECIFICATIONS
DISINFECTION
POWER ROOM AREA
RECOMMENDED
DISINFECTION
TIME
RECOMMENDED
VENTILATION TIME
OZONE OZONE FREE
200W <100m230min 30min 20min
250W <150m230min 30min 20min
300W <200m230min 30min 20min
400W <250m230min 30min 20min
Ambienttemperature0-50˚C
OZONE CONTENT TEST
• Generalhealthstandardssuggestthatpeopleshouldnotbeinindoorareaswithanozonecontentof0.04ppm(partspermillion).
• Itis important toproperlyventilatethe areapost sterilisation toreducetheozone content. Seethe DISINFECTION TIMEAND
RELATIVEAREAtablebelowforguidelines.
• Theozonecontentintheairisinuencedbyambienttemperature,humidityandatmosphericpressure.SeetheOZONECONTENT
TESTbelowwhichwascompiledinarelativespaceandenvironment,andthedataisforreferenceonly.
• Anozonecontentof1ppmintheairequals2.144mg/m3.
• During sterilisation with the ozone version of the UV sterilisation unit, the ozone level will increase as long as the unit is operational.
Forgreatersterilisationofagivenarea,theunitmaybeusedforlongerthan30minutes,aslongasproperventilationisdoneafterwards.
TheINLED™UVsteriliserunitwiththeoptionalozonewavelengthlampprovidesadditionalsterilisationthroughthesterilisingaction
ofozone(O3).
MODEL WATTAGE TESTING METER/ ROOM
OZONE CONTENT
AFTER 30 MINUTES
STERILISATION
OZONE CONTENT
AFTER 30 MINUTES
VENTILATION
UVL-200W-UVC 200W
EST-101OzoneMeter
Temperature-HumidityMeter
TestingRoom135.2m2
(7.45mx6.6mx2.75m)
Enclosedroomfor30minutes
Temperature30˚C,Humidity87%
AtmosphericPressure1004.7hpa
1ppm
2.144mg/m3
0.078ppm
0.167mg/m3
UVL-250W-UVC-O 250W 1.5ppm
3.216mg/m3
0.08ppm
0.17mg/m3
UVL-300W-UVC-O 300W 1.8ppm
3.86mg/m3
0.08ppm
0.17mg/m3
UVL-400W-UVC-O 400W 2.6ppm
5.58mg/m3
0.08ppm
0.17mg/m3
DISINFECTION TIME AND RELATIVE AREA

WARNING
OncetheUV-Clightisswitchedonthereis30secondsbeforetheunitbecomesfullyoperational.Ifsomeoneenterstheroomduring
sterilisationtheunitwillturnoffautomaticallyastheinfraredsensordetectsmovement.Inordertocontinuesterilisation,turnoffthe
powerswitchandturnonagainafter30seconds.Sterilisationtimesettingoptions:10seconds,1minute,5minutes,10minutes,30
minutes.Defaulttimeis30minutes.
Setthetimingofthelightto4,5,6,7
for10seconds-30minutedelays
ON/OFF
INFRARED INDUCTION
NO SETTINGS
DETECTION RANGE SETTINGS:
FACTORY SETTING = 100%
1. ALL PEOPLE MUST VACATE THE AREA IMMEDIATELY BEFORE THE UV-C LIGHT IS SWITCHED ON OR BECOMES OPERATIONAL.
LIKEWISE ANIMALS AND BIRDS MUST BE REMOVED FROM THE AREA BEFORE STERILISATION BEGINS.
2. PLANTS AND/OR ARTWORK MUST EITHER BE REMOVED OR BE PROPERLY PROTECTED SO AS TO AVOID DIRECT IRRADIATION.
3. NEVER EXPOSE ANYBODY’S SKIN OR EYES TO DIRECT ULTRAVIOLET RADIATION.
4. KEEP CHILDREN AWAY FROM THE UV-C LIGHT UNIT AT ALL TIMES.
5. THE UV-C STERILISATION UNIT MUST ONLY BE OPERATED BY TRAINED PERSONNEL.
6. DO NOT USE UV-C LIGHT AS A CONVENTIONAL LIGHT.
7. THE UV-C LIGHT MUST NOT BE USED FOR LONGER THAN IS RECOMMENDED IN THE MANUAL.
8. DO NOT IMMERSE THE UV-C LIGHT UNIT IN WATER AND/OR DO NOT WASH WITH WATER. TO AVOID DAMAGING THE UNIT,
KEEP IT DRY AT ALL TIMES.
SPECTRAL CURVES
SENSOR SWITCH TIMER SETTING
Wavelength(nm)
Relativespectrum
Wavelength(nm)
Transmittance
