Norka BUENOS AIRES UV-C 997 100 02 Series User manual

1
Operating instructions
BUENOS AIRES UV-C
Wall mounting
Article number 997 100 02 ..
Article number 997 180 02 ..

2
FOR YOUR SAFETY
Read these operating instructions carefully
before operating the unit and keep them for
subsequent reference.
>Make sure that no water, other liquids or
ammable cleaning agents get into the
unit to avert the risk of electric shock
and/or re.
>Do not clean the unit with water, other
liquids or (ammable) cleaning agents
to avert the risk of electric shock and/
or re.
>Do not spray ammable materials, such
as insecticides or disinfectants, around
the unit.
>Before connecting the unit to the power
supply, check that the voltage rating on
the unit matches the local line voltage.
>This unit can be used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given su-
pervision or instruction concerning use
of the unit in a safe way and understand
the hazards involved. Children must not
be allowed to play with the unit. Cleaning
and maintenance must not be carried out
by children without supervision.
>Make sure that the air inlet and outlet are
not covered. Therefore, do not place or
hang any objects in front of the air outlet
or inlet. Make sure that no foreign objects
fall into the unit.
>Do not place the unit directly under an air
conditioner to prevent condensation from
dripping onto the unit.
>Always disconnect the unit from the pow-
er supply after use and before cleaning,
maintenance work or replacing the UV-C
lamps.

3
TECHNICAL DATA
Article number 997 100 .. .. 997 180 .. ..
Lamp OSRAM®G36T8/OF HNS 36W G13 OSRAM®G36T8/OF HNS 36W G13
Lamp service life 9000 h at +40 °C 9000 h at +40 °C
Wavelength 253.7 nm 253.7 nm
Air-ow rate 100 m³/h 180 m³/h
UV-C interference radiation < 1 mW/m² according to DIN EN
12198-1
< 1 mW/m² according to DIN EN
12198-1
Flow velocity Approx. 1 m/s Approx. 1.75 m/s
Radiation (dose) 41 J/m² 24 J/m²
Air humidity,
non-condensing
5% to 85% 5% to 85%
Max. system power,
continuous operation
75 W 75 W
Protection class I I
Protection rating (IP) IP 20 IP 20
Sound pressure level 20 db(A) 32 db(A)
Transformer 220–240 V AC, 50 Hz/60 Hz 220–240 V AC, 50 Hz/60 Hz
Ozone-free Yes Yes
Installation type Wall mounting Wall mounting
Dimensions (L x W x H) 1870 mm x 155 mm x 185 mm 1870 mm x 155 mm x 185 mm
Mounting spacing
(mounting dimension)
1214 mm 1214 mm
Max. weight 11 kg 11 kg

4
INSTALLATION
>Wall plug load capacity is designed for
12 kg.
>Fit the housing into the wall bracket, with
the lamp control light pointing down-
wards towards the  oor.
>The spacer nut must be inside the recess
of the wall bracket.
>Tighten the fastening nut (SW10) to 2 Nm.
>Plug in the mains cable and switch on.
1214 mm
115 mm
Ø 8,5 mm
min. 500 mm
max. 600 mm
Lamp control
light

5
Spacer nut Fastening nut (SW 10)

6
COMMISSIONING
!Note
the visible “blue” light has no harmful UV-C radiation.
The BUENOS AIRES UV-C unit is designed for continuous operation.
Commissioning should begin approx. one hour before the room is to be used to ensure that
it functions properly.
!Note
As the unit is delivered with new UV-C lamps, there may be a slight odour during the
rst hours of operation due to the burning-in process of the lamps. This is normal and
does not constitute a defect.
MAINTENANCE
Always switch off the air disinfection unit before maintenance. Disconnect the air disinfec-
tion unit from the mains. Never immerse the air disinfection unit in water or other liquids.
Do not use abrasive cleaners or aggressive or ammable cleaners, such as bleach or
alcohol, to clean the parts of the air disinfection unit.
!WARNING
UV-C light is harmful to the retina. Never operate the lamp without the housing
closed.
Replace the UV-C lamps after approx. 8,000 operating hours (after approx. 3 years of use
8 hours/day), as the performance diminishes after that.
CLEANING
Clean the outside of the air disinfection unit with a soft, dry cloth. The air outlet can also be
cleaned with a soft, dry cloth.

7
REPLACING THE UV-C LAMP
A Wait until the unit has cooled down completely.
B Remove the housing screws.
C Pull the lamps towards the housing
opening.
C
B

8
D Insert the new lamps
type OSRAM HNS 36W G13.
E Check whether the lamp is centred
in the socket.
D
E
!

9
F
F Tighten the 10 housing
screws.
Fault Possible cause Remedy
Green light control lamp
is off.
No mains voltage Check the mains voltage.
UV-C lamp defective Replace both UV-C lamps.
No air owing out of air
outlet
Air inlet blocked Check the air inlet.
Fan defective Please contact NORKA
Customer Service.
Fan wheel is not turning al-
though green control lamp
is on.
Fan wheel blocked Check the air inlet for
foreign bodies.
Fan defective Please contact NORKA
Customer Service.
Other fault Please contact NORKA
Customer Service.
TROUBLESHOOTING

10
DISPOSAL
When disposing of the unit or the UV-C lamp, observe the relevant legal regulations.
Information on the disposal of electrical and electronic equipment in the European Com-
munity:
Within the European Community, the disposal of electrically operated devices is governed
by national regulations based on the EU Directive 2012/19/EU on Waste Electrical and
Electronic Equipment (WEEE). According to this Directive, the unit or the UV-C lamp must
not be disposed of with municipal or household waste. The unit or the UV-C lamp is ac-
cepted free of charge at the municipal collection points or recycling centres.
SHUTDOWN
Clean the unit and store it together with these instructions in a clean and frost-proof place.

11
92-13-000251-02
a
BUENOS AIRES
2014/30/ EU - directive of electromagnetic compatibility
2014/35/ EU - low voltage directive
2011/65/ EU + 2015/863 - directive of the use of certain hazardous substances (RoHS)
EN IEC 63000 / 05.2019
EN 55015 / 07.2019
EN 60335-1 / 08.2020
EN 60335-2-65 / 02.2013
EN 61000-3-2 / 12.2019
Product name:
Document-No.:
Reference:
Dörverden-Hülsen/
The indicated products are in accordance with following European regulations:
Related standards:
EU - Declaration of Conformity
Manufacturer:
Norddeutsche Kunststoff- und Elektrogesellschaft
Stäcker mbH u. Co. KG
Lange Straße 1
27313 Dörverden- Hülsen
Place/Date:
Issuer:
Signed for and on behalf of: NORKA Norddeutsche Kunststoff- und
Elektrogesellschaft Stäcker mbH und Co. KG
v. Rudkowski, Head of Laboratory & Pre-development
This declaration certifies theaccordance with the stated regulations but doesn't include assurance of
characteristics. The safety marking/advices of the supplied product information hasto be observed.
This declaration of conformity is issued under the sole responsibility of the manufacturer.
10.06.2021
Schönfeld, CEO

12
Norddeutsche Kunststoff- und Elektro-
gesellschaft Stäcker mbH & Co. KG
Lichttechnische Spezialfabrik
Weidestraße 122 a
22083 Hamburg
Germany
T. [phone]
[email protected]om
norka.com
102515 V1.0 09/08/2021 Subject to technical changes without prior notice
