Ltech DMX512 User manual

LT-9 05-OLED
Photoelectric
isolation
Dimming curve: 0.1~9.9
Short circuit / Over current / Overheat protection
OLED display
8 bit / 16 bit
www.ltech-led.com
2 kinds of DMX interfaces
CHANNELS

1
Product introduction
www.ltech-led.com
Gamma Value
DMX Value
Output
Brightness
Photoelectric
isolation
0
100%
2.5 3.5
6.5
1.0
0.8
0.9
<1
>1
1.5
255
Short circuit
protection
5-pin XLR RJ45 RDM Over current
protection
Display
6. With firmware upgrade function.
7. With short circuit, over current and overheat protection, as well as warning
function when a fault occurs.
8. With power-on state management and fast self-testing function.
9. 16bit (65536 levels) / 8bit (256 levels) grey level available.
10. Available for standard, liner, LOG or custom 0.1-9.9 dimming curve.
5. With the operations can be completed via the
RDM editor, such as parameters browsing & settings, DMX address settings,
equipment recognition, etc.
RDM remote management protocol,
4. 5-pin XLR, RJ45 DMX interface with photoelectric isolation, improve signal
transmission efficiency and anti-interference ability.
2. Easy operation with OLED display and the touch buttons.
1. Designed with 5 channels output, and Max. 5A per channel, up to 600W output.
3. 5 modes available: DIM, CT, RGB, RGBW, RGBWY.
Overheat
protection

37
2
Photoelectric
isolation:
Yes
-30 ~65
122×110×37mm(L×W×H)
127×123×41mm(L×W×H)
550g
°C °C
LT-905-OLED
DMX512/RDM
~
×
× 5CH Max. 600W
5-pin XLR, RJ45
8bit (256 levels) /16bit (65536 levels)
Short circuit / Overheat / Over current
protection, recover automatically.
12 24Vdc
5A 5CH Max. 25A
(0~60W...120W)
DIM/CT/RGB/RGBW/RGBWY
0.1~9.9, standard, linear, LOG
Working temp. :
:
:
:
Dimensions
Package size
Weight (G.W.)
5-Year
Warranty
110
86
122
110
www.ltech-led.com
Technical specs
Model
Input signal
Input voltage
Current load
:
:
Grey level:
Protection:
:
:
Output power:
DMX interfaces:
Control modes:
Dimming curves:
Product size
Unit: mm
E500585

M
<
<
www.ltech-led.com
3
Main component description
OLED display
Power
indicator
Signal
indicator
OLED display interface
Main page
1. DMX address
settings
DMX: Hz: High
Mode: RGB 8bit
Curve: Standard
Dim: Smo TOOL&v
001
RJ455-pin XLR
DMX/RDM
input & output
DMX/RDM
input & output
12-24Vdc
Power input
Green terminals
LED lamp connection
Press "M" key, switch entries.
Press "∧" or “∨" key, parameter adjustment.
Long press “M” key, back to main page.
Exit: back to previous page.
Press “∧" or “∨" key to set DMX address.
Range: 001~512

4
DMX: 001 Hz:
Mode: RGB 8bit
Curve: Standard
Dim: Smo TOOL&v
High
DMX: 001 Hz: High
Mode: RGB
Curve: Standard
Dim: Smo TOOL&v
8bit
DMX: 001 Hz: High
Mode: RGB 8bit
Curve:
Dim: Smo TOOL&v
Standard
DMX: 001 Hz: High
Mode: RGB 8bit
Curve: Standard
TOOL&v Dim: Smo
DMX: 001 Hz: High
Mode: 8bit
Curve: Standard
Dim: Smo TOOL&v
RGB
www.ltech-led.com
2. PWM
frequency
Press “∧" or “∨" key to choose.
Std (standard)
High
Mid (middle)
Low
Option :
Smooth and delicate,
human eye is comfortable.
It is recommended to
use standard.
3. Modes Press “∧" or “∨" key to choose.
Available: DIM / CT / CT2 / RGB / RGBW / RGBWY
4. Grey scale
5. Dimming
curves
6. Enhance
dimming
Press “∧" or “∨" key to choose.
Available : 8bit
16bit (choose it if the master
controller supports this function)
Press “∧" or “∨" key to choose.
Available :
Linear
Log
0.1~9.9
Standard
It is recommended to use standard,
0.1-9.9 is for special requirements.
Press “∧" or “∨" key to choose.
Available :
Smo (smooth)
Std (standard)
Smo: This option with smooth processing, realizes
flicker-free dimming and smooth dynamic effects.
It is recommended to use standard.
No flicker in
video camera.

5
Screen: ON+Addr
Contrast: 40%
Beep: ON
EXIT&v
TEST&v
001
DMX: 001 Hz: High
Mode: RGBW 8bit
Curve: Standard
Dim: Smo TOOL&v
CH1: 255 CH2: 255
CH3: 255 CH4: 255
CH5: 255 ALL: 255
EXIT &V
DMX: 001 Hz: High
Mode: RGBW 8bit
Curve: Standard
Dim: Smo TOOL&v
www.ltech-led.com
7. Tool
Press “∧" or “∨"
key to enter submenu
Test Press “∧" or “∨"
key to enter
submenu of test.
Fast self-testing function: press “ or " keys
simultaneously for 2-3 seconds under any page,
decoder will enter self-testing function.
∧"∨"
Screensaver open and display address
without operating in two minutes.
Screen: ON+Addr
Screensaver open and black
without operating in two minutes..
Screen: ON+black
Screensaver not enable.
Screen: OFF
Brightness setting
(range: 0~255)
Press"∨" to exit

V+
V+
V+
V+
V+
V+
V+
V+
V+
V+
1
1
1
1
1
2
2
2
2
2
3
3
3
3
3
4
4
4
4
4
5
5
5
5
5
6
LED LED
LT-905-OLED LT-905-OLED
www.ltech-led.com
Wiring diagram
1. Connecting LED lights:
DMX/RDM signal DMX/RDM signal DMX/RDM signalDMX/RDM signal
12-24Vdc 12-24Vdc
LED
driver LED
driver LED driver
Output port
(Wiring method as follow)
Dimming
mode
RGB
mode
RGBWY
mode
RGBW
mode
CT
mode
Dimming LEDs
CT/CT2 LEDs
RGB LEDs RGBW LEDs
RGBWY LEDs

1
3
2
PUSH
1
3
2
PUSH
LT-905-OLED LT-905-OLED LT-905-OLED
7
www.ltech-led.com
2. DMX console onnectionc :
LT-905-OLED is equipped with 2 kinds of DMX
terminals for users’ selection. The following
diagram takes 5-pin XLR as an example,
same connecting method for RJ45.
DMX
console
DMX signal
DMX signal DMX signal
An amplifier is needed if more than 32 decoders are connected
, signal amplification should not be more than 5 times continuously.
or use overlong signal
line
If the recoil effect occurs because of longer signal line or bad line quality, please try
to connect 0.25W 90-120Ω terminal resistor at the end of each line.
12-24Vdc 12-24Vdc 12-24Vdc
*
*
GND
DATA+
DATA-
Resistor
terminal

LT-905-OLED
LT-905-OLED
LT-905-OLED
LT-905-OLED
LT-905-OLED
LT-905-OLED
8
www.ltech-led.com
3. The connection diagram of 2 kinds of DMX/RDM terminals:
Resistor
terminal
5-pin XLR connected in parallel
Vent
Resistor
terminal
*Installation attentions: Please reserve enough ventilation distance between decoders (>20mm),
be sure not to block the vent, or it will affect lifetime of decoder for .poor heat dissipation
RJ45 connected in parallel
Installation distance > 20mm
These 2 terminals can be connected in a mixed way.

9
www.ltech-led.com
Address setting table
Mode
Mode
Resolution
Resolution
Address quantity
Address quantity
Channel
Channel
DIM
DIM
CT/CT2 RGB
RGB
RGBW
RGBW
RGBWY
1
2
2
4
3
6
4
8
8bit
16bit
8bit
16bit
8bit
16bit
8bit
16bit
1
1
2
2
3
3
4
4
5
5
001
001
002 001 002 001 002 001 002
001
002
003
004 003 004 003 004
005
006 005 006
007
008
007
008
005
006
005
006
003
004
003
004
001
002
001
002
001
002
001
002
001 001 001
001 002 002 002
001 001 003 003
001 002 003 004
001 002 003 004
*
When you select CT2, the DMX address represents brightness ,
color temperature and constant power output respectively.
CT/CT2 RGBWY
5
10
8bit
16bit
001
002
003
004
005
006
007
008
009
010
001
002
003
004
005

10
Work with RDM editor
LT-905-OLED can work with LTECH RDM editor (Model: WiFi-RDM01) to realize changing
the parameters by long-range setting, wiring diagram as below:
5-24Vdc
Power
input
WIFI-RDM01
LT-9 0 5 - OLEDLT-9 0 5 -OLEDLT-9 0 5 - OLED
LED
driver LED driver LED driver LED driver
LT-9 0 5 -OLED
…
…
LEDLEDLED LED
www.ltech-led.com

11
RDM editor App interface instruction
www.ltech-led.com
Update Time: 15/01/2021_A5
Download the App, setting the LT-905-OLED parameters (frequency, bit, curve, modes,
dimming range, screensaver, etc.) after well connecting the RDM editor, more details,
please check the manual of WiFi-RDM01.
Well installation of products first, then working with WiFi -RDM01 to realize setting
parameters and firmware upgrade by App.
ac
b
d
a: Click”Add”, edit the address in corresponding box.
b: Click”ID”, get more product details.
c: Click” ”, enter edited interface.
d: Click”No.”, issue the recognizing command.
Supporting WiFi-RDM01 upgrade
and DMX driver upgrade.
WiFi-RDM01
upgrade
DMX device
upgrade
This manual is subject to changes without further notice.
Product functions depend on the goods.
Please feel free to contact our official distributors if you have any question.
