Ltech LT-DMX-1809 User manual

1
LT- 1809 DMX512 Decoder Manual LT- 1809 DMX512 Decoder Manual
LT-DMX-1809
DMX-SPI Signal Decoder Manual
LT- 1809
1. Product parameter
Input voltage
Input Signal
Output signal
Decoding Channels
Output Grey Scale
DMX512 Connector
Product Dimension
Package Size
Working temperature
Weight (G.W)
DC12V~DC24V
DMX512/1990
SPI(compatible with TM1803,TM1804,TM1809,
TM1812 LED driving IC)
512 channels/unit
256 grey scales
Standard XLR-3 Connector
L125×W52×H40mm
L135×W70×H50mm
-30 ~65
℃ ℃
300g
LT-DMX-1809 DMX decoder works to convert universal DMX512 signal to SPI(TTL)
signal. It can control LED lights based on Tm1803, TM1804, Tm1809, TM1812 via DMX
console.
Tm1803, TM1804, TM1809 and TM1812 are the IC with grey scale processor. It can
support 256 scale levels and only need one signal cable, which convenient for design and
installation for the LED lights. These 4 chips are widely used in LED digital lights among
LED dot light, SMD strip, LED Fence tubes, LED wall light, LED pixel screen, LED Hi-
Power spotlight , flood light, etc.
The kernel of our LED controller adopt MCU from ATMEL to ensure the LT-1809 DMX
decoder runs steady.
RoHS
COM PLIAN T
warranty
3 years
ISO9 001:2008
ZHUHAI LTECH ELECTRONIC TECHNOLOGY CO., LTD. WWW.LTECHONLINE.COM
[e-mail]
Tel: [phone] Fax: [phone]
LTECH LTECH
2
The Port of connecting
Power supply & LED light
2. Configuration Diagram
1 2 3 4 5 6 7 8 9 10
ONDIP
DMX signal input port
DATA DC+
MODEL : LT-1809
DMX512 DECODER
DC5V-DC24V
512 CHANNEL
GND
3. Output Port definition
No. Silk screen Function
1
2
3
4
5
6
Power supply
input port
Output port
Connect LED
LED power supply input anode
LED power supply input cathode
Data cable
Ground wire (power supply cathode), 2 GND ports,
Only connecting 1 GND is OK.
DC+
DC-
DATA
GND
DC+
GND
Attention: The power supply DC+ cannot connect to data cable. Otherwise it will
damage the decoder and the LED’s driving IC.
4. How to set DMX address via dip switch
Figure 1
1 2 3 4 5 6 7 8 9 10
ON
0
1
OFF
ON
1. Set DMX512 original address
123567810
4
001 002 004 008 016 032 064 128 256
1.This decoder adopts Dip switch to set the address. The Dip switches from 1 to 9 are a kind of binary
value coding switches which used for setting DMX512 initial address code, The 1st is the lowest one, The
9th is the highest one. Can set 511 addresses totally.
2.DMX512 initial address is the total amount of the Dip switch 1-9, down dip switch to “ON” position, User
can get its place value, Up dip switch to “OFF” position, Its place value is 0.
Instructions
DIP
Address
LED power supply output anode
GND
M1804, TM1809 and TM1812IC can choose high or low speed when used in LED
design circuit. TM1803 only can choose low speed. Designed in low speed will get
high PWM frequency and designed in high speed can control more LED lights. The
high or low speed choosing of the decoder needs to match the light’s design gears.
Otherwise the LED light can not work. The general LED lights are designed in low-
speed mainly.
high/
low speed
9
The Decoder enter into DMX control mode automatically., when receiving DMX signal.
Like figure 1: Fun=off is high speed(upward), FUN=ON is low speed (downward)
4
1 2 3 4 5 6 7 8 9 10
ON
0
1
OFF
ON
Figure 2

3
2. T esting function:
1 2 3 4 5 6 7 8 9 10
ON
0
1
OFF
ON
The DMX decoder will be entered into self control mode automatically without DMX signal input
DIP1 DIP2 DIP3 DIP4 DIP5 DIP6 DIP7 DIP8 DIP9
Red Green Blue Yellow Purple Cyan White
Jumping
Gradual change
th th
DIP8/DIP9 at “ON” (the 8 /9 DIP swithch is dowanward) is changing mode.DIP switch 1-7 has 8 levels speed changing,
DIP 7 is the fastest speed.DIP switch 1-7 at “OFF” is speed 0
DIP1 DIP2 DIP3 DIP4 DIP5 DIP6
Speed 1
1 2 3 4 5 6 7 8 9 10
ON
0
1
OFF
ON
Speed 2 Speed 3 Speed 4 Speed 5 Speed 6 Speed 7
Like figure 4
it is color fade effect of testing function, the speed is 7.
, if several DIP switch at “ON”, it is subject to the maximum valuei.f all DIP switch at “ON”,
DIP7
Figure 3 Figure 4
DC5V -24V
DC5V -24V
1
1
12
2
23
3
34
4
45
5
56
6
67
7
78
8
89
9
910
10
10
ON
ON
ON
DMX512 OUT
DMX512 OUT
DMX512 OUT
DMX512 IN
DMX512 IN
DMX512 IN
DATA
CLK
DC5V -24V
GND
LPD 180 9
DC+
MODEL: LT-DMX-1809
512 CHANNEL
MODEL: LT-DMX-1809
512 CHANNEL MODEL: LT-DMX-1809
512 CHANNEL
LPD 180 9 LPD 18 09
DMX512
PC SOFTWA RE
IP- DMX
Data C onver tor
DMX5 12
CONT ROL SYSTE M
DMX Data Input
Pow er adap ter
CONN EC T POWER
SUPP LI ER
Sig na l Out put
Inpu t Powe r
pixel lamp
OutputInputOutput InputOutput
CONN EC T POWER
SUPP LI ER
CONN EC T POWER
SUPP LI ER
pixel lamp pixel lamp
Pow er adap ter
Sig na l Out put
Inpu t Powe r
Pow er adap ter
Sig na l Out put
Inpu t Powe r
5. Configuration Diagram
1. LED point source conjunction diagram
DATA
CLK
GND
DC+
DATA
CLK
GND
DC+
For example, Like figure 2, Set initial address to 37, Set the “1st”,”3rd “,”6th”, bit of the DIP switch
down to “1” The rest to “0” as the below figure, In this connection, the summation from 1 to 9 is 1+4+32,
Namely , The DMX512 initial address code is 37.
4
2. LED wall washer conjunction diagram
DC5V -24V
DC5V -24V
1
1
12
2
23
3
34
4
45
5
56
6
67
7
78
8
89
9
910
10
10
ON
ON
ON
DMX512 OUT
DMX512 OUT
DMX512 OUT
DMX512 IN
DMX512 IN
DMX512 IN
DATA
CLK
DC5V -24V
GND
LPD 180 9
IP- DM X
Hi- power w all was her
DC+
MODEL: LT-DMX-1809
360 CHANNEL
MODEL: LT-DMX-1809
360 CHANNEL MODEL: LT-DMX-1809
360 CHANNEL
LPD 180 9 LPD 18 09
DMX Data Input
DMX5 12
PC SOF TWA RE
DMX5 12
CONT ROL SYSTE M
Data C onver tor
Pow er adap ter
CONN EC T POWER
SUPP LI ER
Sig na l Out put
Inpu t Powe r
Pow er adap ter
Sig na l Out put
Inpu t Powe r
Sig na l Out put
Inpu t Powe r
Pow er adap ter
CONN EC T POWER
SUPP LI ER
CONN EC T POWER
SUPP LI ER
Hi- power w all was her Hi- power w all was her Hi- power w all was her Hi- power w all was her Hi- power w all was her
Output Input Output Input Output
DATA
CLK
GND
DC+
DATA
CLK
GND
DC+
DATA
CLK
GND
DC+
ZHUHAI LTECH ELECTRONIC TECHNOLOGY CO., LTD. WWW.LTECHONLINE.COM
[e-mail]
Tel: [phone] Fax: [phone]
LT- 1809 DMX512 Decoder Manual LT- 1809 DMX512 Decoder Manual
LTECH LTECH
6. Attention
7. Warranty Agreement
1. The product shall be installed and serviced by a qualified person.
2. This product is non-waterproof. Please avoid the sun and rain. When installed outdoors please
ensure it is mounted in a water proof enclosure.
3. Good heat dissipation will prolong the working life of the controller. Please ensure good ventilation.
4. Please check if the output voltage of any LED power supplies used comply with the working voltage of the product.
5. Please ensure that adequate sized cable is used from the controller to the LED lights to carry the current.
Please also ensure that the cable is secured tightly in the connector to avoid the accidents due to overheat and
poor contact on the wire.
6. Ensure all wire connections and polarities are correct before applying power to avoid any damages to the LED lights.
7. If a fault occurs please return the product to your supplier. Do not attempt to fix this product by yourself.
1. We provide lifelong technical assistance with this product:
A 3 year warranty is given from the date of purchase. The warranty is for free repair or replacement and covers
manufacturing faults only.
For faults beyond the 3 year warranty we reserve the right to charge for time and parts.
2. Warranty exclusions below:
Any man-made damages caused from improper operation, or connecting to excess voltage and overloading.
The product appears to have excessive physical damage.
Damage due to natural disasters and force majeure.
Warranty label, fragile label and unique barcode label have been damaged.
The product has been replaced by a brand new product.
3. Repair or replacement as provided under this warranty is the exclusive remedy to the customer.
Ltech shall not be liable for any incidental or consequential damages for breach of any stipulation in this warranty.
4. Any amendment or adjustment to this warranty must be approved in writing by Ltech only.
★ This manual only applies to this model. Ltech reserves the right to make changes without prior notice.
