Ltech LT-840-700 User manual

Input Signal:
Input Voltage:
Output Voltage:
Current Load:
Output Power:
DMX512 Socket:
DMX512, RDM
12~48Vdc
3-46Vdc
CC 700mA×4CH
(2.1W~32.2W)×4CH Max. 128.8W
3-pin XLR, RJ45, Green Terminal
1
LT-840-700
LT-840-700
DMX/RDM 4CH CC DECODER
LT-840 700 DMX/RDM 4CH CC Decoder-
LT-840-700 w
0-100% dimming or different lighting effect; workable with
single color, dual color, RGB or RGBW/Y LED lamps.
ith the standard RDM remote device management protocol, supports DMX512 signal
bi-directional communication, achieves remote management of reading and writing DMX address
(DMX master controller must recognize the RDM protocol). Equipped with DMX standard 3-pin XLR,
RJ45, green terminal interface. Realize
40mm
78mm
156mm
146mm
2
4.3 DMX Dimming Instruction:
CH1 0-255
CH2 0-255
CH3 0-255
CH4 0-255
Each LT-840 700 DMX decoder occupied 4 DMX
addresses when connecting the DMX console.
-
PWM 0-100% (LED R)
PWM LED G)0-100% (
PWM LED B)0-100% (
PWM LED W/Y)0-100% (
CH1
CH2
CH3
CH4
DMX Console DMX Decoder
RDM Mode: The dip switch 1-10 are OFF.
FUN=ON (the 10th dip switch=ON)
Self-testing Mode:
FUN=OFF (the 10th dip switch=OFF)
DMX Mode:
Setting DMX addresses with dip switch 1-9
FUN=OFF (the 10th dip switch ) Mode=OFF DMX
4.1 How to set DMX address via dip switch:
E.g.1: Set Initial Address To 32. E.g.2: Set Initial Address To 37. E.g.3: Set Initial Address To 178.
001+004+032=37 002+016+032+128=178
4.2 Self-testing Mode:
DMX address value = the total value of (1-9), to get the place value when in “ON” position,
otherwise will be 0.
e.g., the defaulted initial address is 1, please find
their corresponding relationships in the form.
LT-840 700 DMX/RDM 4CH CC Decoder-
FUN=ON (the 10th dip switch = ON) Self-testing Mode
1=on 4=on 7=on 8=on 9=on2=on 5=on 3=on 6=on
Self-test
Function
1-9=off
Dip Switch
Static
Black Static Red
Static
Red
Static
Green
Static
Green
Static
Blue
Static
Blue
Static
Yellow
Static
Yellow
Static
Purple
Static
Purple
Static
Cyan
Static
Cyan
Static
White
Static
White
7 Colors
Jumping
7 Colors
Jumping
7 Colors
Smooth
7 Colors
Smooth
[Attn] When several dip switches are on, subjected to the highest switch value.
As the figure above shows, the effect will be 7 colors smooth at 7 speed level.
For changing effects (Dip Switch 8 9=on): /
DIP switch 1-7 is used to realize 7 speed
levels. (7=on, the fastest level)
OFF
ON
12345678910
1. Product Parameter:
2. Product Size:
3. Configuration Diagram:
Dimming Range:
Protection:
Working Temperature:
Dimensions:
Package Size:
Weight (G.W.):
0~100%
Short circuit / Over current
-30℃~65℃
L156×W78×H40(mm)
L180×W82×H48(mm)
445g
Dip Switch Operation:
4.
Power Input Socket
Address
Dip Switch
Green Terminal
(with amplifier function) 3-pin XLR RJ45
LED Lamps
Connection Socket

3
LT-840-700 is equipped with 3 types DMX terminals for users’ selection. The
diagram takes 3-pin XLR terminal as an example, same connecting method
for the rest two: green terminal(with amplifier function) & RJ45 terminal.
5.1 Decoder can be connected to a variety of standard DMX512 devices:
LT-840-700 works on the technique of voltage reduction the voltage of power
supply should be no less than the total voltage of the connected lamps.
,
The LED quantity at each channel can be different; LT-840-700 could auto check
and output a proper voltage to each channel according to its LED quantities.
*
An amplifier is needed when more than 32 decoders are connected, signal amplification should not be more than
5 times continuously.
*
terminal resistor at the end of each line.
If the recoil effect occurs because of longer signal line or bad line quality, please try to connect 0.25W 90-120Ω
4
5.2 The connection diagram of three DMX terminals:
5.3 The connection diagram of :AMP signal amplifier terminal
*
when too many DMX decoder are connected or signal line is too long, signal
amplification should be no more than 5 times continuously.
AMP interface can be used for signal amplification
LT-840 700 DMX/RDM 4CH CC Decoder- LT-840 700 DMX/RDM 4CH CC Decoder-
6. Attention:
7. Warranty Agreement:
6.1 The product shall be installed and serviced by the qualified person.
6.2 This product is non-waterproof. Please avoid the sun and rain. When installed outdoors please ensure
it is mounted in a water proof enclosure.
6.3 Good heat dissipation will prolong the working life of the controller. Please ensure good ventilation.
6.4 Please check if the output voltage of the LED power supply used comply with the working voltage of
the product.
6.5 Please ensure that adequate sized cable is used from the controller to the LED lights to carry the current.
Please also ensure that the cable is secured tightly in the connector.
6.6 Ensure all wire connections and polarities are correct before applying power to avoid any damages to
the LED lights.
6.7 If a fault occurs, please return the product to your supplier. Do not attempt to fix this product by yourself.
7.1 We provide lifelong technical assistance with this product:
A 5-year warranty is given from the date of purchase. The warranty is for free repair or replacement
if cover manufacturing faults only.
For faults beyond the 5-year warranty, we reserve the right to charge for time and parts.
7.2 Warranty exclusions below:
Any man-made damages caused from improper operation, or connecting to excess voltage and
overloading.
The product appears to have excessive physical damage.
Damage due to natural disasters and force majeure.
Warranty label, fragile label and unique barcode label have been damaged.
The product has been replaced by a brand new product.
7.3
7.4 Any amendment or adjustment to this warranty must be approved in writing by our company only.
★ This manual only applies to this model. reserve the right to make changes without We prior notice.
Repair or replacement as provided under this warranty is the exclusive remedy to the customer.
We shall not be liable for any incidental or consequential damages for breach of any stipulation
in this warranty.
5. Wiring Diagram:
Update Time: 2017.11.09_A3
www.ltech-led.com
3-pin XLR Connected in Parallel
Green Terminal Connected in Parallel
RJ45 Connected in Parallel
These 3 terminals can be connected
in a mixed way.
Terminal resistor
