Ltech Artnet-DMX-8 Operator's manual

Artnet-DMX converter is the Ethernet Control System based on the Artnet protocol, used to convert
the Artnet network date package into DMX512 date, adopting high-speed ARM processor, stable and
reliable working. Following Art-net standard protocol, it supports RJ45 network interface and standard
DMX512 output interface.
Artnet-DMX-8
Artnet-DMX Converter
1
Artnet-DMX-8 Artnet-DMX Converter
DMX512
5-24VD
(with a power adaptor)
C
L482.6×W200×H44mm
L550×W265×H100mm
2200g
-20 ~65℃ ℃
Working temperature:
Artnet
8×512 channels
warranty
5 years
Artnet-DMX-8
Output signal:
Power input:
Dimension:
Package Size:
Weight (G.W):
Input signal:
DMX channels:
1. Technical Specs
It is compatible with all the effects lighting control software which support Art-net protocol, widely used
in the LED dot matrix and the stage lighting control network in needing lots of DMX-512 data,
especially for TV station recorded scene, stage performances, entertainment and so on.
Artnet-DMX-8 provides 8 standard DMX512 data output port, total output 8×512 data.
Artnet-DMX-8 use standard 1U(19") chassis architecture, convenient installation in professional cabinet,
easily operation setting with LCD display.
RJ45
Network Connection:
XLR-3
IP: Indoor use only
Isolation Ethernet Port: Total Isolation
Isolation Power Input: Total Isolation
Current: 30mA@12VDC
DMX Output Connection:
2. Performance Features
2.1. Based on Artnet protocol network data communication, accept network DMX data.
2.2 Two different IP address for each controller
2.3. Send packets to the network by broadcast mode
3. Product dimension:
4. Interface instruction:
2
Artnet-DMX-8 Artnet-DMX Converter
2.5. Standard 1U(19" ) chassis architecture, convenient installation in the standard cabinet.
2.6. With LCD screen display, convenient operation intuitive settings
2.7. Provides 8 standard DMX512 data output port,output 8×512 data in total.
2.8. Set different network segments to avoid multiple sets Artnet data interference.
2.9. Compatible with the light software based on Artnet Protocol, control stage lighting and LED
lighting simultaneously.
2.10 Connect up to 256 DMX Universes to one network.
2.11 10BaseT Ethernet Port.
2.12 Data activity indicators
2.13 Configurable DMX output refresh rates.
2.4. Manage Artnet on broadcast mode or unicast mode
Back
Other Functions of Button:
Press the menu button in the main interface to enter the menu interface(see the below table).
Press the +/- button / to move up and down the menu and set the relative parameter
through press the setting button . Press the +/- button / can increase or decrease the
parameter. Press the setting button to save the setting when finished and press the menu button
to quit the setting status.
Button Operating Instructions:
In the main interface, long press the setting button to enter test mode (send the
dark, light and highlighting skipping data changing effect to the 8 ports). Press the menu button
or setting button to quit the test mode. In the main interface, long press the +/- button /
at the same time to restore factory settings.
www.ltechonline.com

5. Conjunction Diagram:
3
Artnet-DMX-8 Artnet-DMX Converter
One IP manage 1 Subnet and 4 Universe addresses, that is one IP manage 4 output ports
(see the below table)
The calculation method of DMX group address: Group address=Subnet*16 + Universe:
is Address=2*16+8=40
For example: Subnet for Node 1 is 2, Outlet: Univ for 2 is 8, then Outlet: the group address of 2
IP Subnet(0~15) Universe(0~15)
Remark: Two IP address can not be set to the same value to avoid the controller is not working properly
caused by IP conflict.
4
Artnet-DMX-8 Artnet-DMX Converter
7. Warranty Agreement:
7.1 We provide lifelong technical assistance with this product:
★This manual only applies to this model. We reserve the right to make changes without prior notice.
7.4 Any amendment or adjustment to this warranty must be approved in writing by our company
only.
7.3 Repair or replacement as provided under this warranty is the exclusive remedy to the
customer. We shall not be liable for any incidental or consequential damages for breach
of any stipulation in this warranty.
7.2 Warranty exclusions below:
For faults beyond the 5-year warranty, we reserve the right to charge for time and parts.
A 5-year warranty is given from the date of purchase. The warranty is for free repair or
replacement if cover manufacturing faults only.
Any man-made damages caused from improper operation, or connecting to excess voltage
and overloading.
The product appears to have excessive physical damage.
Damage due to natural disasters and force majeure.
Warranty label, fragile label and unique barcode label have been damaged.
The product has been replaced by a brand new product.
6. Attention:
6.1 The product shall be installed and serviced by the qualified person.
6.7 If a fault occurs please return the product to your supplier. Do not attempt to fix this product
by yourself.
6.6 Ensure all wire connections and polarities are correct before applying power to avoid any
damages to the LED lights.
6.5 Please ensure that adequate sized cable is used from the controller to the LED lights to carry
the current. Please also ensure that the cable is secured tightly in the connector.
6.4 Please check if the output voltage of the LED power supply used comply with the working
voltage of the product.
6.3 Good heat dissipation will prolong the working life of the controller. Please ensure good
ventilation.
6.2 This product is non-waterproof. Please avoid the sun and rain. When installed outdoors, please
ensure it is mounted in a water proof enclosure.
Update Time: 2014.12.30
