LUBE ACM-II User manual

L-0356E
Motor driven gear pump
ACM-Ⅱ
INSTRUCTION
MANUAL
      LUBE CORPORATION
・
For your safety, read and understand this manual
thoroughly before handling the pump.
・Keep this manual at a desi
gnated place for easy
access at all times.

1
        Introduction

■System application
The ACM-Ⅱcontinuous delivery motor driven gear pump delivers a
relatively small amount of oil for lubrication from the distributor to
the lubrication points.
Do not use this system for any other purposes.
■Marks used in manual
In this manual, safety precautions are provided using the marks
below in order to prevent accidents which might cause injuries to
human bodies. Be sure to carefully read these safety precautions to
understand the contents thoroughly before handling the pump.

                                                                                                                    
In addition to the above, the marks below will also appear in this
manual. Please read the following explanation in order to handle
the pump correctly.
     Indicates referential information or points to
   
     which special attention should be paid while
handling the pump. If ignored, the pump and/or
the machine could be damaged.
Indicates referential information or points
which are helpful for handling the pump.
      Indicates a reference clause.
Indicates a potentially hazardous
situation which, if ignored, could
result in death or serious injury.
Indicates a potentially hazardous
situation which, if ignored, may result
in minor or moderate injury.
ＷＡＲＮＩＮＧ
ＣＡＵＴＩＯＮ

2
■Questions/Contacts
If any question or doubt arises concerning the contents of
this manual, contact following:
■Details of contents
Details of all illustrations and specifications in this manual
are subject to change without prior notice for improvement
and development of the pump.
■Resale or leasing
At the time of resale, leasing out or lending out the pump to
the third party, make sure to include with the pump all the
manuals and any other documents found supplied at the
time of initial installation.
■Disposal of pump/Oil
Make sure to dispose pump or oil as designated by national
laws and/or local regulations.
■Japan
LUBE Corporation Head Office
3-30-16(Horizon 1), Nishi Waseda, Shinjuku-ku, Tokyo,
169-0051 Japan
TEL:[phone] FAX:[phone]
■China
LUBE LUBRICATING SYSTEM(SHANG HAI)CO.,LTD
C, 3F, 88 Taigu Road, Waigaoqiao Free Trade Zone,
Shanghai
TEL: [phone] FAX: [phone]
■U.S.A
LUBE USA , Inc.
781 Congaree Road,Greenville,S.C.29607
TEL:[phone] FAX:[phone]

3
       Table of contents
       
Introduction ...................................................................................................1
Table of contents............................................................................................3
1. Safety precautions ..................................................................................4
1-1 Basic safety precautions.....................................................................4
1-2 Labels.................................................................................................4
1-2-1 Type of labels................................................................................5
1-2-2 Location of labels..........................................................................6
2. Specification and outline.........................................................................7
2-1 Specifications .....................................................................................7
2-2 Name of each component....................................................................7
3. Installation .............................................................................................8
3-1 Environmental requirement...............................................................8
3-2 Mounting unit ....................................................................................8
3-3 Wiring ................................................................................................9
3-4 Tubing connection............................................................................10
3-5 Oil volume adjusting valve...............................................................10
4. Lubricating oil and refilling..................................................................11
4-1 Lubricating oil to be used.................................................................11
4-2 Refilling lubrication oil.....................................................................11
5. Maintenance .........................................................................................12
5-1 Suction filter ....................................................................................12
5-2 Troubleshooting ...............................................................................13
Appendix．Oil contamination : Causes and measures .............................15

4
     1. Safety precautions
           
1-1Basic safety precautions

1-2Labels
The following labels are affixed on the pump.
If any label gets damaged or becomes illegible,
contact LUBE immediately. A new one will be
supplied at your own cost.
・Carefully read this manual to understand the
contents before handling the pump.
・Keep this manual at a designated place for easy
access at all times.
・This pump is handled by only personnel who have
the knowledge and skill of its installation and
adjustment.
・Never modify or change this pump without prior
permission of LUBE.
・Strictly observe the instructions on the labels
affixed to the pump.
ＷＡＲＮＩＮＧ
ＣＡＵＴＩＯＮ

5
1-2-1Types of labels
①Pump label
100V                 200V
②Terminal connection
100V             200V
③Electricity warning sign
ＶＯＬＴＡＧＥ １００Ｖ
ＦＲＥＱＵＥＮＣＹ ５０Ｈｚ ６０Ｈｚ
ＲＡＴＥＤ ＯＵＴＰＵＴ ２５Ｗ
ＡＭＰＥＲＥ ０．５１Ａ ０．５２Ａ
ＭＡＤＥ ＩＮ ＪＡＰＡＮ
Ｉｎｓ．Ｃｌａｓｓ Ｂ
ＣＯＲＰＯＲＡＴＩＯＮ
ＤＩＲＥＣＴＩＯＮ ＯＦ ＲＯＴＡＴＩＯＮ
ＮＯ ＲＥＶＥＲＳＥ ＲＯＴＡＴＩＯＮ
Ｉｎｓ．Ｃｌａｓｓ Ｂ
ＭＡＤＥ ＩＮ ＪＡＰＡＮ
ＣＯＲＰＯＲＡＴＩＯＮ
ＤＩＲＥＣＴＩＯＮ ＯＦ ＲＯＴＡＴＩＯＮ
ＮＯ ＲＥＶＥＲＳＥ ＲＯＴＡＴＩＯＮ
ＶＯＬＴＡＧＥ
ＦＲＥＱＵＥＮＣＹ
ＲＡＴＥＤ ＯＵＴＰＵＴ
２５Ｗ
ＡＭＰＥＲＥ
３φ ２２０Ｖ３φ ２００Ｖ ３φ ２３０Ｖ
５０Ｈｚ ６０Ｈｚ ６０Ｈｚ ６０Ｈｚ
０．２３Ａ ０．２１Ａ ０．２１Ａ ０．２２Ａ

6
1-2-2Location of labels

 
                    


①
②Inside
③Outside

7
  2. Specifications and outline
            
2-1Specification

2-2Name of each component






 

Item Specification
    Code No. 102484 102486
Power supply AC100 V,φ1,4P AC200 V,φ3,4P
Rated voltage AC100 V,φ1,4PAC200 V,φ3,4P
Frequency 50/60 Hz50/60 Hz
Rated amperage 0.51/0.52A0.23/0.21A
Rated output 25W
Ins. Class B
Direction of rotation Counter-clockwise from motor upper side
Motor

Condenser 8μF ――
Discharge volume 60 m /min
Discharge pressure 0.8 MPa(Relief valve set pressure)
Pump

Working viscosity range
32〜1300 mm2/s
Oil volume adjusting valve
Terminal box
Wiring port:φ6〜12
Terminal
Discharge port
(M8×1)
Motor
Suction filter
Pump flange
Relief valve
Oil refilling port

8
     3. Installation
            
3-1Environmental requirement

Be sure to this pump in the following environment.
・Ambient temperature：0 ~ +40℃
・Humidity    ：35 ~ 85%RH
3-2Mounting unit

Make sure to fix the pump firmly.
Insufficient mounting of the pump could
fall itself and cause injury.
Mount and fix the pump firmly using four (4) M6
bolts.
LUBE recommends anti-vibration rubber
to be applied when the pump is exposed to
vibration.
Be sure to allow necessary space around the
pump for operation and maintenance.
ＣＡＵＴＩＯＮ

9
3-3Wiring
 Rotatory direction of a motor is only constant
direction. If the motor is reversely rotated, it
becomes an unexpected accident.
Please wiring refer to terminal connection.
Detailed figure of the terminal box








Figure 1








Figure 2

Applicable cable diameter：φ6〜12mm
Applicable lead wire ：AWG20〜12(0.5〜3.5 mm2)
Stripping length ：8mm
※In the case of stick terminal use
Conformity stick terminal : For 0.75〜2.5 mm2
Only qualified personnel electrical work can
connect wiring.
ＷＡＲＮＩＮＧ
Terminal cover
installation screw
(With rubber seal and metal washer)
Terminal cover
Cable gland
Cable clamp
Terminal block
Gasket
Gasket
Cable clamp
Terminal block
Terminal cover
Cable gland
Rubber packing
Cable

10
Use a 8μF condenser for 100V AC motor.
If the wire to the outside touches the outside of the machine
or other objects or if it comes in contact with the hand of the
operator, use an insulated wire.
3-4Tubing connection


Connect tubing to the machine to the discharge port
(M8×1).
Use tubing good for the pressure 1.0 MPa or
higher.
Clamping torque please refer to “Tightening
level for connecting section”
After connection, make sure there is no oil leakage from the
joint.
 Discharge pressure of a pump is adjusted 0.8
MPa at a relief valve.
Please do not change discharge pressure.
3-5Oil volume adjusting valve
The oil amount adjustment screw is set to the full discharge
position (maximum discharge amount) when delivered from
the factory.
Adjust the oil amount as follows.
1) Loosen the cap.
2) Loosen the needle valve by turning it counterclockwise
using a flathead screwdriver to determine the oil amount.
3) Fix the cap.
Ｚ２ Ｕ２ Ｕ１
ＡＣ１００Ｖ，φ１
Ｉｎｐｕｔ
８μＦ
Ｃ
Ｕ Ｖ Ｗ
Ｍ４
Ｓｃｒｅｗ
ＡＣ２００Ｖ，φ３
Ｉｎｐｕｔ
Ｒ ＴＳ
Earth
Earth

11
  4. Lubricating oil and refilling
     
4-1 Lubricating oil to be used
Use industrial lubricating oil in the range from 32 to
1300 mm2/s of ISO viscosity.
Do not use any lubricating oil other than that
which has been recommended.
Use lubricating oil of the same grade made by the
same manufacturer.


4-2 Refilling lubrication oil
When the oil in the tank reaches the Ｌlevel on the oil
level gauge provided, refill the tank with more oil, up to
the Ｈlevel, from the refill port on the pump flange.
      Use new lubricating oil. If lubricating oil contains
any foreign substances, clogging may occur,
causing the pump to stop discharging oil.
Refill it through the refill port that you find above the
pump flange.
Keep checking the oil level gauge provided when refilling
the tank with oil.
If lubricating oil overflows or leaks, wipe off the
overflowing or leaking oil.











12
   5. Maintenance     
5-1 Suction filter
Replace or clean filter once a year.
Before conducting maintenance on the pump, turn
off the power and make sure that the pump is not
operating. Conducting maintenance with the power
turned on will increase the risk of the operator
getting an electric shock or the fingers being
pinched in moving parts of the pump drive unit.
Proper lubrication cannot be expected if the
suction filter is clogged or become dirty because
oil may not sucked well Clogged or dirty suction
filter may cause over load, too.
When oil is reused, remove sediments in the
tank. Otherwise, sediments will flow to the
pump suction opening and may clog the suction
filter.
                
Suction filter



ＷＡＲＮＩＮＧ

13
5-2 Troubleshooting
When troubles occur, take the measures as defined in the chart below.
TroubleCauseMeasures to take
The motor is not runningCheck the wire
connection
Motor is rotating backward
Check the wire
connection
Low oil levelRefill the same oil in use
Refer to
“4. Lubricating oil
and refilling”
Clogged suction filterClean or replace filter, or
change oil to new oil
Refer to
“5-1 Suction filter”

Damage in the tubing
inside the pump (Twisted,
crashed, or disconnected)
Tighten or replace the
connecting parts
No oil discharged
from pump
Viscosity is too high, so
that oil can not be suckedRecheck oil in use and
replace it to proper oil
Refer to
“4. Lubricating oil
and refilling”
No oil discharged from
pump due to any of above
causes
Refer to above measures
Foreign particle(s) at the
ball seating section of
relief valve
Contact LUBE
Pump discharge low
pressure due to relief valve
wrong pressure
setting
Contact LUBE
The relief valve
pressure has been
set before shipment

Pressure in main
tubing is not built
up
Air in the tubing Take off closure plug(s) at
the end and operate
pump and bleed air in
tubing

14
■Tightening level for connecting section

Tightening level Reference torque
(N･m)
OD 4mm nylon pipe
(Valve discharge port &
main pipe)
Turn compression bushing with
hands until it stops and then
tighten it 2/3 turn with a
spanner, etc
3.5
OD 4mm copper tubing
& steel tubing
(Valve discharge port &
main pipe)
Turn compression bushing with
hands until it stops and then
tighten it 2/3 turn with a
spanner, etc
4.1
Taper screw for tubing

Rc1/8
(Junction)
Turn the undercut joint with
hands until it stops and then
tighten it two and a half to
three turns with a spanner, etc
7.1

TroubleCauseMeasures to take
Oil leaking from pump
discharge port or pipe
connection parts on
machine
(Due to looseness or
excessive tightness)
Tighten them with proper
torque or re-pipe them
For proper torque
refer to “Tightening
level for connecting
sections” of the next
page
Pressure in main
tubing is not built
up
Damaged tubingReplace damaged tubing
Air in the system due to
above reasonsRefer to above measures for “Air in the tubing”
Air in the system
Due to low level of oil in
tank, air is introduced into
pump
Refill tank with same or
equivalent oil and then
bleed air

15
Appendix. Oil contamination
      Causes and measures
         
■Causes

Causes for contamination can be divided into two categories.

○Before the completion of installation
  Foreign particles in the tubing or pump tank.
（Manufacturing defects of the assembly parts or
connecting parts and unconformity during construction.）

○During operation
  Foreign particles from outside or generated inside of
the system.
（Condensation of the moisture in the air due to change in
temperature or sludge by oxidation of lubrication oil
itself.）


■Measures

1. Clean the tank and remove the foreign particles.

2.Keep the oil for refilling in the proper place.
 If the system is installed and/or oil is stored outdoors,
proper care must be taken since introduction of dust or
rain into the oil would lead to system malfunction.



