Lucent Technologies PacketStar 20N32 User manual

Doc. No.: 255-700-467
PacketStar®
PSAX 4-Port Voice 2-Wire Office Module
User Guide
Model 20N32
for the PacketStar®PSAX Multiservice Media Gateways
Issue 1, October 2003
System Software Release 9.0.0
Navis®AQueView®EMS Software Release 9.0.0

Copyright © 2003 by Lucent Technologies. All rights reserved.
For trademark, regulatory compliance, and related legal information, see
the "Legal Notices, Safety, and Regulatory Information" section.

PacketStar®PSAX 4-Port Voice 2-Wire Office Module User Guide,Issue1 Release9.0.0
255-700-467 iii
Legal Notices, Safety, and Regulatory
Information
Copyright
Copyright © 2003 by Lucent Technologies. All rights reserved.
This material is protected by the copyright laws of the United States and
other countries. It may not be reproduced, distributed, or altered in any fash-
ion by any entity (either internal or external to Lucent Technologies), except
in accordance with applicable agreements, contracts or licensing, without the
express written consent of the originating organization and the business
management owner of the material.
This document was prepared by the Information Design and Development
Team of Lucent Technologies, PacketStar PSAX products. Officesare located in
Landover, Maryland, USA.
Trademarks
PacketStar, AQueView, Lucent, Lucent Technologies, and the Lucent Technolo-
gies logo are registered trademarks of Lucent Technologies in the USA. Other
product and brand names mentioned in this guide are trademarks or regis-
tered trademarks of their respective owners.
Notices
The information in this document is for informational use only, is subject to
change without notice, and should not be construed as a commitment by
Lucent Technologies, Inc. This document is without warranty of any kind,
either expressed or implied. Lucent Technologies, Inc. assumes no responsi-
bility for any errors, inaccuracies, or omissions. Neither is any liability
assumed for damages resulting from the use of the information or instruc-
tions contained herein. Lucent Technologies, Inc. is not responsible for any
damage or loss to your data or equipment resulting either directly or indi-
rectly from use of this document.
Warranty Information
Software and Hardware Limited Warranties
Lucent Technologies provides a 90-day limited software warranty, and a one-
year limited hardware warranty on this product. Refer to the Software License
and Limited Warranty Agreement and the Lucent Technologies InterNetworking Sys-
tems Global Warranty that accompanied your package for more information.

Legal Notices, Safety, and Regulatory Information
Safety Information
iv 255-700-467
PacketStar®PSAX 4-Port Voice 2-Wire Office Module User Guide, Issue 1 Release 9.0.0
Warranty Warnings
WARNING:
!
When inserting modules into the chassis, slide them gently, not force-
fully. Excessive force may cause the modules to be seated improperly in
the chassis, and result in possible damage to the module or the chassis.
Install or remove modules one at a time. Doing this aids in preventing
the PSAX system from indicating any erroneous failure messages, and
allows the PSAX system time to reinitialize and display the accurate con-
figuration of the module that is inserted.
!CAUTION:
Modifying or tampering with PSAX chassis components may void your
warranty. Any modification to this equipment not expressly authorized
by Lucent Technologies may void your granted authority to operate such
equipment.
!CAUTION:
Shipping the chassis with removable I/O, server, or CPU modules
installed may cause damage to the chassis and the modules. Damage to
any of the components in the system resulting from shipping the chassis
with removable modules installed will void your warranty.
!
DANGER:
Interface lines connected to the 4-Port Voice 2-Wire Office module
(model 20N32) that exit the building premises must be connected to tele-
communication devices that provide primary and secondary protection.
Safety Information
When installing and operating the 4-Port Voice 2-Wire Office module, follow
the safety guidelines provided in the PacketStar®PSAX Multiservice Media Gate-
way Safety Guidelines, which accompanies this product, to help prevent serious
personal injury and damage to the module. Please read all warnings and
instructions supplied before beginning installation or configuration of this
module. In addition to the general safety information provided, you should
also refer to the text in the PacketStar PSAX installation guides for other
important safety information and procedures.
Regulatory Standards Compliance
Safety and Electromagnetic Compatibility (EMC)
The following PacketStar PSAX systems are compliant with applicable safety
and EMC standards when configured with the 4-Port Voice 2-Wire Office
module (model 20N32):

255-700-467 v
PacketStar®PSAX 4-Port Voice 2-Wire Office Module User Guide,Issue1 Release9.0.0
Legal Notices, Safety, and Regulatory Information
Regulatory Statements
•PSAX 1000 system
•PSAX 1250 system
•PSAX 2300 system
•PSAX 4500 system
Please refer to the PacketStar PSAX 1000, PSAX 1250, PSAX 2300, or
PSAX 4500 Multiservice Media Gateway installation guide for details on
safety and EMC standards compliance.
Telecommunications
•FCC Part 68 (USA)
•CS-03 Issue 8 (Canada)
Regulatory Statements
USA Regulatory Statements
FCC Part 68 This equipment complies with Part 68 of the FCC rules. On the back of the
PSAX chassis is a label that contains the FCC registration number, in addition
to other information. You must provide this information to the telephone
company, if they request it. The FCC requires Lucent Technologies to provide
you with the following information:
1. This equipment has digital service interface capabilities using RJ-48C and
RJ-48H connectors. The facility interface codes with which this equip-
ment complies for digital services are as follows: 04DU9-BN, 04DU9-DN,
04DU9-1KN, and 04DU9-1SN. This equipment has loop start interface
capabilities using an RJ-11C connector. The facility interface code with
which this equipment complies for service is 02LS2. The service order
codes for this equipment are 6.0F for the T1 interface and 9.0Y for the
loop start interface.
2. An FCC-compliant telephone network interface jack is built into this
equipment and is compatible with interconnections that are Part 68
compliant.
3. The REN for the 4-Port Voice 2-Wire Office module when used in this
equipment is 0.7B.
4. If this equipment causes harm to the telephone network, the telephone
company will notify you in advance that temporary discontinuance of
service might be required. But if advance notice is not practical, the tele-
phone company will notify you as soon as possible. Also, you will be
advised of your right to file a complaint with the FCC if you believe this
is necessary.
5. The telephone company might make changes in its facilities, equipment,
operations, or procedures that could affect the operation of this equip-
ment. If this happens, the telephone company will provide advance
notice for you to make necessary modifications to maintain uninter-
rupted service.

Legal Notices, Safety, and Regulatory Information
Regulatory Statements
vi 255-700-467
PacketStar®PSAX 4-Port Voice 2-Wire Office Module User Guide, Issue 1 Release 9.0.0
6. If you experience trouble with this equipment, or need repairs or war-
ranty information, please refer to the Lucent Technologies InterNetworking
Systems Global Warranty that accompanied your PSAX product shipment
for instructions on obtaining technical support in your area.
If this equipment is causing harm to the telephone network, the tele-
phone company might request that you disconnect the equipment until
the problem is resolved.
7. This equipment has no user-serviceable parts.
This equipment cannot be used on public coin telephone service provided by
the telephone company. Connection to party line service is subject to state
tariffs. Contact your state public utility commission, public service commis-
sion, or corporation commission for information.
Canadian Regulatory Statements
CS-03 Issue 8 NOTICE: This equipment meets applicable Industry Canada Termi-
nal Equipment Technical Specifications. This is confirmed by the reg-
istration number. The abbreviation, IC, before the registration num-
ber signifies that registration was performed based on a Declaration
of Conformity indicating that Industry Canada technical specifica-
tions were met. It does not imply that Industry Canada approved the
equipment.
The Ringer Equivalence Number (REN) assigned to the 4-Port Voice 2-Wire
Office module denotes the percentage of the total load to be connected to a
telephone loop, which is used by the device, to prevent overloading. The ter-
mination on a loop may consist of any combination of devices subject only to
the requirement that the total of the REN of all devices does not exceed 5.
The REN for the 4-Port Voice 2-Wire Office module when used in the PSAX
system is 0.7B.
SH-03 Version 8 AVIS: Le présent matériel est conforme aux spécifications techniques
d’Industrie Canada applicables au matériel terminal. Cette confor-
mité est confirmée par le numéro d’enregistrement. Le sigle, IC,
placé devant le numéro d’enregistrement, signifie que l’enregistre-
ment s’est effectué conformément à une déclaration de conformité
et indique que les spécifications techniques d’Industrie Canada ont
été respectées. Il n’implique pas qu’Industrie Canada a approuvé le
matériel.
Le nombre équivalent de sonnerie (REN) attribué au module central bifilaire
(Voice 2-Wire Office) correspond au pourcentage de la charge totale à con-
necter à un circuit téléphonique bifilaire; il est utilisé par l’appareil pour
prévenir la surcharge. Le circuit peut être terminé par n’importe quelle com-
binaison d’appareils, à la seule condition que le total des REN de ces derniers
ne dépasse pas cinq.
Lorsqu’il est utilisé dans le système PSAX, le module central bifilaire possède
un REN de 0,7 B.

255-700-467 vii
PacketStar®PSAX 4-Port Voice 2-Wire Office Module User Guide,Issue1 Release9.0.0
Legal Notices, Safety, and Regulatory Information
Regulatory Statements

Legal Notices, Safety, and Regulatory Information
Regulatory Statements
viii 255-700-467
PacketStar®PSAX 4-Port Voice 2-Wire Office Module User Guide, Issue 1 Release 9.0.0

255-700-467 ix
PacketStar®PSAX 4-Port Voice 2-Wire Office Module User Guide, Issue 1 Release 9.0.0
Contents
Legal Notices, Safety, and Regulatory Information . . . . . . . . . . . . . . . . . iii
Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iii
Trademarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iii
Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iii
Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iii
Software and Hardware Limited Warranties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iii
Warranty Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iv
Regulatory Standards Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
Safety and Electromagnetic Compatibility (EMC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
Telecommunications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v
Regulatory Statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v
USA Regulatory Statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v
FCC Part 68 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v
Canadian Regulatory Statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi
CS-03 Issue 8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi
SH-03 Version 8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi
List of Figures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiii
List of Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiv
1Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Purpose of This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1
Audience for This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1
What You Should Know . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1
Related Reading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2
Lucent Technologies Information Products . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2
Product Information Library . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2
Printed Documents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2
Other Publications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2
About Lucent Technologies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2
About the PacketStar PSAX Product Family . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3
PSAX 1000 Multiservice Media Gateway. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3
.1-3
.1-3
.1-2
.1-2
.1-2
.1-2
.1-2
.1-2
.1-1
.1-1
.1-1
1-1
xiv
xiii
vi
vi
vi
v
v
v
v
iv
iv
.iv
iv
iii
iii
iii
iii
iii
iii

Contents
x255-700-260
PacketStar®PSAX 4-Port Voice 2-Wire Office Module User Guide, Issue 1 Release 9.0.0
PSAX 1250 Multiservice Media Gateway . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
PSAX 2300 Multiservice Media Gateway . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
PSAX 4500 Multiservice Media Gateway . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Document Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
Text Types Used in This Document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
Icons and Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
Use of Command Description Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
Use of Field Description Tables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
General Document Navigational Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
Selecting Options, Fields, and Commands Using the Console Interface . . . . . . . . . . . 1-7
Selecting Menu Options and Fields in the AQueView GUI . . . . . . . . . . . . . . . . . . . . . 1-8
Help Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10
Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
Before You Begin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12
Comments on This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12
2Module Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1
Overview of This Chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
4-Port Voice 2-Wire Office Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Module Placement Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Hardware Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
General Hardware Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Chassis Speed, Power Consumption, and Memory Allocation . . . . . . . . . . . . . . . . . . . . . 2-3
LED Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
3Configuring Ports and Channels Using the Console Interface . . . . . . . . . . .3-1
Overview of This Chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Before You Begin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Using the Equipment Configuration Window. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Accessing the Equipment Configuration Window . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Alarm Status Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
Configuring the Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
Saving the Equipment Configuration and Logging Off . . . . . . . . . . . . . . . . . . . . . . . . . . 3-13
4Configuring Interfaces Using the Console Interface . . . . . . . . . . . . . . . . . . .4-1
Before You Begin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Errors When Applying Interfaces to Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
The Circuit Emulation Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Managing Circuit Emulation Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-14-1
4-1
4-1
4-1
4-1
3-13
3-7
3-6
3-1
3-1
3-1
3-1
3-1
2-3
2-3
2-2
2-2
2-2
2-2
2-1
2-1
1-12
1-12
1-11
1-10
1-8
1-7
1-7
1-6
1-6
1-5
1-5
1-5
1-4
1-4
1-3

Contents
255-700-467 xi
PacketStar®PSAX 4-Port Voice 2-Wire Office Module User Guide, Issue 1 Release 9.0.0
Configuring a Circuit Emulation Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2
Bringing a Circuit Emulation Interface Into Service . . . . . . . . . . . . . . . . . . . . . . . . . . .4-4
Viewing the Parameters of a Specific Circuit Emulation Interface. . . . . . . . . . . . . . . . .4-4
Viewing the Circuit Emulation Module Port Statistics . . . . . . . . . . . . . . . . . . . . . . . . .4-5
Taking a Circuit Emulation Interface Out of Service . . . . . . . . . . . . . . . . . . . . . . . . . . .4-5
Deleting a Circuit Emulation Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-6
Modifying a Circuit Emulation Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-6
Provisioning Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-7
5Configuring Ports and Channels Using the AQueView EMS . . . . . . . . . . . . 5-1
Overview of This Chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-1
Using the Right-Click Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-1
Accessing Configuration Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-2
Configuring the Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-3
Configuring Channels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-7
Applying an Interface to a Channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-7
6Configuring Interfaces Using the AQueView EMS. . . . . . . . . . . . . . . . . . . . 6-1
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-1
Errors Applying Interfaces to Ports. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-1
The Circuit Emulation Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-1
Configuring Circuit Emulation Interface Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-3
Naming an Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-8
Using the Interface Name Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-8
Viewing Existing Named Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-8
Correcting Errors When Applying an Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-9
Bringing an Interface Into Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-10
Performing Bulk Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-10
Copying an Interface Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-12
Changing Interface Configuration Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-14
Taking the Interface Out of Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-14
Deleting an Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-14
Saving Your Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-15
Provisioning Connections for the PSAX System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-15
AReference Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
Overview of This Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
DSP Tone Detection Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
DSP Channel Reduction Availability Due to Fax Relay Mode. . . . . . . . . . . . . . . . . . . . . . . A-2
Industry Compliance Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2
Connection Type by Interface Type Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-11
A-11
A-2
A-2
A-1
A-1
A-1
.6-15
.6-15
.6-14
.6-14
.6-14
.6-12
.6-10
.6-10
.6-9
.6-8
.6-8
.6-8
.6-3
.6-1
.6-1
.6-1
6-1
.5-7
.5-7
.5-3
.5-2
.5-1
.5-1
5-1
.4-7
.4-6
.4-6
.4-5
.4-5
.4-4
.4-4
.4-2

Contents
xii 255-700-467
PacketStar®PSAX 4-Port Voice 2-Wire Office Module User Guide, Issue 1 Release 9.0.0
Interface Type by Input/Output Module Type Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-13
Module Alarm Status Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-16
4-Port Voice 2-Wire Office Module Line Status Table . . . . . . . . . . . . . . . . . . . . . . . . . . . A-17
ATM Service Categories in the PSAX System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-17
ATM Service Category Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-17
Priority of ATM Service Categories in the PSAX System . . . . . . . . . . . . . . . . . . . . . . A-17
Module Cable for the 4-Port Voice 2-Wire Office Module . . . . . . . . . . . . . . . . . . . . . . . A-18
A-18
A-17
A-17
A-17
A-17
A-16
A-13

255-700-467 xiii
PacketStar®PSAX 4-Port Voice 2-Wire Office Module User Guide, Issue 1 Release 9.0.0
List of Figures
1-1 Field Description Table Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-7
1-2 Main Menu Help Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-11
2-1 4-Port Voice 2-Wire Office Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1
3-1 Sample Equipment Configuration Window on a PSAX 1000 System (Page 1) . . . . . . . . . . . . .3-2
3-2 Sample Equipment Configuration Window on a PSAX 1250 System (Page 1) . . . . . . . . . . . . .3-3
3-3 Sample Equipment Configuration Window on a PSAX 2300 or PSAX 4500 System (Page 1) . .3-3
3-4 Sample Equipment Configuration Window on a PSAX 1000, PSAX 2300, or PSAX 4500
System (Page 2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-4
3-5 Sample Equipment Configuration Window on a PSAX 1250 System (Page 2) . . . . . . . . . . . . .3-4
3-6 Console Interface Main Menu (Equipment Configuration Selected) . . . . . . . . . . . . . . . . . . . . .3-8
3-7 Equipment Configuration Window (As Displayed on the PSAX 1000, PSAX 1250, PSAX 2300, and
PSAX 4500 Console) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-9
3-8 Two Wire Office Configuration Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-9
3-9 Two Wire Office Port and Channel Configuration Window . . . . . . . . . . . . . . . . . . . . . . . . . .3-11
3-10 Save Configuration [Modified] (Before Saving) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-14
4-1 Circuit Emulation Interface Configuration Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-3
5-1 Sample Port Configuration (Displaying Right-Click Menu) . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-1
5-2 Sample Channel Configuration (Displaying Right-Click Menu) . . . . . . . . . . . . . . . . . . . . . . . . .5-1
5-3 Device Tree and Device Window (Displaying a Typical Setup) . . . . . . . . . . . . . . . . . . . . . . . . .5-3
5-4 Front Panel View of the 4-Port Voice 2-Wire Office Module . . . . . . . . . . . . . . . . . . . . . . . . . .5-4
5-5 Two Wire Office Port and Channel Configuration Window . . . . . . . . . . . . . . . . . . . . . . . . . . .5-5
5-6 Channel Configuration Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-8
6-1 Circuit Emulation Interface Configuration Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-2
6-2 Interface Search By Name Window (Displaying Menu) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-9
6-3 Sample Copy Interface Configuration Window (After Initially Selecting the Copy Button From a
Port Configuration Page) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-13
6-4 Sample Copy Interface Configuration Window (After Selecting Valid Attributes) . . . . . . . . . .6-13
6-5 Delete Interface Confirmation Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-15
.6-15
.6-13
.6-13
.6-9
.6-2
.5-8
.5-5
.5-4
.5-3
.5-1
.5-1
.4-3
.3-14
.3-11
.3-9
.3-9
.3-8
.3-4
.3-4
.3-3
.3-3
.3-2
.2-1
.1-11
.1-7

255-700-467 xiv
PacketStar®PSAX 4-Port Voice 2-Wire Office Module User Guide, Issue 1 Release 9.0.0
List of Tables
1-1 Text Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-5
1-2 Command Description Table Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-6
1-3 System Responses to Selecting Options, Fields, or Commands . . . . . . . . . . . . . . . . . . . . . . . .1-8
1-4 Shortcut Keys for Navigating Console Interface Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-8
1-5 Selecting Multiple Menu Options or Buttons in Succession . . . . . . . . . . . . . . . . . . . . . . . . . . .1-9
1-6 How Fields Are Displayed in the AQueView GUI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-9
1-7 Shortcut Keys for Navigating the AQueView GUI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-9
2-1 Physical Hardware Specifications for PSAX I/O and Server Modules . . . . . . . . . . . . . . . . . . . . .2-2
2-2 Performance and Power Specifications for the 4-Port Voice 2-Wire Office Module . . . . . . . . .2-3
2-3 LED Indicators for the 4-Port Voice 2-Wire Office Module . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-4
3-1 Commands for the Equipment Configuration Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-5
3-2 Field Descriptions for the Equipment Configuration Window . . . . . . . . . . . . . . . . . . . . . . . . .3-5
3-3 Alarm Status Descriptions for Modules on the Equipment Configuration Window . . . . . . . . .3-7
3-4 Commands for the Two Wire Station Configuration Window . . . . . . . . . . . . . . . . . . . . . . . .3-10
3-5 Commands for the Voice Two Wire Office Port and Channel Configuration Window . . . . . .3-11
3-6 Field Descriptions for the Two Wire Office Port and Channel Configuration Window . . . . . .3-12
3-7 Messages Generated after the Save Configuration Process . . . . . . . . . . . . . . . . . . . . . . . . . .3-15
4-1 Commands for the Circuit Emulation Interface Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-3
4-2 Field Descriptions for the Circuit Emulation Interface Configuration Window . . . . . . . . . . . . .4-4
5-1 Menu Options for a Sample Port Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-2
5-2 Field Descriptions for the Two Wire Office Port and Channel Configuration Window . . . . . . .5-6
6-1 Field Descriptions for the Circuit Emulation Interface Configuration Window . . . . . . . . . . . . .6-3
6-2 Buttons for the Interface Name Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-8
6-3 Performing an Action on an Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-10
6-4 Enabling or Disabling Traps Decision Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-11
6-5 Buttons for the Copy Interface Configuration Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-13
A-1 DSP Tone Detection Modes and Associated Processing Performed . . . . . . . . . . . . . . . . . . . . A-1
A-2 Channel Reduction Availability Caused by Fax Relay Connections vs. Voice
Processing Connections on a DSP2C Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2
A-3 Industry Compliance Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-3
A-4 Connection Type by Interface Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-12
A-5 Interface Type by I/O Module Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-13
A-6 Alarm Status Descriptions for Modules on the Equipment Configuration Window . . . . . . . A-16
A-7 4-Port Voice 2-Wire Office and 8-Port Voice 2-Wire Station Line Status Codes . . . . . . . . . . A-17
A-8 PSAX System-Supported Quality of Service Category Descriptions . . . . . . . . . . . . . . . . . . . . A-17
A-9 Mapping ATM Service Categories to PSAX System Priority Levels . . . . . . . . . . . . . . . . . . . . A-18
A-18
A-17
A-17
A-16
A-13
A-12
A-3
A-2
A-1
.6-13
.6-11
.6-10
.6-8
.6-3
.5-6
.5-2
.4-4
.4-3
.3-15
.3-12
.3-11
.3-10
.3-7
.3-5
.3-5
.2-4
.2-3
.2-2
.1-9
.1-9
.1-9
.1-8
.1-8
.1-6
.1-5

List of Tables
255-700-467 xv
PacketStar®PSAX 4-Port Voice 2-Wire Office Module User Guide, Issue 1 Release 9.0.0
A-10 Orderable I/O and Common Equipment Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-18A-18

List of Tables
xvi255-700-467
PacketStar®PSAX 4-Port Voice 2-Wire Office Module User Guide, Issue 1 Release 9.0.0

PacketStar®PSAX 4-Port Voice 2-Wire Office Module User Guide,Issue1 Release9.0.0
255-700-467 1-1
1Getting Started
Purpose of This Guide
The PacketStar®PSAX 4-Port Voice 2-Wire Office Module User Guide provides a
description of the 4-Port Voice 2-Wire Office module. It also provides the fol-
lowing information:
•Overview of configuring the module
•Configure the module ports and channels
•Configure the interfaces
For information on provisioning connections, see the PacketStar®PSAX System
Connections Provisioning Guide.
Note: If you are using this module for the first time, you should read
through this guide in its entirety before beginning the configura-
tion process. The chapters in this guide are arranged in the logical
order of normal configuration and should be performed in that
order for the module to operate successfully.
Audience for This Guide
The information in this guide is intended for users who will configure ports
and channels for the 4-Port Voice 2-Wire Office module, and configure the
interface types for the PSAX Multiservice Media Gateway system, whether
using the console interface or the AQueView Element Management System
(EMS).
What You Should Know
Before you use this document or operate a PacketStar PSAX system, you
should already understand and have experience with the following:
•ATM Forum, Frame Relay Forum, and other telecommunications specifica-
tions
•Ethernet network capabilities
•Internet Protocol capabilities
•Data network design
•Telephony network design

Chapter 1 Getting Started
Related Reading
1-2 255-700-467
PacketStar®PSAX 4-Port Voice 2-Wire Office Module User Guide, Issue 1 Release 9.0.0
Related Reading
Lucent Technologies Information Products
Product Information
Library To install, operate, and configure your PSAX system and I/O and server mod-
ules, read the PSAX publications provided on your Lucent Technologies
PacketStar PSAX Multiservice Media Gateways Products, Product Information
Library CD-ROM.
Printed Documents For your convenience, many of the documents included on the PacketStar
PSAX Multiservice Media Gateways Product Information Library CD-ROM
are also available in printed form. You can order these documents through
the Lucent Technologies Customer Information Center Web site at:
http://www.lucentdocs.com.
Other Publications
Numerous books are currently available on the subject of basic telecommuni-
cations technology and specific protocols. In addition to such general reading,
you should also be familiar with industry specifications identified in the
appendix entitled “Reference Information” at the end of this guide.
About Lucent Technologies
Lucent Technologies is the communications systems and technology com-
pany formed through the restructuring of AT&T. We bring with us a tradition
of more than 125 years of experience and a dedication to superior customer
service.
Lucent Technologies manufactures, sells, and services a complete line of cus-
tomer premises communications units, and commercial and multimedia
communications and messaging systems designed and supported by our
research and development unit, Bell Laboratories.

255-700-467 1-3
PacketStar®PSAX 4-Port Voice 2-Wire Office Module User Guide,Issue1 Release9.0.0
Chapter 1 Getting Started
About the PacketStar PSAX Product Family
Our legacy and our spirit of innovation allow Lucent to provide our custom-
ers with the tools needed to communicate effectively, any time and any-
where, and to integrate the latest technologies into real-life solutions that
help make business work.
About the PacketStar PSAX Product Family
Lucent Technologies provides a complete range of PSAX Multiservice Media
Gateways in the PacketStar PSAX family.
PSAX 1000 Multiservice Media Gateway
The PacketStar PSAX 1000 Multiservice Media Gateway is designed to provide
a full range of central office-based multiservice media gateway functions in a
small, competitively-priced package suitable for customer premise deploy-
ment. Ideal for central office, large enterprise, or wireless cell site multiser-
vice media gateway applications, the PSAX 1000 system provides highly reli-
able network access for time-division multiplex voice, frame relay,
10/100BASE-T Ethernet, and ATM data applications.
When it is functioning in a redundant operating mode and after it has experi-
enced a single-point failure, the PSAX 1000 system provides up to 630 Mbps
of ATM cell bus capacity. The total ATM cell bus capacity of the system may
also be scaled to provide nonblocking, nonredundant chassis bandwidths
beyond 630 Mbps.
Supporting up to five slots (19–inch chassis) for I/O and server mod-
ules—with a full range of interfaces such as DS0A, DS1/E1, DS3/E3, OC-3,
OC-3c/STM-1, OC-12c/STM-4c, 10/100BASE-T Ethernet, and serial—the
PSAX 1000 system is a cost-effective access switch solution for connecting to
legacy equipment.
PSAX 1250 Multiservice Media Gateway
The PacketStar PSAX 1250 Multiservice Media Gateway is designed to provide
a full range of central office-based multiservice ATM access functions. Ideal
for the central office or a large enterprise’s multiservice media gateway, the
PSAX 1250 system provides highly reliable network access for time-division
multiplex voice, frame relay, 10/100BASE-T Ethernet, and ATM data applica-
tions.
When it is functioning in a redundant operating mode and after it has experi-
enced a single-point failure, the PSAX 1250 system provides up to 600 Mbps
of ATM cell bus capacity. The total ATM cell bus capacity of the system may
also be scaled to provide nonblocking, nonredundant chassis bandwidths
beyond 600 Mbps.
Supporting 10 slots (19-inch chassis) or 14 slots (23-inch chassis) for I/O and
server modules—with a full range of interfaces such as DS0A, DS1/E1,
DS3/E3, OC-3, OC-3c/STM-1, OC-12c/STM-4c, 10/100BASE-T Ethernet,
and serial—the PSAX 1250 system is a cost-effective access switch solution
for interworking with legacy equipment.

Chapter 1 Getting Started
About the PacketStar PSAX Product Family
1-4 255-700-467
PacketStar®PSAX 4-Port Voice 2-Wire Office Module User Guide, Issue 1 Release 9.0.0
PSAX 2300 Multiservice Media Gateway
The PacketStar PSAX 2300 Multiservice Media Gateway offers carrier-grade,
high-density multiservice ATM access functions. Designed as the multiservice
media gateway for the central office or for a large enterprise customer, the
PSAX 2300 system provides network access for time-division multiplex
voice, frame relay, 10/100BASE-T Ethernet, and ATM data applications.
When it is functioning in a redundant operating mode and after it has experi-
enced a single-point failure, the PSAX 2300 system provides up to 1.9 Gbps
of ATM cell bus capacity. The total ATM cell bus capacity of the system may
also be scaled to provide nonblocking, nonredundant chassis bandwidths
beyond 1.9 Gbps.
Supporting 15 slots for I/O and server modules—with provisions for OC-3,
OC-3c/STM-1, and OC-12c/STM-4c interfaces with 1:1 protection, 1:1 DS1
module protection switching, and a full range of interfaces such as DS0A,
DS1/E1, DS3/E3, 10/100BASE-T Ethernet, and serial—the PSAX 2300 sys-
tem solves demanding and diverse network design challenges with ease.
PSAX 4500 Multiservice Media Gateway
The PacketStar PSAX 4500 Multiservice Media Gateway provides carrier-class
reliability, with an unmatched range of service capabilities, end-to-end traffic
prioritization, “any-service, any-channel” flexibility, and breakthrough voice
technology. Ideal for the central office or a large enterprise multiservice
media gateway, the PSAX 4500 system provides highly reliable network
access for time-division multiplex voice, frame relay, 10/100BASE-T Ether-
net, and ATM data applications.
When it is functioning in a redundant operating mode and after it has experi-
enced a single-point failure, the PSAX 4500 system provides up to 4.2 Gbps
of ATM cell bus capacity. The total ATM cell bus capacity of the system may
also be scaled to provide nonblocking, nonredundant chassis bandwidths
beyond 4.2 Gbps.
The high-performance midplane design supports 15 interface slots. Module
protection for two groups of four or six multiport DS3, STS-1e, or E3 mod-
ules is provided via an N:1 protection scheme using rear access line interface
modules. The protection module provides backup so that on the failure of
any one of the modules in a group, traffic is maintained. A single PSAX 4500
system at the edge of the carrier network can transition traffic from a large
number of network customers over high-speed DS1/E1 IMA, DS3/E3, OC-3,
OC-3c/STM-4c, and OC-12c/STM-4c trunks into the ATM core, managing
the whole quickly and efficiently, down to the individual permanent virtual
circuit.
Through the use of the latest DSP voice technology, the PSAX 4500 system
supports advanced voice traffic over ATM (VToA) services for up to 6048 DS0
channels. As a multiservice media gateway—with H.248 call control, CAS,
PRI, GR-303, and V5.2 protocols, 3-Port DS3/STS-1e, 1-Port OC-3/STM-1
