LUDLUM MODEL 44-172
YSO GAMMA SCINTILLATOR
March 2019
Serial Number 240057 and Succeeding
Serial Numbers

LUDLUM MODEL 44-172
YSO GAMMA SCINTILLATOR
March 2019
Serial Number 240057 and Succeeding
Serial Numbers

Ludlum Measurements, Inc. March 2019
STATEMENT OF WARRANTY
Ludlum Measurements, Inc. warrants the products covered in this manual to be free of
defects due to workmanship, material, and design for a period of twelve months from
the date of delivery. The calibration of a product is warranted to be within its
specified accuracy limits at the time of shipment. In the event of instrument failure,
notify Ludlum Measurements to determine if repair, recalibration, or replacement is
required.
This warranty excludes the replacement of photomultiplier tubes, G-M and
proportional tubes, and scintillation crystals which are broken due to excessive
physical abuse or used for purposes other than intended.
There are no warranties, express or implied, including without limitation any implied
warranty of merchantability or fitness, which extend beyond the description of the
face there of. If the product does not perform as warranted herein, purchaser’s sole
remedy shall be repair or replacement, at the option of Ludlum Measurements. In no
event will Ludlum Measurements be liable for damages, lost revenue, lost wages, or
any other incidental or consequential damages, arising from the purchase, use, or
inability to use product.
RETURN OF GOODS TO MANUFACTURER
If equipment needs to be returned to Ludlum Measurements, Inc. for repair or calibration, please
send to the address below. All shipments should include documentation containing return shipping
address, customer name, telephone number, description of service requested, and all other necessary
information. Your cooperation will expedite the return of your equipment.
LUDLUM MEASUREMENTS, INC.
ATTN: REPAIR DEPARTMENT
501 OAK STREET
SWEETWATER, TX 79556
800-622-0828 325-235-5494
FAX [phone]

Ludlum Measurements, Inc. March 2019
Table of Contents
Introduction 1
Packing and Unpacking 2
Specifications 3
Parts List 4
Model 44-172 YSO Gamma Scintillator 4-1
Assembly View, Drawing 2 × 236 4-1
1.125 Inch Tube Socket Board , Drawing 435 × 1700 4-1
Drawings and Diagrams 5

Model44-172 TechnicalManual Section1
Ludlum Measurements, Inc. Page 1-1 March 2019
Introduction
he Ludlum Model 44-172 YSO (Yttrium Oxyorthosilicate) detector is used primarily for the
detection of low-energy gamma radiation from approximately 5 keV to 145 keV. The Model 44-
172 will also detect beta particles from 14C (49 keV average energy).
The detector consists of a 2.5 cm (1 in.) diameter by 1 mm (0.04 in.) thick YSO scintillator. The
window area is approximately 5 cm2and is covered by 1.2 mg/cm2metallized polyester for light
tightness.
Compatible instruments for use by this detector provide detector high voltage of 500-1200 Vdc
and input sensitivity of approximately -35 mV.
Model 44-172 YSO Detector
Section
1
T

Model44-172 TechnicalManual Section2
Ludlum Measurements, Inc. Page 2-1 March 2019
Packing and Unpacking
Remove the calibration certificate or detector functional check certificate and place it in a secure location.
Remove the detector(s) and accessories (if applicable) and ensure that all items on the packing list are in
the carton. If multiple detectors are included, refer to the calibration certificates for the serial number (SN)
matches.
To return an instrument or detector for repair or calibration, provide sufficient packing material to
prevent damage during shipment and affix appropriate warning labels to promote careful handling. Every
returned instrument must be accompanied by an Instrument Return Form, which can be downloaded
from the Ludlum website at www.ludlums.com. Find the form by clicking the “Support” tab and selecting
“Repair and Calibration” from the drop-down menu. Then choose the appropriate Repair and Calibration
division where you will find a link to the form.
0
Section
2

Model44-172 TechnicalManual Section3
Ludlum Measurements, Inc. Page 3-1 March 2019
Specifications
0
Voltage Requirements: 500 volts to 1200 volts maximum.
Scintillator: 2.5 cm (1 in.) diameter by 1 mm (0.04 in.) thick YSO crystal (non-hygroscopic)
Photomultiplier Tube: 2.86 cm (1.125 inch) diameter; head-on type; magnetically shielded
Connector: Standard Series ˝C˝(other types available upon request)
Window Area: 5 cm2
Window Density: 1.2 mg/cm2
Background: 250 cpm or less in a 10 µR/hr field
Efficiency (4): 40% for 125I; 25% for 129I, 2.5% for 137Cs, 7% for 55Fe, 11.2% for 241Am, 8% for 14C;
and 7.4% for 57Co
Input Sensitivity: typically -35 mV
Recommended Energy Range Operation: 5 keV to 145 keV gamma
Construction: cast-and-drawn aluminum with beige powder-coat finish
Size: 5.1 x 17.8 cm (2 x 7 in.) (Dia x L)
Weight: 0.5 kg (1 lb) including batteries.
Temperature: -4 to 50 °C (24 to122 °F); may be certified for operation from -40°to 65°C (-40° to
150°F).
Section
3

Model44-172 TechnicalManual Section3
Ludlum Measurements, Inc. Page 3-2 March 2019
Pollution: Pollution Degree 3 (as defined by IEC 664) (Conductive pollution or dry nonconductive
pollution that becomes conductive due to condensation occurs. To be found in industrial
environment or construction sites (harsh environments).

Model44-172 TechnicalManual Section4
Ludlum Measurements, Inc. Page 4-1 March 2019
Parts List
Reference Description Part Number
UNIT Completely Assembled
Model 44-172 YSO
Gamma Scintillator 47-3543
* FOIL-NETIC 01-5019
* FOIL-CO-NETIC 01-5026
* Photomultiplier Tube 1.125 inch 01-5238
* YSO Scintillator 01-5782
* CAPLUG 1 7/8 SC MOD M44-1 03-5475
* O-Ring-2-029 16-8317
4 ea SCREW 4-40 ×3/16 17-8811
* LUG-1497 18-8766
* Housing 2002-357
* Window Assembly 2002-358
* Tube Shield 40-4006
* Receptacle UG706/U ˝C˝4478-011
* 1.125 inch Voltage Divider 5435-182
7 ea. Sponge 7002-029-05
* Light Pipe 7002-353
* Gasket 7002-355
BOARD Completely Assembled
1.125 inch Voltage Divider Board 5435-533
C1-C3 0.01µF, 200V 04-5725
C4 0.0047µF, 3KV 04-5958
R1 10M, 1/8W, 1% 12-7996
R2 7.5M, 1/8W, 5% 12-7971
R3-R10 10M, 1/8W, 1% 12-7996
R11 2.21M, 1/8W, 1% 12-7002
R12-R13 6.04M, 1/8W, 1% 12-7071
* Socket 1.125 inch PCB MOUNT 4435-103
Section
4
Model 44-172 YSO
Gamma Scintillator
Assembly View,
Drawing 2 × 236
1.125 inch Tube
Socket Board,
Drawing 435 x 1700
CAPACITORS
RESISTORS
MISCELLANEOUS

Model44-172 TechnicalManual Section5
Ludlum Measurements, Inc. Page 5-1 March 2019
Drawings
4Efficiency Curve
Assembly View, Drawing 2 × 236
1 1/8 Inch Voltage Divider Board, Drawing 435 × 1700
1 1/8 Inch Voltage Divider Board Component Layout, Drawing 435 ×
1701 (2 sheets)
Window Assembly, Drawing 2 x 232A
