Mini-Converter / BAT-3HS / HDMI to 3G/HD/SD-SDI Manual ver 1.0
Updated 2012/02/06
/ Operational Manual
For your protection, please read these safety instructions
completely before operating the equipment and keep
this manual for future reference. The information in this
summary is intended for operators. Carefully observe
all warnings, precautions and instructions both on the
apparatus and in the operating instructions.
Equipment Markings
The lighting ash symbol within an equilateral triangle is
intended to alert the user to the presence of un insulated
“dangerous voltages”within the product’s enclosure
that may be of sucient magnitude to constitute a
risk of electrical shock. The exclamation mark within
an equilateral triangle is intended to alert the user to
the presence of important operating and maintenance
(servicing) instructions within literature accompanying
the equipment.
Warnings
Water and Moisture :
Do not operate the equipment under or near water - for
example near a bathtub, kitchen sink, or laundry tub, in
a wet basement, near a swimming poor or in areas with
high humidity. Cleaning - Unplug the apparatus from the
wall outlet before cleaning or polishing. Do not use liquid
cleaners or aerosol cleaners. Use a lint-free cloth lightly
moistened with water for cleaning the exterior of the
apparatus.
Ventilation :
Do not block any of the ventilation openings of the
apparatus. Install in accordance with the installation
instructions. Never cover the slots and openings with a
cloth or other material. Never install the apparatus near
heat sources such as radiator, heat registers, stoves, or
other apparatus (including ampliers) that produce heat.
Grounding or Polarization - Do not defeat the safety
purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the
other. A grounding type plus has two blades and a third
OPERATOR SAFETY SUMMARY grounding prong.
The wide blade or third prong is provided for your
safety. If the provided plug does not t into your outlet,
consult an electrician. Power-Cord Protection - Route the
power cord so as to avoid it being walked on or pinched
by items placed upon or against it, paying particular
attention to the plugs, receptacles, at the point where the
cord exits form the apparatus.
Attachments :
Only use attachments as recommended by the
manufacture.
Accessories :
Use only with a cart, stand, tripod, bracket, or table
specied by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when moving
the cart/apparatus combination to avoid injury from tip-
over.
Lighting :
Unplug this apparatus during lightning storms or when
unused for long periods of time.
ISDN cables :
CAUTION - to reduce the risk of re, use only No. 26 AWG
or larger telecommunication line cord.
Servicing :
Do not attempt to service the apparatus yourself
as opening or removing covers may expose you to
dangerous voltages or other hazards, and will void the
warranty. Refer all servicing to qualied service personnel.
Damaged Equipment :
Unplug the apparatus from the outlet and refer servicing
to qualied personnel under the following conditions
- When the power cord or plug is damaged or frayed If
liquid has been spilled or objects have fallen into the
apparatus If the apparatus has been exposed to rain or
moisture If the apparatus has been subjected to excessive
shock by being dropped, or the cabinet has been
