Lumantek ez-SHV+ User manual

SDI to HDMI
Converter with
Display and Scaler
Operation manual
Manual
Updated November. 2019

Copy Rights
Copyright © 2006~2019 LUMANTEK Co., Ltd.
All Rights Reserved
This document contains information that is proprietary to LUMANTEK.
CO., LTD. The information in this document is believed to be accurate and
reliable; however, LUMANTEK assumes no responsibility or liability for
any errors or inaccuracies that may appear in this document, nor for any
infringements of patents or other rights to third parties resulting from its
use.
This publication may contain technical issues, inaccurate information or
typos. These will be revised in revised edition, if there is any. No part of
this publication is subject to be reproduced, stored in retrieval system,
or transmitted in any forms, or any means without the prior consent by
Lumantek.
Trademarks
HD ENCODULATOR TM, SD ENCODULATOR TM LUMANTEK Logo, Mega
CruiserTM, ORIXTM, X-CruiserTM, DTA-PlusTM, Media BlasterTM, are
Trademarks of Lumantek. Co., Ltd.
Any other trademarks than stated above in this document belongs to its
pertinent corporation.
Warranty Period
Lumantek’s products comes with One(1) year limited warranty. Please
contact below if you need more information.
LUMANTEK CUSTOMER SERVICES
[email protected]
TEL: [phone]
FAX: [phone]

5
Lumantek's ez-SHV+ is an SDI to HDMI converter with Display and Scaler.
The ez-SHV+ does more than just coverting. Through its 2.7 inch TFT-LCD, it dislays the
video input.
The display also shows an eye pattern for video quality monitoring, the resolution of
incoming video and approximate cable length relative to the quality of the video.
Features
①Inputs & outputs
Input: 1 x SD/HD/3G-SDI (BNC 75Ω)
Output: 1 x SD/HD/3G HDMI (Type A)
1 x SD/HD/3G-SDI loop (BNC 75Ω)
1 x Analog audio stereo
②Supports SD/HD/3G
③TFT-LCD Display (2.7 inch)
④Push switch for mode change
Diagram
01. ez-SHV+
(SDI to HDMI Converter with Display and Scaler)
EQ
SDI IN
SDI OUT
LCD Display
DAC
SDI RX Scaler HDMI TX
Audio OUT
HDMI OUT

6
02. Interface
Specifications
DIP Switch
Resolution and other
settings switch
SDI IN
SDI Video
input port
SDI OUT
SDI Video loop output port
DC Input
DC Power Input
+5V to +18V
AUDIO OUT
Analog audio output port
HDMI OUT
HDMI Video output
port
MODE Switch
LCD Menu setting switch

7
02. Interface
DIP Switch Settings
VIDEO OUT : Video output resolution (Position 1, 2, 3, 4)
- 720x480i@59.94 (DIP SW : 1111)
- 720x576i@50 (DIP SW : 0111)
- 1280x720p@50 (DIP SW : 1011)
- 1280x720p@59.94 (DIP SW : 0011)
- 1280x720p@60 (DIP SW : 1101)
- 1920x1080i@50 (DIP SW : 0101)
- 1920x1080i@59.94 (DIP SW : 1001)
- 1920x1080i@60 (DIP SW : 0001)
- [email protected] (DIP SW : 1110)
- 1920x1080p@24 (DIP SW : 0110)
- 1920x1080p@25 (DIP SW : 1010)
- 1920x1080p@29.97 (DIP SW : 0010)
- 1920x1080p@30 (DIP SW : 1100)
- 1920x1080p@50 (DIP SW : 0100)
- 1920x1080p@59.94 (DIP SW : 1000)
- 1920x1080p@60 (DIP SW : 0000)
RATIO : Video output screen ratio (Position 5)
- FULL 16:9 (DIP SW : 1)
- Latter 4:3 or Pillar Box (DIP SW : 0)
BRIGHTNESS : LCD brightness (Position 6)
- Dark (DIP SW : 1)
- Bright(DIP SW : 0)

8
02. Interface
LCD Displays
1080P601080i30
SHORT
Input Resolution
SDI Input resolution
* Shown as “Unknown”
where there is no input.
* If input is 3G Level-B,
1080P60B will be displayed.
Input cable length
Shows approximated cable
length in 3 stages
(SHORT, MEDIUM, LONG).
* Please refer to the chart
below for your reference.
* Reference cable is
Belden 1694A cables.
Input video
SDI input video display
* In case 3G-SDI Level-B
is inserted, grey scale
bars will be shown instead
Input Audio Level Bar
Shows Audio Level Bar
if input audio signal
quality is poor.
Input SDI Eye Pattern
Shows thick eye
pattern if input video
signal quality is poor.
HDMI Output Resolution
* Resolution configured
through DIP Switch
Output Resolution
SHORT medium l ong
SHORT medium l ong
SHORT medium l ong

9
02. Interface
LCD Displays
Output Resolution ①LCD Display ON/ OFF
Turn off the display by pressing
and holding the mode switch for
less than 6 sec
Turn on the display by pressing
and holding the mode switch for
less than 6 sec

10
②SDI input eye pattern or audio level meter
Turn on the eye pattern by
pressing the mode switch for
less than 1 sec.
Turn on audio level meter by
pressing the mode switch for
less than 1 sec.
02. Interface
LCD Displays
