Lumantek ez-HSV+ User manual

Operation manual
ez-HSV+
HDMI to SDI
Converter with
Display and Scaler

REVISION NUMBER: 1.0.0
DISTRIBUTION DATE: MARCH. 2019
Copy Rights
Copyright © 2006~2019 LUMANTEK Co., Ltd.
All Rights Reserved
This document contains information that is proprietary to LUMANTEK.CO., LTD. The
information in this document is believed to be accurate and reliable; however, LUMANTEK
assumes no responsibility or liability for any errors or inaccuracies that may appear in this
document, nor for any infringements of patents or other rights to third parties resulting
from its use.
This publication may contain technical issues, inaccurate information or typos. These will be
revised in revised edition, if there is any. No part of this publication is subject to be
reproduced, stored in retrieval system, or transmitted in any forms, or any means without
the prior consent by Lumantek.
Trademarks
HD ENCODULATOR TM, SD ENCODULATOR TM LUMANTEK Logo, Mega CruiserTM, ORIXTM,
X-CruiserTM, DTA-PlusTM, Media BlasterTM, are Trademarks of Lumantek. Co., Ltd.
Any other trademarks than stated above in this document belongs to its pertinent
corporation.
Warranty Period
Lumantek’s products comes with One(1) year limited warranty. Please contact below if you
need more information.
LUMANTEK CUSTOMER SERVICES
[email protected]
TEL:[phone]
FAX:[phone]

Introduction
ez-HSV+(HDMI to SDI Converter with Display and Scaler)
ez-HSV+ is an HDMI to SDI with Scaler Converter with 1 x HDMI input and 2 x SDI outputs. It
receives External Analog Audio (Stereo) input which can be embedded into the video.
Ez-HSV+ is a mini converter that can display incoming video through 2.7inch TFT-LCD. The
display shows input audio level meter and input & output resolutions. Resolution can be up
or down scaled (from 480i to 1080p60) with a DIP switch.
Features
① Supports SD/HD/3G
② HDMI Video In: : SD/HD/3G (HDMI Type A) x1
③ SDI Video Output: SD/HD/3G-SDI (BNC 75Ω) x2
④ Audio IN: Analog audio (3.5mm Stereo Jack) x1
⑤ LCD Display :2.7inch TFT-LCD x1
⑥ MODE : Push Switch x1
Block Diagram
LCD Display
HDMI IN
AUDIO IN
SDI OUT
SDI OUT
Scaler
DAC
SRC
MUX
SDI TX
HDMI RX
01. Introduction

02. Product Interface
HDMI IN
HDMI Video Input Port
DC Input
DC Power Input
+5V to +18V
DIP Switch
DIP Switch
6 Position for
Mode Setting
MODE
LCD Menu Setting Switch
SDI OUT
SDI Video Output Port
AUDIO In
Analog Audio Input Port
System Information
LCD
2.7inch
TFT LCD
1080p601080i60 EXT

VIDEO OUT : Output Video Resolution Settings (Position
1, 2, 3, 4)
- 720x480i@59.94 (DIP SW : 1111)
- 720x576i@50 (DIP SW : 0111)
- 1280x720p@50 (DIP SW : 1011)
- 1280x720p@59.94 (DIP SW : 0011)
- 1280x720p@60 (DIP SW : 1101)
- 1920x1080i@50 (DIP SW : 0101)
- 1920x1080i@59.94 (DIP SW : 1001)
- 1920x1080i@60 (DIP SW : 0001)
- [email protected] (DIP SW : 1110)
- 1920x1080p@24 (DIP SW : 0110)
- 1920x1080p@25 (DIP SW : 1010)
- 1920x1080p@29.97 (DIP SW : 0010)
- 1920x1080p@30 (DIP SW : 1100)
- 1920x1080p@50 (DIP SW : 0100)
- 1920x1080p@59.94 (DIP SW : 1000)
- 1920x1080p@60 (DIP SW : 0000)
RATIO : Output Video Screen Ratio (Position 5)
- FULL 16:9 (DIP SW : 1)
- Latter 4:3 or Pillar Box (DIP SW : 0)
AUDIO : Input Audio Settings (Position 6)
- INT. (DIP SW : 1)
- EXT. (DIP SW : 0)
02. Product Interface
DIP Switch setting

Input Resolution
Input HDMI signal resolution
(Shows UNKNOWN with no signal)
Output Resolution
Shows SDI output resolution
(set by DIP Switch)
1080P601080i30 EXT
Input Audio
If DIP Switch Audio settings is
set to external, then shows
“EXT”. If DIP Switch Audio
setting is set to internal,
shows nothing.
Input Audio level meter
Left and right level of Input Audio signal
02. Product Interface
LCD Screen Configuration

① LCD Backlight brightness control (Dark or Bright)
Turns dark when pressing
for less than 1 second
Turns bright when pressing
for less than 1 second
02. Product Interface
MODE Switch Settings
1080p601080i60 EXT
1080p601080i60 EXT

Turn LCD Screen OFF by
pressing and holding button
between 1~6 seconds
Turn LCD Screen ON by
pressing and holding for
less than 6 seconds
② LCD Screen ON/OFF
02. Product Interface
MODE Switch Settings
1080p601080i60 EXT

Rotates to 180 degrees
when pressed for
more than 6 seconds
Rotates to 0 degrees
when pressed for
more than 6 seconds
▶ LCD Screen rotation (0 or 180 degrees)
02. Product Interface
MODE Switch Settings
1080p601080i60 EXT
1080p601080i60 EXT
1080p601080i60 EXT

03. Product Configuration
Adaptor Specification
AC Input : AC100 to 240V,50/60Hz
DC Output : DC12V, 1A
ez-HSV+ body AC to DC adapter

Data Input
Analog Audio Input: Stereo Jack x1
HDMI Video Input : SD/ HD/ 3G (HDMI Type A) x 1
Video Formats:
- 720x480i@59.94/60
- 720x576i@50
- 1280x720p@50/59.94/60
- 1920x1080i@50/59.94/60
- [email protected]/24/25/29.97/30
- 1920x1080p@50/59.94/60
Data Output
SDI Video Output: SD/HD/3G-SDI (BNC 75Ω) x1
Video Formats:
- 720x480i@59.94 (DIP SW : 1111)
- 720x576i@50 (DIP SW : 0111)
- 1280x720p@50 (DIP SW : 1011)
- 1280x720p@59.94 (DIP SW : 0011)
- 1280x720p@60 (DIP SW : 1101)
- 1920x1080i@50 (DIP SW : 0101)
- 1920x1080i@59.94 (DIP SW : 1001)
- 1920x1080i@60 (DIP SW : 0001)
- [email protected] (DIP SW : 1110)
- 1920x1080p@24 (DIP SW : 0110)
- 1920x1080p@25 (DIP SW : 1010)
- 1920x1080p@29.97 (DIP SW : 0010)
- 1920x1080p@30 (DIP SW : 1100)
- 1920x1080p@50 (DIP SW : 0100)
- 1920x1080p@59.94 (DIP SW : 1000)
- 1920x1080p@60 (DIP SW : 0000)
Connections
Power : DC Power Input (DC Jack) x1
DIP Switch : (6 Pole) x1 Video In/Out Resolution,
Video Output Ratio, Audio(INT. or EXT.)
MODE : (Push Switch) x1 LCD ON/OFF, Menu
Selection
Display
2.7 inch TFT LCD : Input Video
Display, In/Output Video
Resolution Display,
Input Audio Level Meter Display
Electrical
Power Input: DC +5V to +18V
Power Consumption: 4W(max.)
Operation Temperature: 0~45℃
Physical
Dimension: 86.3x57.2x26.6 (include
connector)
Weight: 0.66lbs (0.3 kg)(typ.)
04. Technical Specification
