Lumenier LUX-H7 Installation guide

Apr.2021 Rev 1.0 www.getfpv.com
FLIGHT CONTROLLER LUX-H7
BASIC MANUAL
MCU: STM32H743VIT6, 480MHz , 1MB RAM, 2MB Flash
IMU: MPU6000 (SPI1) & ICM20602 (SPI4)
Baro: Infineon DPS310 (I2C2)
OSD: AT7456E (SPI2)
Blackbox: MicroSD card socket (SDIO)
7x UARTs (1,2,3,4,6,7,8) with built-in inversion.
13x PWM outputs(including “LED” pad)
2x I2C ports
1x CAN bus
6x ADC
USB Type-C(USB2.0)
2x JST-SH1.0_8pin connector for 4in1 ESC
1x JST-SH1.0_8pin connector for DJI FPV Air Unit
Dual Camera Inputs switch
9V ON/OFF switch
Vbat Input: 6~36V (2~8S LiPo)
BEC 5V 2A cont. (Max.3A)
BEC 9V 2A cont. (Max.3A)
Firmware
ArduPilot: MATEKH743
BetaFlight: MATEKH743
Mounting: 30.5 x 30.5mm, Φ4mm with Grommets Φ3mm
Dimensions: 36 x 36 x 5 mm

DPS
310
C1: Camera-1 video IN (Default)
C2: Camera-2 video IN
*** C1/C2 can be switched via ArduPilot Relay
or Modes/USER2 (BetaFlight)
VTx: Video OUT for Video Transmitter
LED 3.3: Red, 3.3V Status
LED 1: Green, FC Status
LED 0: Blue, FC Status
C-L: CAN bus Low
C-H: CAN bus High
Rx6: UART6-RX for Serial_RX by default
PPM share RX6 pad
Tx6: UART6-Tx
LAYOUT
VB2: 1K:20K Voltage divider built-in
Max.69V supported
BATT2_VOLT_PIN 18,
BATT2_VOLT_MULT 21
Betaflight voltage meter scale 210
MCU PIN PA4(A04)
CU2: For external current sensor2, 0~3.3V
BATT2_CURR_PIN 7
MCU PIN P74(A07)
AirS: Analog Airspeed sensor (0~6.6V)
20K:20K voltage divider built-in
ARSPD_PIN 4
DA2 & CL2: I2C2
Rssi: Analog RSSI IN, 0~3.3V
RSSI_ANA_PIN 8 (ArduPilot)
Buz- & 5V: Passive 5V buzzer
Rx6-SBus Jumper
If using non-DJI FPV remote controller,
keep this pad unbridged
If using DJI FPV Remote Controller,
Bridging this pad will link Rx6 to SBus pin
on JST-SH-6P connector
Tx7/Rx7: UART7_Tx & Rx
CTs7/Rts7: UART7_CTS/RTS for ArduPilot telemetry
Tx2/Rx2: UART2_Tx & Rx
DA1 & CL1: I2C1, for compass
4V5: 4.4~4.8V, Max.500mA
*** the voltage is also supplied when connecting via USB
S1-S12: PWM1~PWM12
LED: 2812LED signal, PWM13(ArduPilot)
Tx8 & Rx8: UART8_Tx & Rx
CU1: current sensor signal IN, 0~3.3V
BATT_CURR_PIN 11
Vbat: Battery Voltage IN, 6~36V DC
Battery Voltage divider: 1K:10K
BATT_VOLT_PIN 10
BATT_VOLT_MULT 11
BF voltage meter scale 110
G: Ground
Vbat: Battery Voltage IN, 6~36V DC
Battery Voltage divider: 1K:10K
BATT_VOLT_PIN 10
BATT_VOLT_MULT 11
BF voltage meter scale 110
*** DO NOT connect different batteries to “Vbat” in parallel
G: Ground
Rx8: UART8_Rx for BL32_ESC telemetry
CU1: current sensor signal IN, 0~3.3V
MCU pin PC1(C01)
CU2: current sensor2 IN, 0~3.3V
MCU pin PA7(A07)
If using CU2 as current ADC in Betaflight
CLI: resource ADC_CURR 1 A07
3V3: LDO 3.3V
swd: SWDIO
swc: SWCLK
9V: onboard regulator 9V 2A cont. Max.3A
*** ON/OFF switchable via ArduPilot Relay or Modes/USER1 (Betaflight), Default ON
5V: onboard regulator 5V 2A cont. Max.3A
G: Ground
Tx1/Rx1: UART1_Tx & Rx
Tx3/Rx3: UART3_Tx & Rx
Tx4/Rx4: UART4_Tx & Rx
BlackBox
MicroSD Socket
MCU
STM32H743VIT6
CAN
Size & Weight: 36x36x6mm /7g
Holes: Φ4mm, 30.5mm x 30.5mm
Packing
1x LUX-H7
2x JST-SH-8P cable 5cm
2x JST-SH-8P connector
1x JST-SH-6P to JST-GH-8P cable 8cm for DJI air unit
6x M3 Silicon Grommets
MPU
6000
ICM
20602
OSD
AT7456E
5V Reg.
9V Reg.
DPS310
TYPE-C
USB2.0
BOOT
Vbat
G
CU1
RX8
S1
S2
S3
S4
JST-SH-8P
Vbat
G
CU2
RX8
S5
S6
S7
S8
JST-SH-8P
9V
G
Tx3
Rx3
G
SBus
JST-SH-6P
9V
G
Tx3
Rx3
G
SBus
JST-SH-6P
Apr.2021 Rev 1.0 www.getfpv.com

Apr.2021 Rev 1.0 www.getfpv.com
ArduPilot hwdef: MATEKH743
BetaFlight target: MATEKH743
M8
M7
M6
M5
CRNT
TLM
GND
VBAT
LIPO
4in1 ESC
w/ one current sensor
M4
M3
M2
M1
CRNT
TLM
GND
VBAT
LIPO
4in1 ESC
w/ one current sensor
Wiring (Multirotors)
with BetaFlight firmware
*** SBUS/IBUS/DSM can be connected to any spare UART_RX
*** FPort, SmartPort, SRXL can be connected to any spare UART_TX
*** PPM share Rx6 pad, must disable Serial RX on UART6
CRSF
Gnd
5V
CH1
CH2
G
4V5
Rx6
Tx6
Gnd
5V
FPORT/S.Port/SRXL
FPORT
SRXL
G
4V5
Tx6
Gnd
5V
PPM/IBUS/DSM
G
4V5
Rx6
G
4V5
Rx6
Tx7
Gnd
5V
SBUS
SmartPort
SBUS
BlackBox
MicroSD Socket
MCU
STM32H743VIT6
This Side UP by default
CAN
LUX-H7 has betaflight firmware preloaded for QC
BetaFlight Target MATEKH743 is supported since 4.3, pls download BetaFlight firmware 4.2.x from our website.
It is highly recommended to use STM32CubeProgrammer to erase MCU and upload ArduPilot firmware.
If H743 MCU will not initialize with Ardupilot firmware, Pls follow this wiki to fix
https://ardupilot.org/copter/docs/common-when-problems-arise.html#h7-autopilot-will-not-initialize
MPU
6000
ICM
20602
OSD
AT7456E
5V Reg.
9V Reg.
DPS310
TYPE-C
USB2.0
BOOT
Vbat
G
CU1
RX8
S1
S2
S3
S4
JST-SH-8P
Vbat
G
CU2
RX8
S5
S6
S7
S8
JST-SH-8P
9V
G
Tx3
Rx3
G
SBus
JST-SH-6P
If using DJI FPV Remote Controller, Bridging this pad will link Rx6 to SBus pin on JST-SH-6P connector
If using other remote controllers, keep this pad unbridged
Passive 5V buzzer
DO NOT connect different batteries voltage to “Vbat” in parallel.
The 2nd battery voltage can be connected to “VB2” for voltage sensing
VB2 pad supports 0~69V
BF CLI: resource ADC_BATT 1 A04, scale 210
CU1: current sensor signal IN, 0~3.3V, MCU pin PC1(C01)
CU2: current sensor2 IN, 0~3.3V, MCU pin PA7(A07)
If using CU2 as current ADC in Betaflight, CLI: resource ADC_CURR 1 A07

Apr.2021 Rev 1.0 www.getfpv.com
Analog video wiring
with BetaFlight firmware
*** SBUS/IBUS/DSM can be connected to any spare UART_RX
*** FPort, SmartPort, SRXL can be connected to any spare UART_TX
*** PPM share Rx6 pad, must disable Serial RX on UART6
CRSF
Gnd
5V
CH1
CH2
G
4V5
Rx6
Tx6
Gnd
5V
FPORT/S.Port/SRXL
FPORT
SRXL
G
4V5
Tx6
Gnd
5V
PPM/IBUS/DSM
G
4V5
Rx6
G
4V5
Rx6
Tx7
Gnd
5V
SBUS
SmartPort
SBUS
BlackBox
MicroSD Socket
MCU
STM32H743VIT6
This Side UP by default
CAN
Passive 5V buzzer
*** Two cameras should be set with identical video format,
both PAL or both NTSC
*** Double check out Camera signal and power cables before
powering them up.
*** Rx4 rail has 200ohm built-in, can be remapped as PWM camera control
(BetaFlight CLI resource camera_control 1 B08)
PWM camera control
Camera-1Camera-2
9V Power / Camera switch
9V OFF 9V ON
C1 ON & C2 OFF C2 ON & C1 OFF
No USER1 definition
9V ON by default
No USER2 definition
C1 (Camera-1) ON by default
ArduPilot Relay
Camera-1 and 9V On by default
# GPIOs
PD10 PINIO1 OUTPUT GPIO(81) //9V pad power switch
PD11 PINIO2 OUTPUT GPIO(82) //Camera switch
# RCx_OPTION: RC input option
28 Relay On/Off
34 Relay2 On/Off
RELAY_PIN 81 //Vsw GPIO
RC7_OPTION 28 //Relay On/Off, Use CH7 of Transmitter to switch 9V
RELAY_PIN2 82 //Camera switch GPIO
RC8_OPTION 34 //Relay2 On/Off, Use CH8 of Transmitter to switch camera
The configured feature will be triggered when the auxiliary switch’s pwm value becomes higher than 1800. It will be deactivated when the value falls below 1200.
Check the pwm value sent from the transmitter when the switch is high and low using the Mission Planner’s Initial Setup >> Mandatory Hardware >> Radio Calibration screen.
If it does not climb higher than 1800 or lower than 1200, it is best to adjust the servo end points in the transmitter.
BetaFlight PINIO
If using DJI FPV Remote Controller and Air Unit is powered by 9V, DO NOT enable 9V power switch, just keep it ON by default.

Apr.2021 Rev 1.0 www.getfpv.com
I/O Mapping
S1 PB0 5 V tolerant I/O PWM1 GPIO50 TIM8_CH2N
S2 PB1 3.3 V tolerant I/O PWM2 GPIO51 TIM8_CH3N
S3 PA0 5 V tolerant I/O PWM3 GPIO52 TIM5_CH1
S4 PA1 5 V tolerant I/O PWM4 GPIO53 TIM5_CH2
S5 PA2 5 V tolerant I/O PWM5 GPIO54 TIM5_CH3
S6 PA3 5 V tolerant I/O PWM6 GPIO55 TIM5_CH4
S7 PD12 5 V tolerant I/O PWM7 GPIO56 TIM4_CH1
S8 PD13 5 V tolerant I/O PWM8 GPIO57 TIM4_CH2
S9 PD14 5 V tolerant I/O PWM9 GPIO58 TIM4_CH3
S10 PD15 5 V tolerant I/O PWM10 GPIO59 TIM4_CH4
S11 PE5 5 V tolerant I/O PWM11 GPIO60
TIM15_CH1
S12 PE6 5 V tolerant I/O PWM12 GPIO61
TIM15_CH2
LED PA8 5 V tolerant I/O PWM13 GPIO62 TIM1_CH1 Group5
No pad
1K:10K divider builtin
PC0 0~36V Vbat ADC
BATT_VOLT_PIN
BATT_VOLT_MULT
10
11.0
CU1 Pad PC1 0~3.3V Current ADC BATT_CURR_PIN 11
VB2 Pad
1K:20K divider builtin
PA4 0~69V Vbat2 ADC
BATT2_VOLT_PIN
BATT2_VOLT_MULT
18
21.0
CU2 Pad PA7 0~3.3V Current2 ADC BATT2_CURR_PIN 7
RSSI Pad PC5 0~3.3V
RSSI ADC
Analog RSSI
RSSI_ANA_PIN
RSSI_TYPE
8
1
AirS Pad
20K:20K divider builtin
PC4 0~6.6V
AirS ADC
Analog Airspeed
ARSPD_PIN
ARSPD_TYPE
4
2
Digital Airspeed I2C
ARSPD_BUS 1
MS4525
DLVR-L10D
ARSPD_TYPE
1
9
Compass COMPASS_AUTODEC 1
I2C2
CL2/DA2
PB10/PB11 5 V tolerant I/O on board Baro DPS310
CAN Node
CAN_D1_PROTOCOL
CAN_P1_DRIVER
1
1
CAN GPS GPS_TYPE 9
CAN Compass COMPASS_TYPEMASK 0
CAN Airspeed sensor
ARSPD_TYPE 8
USB PA11/PA12 5 V tolerant I/O USB console SERIAL0
RX7 TX7 RTS7 CTS7 PE7/8/9/10 3.3 V tolerant I/O UART7 telem1 SERIAL1
TX1 RX1 PA9/PA10 5 V tolerant I/O USART1 telem2 SERIAL2
TX2 RX2 PD5/PD6 5 V tolerant I/O USART2 GPS1 SERIAL3
TX3 RX3 PD8/PD9 5 V tolerant I/O USART3 GPS2 SERIAL4
TX8 RX8 PE1/PE0 5 V tolerant I/O UART8 USER SERIAL5
TX4 RX4 PB9/PB8 5 V tolerant I/O UART4 USER SERIAL6
USART6 RC input/Receiver
RX6 SBUS/IBUS/DSM/PPM
Group1
Group2
Gourp3
Group4
PWM1~PWM13 are Dshot and PWM capable. However, mixing Dshot and norm al PWM operation for outputs is restricted into groups,
ie. enabling Ds hot for an output in a group requires that ALL outputs in that group be configured and used as Ds hot, rather than PWM outputs.
If servo and m otor are m ixed in same group, make sure this group run lowest PWM frequency according to the servo specification.
ie. Servo supports Max. 50Hz, ESC must run at 50Hz in this group.
CAN CAN1 PD0/PD1 5 V tolerant I/O
PWM
5 V tolerant I/OTX6 RX6 SERIAL7
ArduPilot
UART
PC6/PC7
ADC
I2C
I2C1
CL1/DA1 PB6/PB7 5 V tolerant I/O
S1 PB0 5 V tolerant I/O TIM3_CH3
S2 PB1 3.3 V tolerant I/O TIM3_CH4
S3 PA0 5 V tolerant I/O TIM5_CH1
S4 PA1 5 V tolerant I/O TIM5_CH2
S5 PA2 5 V tolerant I/O TIM5_CH3
S6 PA3 5 V tolerant I/O TIM5_CH4
S7 PD12 5 V tolerant I/O TIM4_CH1
S8 PD13 5 V tolerant I/O TIM4_CH2
S9 PD14 5 V tolerant I/O TIM4_CH3
S10 PD15 5 V tolerant I/O TIM4_CH4
S11 PE5 5 V tolerant I/O
TIM15_CH1
S12 PE6 5 V tolerant I/O
TIM15_CH2
LED PA8 5 V tolerant I/O
TIM1_CH1 2812LED
RX4 PB8 5 V tolerant I/O
TIM16_CH1
TX4 PB9 5 V tolerant I/O
TIM17_CH1
Vbat ADC, No pad
1K:10K divider builtin
PC0 0~36V Vbat ADC scale 110
CU1 pad PC1 0~3.3V Current ADC
VB2 Pad
1K:20K divider builtin
PA4 0~69V Vbat2 ADC scale 210
CU2 Pad PA7 0~3.3V Current2 ADC
RSSI Pad PC5 0~3.3V RSSI ADC Analog RSSI
AirS Pad
20K:20K divider builtin
PC4 0~6.6V AirS ADC Analog Airspeed
I2C1
CL1/DA1
PB6/PB7 5 V tolerant I/O Compass
qmc5883l/hmc5883l
/lis3mdl
I2C2
CL2/DA2
PB10/PB11 5 V tolerant I/O on board Barometer DPS310
USB PA11/PA12 5 V tolerant I/O USB
RX7 TX7 PE7/PE8 3.3 V tolerant I/O UART7 USER
TX1 RX1 PA9/PA10 5 V tolerant I/O USART1 USER
TX2 RX2 PD5/PD6 5 V tolerant I/O USART2 USER
TX3 RX3 PD8/PD9 5 V tolerant I/O USART3 USER
TX8 RX8 PE1/PE0 5 V tolerant I/O UART8 USER
TX4 RX4 PB9/PB8 5 V tolerant I/O UART4 USER
UART6_RX PPM & Serial RX
UART6_TX FPORT/SRXL
I2C
UART
TX6 RX6 PC6/PC7 5 V tolerant I/O
ADC
PWM
Motor
Servo
BetaFlight
