Special functions
There are two ways to activate the special functions:
1) The light is turned off:
Keep the respective button pressed for about 2 sec.
2) The light is on:
- The lamp lights with a white light setting. Keep the button for the
red LEDs pressed for about 2 sec. to activate the red special functions.
- The lamp lights with a red light setting. Keep the button for the
white LEDs pressed for about 2 sec. to activate the white special functions.
Note: It‘s not possible to switch to boost mode, while a special function is
activated.
0.05 W Diffuse low
0.5 W Diffuse middle
1 W Diffuse high
1.2 W SOS
2 W Flash
0.05 W Diffuse
0.4 W Diffuse
2 W Flash
Special functions red LEDs
Special functions white LEDs
Operation Battery and Charging
Capacity indicator:
Shortly press both buttons at the same time. The four small LEDs will show
the capacity in 25% steps. Note: It can take up to two charging processes
before the battery charging module can precisely identify the charging
status.
Boost Mode
In this mode either the white or the red LEDs are lighting in full power for
15 Sec. Regardless which light setting is activated, you can turn on this
mode by pushing the relevant button twice (doubleclick). Afterwards the
light automatically switches back to your former light setting. Note: With
less 30% battery capacity, there is no boost mode available anymore.
25-50%
0-25%
50-75%
75-100%
= 25-50%
Remaining
capacity
Example:
Reserve tank:
With aprox. 10% remaining capacity, the Penta will flash several times
and turns off afterwards. When you turn it back on, every light setting is
available (except boost mode) for the remaining capacity of the battery. You
can interrupt the battery warning by pushing the button once. The Penta will
then continue to light.
Charge:
While charging, the red LEDs turns on and will turn off, as soon as the lamp
is fully charged. While charging you can still use the capacity indicator.
Note: When key lock is activated, there‘s no charging indicator through the
red LEDs.
Attention: The maximum voltage of the power supply for charging
the battery is 6V. A higher voltage can lead to heat build-up and
defects.
