Lutron Electronics Homeworks RF Maestro HRD-6D User manual

1
Installation Instructions
Designer-Style RF Maestro® Dimmers,
Switches, and Remotes
HRD-6D, -6ND, -10D, -10ND, -5NE*, -8ANS
HD-RD, -RS
120/127 V ~, 50/60Hz
Operation of a low-voltage circuit with lamps inoperative
or removed may result in transformer overheating and
premature failure. Lutron strongly recommends the
following:
a. Do not operate low-voltage circuits without operative
lamps in place.
b. Replace burned-out lamps as quickly as possible.
c. Use transformers that incorporate thermal protection
or fused transformer primary windings to prevent
transformer failure due to overcurrent.
Load Specifications:
Control Min. Load Max. Load
-5NE 40W 500W
-6D 50W/VA 600W/VA
-10D 50W/VA 1000W/VA
-6ND 10W/VA 600W/VA
-10ND 10W/VA 1000W/VA
-8ANS 10W/VA 8A
Wallplates: Lutron Claro®and Satin ColorsTM wallplates
are recommended for best color match and aesthetic
appearance. Do not paint controls or wallplates.
Important Notes
Codes: Install in accordance with all local and national
electrical codes.
Danger: These controls must not be used to
control equipment which is not visible from
every control location. They must also not be
used to control equipment which could create
hazardous situations such as entrapment if operated
accidentally. Examples of such equipment which must not
be operated by these controls include (but are not limited
to) motorized gates, garage doors, industrial doors,
microwave ovens, heating pads, etc. It is the installer’s
responsibility to ensure that the equipment being
controlled is visible from every control location and that
only suitable equipment is connected to these controls.
Overheat Damage: To reduce the risk of overheating and
possibly damaging other equipment, do not install
to control receptacles or motor-operated appliances.
Environment: Ambient operating temperature:
0-40°C, 32-104°F, 0-90% humidity, non-condensing.
Indoor use only. It is normal for dimmers and switches to
feel warm to the touch during operation.
Spacing: If mounting one control above another, leave at
least 4.5" (114mm) vertical space between them.
Lamp Type: -6D, -6ND, -10D and -10ND are designed for
use with permanently installed incandescent, magnetic
low-voltage, or tungsten halogen only. -5NE is designed
for use with permanently installed incandescent or
electronic low-voltage only. -8ANS is designed for use
with all permanently installed lighting loads.
Low-Voltage Applications: Use -6D, -6ND, -10D and
-10ND with magnetic (core and coil) low-voltage
transformers only. Not for use with electronic (solid-state)
low-voltage transformers.
Use -5NE with electronic (solid-state) low-voltage
transformers only. Not for use with magnetic (core and
coil) low-voltage transformers.
*HRD-5NE available 2Q 2003.
Please Read Before Installing
HRD-6D
HRD-6ND
HRD-10D
HRD-10ND
HRD-5NE HD-RD
HD-RS
HRD-8ANS
Overview
The HRD-6D, -6ND, -10D, -10ND, -5NE dimmers and the
HRD-8ANS switch are for use with HomeWorks systems.
The dimmers and switch may be installed in either single-
pole, 3-way or 4-way applications.
The dimmers may be used with the HD-RD Remote
Dimmer, and the switch may be used with the HD-RS
Remote Switch for control from up to 9 additional
locations.

2
End Of Gang
End of Gang
-5NE
-6D, -6ND
-10D, -10ND
-8ANS
450W
500W/VA
800W/VA
6.5A
400W
400W/VA
650W/VA
5A
Middle of Gang
Derating Chart
Middle Of Gang
Multigang Installations
In multigang installations, several controls are grouped
horizontally in one multigang wallbox.
• When combining controls in a wallbox, derating is
required; however, no derating is required for
Remotes.
Note: Controls do not have fins that need to be removed
for multigang installations.
Control Location for Ganging
Cleaning: To clean, wipe with a clean damp cloth. DO
NOT use any chemical cleaning solutions.
Wallboxes: Lutron recommends using 3.5" (89mm) deep
wallboxes for easier installation. Several controls may be
installed in one multigang wallbox - see Derating Chart.
Single Location Installations: When using controls in
single location installations, cut off the uninsulated portion
of the control’s multi-location wire (blue wire) and cap off
using one of the provided wire connectors. DO NOT
connect the blue wire to any other wiring or to ground.
Remotes: Use only Lutron HomeWorks Maestro Remote
Dimmers (HD-RD) with -6D, -6ND, -10D, -10ND, and -
5NE controls. Use only Lutron HomeWorks Maestro
Remote Switches (HD-RS) with -8ANS controls. Up to 9
HD-RD or HD-RS controls may be used with a
HomeWorks RF Maestro Dimmer or Switch. Mechanical
3- or 4-way switches will not work.
RF Device Placement: RF Dimmers and Switches must
be located within 30 feet (10m) of an RF Signal Repeater
or an RF Processor. Remote Dimmers and Switches are
not required to be within a specific range of a repeater or
processor.
RF Dimmers or Switches cannot be controlled by the
system until they are addressed and programmed. See
the HomeWorks Utility online help.

3
Installation
Short Circuit Check: Check the installation for short
circuits before installing control(s). With power OFF,
install standard mechanical switch(es) between Hot and
load. Restore power. If lights do not work or a breaker
trips, check wiring. Correct wiring and check again.
Install control(s) only when short is no longer present.
Warranty is void if control is turned ON with a shorted
circuit.
Danger - Locate and remove fuse or lock
circuit breaker in the OFF position before
proceeding. Wiring with power ON may result
in personal injury.
1. Turn power OFF at fusebox or circuit breaker.
2. Prepare wires. When making wire connections,
follow the recommended strip lengths and
combinations for the supplied wire connectors.
Note: Wire connectors provided are suitable for
copper wire only.
Small:
Large:
3. Wire controls as follows:
Single location installation: See Wiring Diagrams 1
and 2 (page 4). When using power boosters or
interfaces, see Wiring Diagrams 5, 6, and 7 (page 5).
Note: When using controls in single location
installations, cut off the uninsulated portion of the
control’s multi-location wire (blue wire) and cap off
using one of the provided wire connectors. DO
NOT connect the blue wire to any other wiring or
to ground.
Multi-location installation: See Wiring Diagrams 3
and 4 (page 4). When using power boosters or
interfaces, see Wiring Diagrams 5, 6, and 7 (page 5).
Up to nine HD-RD or HD-RS remotes may be
connected to the -6D, -6ND, -10D, -10ND, -5NE, or
-8ANS controls.
Mounting Diagram
Control
Mounting
Screws
Wallbox
Control
Included:
Wire Connectors (4 or 5)
Mounting Screws (2)
4. Push all wires back into the wallbox and loosely
fasten the control to the wallbox using the control
mounting screws provided. Do not pinch the wires.
5. Attach Lutron Claro®or Satin ColorsTM wallplate
adapter and wallplate.
a. Loosely install control mounting screws.
b. Tighten wallplate adapter mounting screws
snug.
c. Tighten control mounting screws until
wallplate adapter is flush to wall (do not over-
tighten).
d. Snap wallplate onto wallplate adapter, and
verify that control is not submerged.
e. If control is submerged, loosen mounting
screws appropriately.
6. Restore power. Check for correct local operation (see
page 6).
Wallplate
Adapter
Mounting
Screws
Wallplate/Adapter purchased
separately.
Strip insulation .375" (10mm) for
14AWG (2.5mm2).
Strip insulation .5" (13mm) for
16AWG (1.5mm2).
Use to join one 14AWG supply wire
with one 16 or 18AWG (1.0mm2)
control wire.
Strip insulation .5" (10mm) for 10AWG (6mm2),
12AWG (4mm2) or 14AWG (2.5mm2).
Strip insulation .625" (16mm) for 16AWG (1.5mm2) or
18AWG (1.0mm2).
Use to join one or two 12 or 14AWG supply wires with one
10, 12, 14, 16 or 18AWG control wire.
Small Large

4
Multi-Location Installation1
-6D, -10D with HD-RD
120/127VAC
50/60Hz
Black
Green
Hot
Neutral
Red
Blue
Black
Green
Red
Blue
Black
Green
Red
Blue
Lighting
Load
Wiring Diagram 3
Single Location Installation with Neutral
-6ND, -10ND, -5NE, -8ANS
120/127VAC
50/60Hz
Red
Black
Blue
Green
Hot/Live
Neutral
Lighting
Load
Wiring Diagram 2
Single Location Installation
-6D, -10D
120/127VAC
50/60Hz
Dimmer
Red
Black
Blue
Green
Hot/Live
Neutral
Lighting
Load
Wiring Diagram 1
Multi-Location Installation with Neutral1, 2
-6ND, -10ND, -5NE with HD-RD, -8ANS with HD-RS
Wiring Diagram 4
Remote Dimmer
Dimmer/Switch
Dimmer
120/127VAC
50/60Hz
Black
Green
Hot
Neutral
Red
Blue
Black
Green
Red
Blue
Black
Green
Red
Blue
Lighting
Load
White
White
2Neutral wire Dimmers/Switches must be connected on the Lighting Load side of a multi-location installation.
1Up to 9 HomeWorks®Maestro®Remote Dimmers/Switches may be connected to the HomeWorks RF Maestro Dimmer/Switch.
Total Blue wire length may be up to 250' (76m).
Cap Off* Cap Off*
Remote Dimmer
Remote
Dimmer/Switch Dimmer/Switch
Remote
Dimmer/Switch
Note: When using controls in single location installations, cut off the uninsulated portion of the control’s multi-location wire (blue wire) and cap off using one of
the provided wire connectors. DO NOT connect the blue wire to any other wiring or to ground.
*

5
DIM HOT OUT HOT IN CONTR OL NEUTRAL
120/127VAC
50/60 Hz
Red
Black
Blue
Green
Hot/Live
Neutral
Lighting
Load
NGRX-PB
or
ELVI-1000
DIM HOT OUT HOT IN CONTRO L NEUTRAL SW HOT
120/127VAC
50/60 Hz
Red
Black
Blue
Green
Hot/Live
Neutral
Lutron Hi-lume®Fluorescent
Dimming Ballast(s)
FDBI-16A-120
Black
Orange
White
Installation with Power
Booster or ELV Interface1, 2
-6ND, -10ND with HD-RD
Wiring Diagram 5
Installation with Fluorescent
Dimming Ballast Interface1, 2
-6ND, -10ND with HD-RD
Wiring Diagram 6
Blue
Red
Black
White
Blue
Red
Black
Green
White
Green
N1H1DH1SH1NNHHDH1 2 3
NNHHDH123
N1H1DH1SH1N2H2DH2SH2N3H3DH3SH3
120-277VAC
50/60 Hz
Load Circuit
Hot/Live
Neutral
Hot/Live
Neutral
Control Circuit
Load
Terminals
Control
Terminals
Dimmer/Switch
HP 2•4•6TM
Hi-Power Module
120/127VAC
50/60 Hz
Red
Black
Blue
Green
Blue
Red
Black
Wiring Diagram 7
Installation with Neutral and
Hi-Power Module1, 2
-6ND, -10ND with HD-RD
-8ANS with HD-RS
White
Green
Lighting
Load
2Neutral wire Dimmers must be connected on the Interface side of a multi-location installation.
1Up to 9 HomeWorks®Maestro®Remote Dimmers may be connected to the HomeWorks RF Maestro Dimmer. Total Blue wire
length may be up to 250' (76m).
Remote
Dimmer/Switch
Dimmer
Remote Dimmer
Dimmer
Remote Dimmer

6
Local Operation
Pressing the Tapswitch on any Dimmer, Switch, or
Remote will alternately turn the lights ON and OFF.
For -5NE, -6D, -6ND, -10D, -10ND, and HD-RD, the ON
level will be the level previously set using the Dimming
Rocker to the right of the Tapswitch. The LED (on
Dimmer only) that is glowing slightly brighter than the
others indicates the level to which the lights will turn ON.
Press and hold the top or bottom of the Dimming Rocker
to raise or lower the light level. Double-tapping the
Tapswitch (on the Dimmer or the Remote) will turn the
lights ON to full. Pressing and holding the Tapswitch for
1/2 second (while ON) activates a 10-second long fade-
to-off.
Setting High/Low-End Trim (Dimmer Only)
High/Low-End levels may be adjusted with the following
procedure:
a. Press the Dimming Rocker to set the dimmer to the
desired new High/Low-End level (>50% for high-end,
<50% for low-end), and then turn OFF. Note: Middle
LED cannot be used for High-End or Low-End
settings.
b. While pressing and holding the Tapswitch:
1. The dimmer will turn ON to its preset level,
2. The preset LED will light,
3. After 10 seconds, the load will turn OFF and then
back ON,
4. The preset LED will begin to flash quickly (for two
seconds).
c. While the LED is flashing, release the Tapswitch. The
LED will remain ON and the dimmer will be at its
preset level. The High/Low-End value has been
changed.
High/Low-End levels may be restored to their factory
default setting with the following procedure:
a. Press the Dimming Rocker to set the dimmer to >50%
to reset high-end, or to <50% to reset low-end, and
then turn OFF.
b. While pressing and holding the Tapswitch:
1. The dimmer will turn ON to its preset level,
2. The preset LED will light,
3. After 10 seconds, the load will turn OFF and then
back ON,
4. The preset LED will begin to flash quickly (for two
seconds) and then turn OFF. Continue holding the
Tapswitch for at least six seconds after the LED
stops flashing.
c. The load will turn OFF then back ON to its preset
level. The preset LED will flash (for two seconds) and
then remain ON. The default High or Low-End value
has been restored.
Lamp Replacement
For routine lamp replacement, remove power from the
fixture(s) by sliding the Front-Accessible Service Switch
(FASS) to the OFF position (left). After replacing lamps,
slide the FASS back to the ON position (right) to restore
power.
Danger - For any procedure other than routine
lamp replacement, power must be
disconnected at the main electrical panel.
Status LEDs
(Dimmer only)
Indicate light level; glow softly as night
light when light is off
Tapswitch
Tap on/off
Dimming Rocker
Press to Brighten
Press to Dim
FASSTM
Front
Accessible
Service
Switch
OFF ON
Status LED
(Switch only)
Indicates light status; glows softly as night
light when light is off
Tapswitch
Tap on/off
FASS
Front
Accessible
Service
Switch
ON
Dimmer Operation
Switch Operation
OFF

7
Troubleshooting Guide
Symptom Cause and Action
No lights at all
Lights turn ON when
Tapswitch is pressed, then
turn OFF
Light turns ON and OFF
continuously
Lights don’t switch when
Tapswitch is pressed
Lights don’t switch ON/OFF
when HD-RD or HD-RS
Tapswitch is pressed
Lights don’t switch ON/OFF
from Keypad
Wallplate is warm
Power not present
• Circuit breaker OFF or tripped. Perform Short Circuit Check (see page 3).
• FASSTM in the OFF position. Move FASS to the ON position by sliding it to the right. Check both the
dimmer/switch and all of the remote dimmers/switches.
Wiring
• Wires shorted. Make sure the blue wires are not grounded or shorted to any other wires.
• Wiring error. Check wiring to be sure it agrees with installation instructions and wiring diagrams.
Lamps burned out
• Replace lamps.
Dioded lamps
• If dioded lamps are being used, replace with non-dioded lamps.
Wiring
• Wiring error. Check wiring to be sure it agrees with installation instructions and wiring diagrams.
Tapswitch stuck
• Tapswitch stuck at another location. Check to see that tapswitches are not sticking for all control
locations in the circuit.
Load is less than minimum load requirement
• Make sure the connected load meets the appropriate minimum load requirement for that control. See
Load Specifications (page 1).
Wiring
• Wires shorted. Make sure the blue wires are not grounded or shorted to any other wires.
• Wiring error. Check wiring to be sure it agrees with installation instructions and wiring diagrams.
Wiring
• Wires shorted. Make sure the blue wires are not grounded or shorted to any other wires.
• Wiring error. Check wiring to be sure it agrees with installation instructions and wiring diagrams.
Improper programming
• Check programming in HomeWorks®Utility.
Out of RF range
• Reposition RF Signal Repeater or RF Processor to be within 30 feet (10m) of control.
Wiring
• Wires shorted. Make sure the blue wires are not grounded or shorted to any other wires.
• Wiring error. Check wiring to be sure it agrees with installation instructions and wiring diagrams.
Solid-state control dissipation
• Solid-state dimmers and switches internally dissipate about 2% of the total connected load. It is normal
for dimmers and switches to feel warm to the touch during operation.

Lutron Electronics Co., Inc.
7200 Suter Road
Coopersburg, PA 18036-1299
Made and printed in the U.S.A. 02/03 P/N 043-109 Rev. A
LIMITED WARRANTY
Lutron will, at its option, repair or replace any unit that is defective in materials or manufacture
within two years after purchase. For warranty service, return unit to place of purchase or mail
to Lutron at 7200 Suter Rd., Coopersburg, PA 18036-1299, postage pre-paid. Telephone the
Lutron Technical Support Center toll free at 800-523-9466. After the two year period, a pro-
rated warranty applies to this product until eight years after the purchase. For more
information regarding this warranty contact your Lutron representative.
THIS WARRANTY IS IN LIEU OF ALL OTHER EXPRESS WARRANTIES, AND THE
IMPLIED WARRANTY OF MERCHANTABILITY IS LIMITED TO TWO YEARS FROM
PURCHASE. THIS WARRANTY DOES NOT COVER THE COST OF INSTALLATION,
REMOVAL OR REINSTALLATION, OR DAMAGE RESULTING FROM MISUSE, ABUSE,
OR IMPROPER OR INCORRECT REPAIR, OR DAMAGE FROM IMPROPER WIRING OR
INSTALLATION. THIS WARRANTY DOES NOT COVER INCIDENTAL OR
CONSEQUENTIAL DAMAGES. LUTRON’S LIABILITY ON ANY CLAIM FOR DAMAGES
ARISING OUT OF OR IN CONNECTION WITH THE MANUFACTURE, SALE,
INSTALLATION, DELIVERY, OR USE OF THE UNIT SHALL NEVER EXCEED THE
PURCHASE PRICE OF THE UNIT.
This warranty gives you specific legal rights, and you may also have other rights which vary
from state to state. Some states do not allow limitations on how long an implied warranty
lasts, so the above limitation may not apply to you. Some states do not allow the exclusion
or limitation of incidental or consequential damages, so the above limitation or exclusion may
not apply to you.
Technical and Sales Assistance
If you need assistance, call the toll-free Lutron
Technical Support Center. Please provide exact
model number when calling.
[phone] (U.S.A., Canada and the Caribbean)
Other countries call:
Tel: [phone]
Fax: [phone]
Visit our Web site at www.lutron.com
These products may be covered under one or more of the following U.S. patents:
4,835,343; 4,889,999; 4,954,768; 5,038,081; 5,170,068; 5,237,207; 5,248,919; 5,399,940;
5,510,679; 5,637,930; 5,736,965; 5,798,581; 5,838,226; 5,848,054; 5,905,422; 5,982,103;
D353,798 and corresponding foreign patents. U.S. and foreign patents pending. Lutron,
Claro, Maestro, Hi-Lume and HomeWorks are registered trademarks and Satin Colors, HP
2•4•6, FASS and the HomeWorks Logo are trademarks of Lutron Electronics Co., Inc.
© 2003 Lutron Electronics Co., Inc.
FCC Information
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the seperation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution: Changes or modifications not expressly approved by Lutron Electronics Co. could
void the user’s authority to operate this equipment.
Industry Canada Information
The term “IC:” before the radio certification number only signifies that Industry Canada
technical specifications were met.
