Luxier SP07-SS User manual

1Luxier SP07-SS Rev. A3 122017
Features
- Stunning stylish European inspired design
- Durable stainless steel frame construction
- 3 adjustable angle chrome ABS square massage jets with 25 nozzles on each jet
- 4 stage shower functions (Rainfall, Waterfall, Massage Spray, Hand Shower)
- 50 total rainfall nozzles
- Contemporary brass hand shower
Luxier SP07-SS

2Luxier SP07-SS Rev. A3 122017
Thank you for purchasing Luxier products. Please read the information below and keep this
installation guide for future reference. If you require assistance, please contact our customer service
department at 1-877-711-8828, Monday - Friday 9AM - 5PM Pacifi c Time. Or by email at
[email protected].
Limited Two (2) Year Warranty (For USA Only)
The manufacturer warrants this product to be free of manufacture defects during daily normal
household use for as long as it is owned by the original purchaser of this product. Please keep a
copy of the original invoice as proof of purchase.
Should a malfunction occur within the warranty period, Luxier USA will, as its option, (1)
repair or replace the defective part(s) or product(s) at no charge; (2) issue a refund of the original
purchase price of the product(s) (Valid within 30 days from the date of purchase); or (3) issue a
credit to be applied toward the purchase of a new Luxier product. Shipping/delivery charges
may apply and are in Luxier USA’s sole discretion.
This limited warranty shall not apply to goods which have been subject to accident, negligence,
improper installation, product abuse, product misuse, or use of cleaners containing abrasives, alcohol
or other organic solvents, whether performed by a contractor, service company, or yourself, are
excluded from this warranty.
Our responsibility under this limited warranty is limited to only to replacement parts and no other
costs. Luxier USA will not be responsible for labor charges and/or damage incurred by installation,
repair or replacement, nor for any indirect incidental or consequential damages, losses, injury or costs
of any nature relating to this product. Except as provided by law, this limited warranty
is in lieu of and excludes all other warranties, conditions, and guarantees, whether expressed or
implied, statutory or otherwise, including without restriction those merchantability of fi tness for use.
This limited warranty is non-transferable. This limited warranty only applies to products purchased
and installed in the United States. This limited warranty covers the original consumer purchase only
and does not include business, commercial or industrial use of this product. To obtain service under
the Limited Warranty, please contact Luxier USA at [email protected]. The Luxier USA Custom-
er Care Department will determine whether to repair or replace your product, issue a refund, or issue
a credit.

3Luxier SP07-SS Rev. A3 122017
Attention
• This installation guide is subject to change without notice, please contact us to request the most
updated version of this installation guide.
• This is a general installation guideline, actual installation may vary. Consult a professional if
necessary.
• Product drawings in this installation guide is for illustration purpose only. Actual product may vary
depends on model.
• Always take extra precautions and wear appropriate safety equipment when installing this product.
• Proper water pressure needs to be maintained to prevent possible scalding.
• Stainless steel shower panels are handmade and assembled. Product dimensions may vary
slightly, always measure the actual product before installation.
You may also need the following tools
1. Thread Sealant Tape, (PTFE Tape) 5. Pencil or Marker
2. Silicon Sealant 6. Level
3. Phillips Screw Driver 7. Hammer
4. Drill with ¼” Drill bit
Before You Begin
• Read and understand this instructions completely before installation.
• Unpack and inspect the shower panel from the package for shipping damage and make sure all
parts are included with the shower panel.
• Keep the product in its package until you are ready to install.
• Read and understand this installation guide completely.
• Make sure the installation site is clean and free of dust and debris.
• Please make sure the water supply is shut o󰀨 to the installation area. If necessary, shut o󰀨 the
water to the entire house.
• Turn on the water at a bathroom faucet in the house to relieve the pressure in the plumbing
system.
Rough-In
• Please follow all local building and plumbing codes.
• The height and placement of the shut o󰀨 valves will be based on the installation height of
the shower panel, see fi gure A. The installation height is approximately the total distance of
measurement A and measurement B.
• The fi nished wall opening for the valves should not be larger than 4.5” wide by 6” tall. Make sure
the opening is completely waterproof to prevent any water leaking into the wall space. (NOTE:
Product warranty does not cover any damages caused by water leak due to negligent and
improper installation of the shut o󰀨 valves and the shower panel.)
• An outlet box such as the Sioux Chief Ox BoxTM 696-G2001MF, 696-G2303MF, or 696-2403MF is
recommended to expedite the installation process of the shut o󰀨 valves. (NOTE: additional parts
such as brass reducer / adapters are required but not included with this product)

4Luxier SP07-SS Rev. A3 122017
Recommended
10” - 12”
Approximate shower inlet
valve location
approx. outlet
box location
(This is the distance from the oor
to the bottom edge of the shower
panel)
* Shower panel drawing on this page is for
illustration purpose only. Actual product may
vary depends on model.
Fig. A
(This is the distance from the bottom
edge of the shower panel to the
shower panel inlet valve. NOTE: This
distance vary by models, always take
the actual measurement from the
shower panel)
A
B
The installation height of the outlet box
is approximately the total distance of
measurement A and measurement B.
It is recommened to aim the top hori-
zontal body jets at the chest area of the
user for optimal showering experience.

5Luxier SP07-SS Rev. A3 122017
Technical / Flow Rate Data
Recommended Operating Pressure: 50-70 PSI
180mm
7.1”
490mm
19.29”
560mm
22.05”
1,580mm
62.2”
810mm
31.89”
310mm
12.2”
60mm
2.36”
660mm
25.98”
*All Measurements are Approximate

6Luxier SP07-SS Rev. A3 122017
Parts List
01. Shower Panel Body
02. Hand Shower Water Connector
03. Rubber Washer
04. Hand Shower
05. Hand Shower Cradle
06. Rubber Washer
07. Hand Shower Hose
08. Screws X 4
09. Mounting Brackets X 2
10. Wall Anchors X 4
1
234
5
6
8
7
910

7Luxier SP07-SS Rev. A3 122017
Installation
1. Install hand shower cradle (1) to the shower
panel by installing the rubber washer (2) and
the locking nut (3) and attach white plastic
hose tube connector (5) with PVC tubing to
complete the connection. (NOTE: Make sure
the silicon gasket (4) is seated properly inside
the connector.)
1
2
3
45
810mm
31.89”
3. Using a drill with a tile bit, drill the hole
slowly into the tile. Do not drill into any piping
or wiring in the wall. Insert the anchors into
the wall.
1”
2. Mark the positions of the 2 brackets on the
wall and prepare the tile wall for drilling. Use
a piece of painters tape or masking tape over
the drill area to prevent damages to the tiles.
(NOTE: The distance between the two
brackets should be 810 mm or 31.89”)

8Luxier SP07-SS Rev. A3 122017
Installation (cont.)
4. Secure the mounting brackets to the wall
with the screws.
5. Apply thread sealant tape to the threading
on the shut o󰀨 valves before connect both hot
and cold water supply hoses to the valves.
IMPORTANT :
- Make sure the water supply hoses are
connected to the corresponding valves - i.e.
cold water hose to the cold water valve and
the same for hot water hose. The mixing valve
will not function properly if the hoses are
installed incorrectly.
- Before hanging the shower panel on the
wall. Turn on both valves and test all functions
on the shower panel and check for leaks at
this point. You should have good water ow to
the shower panel and full temperature control
from the knobs.

9Luxier SP07-SS Rev. A3 122017
Installation (cont.)
6. Once the shower panel has been tested for
functions and leaks. Hang the unit on the wall
to complete the installation. Due to the limited
space behind the shower panel, do not bend
the hoses. Any restrictions in the water supply
hoses will greatly reduce the performance of
the shower panel. After the shower panel is
set properly on the wall, apply silicon sealant
on both sides of the shower panel to prevent
the unit from moving.
(NOTE: Do not seal the bottom of the panel.)
7. Connect hand shower hose to the main
panel body and connect the hand shower
wand to the hose. Make sure the silicon
gaskets are seated properly to prevent water
leak.

10Luxier SP07-SS Rev. A3 122017
Operation
Water Functions
Horizontal Body Jets
Handheld Shower
Overhead Rainfall Jets
Overhead Waterfall
Hot Cold
Flow Control
Functions
1. Turn the Functions button to select the desired
water feature.
2. Lift up the handle on the Flow Contrl to turn on the
water ow.
3. Swivel the handle from side to side to set the wa-
ter temperature.
Maintenance Guide
Please follow the cleaning material manufacturer’s instructions. In addition, pay attention to the
following points:
1. Regular cleaning can prevent mineral build up on shower head and handheld shower.
2. Use a mild detergent such as liquid dishwashing soap and warm water for cleaning.
3. Do not use abrasive / harsh chemical when cleaning the fi xture as they will damage and dull the
fi nish.
3. Carefully read the cleaner product label to ensure the cleaner is safe for use on the material.
4. Test the cleaner on a small area before using on the entire surface.
5. Do not leave the cleaner on the fi xture longer than necessary.
6. When using spray cleaners, spray fi rst onto a soft cloth or sponge. Never spray directly onto the
faucet as droplets can enter openings and gaps and cause damage.
5. After cleaning, rinse thoroughly with clean water to remove any cleaner residue.
6. Wipe dry with soft cloth to keep shower panel surface spot free.
