Luxier SP27-GS-WHT User manual

1Luxier SP27-GS Rev. A4 092017
Luxier
SP27-GS-WHT (White)
SP27-GS-BLK (Black)
SP27-GS-SLR (Silver)
SP27-GS-AQU (Aqua Blue)
Features
- Stunning stylish European inspired design
- Square thin prole shower head with adjustable shower arm
- 8 swivel massage jets
- 3 stage shower functions (Rainfall, Massage Spray, Hand Shower)
- Elegant safety tempered glass panel (Available in white, black, silver, and aqua blue colors)
- Battery / hydro opereated LCD temperature display

2Luxier SP27-GS Rev. A4 092017
Thank you for purchasing Luxier products. Please read the information below and keep this
installation guide for future reference. If you require assistance, please contact our customer service
department at 1-877-711-8828, Monday - Friday 9AM - 5PM Paci c Time. Or by email at
[email protected].
Limited Two (2) Year Warranty (For USA Only)
The manufacturer warrants this product to be free of manufacture defects during daily normal
household use for as long as it is owned by the original purchaser of this product. Please keep a
copy of the original invoice as proof of purchase.
Should a malfunction occur within the warranty period, Luxier USA will, as its option, (1)
repair or replace the defective part(s) or product(s) at no charge; (2) issue a refund of the original
purchase price of the product(s) (Valid within 30 days from the date of purchase); or (3) issue a
credit to be applied toward the purchase of a new Luxier product. Shipping/delivery charges
may apply and are in Luxier USA’s sole discretion.
This limited warranty shall not apply to goods which have been subject to accident, negligence,
improper installation, product abuse, product misuse, or use of cleaners containing abrasives, alcohol
or other organic solvents, whether performed by a contractor, service company, or yourself, are
excluded from this warranty.
Our responsibility under this limited warranty is limited to only to replacement parts and no other
costs. Luxier USA will not be responsible for labor charges and/or damage incurred by installation,
repair or replacement, nor for any indirect incidental or consequential damages, losses, injury or costs
of any nature relating to this product. Except as provided by law, this limited warranty
is in lieu of and excludes all other warranties, conditions, and guarantees, whether expressed or
implied, statutory or otherwise, including without restriction those merchantability of  tness for use.
This limited warranty is non-transferable. This limited warranty only applies to products purchased
and installed in the United States. This limited warranty covers the original consumer purchase only
and does not include business, commercial or industrial use of this product. To obtain service under
the Limited Warranty, please contact Luxier USA at [email protected]. The Luxier USA Custom-
er Care Department will determine whether to repair or replace your product, issue a refund, or issue
a credit.

3Luxier SP27-GS Rev. A4 092017
Attention
• This installation guide is subject to change without notice, please contact us to request the most
updated version of this installation guide.
• This is a general installation guideline, actual installation may vary. Consult a professional if
necessary.
• Product drawings in this installation guide is for illustration purpose only. Actual product may vary
depends on model.
• Always take extra precautions and wear appropriate safety equipment when installing this product.
• Proper water pressure needs to be maintained to prevent possible scalding.
• Stainless steel shower panels are handmade and assembled. Product dimensions may vary
slightly, always measure the actual product before installation.
You may also need the following tools
1. Thread Sealant Tape, (PTFE Tape) 5. Pencil or Marker
2. Silicon Sealant 6. Level
3. Phillips Screw Driver 7. Hammer
4. Drill with ¼” Drill bit
Before You Begin
• Read and understand this instructions completely before installation.
• Unpack and inspect the shower panel from the package for shipping damage and make sure all
parts are included with the shower panel.
• Keep the product in its package until you are ready to install.
• Read and understand this installation guide completely.
• Make sure the installation site is clean and free of dust and debris.
• Please make sure the water supply is shut o󰀨 to the installation area. If necessary, shut o󰀨 the
water to the entire house.
• Turn on the water at a bathroom faucet in the house to relieve the pressure in the plumbing
system.
Rough-In
• Please follow all local building and plumbing codes.
• The height and placement of the shut o󰀨 valves will be based on the installation height of
the shower panel, see  gure A. The installation height is approximately the total distance of
measurement A and measurement B.
• The  nished wall opening for the valves should not be larger than 4.5” wide by 6” tall. Make sure
the opening is completely waterproof to prevent any water leaking into the wall space. (NOTE:
Product warranty does not cover any damages caused by water leak due to negligent and
improper installation of the shut o󰀨 valves and the shower panel.)
• An outlet box such as the Sioux Chief Ox BoxTM 696-G2001MF, 696-G2303MF, or 696-2403MF is
recommended to expedite the installation process of the shut o󰀨 valves. (NOTE: additional parts
such as brass reducer / adapters are required but not included with this product)

4Luxier SP27-GS Rev. A4 092017
Recommended
10” - 12”
Approximate shower inlet
valve location
approx. outlet
box location
(This is the distance from
the oor to the bottom
edge of the shower panel)
* Shower panel drawing on this page is for
illustration purpose only. Actual product may
vary depends on model.
Fig. A
(This is the distance from
the bottom edge of the
shower panel to the
shower panel inlet valve.
NOTE: This distance vary
by models, always take the
actual measurement from
the shower panel)
A
B
The installation height of the outlet box
is approximately the total distance of
measurement A and measurement B.
It is recommened to aim the top hori-
zontal body jets at the chest area of the
user for optimal showering experience.

5Luxier SP27-GS Rev. A4 092017
Technical Data
Recommended Operating Pressure: 50-80 PSI
320.5mm
12.62”
245mm
9.65”
1300mm
51.18”
710mm
27.95”
270mm
10.63”
403.5mm
15.89”
76mm
2.99”
78mm
3.07”
590mm
23.23”
*All Measurements are Approximate

6Luxier SP27-GS Rev. A4 092017
Parts List
01. Adjustable Shower Arm
02. Rubber Washer
03. Shower Head
04. Shower Panel Body
05. LCD Temperature Display
06. Tub Spout
07. Battery Compartment
(2 AA batteries not included)
08. Locking Nut
09. Rubber Washer
10. Rainfall Shower Supply Connector
11. Hand Shower Supply Connector
12. Rubber Washer
13. Hand Shower Cradle
14. Rubber Washers
15. Hand Shower Hose
16. Screw x 4
17. Mounting Bracket x2
18. Wall Anchors x 4
19. Hand Shower
1
2
3
4
5
6
7
14
13
12
11
8910
15
16 17
18
19

7Luxier SP27-GS Rev. A4 092017
Installation
123
2. Install hand shower connector and attach
PVC tubing to complete the connection.
1
2
3
45
1. Attach the adjustable shower arm assembly
to the panel body. Make sure to install screen
washer to protect shower head from debris in
the plumbing system.
3. Mark the positions of the 2 brackets on the
wall and set a side the panel. (NOTE: The
distance between the two brackets should be
710mm or 27.95”)
710mm
27.95”

8Luxier SP27-GS Rev. A4 092017
Installation (cont.)
4. Using a drill with a tile bit, drill the hole
slowly into the tile. Do not drill into any piping
or wiring in the wall. Insert the anchors into
the wall. (NOTE: Before installing the wall
anchors, use a small piece of painters tape
or masking tape over the drill area. This will
prevent damages to the tile)
1”
5. Secure the mounting brackets to the wall.
6. Apply thread sealant tape to the threading
on the shut o󰀨 valves before connect both hot
and cold water supply hoses to the valves.
Turn on the valves and check all connections
for possible leaks.

9Luxier SP27-GS Rev. A4 092017
7. Hang the unit on the wall to complete the
installation. Make sure the unit is seated prop-
erly. Apply silicon sealant on left and right
sides of the shower panel. (NOTE: do not seal
the bottom of the panel, this will allow any
possible future leaks to drain out the panel)
8. Attache shower head. Apply some (NOTE:
PTFE tape on the thread to prevent leaking)
Installation (cont.)
9. Connect hand shower hose to the main
panel body and connect hand shower to the
hose. Make sure to install the rubber washers
in the connections.

10Luxier SP27-GS Rev. A4 092017
Installation (cont.)
1
234
5
6
100oF
11. This LCD display is powered by running
water and 2 AA batteries. With the water
running on the shower panel. Press the small
button under the digital screen to display
current water temperature. The display will
automatically shutdown about 18 seconds
after the water is turned o󰀨.
10. For your convenience, a small screwdriver
(6) is included with the unit for battery
replacement. Use the screwdriver to remove
the 4 small screws (5) on the battery
compartment door (3). Please make sure 2
AA batteries (2) are properly installed in the
battery compartment (NOTE: batteries not
included). And make sure the silicon gasket
is seated properly to waterproof the battery
assembly. Once the batteries are install, press
down the main power switch (4) to provide
power to the digital display.

11Luxier SP27-GS Rev. A4 092017
Operation
1. Turn the bottom control knob to turn on water and to set desired water temperature.
2. Press the small button under the LCD screen to display water temperature.
3. Turn the top knob to select shower functions.
Overhead Rainfall Shower
Horizontal Body Jets
Handheld Shower
Tub Spout
Maintenance Guide
Please follow the cleaning material manufacturer’s instructions. In addition, pay attention to the
following points:
1. Regular cleaning can prevent mineral build up on shower head and handheld shower.
2. Use a mild detergent such as liquid dishwashing soap and warm water for cleaning.
3. Do not use abrasive / harsh chemical when cleaning the  xture as they will damage and dull the
 nish.
3. Carefully read the cleaner product label to ensure the cleaner is safe for use on the material.
4. Test the cleaner on a small area before using on the entire surface.
5. Do not leave the cleaner on the  xture longer than necessary.
6. When using spray cleaners, spray  rst onto a soft cloth or sponge. Never spray directly onto the
faucet as droplets can enter openings and gaps and cause damage.
5. After cleaning, rinse thoroughly with clean water to remove any cleaner residue.
