Luxier SP06-CEC User manual

Luxier SP06-CEC Rev. A 1020191
Features
- EZ-Connect: Connects to existing shower plumbing
- Elegant & Durable stainless steel frame construction
- 4 stage shower function (Rainfall, Waterfall, Horizontal Massage Jets, Hand Shower)
- 2 ABS square message body jets with adjustable angle
SP06-CEC

Luxier SP06-CEC Rev. A 1020192
Thank you for purchasing Luxier products. Please read the information below and keep this
installation guide for future reference. If you require assistance, please contact our customer service
department at 1-877-711-8828, Monday - Friday 9AM - 5PM Paci c Time. Or by email at
[email protected].
Limited Two (2) Year Warranty (For USA Only)
The manufacturer warrants this product to be free of manufacture defects during daily normal
household use for as long as it is owned by the original purchaser of this product. Please keep a
copy of the original invoice as proof of purchase.
Should a malfunction occur within the warranty period, Luxier USA will, as its option, (1)
repair or replace the defective part(s) or product(s) at no charge; (2) issue a refund of the original
purchase price of the product(s) (Valid within 30 days from the date of purchase); or (3) issue a
credit to be applied toward the purchase of a new Luxier product. Shipping/delivery charges
may apply and are in Luxier USA’s sole discretion.
This limited warranty shall not apply to goods which have been subject to accident, negligence,
improper installation, product abuse, product misuse, or use of cleaners containing abrasives, alcohol
or other organic solvents, whether performed by a contractor, service company, or yourself, are
excluded from this warranty.
Our responsibility under this limited warranty is limited to only to replacement parts and no other
costs. Luxier USA will not be responsible for labor charges and/or damage incurred by installation,
repair or replacement, nor for any indirect incidental or consequential damages, losses, injury or costs
of any nature relating to this product. Except as provided by law, this limited warranty
is in lieu of and excludes all other warranties, conditions, and guarantees, whether expressed or
implied, statutory or otherwise, including without restriction those merchantability of  tness for use.
This limited warranty is non-transferable. This limited warranty only applies to products purchased
and installed in the United States. This limited warranty covers the original consumer purchase
only and does not include business, commercial or industrial use of this product. To obtain service
under the Limited Warranty, please contact Luxier USA at [email protected]. The Luxier USA
Customer Care Department will determine whether to repair or replace your product, issue a refund,
or issue a credit.

Luxier SP06-CEC Rev. A 1020193
Attention
• This installation guide is subject to change without notice, please contact us to request the most
updated version of this installation guide.
• This is a general installation guideline, actual installation may vary. Consult a professional if
necessary.
• Product drawings in this installation guide is for illustration purpose only. Actual product may vary
depends on model.
• Always take extra precautions and wear appropriate safety equipment when installing this product.
• Proper water pressure needs to be maintained to prevent possible scalding.
• Stainless steel shower panels are handmade and assembled. Product dimensions may vary
slightly, always measure the actual product before installation.
You may also need the following tools
1. Thread Sealant Tape, (PTFE Tape) 5. Pencil or Marker
2. Silicon Sealant 6. Level
3. Phillips Screw Driver 7. Hammer
4. Drill with ¼” Drill bit
Before You Begin
• Read and understand this instructions completely before installation.
• Please follow all local building and plumbing codes.
• Unpack and inspect the shower panel from the package for shipping damage and make sure all
parts are included with the shower panel.
• Keep the product in its package until you are ready to install.
• Read and understand this installation guide completely.
• Make sure the installation site is clean and free of dust and debris.
• Please make sure the water supply is shut o󰀨 to the installation area. If necessary, shut o󰀨 the
water to the entire house.
• Turn on the water at a bathroom faucet in the house to relieve the pressure in the plumbing
system.
Before installation begins, measure the distance
between the existing shower head and the control
to make sure there is su󰀩cient space to t the
shower panel. The distance needs to be 34” - 42”
to t the shower panel.
Distance required for
proper installation:
34” - 42”

Luxier SP06-CEC Rev. A 1020194
EZ Connect let’s you quickly install the shower panel to the
existing shower plumbing with ease.
EZ Connect Diagram
2. Connect shower panel water supply
hose to the existing plumbing
1. Remove existing shower head assembly
BEFORE AFTER

Luxier SP06-CEC Rev. A 1020195
Technical Data
Recommended Operating Pressure: 60 - 80 psi
Flow Rate: 1.8 gpm at 80 psi
NOTE: This product is equipped with a water saving device with restricted ow rate as required by the state of California.
To learn more about this water saving feature, please contact our customer service department.
1050 mm
41.34”
140 mm
5.51”
459.5 mm
18.09”
444 mm
17.48”
450 mm
17.2”
65 mm
2.56”
190 mm
7.48”
* Drawings not to scale. All measurements are approximate *

Luxier SP06-CEC Rev. A 1020196
Parts List
01. Overhead Rainfall Shower Box
02. Shower Panel Body
03. Hand Shower Water Connector
04. Locking Nut
05. Gasket
06. Hand Shower
07. Hand Shower Cradle
08. Rubber Gasket
09. Hand Shower Hose
10. Overhead Waterfall Unit
11. Main Water Supply Hose
12. Cover
13. Base
14. Hose Clamp
15. Elbow Connector
16. Brass Nipple
17. Screws X 4
18. Mounting Brackets X 2
19. Wall Anchors X 4
20. Check Valve
1
2
3456
7
8
9
10
11
12
13
14
15
16
17 18
19
20

Luxier SP06-CEC Rev. A 1020197
1. Remove existing shower head and shower arm.
2. Connect the 3” brass nipple to the water pipe inside
the wall. Leaving about 1” of the connector outside
the wall.
(NOTE: Apply PTFE tape on both end of the
connector.)
(IMPORTANT: Insert the brass nipple with ow
restricting device end rst into the wall. Failuare
to follow this step will result in no water ow to the
shower panel. See gure A)
Teon (PTFE) Tape
To Wall To Shower Panel
white plastic restrictor
Figure A
Installation
1
2
3
45
3. Install hand shower cradle (1) to the shower panel
by installing the rubber washer (2) and the locking nut
(3) and attach white plastic hose tube connector (5)
with PVC tubing to complete the connection.
(NOTE: Make sure the silicon gasket (4) is seated
properly inside the connector.)

Luxier SP06-CEC Rev. A 1020198
1”
Installation (cont.)
4. Lift the panel to determine the proper height and
placement. It is recommened to aim the top horizon-
tal body jet to the chest area for optimal showering
experience. Mark the positions of the 2 brackets on
the wall and set a side the panel.
(NOTE: The distance between the two brackets
should be 444 mm or 17.48”)
444 mm
17.48 ”
5. Using a drill with a tile bit, drill the hole slowly into
the tile. Do not drill into any piping or wiring in the
wall. Insert the anchors into the wall.
(NOTE: Before drilling the tiles, use a small piece of
painters tape or masking tape over the drill area. This
will prevent damages to the tiles)
6. Secure the mounting brackets to the wall.
7. Hang the unit on the wall to complete the
installation. Due to the limited space behind the
shower panel, do not bend the hoses. Any restrictions
in the water supply hoses will greatly reduce the
performance of the shower panel.

Luxier SP06-CEC Rev. A 1020199
Installation (cont.)
8. Measure the length needed for the main water
supply hoses. Trim o󰀨 the excess PVC tubing.
9. After the excess hose has been trimmed. First slip
hose clamp (B) onto the PVC hose (C). Insert the
elbow connector (A) into the hose. Push the hose
(B) up toward the end of the hose. Tighten the hose
clamp (B)
(NOTE: Do not over tighten the clamp)
A
B
C
10. Wipe the surrounding surface around the pipe free
of dirt and debris. Peel o󰀨 the adhesive backing of the
cover base (A) and press it rmly against the wall to
ensure a tight bond. Apply some PTFE tape on the
pipe threading. Connect the main water supply hose
assembly to the pipe.
(NOTE: Do not over tighten the nut as it may damage
the seal and causes leaks) Once the connection is
made, install the cover over the elbow connector.
A
B
11. Connect hand shower hose to the main panel
body and connect the hand shower wand to the hose.
Make sure the silicon gaskets are seated properly
to prevent water leak. Run water to the unit for few
minutes and check for leaks at all connections.

Luxier SP06-CEC Rev. A 10201910
Operation
1. To use your new Decor Star shower panel, rst turn on the water supply at the existing valve (B)
and divert the water to the shower panel.
2. Use the control knob (A) to select the desired shower function.
3. This product is equipped with a water saving device with restricted ow rate as required by the
state of California. To learn more about this water saving feature, please contact our customer
service department.
Horizontal Body Jets
Handheld Shower
Overhead Jets
Overhead Waterfall
A
B
Maintenance Guide
Please follow the cleaning material manufacturer’s instructions. In addition, pay attention to the
following points:
1. Regular cleaning can prevent mineral build up on shower head and handheld shower.
2. Use a mild detergent such as liquid dishwashing soap and warm water for cleaning.
3. Do not use abrasive / harsh chemical when cleaning the  xture as they will damage and dull the
 nish.
4. Carefully read the cleaner product label to ensure the cleaner is safe for use on the material.
5. Test the cleaner on a small area before using on the entire surface.
6. Do not leave the cleaner on the  xture longer than necessary.
7. When using spray cleaners, spray  rst onto a soft cloth or sponge. Never spray directly onto the
faucet as droplets can enter openings and gaps and cause damage.
8. After cleaning, rinse thoroughly with clean water to remove any cleaner residue.
9. Wipe dry with soft cloth to keep shower panel surface spot free.
