LUXTEC CLX User manual

User Manual for CLX Xenon Light Source
ENGLISH

TABLE OF CONTENTS
Table of Symbols ……………………………………………………..…1
General Warnings ……………………………………………………… 2
Overview ………………………………………………………………... 3
Operation ……………………………………………………………….. 4
Xenon Lamp Replacement …………………………………………. 5-6
Optional Floor Stand Installation ………………………………….….. 7
Equipment & Parts List ...…………………………………………….... 8
Troubleshooting …...……………………………………………….…... 9
Maintenance and Cleaning .……………………………………….…. 10
Specifications .…………………………………………………….…… 10
Electromagnetic Compatibility (EMC) User Information .…….…11-14
Product Warranty .…………………………………………………….. 15
Repair and Return .……………………………………………………. 15
TABLE OF SYMBOLS
Found on Light Source
Attention: Consult
Accompanying Documents Stand-by
Type CF Equipment
High Voltage Fuse ETL listed
High Temperature “ON” (power) CE marking of conformity
Equipotentiality “OFF” (power)
-1-

GENERAL WARNINGS
FIRE HAZARD: Do Not drape or cover the light source while it is operating
EXPLOSION HAZARD: Do Not use in the presence of flammable anesthetics.
ELECTRIC SHOCK HAZARD: Do Not Open the light source if it is not functioning properly or if damage
is apparent (such as case damage or loose screws). Refer to the Repair and Return Section of this
Manual.
•The User of this equipment should carefully read the Users Manual and be familiar with the set-up,
use, and care of the light source before using it. The instructions in the Users Manual should be
followed carefully with special attention to warnings and control features on the light source. The
Users Manual should be readily available to users and other appropriate personnel.
•Before each use ensure that the light source is not damaged and is operating properly. Ensure that
cooling vents and fans are free of obstruction.
•The light source generates high intensity light that can heat objects in its path. This light can cause
flammable materials to burn or cause burns to skin. Prevent flammable materials from coming into
close proximity with the output of the light source and light cable.
•The light emitted from the light source and the light cable can cause eye damage if viewed directly for
more than momentary periods of time. Do not look directly into the light source or the cable.
Do not point the light cable at another person’s eyes. For this reason this product must not be used
in ocular surgery or in any surgical procedure requiring direct illumination of the eye.
•Avoid extreme heat or jarring of the light source to maintain the integrity of the Xenon lamp.
Refer to the Xenon Lamp Replacement Section of this Manual when replacing the lamp or removing
it for any reason.
•Follow the instructions of other manufacturers equipment when using them in conjunction with this
light source.
•This product must be removed from the surgical field prior to use of a defibrillator.
•Before any service, disconnect the power cord from the main outlet.
Medical Electrical Equipment such as the CLX Light Source require special precautions regarding
electromagnetic compatibility or EMC. These precautions are defined on pages 11 thru 14 of this Users
Manual. The CLX must be installed and put into service according to the EMC information provided.
The leakage current of medical electrical devices can be additive. When using the CLX in combination
with other medical electrical devices, such as endoscopes and/or endoscopically-used accessories, the
leakage current should be verified to ensure it continues to meet requirements.
-2-

OVERVIEW
Indication for Use
This device is designed to supply high-intensity white light to a fiber optic cable for illumination of a surgical field or
other area of examination or operation. The Light Source should never be used in ocular surgery or in a surgical
procedure requiring direct illumination of the eye.
The CLX delivers white Xenon light. The lamp can be easily replaced by the user without special tools.
The rear panel, main power on/off rocker switch, is located on the back of the CLX. See Figure 1. The front panel
push button, on / standby switch, is used to select lamp on or lamp standby. See Figure 2.
The intensity of the light output is controlled manually by rotating the attenuator ring, clockwise to increase intensity,
counter-clockwise to decrease intensity.
CLX Rear View Figure 1 Figure 2
CLX Front View
Main power on/off switch
Power cord receptacle
On / standby switch
Fiber optic port
Attenuator ring
Inspection Before Use
The CLX light source comes with a hospital grade power cord. Please verify that both the light source and the
power cord have been received undamaged.
All fiber optic light guides should be properly cleaned and sterilized prior to first time use. See light guide
manufacturer’s manual for information.
Warnings
FIRE HAZARD: DO NOT DRAPE OR COVER THE LIGHT SOURCE WHILE IT IS OPERATING.
Explosion Hazard. Do not use in the presence of flammable anesthetics, liquids, vapors, gases or dusts.
Electric shock hazard. If unit is not functioning properly, DO NOT OPEN.
Please refer to the Repair and Return Section of this Manual.
Use care not to point any light guide directly at the eye while operating the Light Source.
Keep cooling and fan vents free of obstructions.
Do not use or store liquids on or above the Light Source.
When Light Source is not in use, turn off the power switches on both the front and the back of the CLX.
Setting Up
Before turning power on, make sure the unit is plugged into any standard 100V to 240V 50/60Hz (as appropriate)
three-conductor outlet. Grounding reliability is guaranteed only when connected to a “hospital grade” receptacle.
-3-

OPERATION
Controlling Lamp Operation
The main power on/off switch is used to power the
unit on or off. See Figure 3.
The on / standby switch is used to select lamp on
or lamp standby. See Figure 4.
The light source requires both the main power and
the standby switches to be in the “on” state for the
lamp to operate.
When the lamp starts operating, there is a brief
clicking sound, which is normal. If the main power
on/off switch is used to toggle lamp operation,
leaving the standby switch in the “on” state, then
there will be a short delay (3 or 4 seconds), after
turning the main power switch to the “on” position,
before the lamp will energize. This delay will not
occur when the standby switch is used to control
the lamp.
Note that if the light source is left in standby, with
power applied, with the main power on/off switch in
the “on” position and the on / standby switch in the
standby state, the unit will consume a small amount
of power and be slightly warm to the touch. This is
normal and permits the lamp to quickly energize
with the on / standby switch.
When the lamp is operating there is light visible
through the vent holes and the fan grill.
Light Attenuation
The CLX has a manually operated light intensity
ring to control the desired light output level. To
increase the light output, rotate the ring clockwise
until the desired level is reached. See Figure 5.
Figure 5
CLX Front View
Figure 3
CLX Back View
Main power on/off switch
On / standby switch
Attenuator ring
Retaining screw
Figure 4
Attenuator ring
-4-

XENON LAMP REPLACEMENT
Warnings:
Disconnect the light source from main power and allow the equipment to cool before handling the
Xenon lamp. Use protective eye, face, and hand equipment when handling the Xenon lamp. Please
know that Xenon lamps have been known to explode. The chance of this happening when the lamp is
handled properly is very low. The chance of injury if the lamp should explode are very high if the
proper precautions are not taken. The chance of a lamp failure while the light source is not in
operation is very rare. Each lamp is tested thoroughly during manufacture to ensure against failure.
Figure 7
Figure 6
Retaining clips (locked)
Replace lamp when illumination is no longer satisfactory or sufficient for use.
To remove the lamp:
1. Make sure the main power on/off switch is turned off. Disconnect the power cord.
2. Allow the unit to cool down for a minimum of 15 minutes before replacing the lamp. The lamp may represent a
burn hazard if not allowed to cool sufficiently prior to servicing the unit.
3. Remove the retaining screw located at the back of the at the CLX. See Figure 3.
4. Slide the top cover of the CLX towards the back of the unit. Do not slide the cover off completely, rather just
enough to remove and replace the lamp. See Figure 6.
5. Unlock the lamp retaining clips holding the lamp in the CLX. Grasp and pull the lamp straight up. See Figure 7.
-5-

XENON LAMP REPLACEMENT
To replace the lamp:
1. Orient lamp to face forward. See Figure 8. Lower lamp into the CLX with lamp against fan. See figure 9.
The lamp receptacles must engage with lamp base plugs. Press firmly into place to seat lamp.
Note: Do not touch lamp glass window.
2. Snap the lamp retainer clips, located on each side of the lamp, onto the top of the lamp. The lamp is now in a
locked position. See Figure 6.
3. Fully slide the top cover of the CLX forward. Install the retaining screw (Figure 3) using a screwdriver.
4. Connect power cord to the back of the CLX. Set main power on/off switch to the “on” position then press on /
standby switch to turn the unit “on”.
5. Adjust attenuator ring to verify that the unit emits light.
Figure 9
Figure 8
Forward
Lamp module
Lamp disposal:
No disposal restrictions are known for the Xenon lamp. User should check and follow any applicable federal,
state and/or local regulations.
To dispose of Luxtec Xenon lamps, simply break the fill tab to release any remaining gas and then dispose of the
lamp with no environmental concerns. Luxtec lamps are constructed entirely of metal, sapphire and ceramic.
No organic (carbon-based) materials, mercury, rare-earth elements, or any other materials with disposal
problems are used in the construction of our lamps. The Xenon fill gas is an inert gas and is non-toxic.
-6-

OPTIONAL FLOOR STAND INSTALLATION
Figure 8
Power cord
hanger
Upper column
Lower column
Caster base
Figure 9
There are four (4) parts to the floor stand
assembly: See Figure 8.
1. Caster base
2. Two-piece column
3. Light source base with cable hangers
4. Handle
Floor stand assembly instructions:
1. Assemble the column. Note arrow on the
lower column must point up. Slide the
upper column over the arrow end of the
lower column. Seat firmly.
2. Insert assembled column into base. Seat
firmly.
3. With the handle screw positioned at the
top of the handle, slide the handle onto the
upper column so there is about 5 inches
(13 cm) of space between the handle and
the top of the column. Tighten handle
screw to hold in place.
4. Fully insert post of the CLX base plate into
plastic bushing on top of upper column.
Rotate base plate until fingers in the
bushing engage slots at the bottom of the
post.
5. Loosen handle screw and position handle
opposite power cord hanger. Adjust
height as preferred by user, and firmly
secure handle screw.
6. Secure CLX to base plate by aligning
mounting screws to screws holes on
bottom surface of CLX and tighten. See
Figure 9.
Handle
Mounting screws CLX base
plate
Handle screw
-7-

EQUIPMENT & PARTS LIST
To place an order, contact your local Luxtec distributor or call Luxtec Customer Service at
800-325-8966 (USA) or [phone] (International).
Light Source
00-CLX CLX, Xenon light source
850358 User Manual for the CLX
Adapter Options
401193 Storz adapter
Lamp
00-1187 CLX Lamp replacement module
Power Cords
601949-AUSTL6M Australian Power Cord 6m
601949-EUR6M European Power Cord 6m
601949-UK6M UK Power Cord 6m
601949-US6.1M Hospital Grade USA Power Cord 20‘
Other parts
005418 CLX floorstand bracket (top base)
601919 Fuse, 3.15A 250VAC, 5x20mm, Slo-Blo IEC Standard
Front View Rear View
-8-

TROUBLESHOOTING
Problem Cause Action
No light output Both switches are not “on”
Power not applied to the unit
Attenuator closed
Blown fuse
Turn main power switch on/off and on/
standby switch “on”
Ensure the power cord is connected to
a live, hospital-grade, receptacle
Rotate attenuator clockwise
Replace fuse as indicated in
maintenance section
No light output and unit
is making clicking
sound
Lamp is too old or is defective
A lamp is not installed Replace/Install lamp. See lamp replacement section of this user manual
Reduced light output Attenuator mis-positioned
Aged or defective lamp
Headlight or fiber optic light
guide is damaged
Rotate attenuator
Replace lamp
Check or replace faulty component
Unit feels warm when
not on Main power switch is on (Figure 3) This is normal when main power switch is on and stand by switch is off
CLX enclosure is
overheated Possible fan failure Return the unit (See Return and Repair section of this user manual)
MAINTENANCE AND CLEANING
Maintenance:
If the Light Source does not operate properly when connected to a grounded receptacle, disconnect
the power cord and check the fuse (see below). Do not attempt to repair the unit if the lamp fails in
use. Turn off the unit and allow it to cool for at least 15 minutes, then try to restart the unit. If the lamp
still fails to illuminate, it may need to be replaced. If you still experience difficulties, return the unit to
Luxtec or an authorized distributor for evaluation.
To replace the fuse:
The fuses for the Light Source are located in the power entry module in the rear of the unit. Remove
the power cord from the unit. Using a small flat head screwdriver, open fuse access cover then pry out
the red plastic fuse holder from the power entry module. Check to see if the fuses are blown. If
necessary, replace the fuse(s) with a new one of the same rating (Fuse 3.15A, 250VAC, 5x20 mm,
Slo-Blo, IEC Standard, Luxtec part number 601919). After replacing fuse(s), push the red plastic fuse
holder back into the power entry module and snap access cover close. Plug the cord back into Light
Source and re-test the unit.
Cleaning:
Allow unit to cool for at least 15 minutes prior to cleaning.
The Light Source exterior can be cleaned and disinfected using 70% isopropyl alcohol. Unplug the
power cord before cleaning. Allow 5 minutes for alcohol to evaporate before reconnecting to power.
Use a vacuum cleaner and a soft brush to remove visible dust accumulation from fan and vent holes
whenever necessary and always when replacing the lamp.
-9-

SPECIFICATIONS
Lamp
Type Xenon Short Arc Lamp
Wattage 150 Watts
Lamp life 500 Hours
Light Source
Dimensions 12.6"L x 6.2"W x 5.9"H
(320mm L x 157mm W x 150mm H)
Weight 9.2 lbs. (4.2kg)
Power Input 100~240VAC 50-60 Hz ± 10%
Fuses (2) 3.15A, 250VAC, 5x20 mm, Slo-Blo, IEC Standard
Power Consumption 225 Watt nominal
AC Power Leakage Leakage current to chassis (with ground wire
intact), less than 100 microamps
Leakage current to chassis (with ground wire
interrupted), less than 500 microamps
Classification Type CF, Class 1, IEC 60601-1
Conducted and radiated emissions Class A, IEC 60601-1-2
PFC Conformance Harmonics and Flicker
IEC1000-3-2 and IEC61000-3-3
Environment:
Storage 0°C - 50°C (32° - 122°F)
10-85% Relative Humidity Non-Condensing
Operating 5°C – 40°C (41° - 104°F)
0-85% Relative Humidity Non-Condensing
- 10 -

Electromagnetic Compatibility (EMC) User Information
WARNING: Medical Electrical Equipment, such as the CLX Light Source, needs special precautions regarding
Electromagnetic Compatibility (EMC) and needs to be installed and put into service according to the EMC
information provided in the following tables.
WARNING: Portable and Mobile RF Communications Equipment can affect Medical Electrical Equipment.
WARNING: The CLX Light Source should not be used adjacent to or stacked with other equipment. If this becomes
necessary the CLX should be observed to verify normal operation in the configuration in which it will be used.
NOTE: The EMC tables and other guidelines below provide information to the customer or user that is essential in
determining the suitability of the CLX Light Source for the Electromagnetic Environment of use, and in managing the
Electromagnetic Environment of use to permit the CLX Light Source to perform its intended use without disturbing
other Equipment and Systems or non-medical electrical equipment.
Guidance and Manufacturer’s Declaration – Emissions All Equipment and Systems
The CLX Light Source is intended for use in the electromagnetic environment specified below. The customer
or user of the CLX Light Source should assure that it is used in such an environment.
Emissions Test Compliance Electromagnetic Enforcement – guidance
RF Emissions
CISPR 11 Group 1 The CLX Light Source uses RF energy only for its internal function.
Therefore, its RF emissions are very low and are not likely to cause any
interference in nearby electronic equipment.
RF Emissions
CISPR 11 Class A
The CLX Light Source is suitable for use in all establishments
including domestic, and those directly connected to the public low-
voltage power supply network that supplies buildings used for domestic
purposes.
Harmonics
IEC 61000-3-2 Complies or Not applicable Complies
Flicker
IEC 61000-3-3 Complies or Not applicable Complies
- 11 -

Electromagnetic Compatibility (EMC) User Information
Guidance and Manufacturer’s Declaration—Immunity All Equipment and Systems
The CLX Light Source is intended for use in the electromagnetic environment specified below. The customer
or user of the CLX Light Source should assure that it is used in such an environment.
Immunity Test IEC 60601 Test
Level Compliance Level Electromagnetic Environment - Guidance
Electrostatic
Discharge
(ESD)
IEC 61000-4-2
±6kV contact
±8kV air
±6kV contact
±8kV air
Floors should be wood, concrete or ceramic
tile. If floors are synthetic, the relative humidity
should be at least 30%.
Electrical Fast
Transient/burst
IEC 61000-4-4
±2kV on AC Mains ±2kV on AC Mains Mains power quality should be that of a typical
commercial or hospital environment.
Surge
IEC 61000-4-5 ±1kV Differential ±2kV Common ±1kV Differential ±2kV Common Mains power quality should be that of a typical commercial or hospital environment.
Voltage dips,
short
interruptions
and voltage
variations on
power supply
input lines
IEC 61000-4-11
>95% Dip for
0.5 Cycle
60% Dip for
5 Cycles
30% Dip for
25 Cycles
>95% Dip for
5 Seconds
>95% Dip for
0.5 Cycle
60% Dip for
5 Cycles
30% Dip for
25 Cycles
>95% Dip for
5 Seconds
Mains power quality should be that of a typical
commercial or hospital environment. If the user
of the CLX Light Source requires continued
operation during power mains interruptions, it
is recommended that the CLX Light Source
be powered from an uninterruptible power
supply or battery.
Power
Frequency
50/60Hz
Magnetic Field
IEC 61000-4-8
3A/m 3A/m
Power frequency magnetic fields should be that of a typical location in a typical commercial
or hospital environment.
- 12 -

Electromagnetic Compatibility (EMC) User Information
Please note: The CLX light source has been successfully tested to IEC 60601-2-25. The
CLX was in the presence of an electrical-surgical generator, ESG, generating a field
strength of between 18 and 23 V/m. During the testing the energized probes of the
ESG were at a distance of 6" from the CLX and the ESG was energized in the cut and
coagulate modes. The functioning of the CLX was not effected by exposure to this
energy. The results of this testing are available from Luxtec.
Guidance and Manufacturer’s Declaration –
Emissions Equipment and Systems that are NOT Life-Supporting
The CLX Light Source is intended for use in the electromagnetic environment specified below. The
customer or user of the CLX Light Source should ensure that it is used in such an environment.
Immunity
Test IEC 60601 Test Level Compliance Level Electromagnetic Environment – Guidance
Conducted RF
IEC 61000-4-6
3 Vrms from
150 kHz to
80 MHz
V1 = 3 Vrms Portable and mobile RF communications equipment should
be separated from the CLX Light Source by no less than the
recommended separation distances calculated/listed below:
Radiated RF
IEC 61000-4-3
3 V/m
80 MHz to
2.5 GHz
E1 = 3V/m PD 17.1=80 to 800 MHz
PD 33.2=800 MHz to 2.5 GHz
Where P is the maximum power rating in watts and D is the
recommended separation distance in meters.
Field strengths from fixed transmitters, as determined by an
electromagnetic site survey, should be less that the
compliance levels (V1 and E1).
Interference may occur in the vicinity of equipment containing
a transmitter.
PD 17.1=
- 13 -

Electromagnetic Compatibility (EMC) User Information
Recommended Separation Distances Between Portable and Mobile RF Communications
Equipment and the CLX Light Source Equipment and Systems that are NOT Life-Supporting
The CLX Light Source is intended for use in the electromagnetic environment in which radiated disturbances are controlled. The
customer or user of the CLX Light Source can help prevent electromagnetic interference by maintaining a minimum distance between
portable and mobile RF Communications Equipment and the CLX Light Source as recommended below, according to the maximum
output power of the communications equipment.
Recommended Separation Distances for the CLX Light Source (meters)
Maximum
Output
Power
(Watts)
150 kHz to 80
MHz
Pd 17.1=
80 to 800MHz
Pd 17.1=
800 MHz to 2.5 GHz
Pd 33.2=
0.01 0.12 0.12 .023
0.1 0.37 0.37 0.74
1 1.17 1.17 2.33
10 3.69 3.69 7.38
100 11.67 11.67 23.33
- 14 -

PRODUCT WARRANTY
Luxtec warrants that the CLX light source (except the lamp) shall be free from defects
in material and workmanship under normal use and service for a period of three (3)
years from the date of shipment from Luxtec. Luxtec’s sole and exclusive liability under
the warranty shall be, at Luxtec’s option, either to repair or to replace any component
which fails during the warranty period due to any defect in workmanship or material
F.O.B. factory if:
1. Customer promptly reports such defect to Luxtec in writing,
2. If requested by Luxtec, customer returns equipment to Luxtec at the customer
expense and,
3. Upon inspection, Luxtec finds the equipment to be defective.
This warranty is contingent upon normal and proper use of the equipment. It does not
cover equipment modified without the written approval of Luxtec, subjected to unusual
physical or electrical stress, altered with non-Luxtec parts or damaged during shipment
back to Luxtec. This warranty is non-transferable unless authorized in writing by
Luxtec.
Luxtec reserves the right to make design changes on its products without liability to
incorporate said change in Luxtec products previously designed or sold.
Upon receipt of the product, it should be carefully inspected. If any defect is
discovered, Luxtec must be notified immediately.
REPAIR AND RETURN
This device must be clean of all blood or other organic material prior to returning
to Luxtec. Luxtec reserves the right to return unrepaired any equipment that is
contaminated with blood or other organic material.
Warranty Service and Repair:
To obtain service under warranty or return product for repair, the customer
should contact your local Luxtec distributor or call Luxtec Customer Service at
[phone] (US only) or [phone].
Information contained in this manual is subject to change without notice.
- 15 -

Luxtec Corporation declares that this product meets the
Essential Requirements specified in Annex 1
of the Medical Device Directive (MDD).
99 Hartwell Street • West Boylston, MA 01583• USA
Telephone: [phone] (USA only) or [phone]
Facsimile: [phone] E-mail address: [email protected]
P/N 850358 Rev D
