Luxul XAP-1500 Manual

READ ME FIRST
Fold Fold Fold
QUICK INSTALL GUIDE
High Power Dual-Band Wireless
900N Low Profi le Access Point
XAP-1500
Includes:
One: XAP-1500 Dual Band Wireless AP
One: Mounting Bracket and Hardware
One: PoE Injector and Power Cord
Two: Ethernet Cables
READ ME FIRST - AP COMPATIBILITY
This XAP-1500 is compatible with the Luxul Wireless Controller for fast, easy
confi guration and deployment of wireless networks with multiple APs.
nNote: If you’ll be using this AP with a Wireless Controller, refer to
the Quick Install Guide included with the Wireless Controller for
setup instructions.
If you’re using separately-purchased Luxul APs or installing this AP along
with a Wireless Controller in an existing Luxul deployment, you may
need to manually upgrade some of those APs fi rmware before installing
the Wireless Controller.
Luxul APs running fi rmware version 5 or later (like the one in
this package) are Wireless Controller-compatible and can
be used with the Controller as-is. When purchasing Luxul
APs for use with the Wireless Controller, look for an orange
“Version 5 Firmware” sticker on the box to avoid the manual
upgrade process.
nNote: Visit http://luxul.com/ap-upgrade for help upgrading your AP’s
fi rmware to version 5 or newer.
AP SETUP AND CONFIGURATION
1Physical Installation
The XAP-1500 access point is designed for simple and effi cient installation. It
can be mounted on the ceiling or wall with the included mount, or placed on a
fl at surface by attaching the included rubber feet to the mount.
cCaution: Attach the rubber feet to the mount and attach the mount to
the AP for fl at surface placement to avoid overheating and failure.
uSingle Access Point Placement: Because the signal generated by the
XAP-1500 is omnidirectional, the unit should be located as near as
possible to the center of the desired coverage area.
XAP-1500 Single AP Coverage Pattern
uMultiple Access Point Placement: You may need to experiment with
AP placement to optimize the roaming experience. Place APs to ensure
adequate coverage, but not so far apart that there is no signal overlap.
Adjacent APs should overlap enough that the client device has a good
connection to the AP to which it is currently attached, but also sees the
next-nearest AP. Ideally, roaming clients should see signal strength of
two overlapping APs in the range of -60 to -70 dBm at the midway
point between two APs. To learn more about AP placement, visit
luxul.com/ap-placement.
Ideally, roaming clients should see
signal strength of two overlapping
APs in the range of -60 to -70 dBm at
the midway point between two APs
XAP-1500 Multiple AP Coverage and Overlap
nNote: Consider using Ekahau HeatMapper to assist with this process,
available from www.ekahau.com. Luxul also offers an informative
“How-To” video on HeatMapper at luxul.com/how-to-videos.
LEGAL AND REGULATORY INFORMATION
No part of this publication, or any other publication may be modifi ed or adapt-
ed in any way, for any purposes without permission in writing from Luxul. The
material in this manual is subject to change without notice. Luxul reserves the
right to make changes to any product to improve reliability, function, or design.
No license is granted, either expressly or by implication or otherwise under any
Luxul intellectual property rights. An implied license only exists for equipment,
circuits and subsystems contained in this or any Luxul product.
FCC Compliance
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful inter-
ference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
FCC ID: W59XAP1500
IC: 8584A-XAP1500
FCC Statement—Wireless FCC 2.4GHz & 5GHz 802.11abgn
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules.
Hereby, Luxul, 14203 Minuteman Drive, Suite 201, Draper, Utah,
84020, declares that this Luxul XAP-1500 is in compliance with the
essential requirements and other relevant provisions of Directive
1995/5/EC.
For a copy of this report send a self addressed stamped envelope
to: Luxul CE, 14203 Minuteman Drive, Suite 201, Draper, Utah, 84020.
Industry Canada (RSS-Gen Issue 4)
CAN ICES-3(B)/NMB-3(B)
Sales
P: 801-822-5450
E: s[email protected]
Technical Support
P: 801-822-5450 Option 3
E: suppor[email protected]
© 2015 Luxul. All Rights Reserved. LUX-QIG-XAP-1500-v7 05271503
