Lynx GXR-12 User manual

USER MANUAL
V.16.04
GXR-12
Lynx Pro Audio S.L.
Valencia, Spain - www.lynxproaudio.com - [e-mail]
GXRseries

Manufacturer
CE CERTIFICACTION, EUROPEAN PRODUCT
LYNX Pro Audio S.L.
Calle 1 - Pol. Ind. Picassent
E-46220 Picassent (Valencia)
This user manual is property of Lynx Pro Audio S.L. Any reproduction of this manual, by any means is strictly prohibited.
Copyright 2016. All rights reserved.
GXR-12

LYNX Pro Audio S.L. - Valencia, Spain - www.lynxproaudio.com [e-mail]
GXR-12
CONTENTS
- SAFETY PRECAUTIONS 4
- SYSTEM OVERVIEW
GXR-12 5
BACK PANEL 6
CONNECTORS AND CONNECTIONS 6
- CONFIGURING THE DIGITAL SIGNAL PROCESSOR
CONFIGURING THE DSP OPTIONS 8
CONFIGURATION PANEL 8
SELECT THE INPUT 9
SELECTAND RUN PRESET 9
- ONLINE CONTROL SYSTEM 10
- CERTIFICATIONS AND GUARANTEE 11

LYNX Pro Audio S.L. - Valencia, Spain - www.lynxproaudio.com [e-mail]
GXR-12
Before starting to use this device, please read this instruction manual carefully.
Keepthese instructionsin theplacewheretheequipmentwillbeusedandwitheasyaccesstothem.
- Electrical appliance.
The exclamation mark within a triangle identifi es the presence of electricity. Use the system care-
fully without wet hands or feet. Avoid installing the speaker in wet or excesivelly humid places. Do
not place material that contains liquid on or near the unit. Avoid dripping or splashing water or any
liquid over the unit. Regularly check the condition of the cables and make sure these are not being
walked on or pinched. Connect the speaker to bipolar, earthed mains. The mains plug mustbe con-
nected to the appropriate protection (fuse or breaker). Connection to any other type of mains could
result in an electrical shock and violate local electrical codes. CAUTION: DO NOT CONNECT OR
DISCONNECT THE AC POWER CONNECTORS UNDER LOAD.
- Heavy equipment.
Apply back protection when using the system.Avoid loading and unloading at heights.
- Electrical shock risk.
The diagonal mark within a triangle identifi es the presence of dangerous voltage.
Do not open or handle the interior of the box. These parts are not to be adjusted by the user. For
maintenance and/or repair please go to an authorized service centre.In order to reduce the risk of
electricshock,disconnect fromACbefore pluginorunpluggingAudiosignalcables.ReconnecttoAC
onlyifallsignalconnectionsaremadeandsecured.Nevermanipulatethegroundtypeplugprovided.
TheAC mains plugs should always remain accessible for operation.
Unplug the loudspeaker during storms or when it’s being used for a long time.
- Hearing damage risk.
These systems can reproduce large quantities of sound pressure which can damage hearing. Take
precautions if you are going to be near them for extended amounts of time and do not get too close.
- Hanging – Flying.
Do not hang the cabinets from the handles or from any other part other than the designated hanging
point. When fl ying this system please observe the technical and “Rainbow” software data carefully.
Never exceed themaximum safe workingloads or ignoretheinstructionsincludedwithinthismanual.
Use Only fl ying accessories provided by Lynx Pro Audio S.L.
Rigging must be always carried out by professionals.
- Delicate Material.
Please ensure no foreign object or water enters the speaker. Only clean the unit with dry cloths. Do
not use solvents.
-Overheating – Fire risk.
To reduce the risk of the speaker over heating, avoid direct contact with sunlight.Avoid placing the
unit close to heat inducing objects such as radiators. Do not cover the equipment in use and do not
block any ventilation openings. Do not put naked fl ame, such as lighted candles, close or on top
of the unit.
- Electromagnetic and interferente emissions.
Avoid placing objects which through electromagnetic waves can damage the unit, such as mobile
phones, lap tops, magnetic strip cards etc.
This system complies with normatives EN 55103-1 (1)
EN 55103-2 (2)
(1) This device may not cause harmful interferences.
(2) This device may receive interference including interferences that may cause undesired working.
-IMPORTANT NOTE.
This Equipment must be used in accordance with these instructions and by trained professional
personnel only. This equipment should not be used in places with extreme tropical climates. Don’t
4

LYNX Pro Audio S.L. - Valencia, Spain - www.lynxproaudio.com [e-mail]
GXR-12
CABINET OVERVIEW
GXR-12
Ethernet connection is optional.
Dimmensions in mm
5

LYNX Pro Audio S.L. - Valencia, Spain - www.lynxproaudio.com [e-mail]
GXR-12
GXR BACK PANEL
USB connection
LCD display
&
digital control
Signal
Input
Signal
Output * Ethernet
OPTIONAL
Main
Link
Main
input
The rear pannel includes the connectors and digital control display.
CONNECTORS AND CONNECTIONS
SOCKET POWERCON TRUE1
CAUTION: Do not connect
or disconnect the AC Power
connectors under load.
NAC3FX-W
NAC3MX-W
* Available when the user has requested the
cabinets to be supplied with the Ethernet
Module kit.
6

LYNX Pro Audio S.L. - Valencia, Spain - www.lynxproaudio.com [e-mail]
GXR-12
CONNECTORS AND CONNECTIONS
OUTPUTS
1.- EARTH
2.- LIVE (+)
3.- LIVE (-)
INPUTS
1.- EARTH
2.- LIVE (+)
3.- LIVE (-)
XLR SOCKET CONNECTORS
XLR AEREAL CONNECTORS
Connect to output
Connect to input
2 Live(+)
3 Live(-)
1 Earth
3 Live(-)
1 Earth
2 Live(+)
7

LYNX Pro Audio S.L. - Valencia, Spain - www.lynxproaudio.com [e-mail]
GXR-12
FIR FILTERS
Finite Impulse Response (FIR) fi lters are used in the signal processing of the GXR-12 cabinet. FIR is a type of
digital fi lter with linear phase characteristics. This frees system designers from the constraints of phase
anomalies associated with analogue fi lters or their digital versions (IIR, Infi nite Impulse Response). When
properly used, FIR fi ltering can audibly improve a system’s impulse response and reduce crossover
interference.
CONFIGURING THE CABINET DSP OPTIONS
From the buttons below the display on the cabinet’s back panel you are able to confi gure the Basic adjustment
functions of the internal DSP.
Please note that you must apply the desired confi guration in each one cabinet and requires electrical power to work.
Fig 1
CONFIGURATION PANEL
On the back panel you will see 3 buttons and an information screen, on which you can read the established
parameters and information such as amplifi cation module temperature, input signal level and name of the current
preset (Fig1). If changes are not made the display will automatically dim to save energy and avoid unnecessary
light in situations where light is not wanted. To re-activate the light simply press the OK button.
8

LYNX Pro Audio S.L. - Valencia, Spain - www.lynxproaudio.com [e-mail]
GXR-12
Fig 2 Fig 3 Fig 4
SELECT AND RUN PRESET
To change the preset confi guration (see Fig 2) just press the up button (1) and down button (2) until you see
the title and present number required and once found press OK (3) until the progress bar fi nishes (Fig 3). The
display will indicate “Loading DSP” (Fig 4)
Note: In case of a power cut, the DSP will save its last confi guration when restarted.
SELECT THE INPUT: DIGITAL OR ANALOG
This selection is only available when the user has requested the cabinets to be supplied with the Digital input
kit. There are four input options: Analog / Digital L / Digital R / Digital L+R
To select the input mode just press the OK button (3) and the up button (1), both at the same time but pressing
the OK button fi rst. Then you can select one of the four options using the up button (1).
To confi rm your selection press OK (3) until the progress bar fi nishes.
The display will show an inverted D (digital) or an invertedA (analog) so you can always know if the input is
digital or analog.
23
1
9

LYNX Pro Audio S.L. - Valencia, Spain - www.lynxproaudio.com [e-mail]
GXR-12
ONLINE CONTROL SYSTEM
Who is it for?
Users of Self powered DSP incorporated Lynx ProAudio Cabinets where the user has requested the cabinets
be supplied with the Ethernet Module kit.
What is it for?
Obtain detailed information of cabinet behaviour and monitor the cabinet/s in real time. You can change the
preset, gain, mute, polarity and phase. You can also activate the air absorption compensation and select the
«SOLO» mode.
How does it work?
Via Ethernet (cable or wireless). Once installed, the O.C.S. software automatically detects all the cabinets
connected to the network and displays them in the O.C.S. window on the users PC.
What does it show?
As well as displaying the cabinet model and IP address the O.C.S will be monitoring in real time and the user
will be able to view RMS levels, Input clip, power module temperature, compression levels, air absorption
compensation and cabinet angulation.
10

LYNX Pro Audio S.L. - Valencia, Spain - www.lynxproaudio.com [e-mail]
GXR-12
DECLARATION OF CONFORMITY
LYNX Pro Audio S.L.
Calle 7 - Pol. Ind. Picassent
E-46220 Picassent (Valencia)
Lynx ProAudio S.L. declares that GR series are in conformity with the following EC directives:
Low Voltage Directive 2006/95/EC
Electromagnetic Compatibility EMC 2004/108/EC
RoHS Directive 2002/95/EC
In accordance with Harmonized European Norms:
EN 60065:2002 Audio, video and similar electronic apparatus. Safety requirements
EN 55103-1:1996 Electromagnetic compatibility. Productfamily standardfor audio, video,audiovisual
and entertainment lighting control apparatus for professional use. Part 1: Emission.
EN 55103-2:1996 Electromagnetic compatibility. Productfamily standardfor audio, video,audiovisual
and entertainment lighting control apparatus for professional use. Part 2: Immunity.
GR series models: GXR-215 / GXR-18S / GXR-15 / GXR-12
WEEE Declaration: Electrical and electronic equipment must be disposed of separately from normal waste atthe end
of its operational lifetime. Pleasedispose ofthis product according to the respective national regulations or contractual
agreements.Ifthereareanyfurther questionsconcerningthedisposal ofthisproduct pleasecontactLynxProAudioS.L.
11

LYNX Pro Audio S.L. - Valencia, Spain - www.lynxproaudio.com [e-mail]
GXR-12
LYNX PRO AUDIO GUARANTEE
Lynx products are guaranteed against every kind of manufacturing fault 2 year after the date of sale. When
products are under guarantee, the repairing and the free supplying of the device parts in order to correct any kind
of defect are guaranteed by Lynx Pro Audio S.L. In the case that the product could not be returned to the factory
for checking and repairing, Lynx Pro Audio S.L. would supply all the necessary parts.
Lynx ProAudio S.L. is not responsible forany damage ordefect caused during the transport or caused by an undue
or improper handling y a non-authorized person during the life of this guarantee.
Allourproductsundergorigoroustestsandqualitycontrols.Weguaranteethecharacteristicsdescribedherewithin
and their quality against any fabrication defect.
The user loses all warranty rights if he incorporates or carries out any modifi cation to the product, if he uses it
outside of the stated safe working loads or does not secure the system properly using all the pins in their
corresponding holes.
