QB SERIES
The QB series comprises 2 two-way, passive full range cabinets and 2 sub basses,
is the smallest series Lynx Pro Audio oers and is designed and intended for back
ground sound reinforcement where the power of the HR series is not required.
The components have been carefully selected to oer a lightweight, versatile series,
delivering a linear phase response with excellent sound distribution and delity for
background installations in bars, restaurants, conferences etc
Both QB Series Full Range cabinets are supplied with high frequency OCPP
protection (Over Current Passive protection) whilst the Sub-bass models come
with SWR (Stationary Wave Reduction) to reduce internal stationary waves.
All the cabinets are nished in rugged, premium birch plywood, coated with water-
based black paint with the QB-5 and QB-8 protected by front steel grilles all backed
with a special dark grey triple layer, acoustical textile which allows greater air ow
and reduces heat and humidity.

www.lynxproaudio.com 5
Accessories
QB-8
QB-5
Ultra-compact, full range,
two way passive cabinet
for background sound
reinforcement.
It consists of a 5” transducer
and a 1” high frequency
neodymium tweeter.
It oers 90ºconic dispersion
and 113 dB SPL peak (160W
program).
High performance, ultra-
compact, full range, two
way passive cabinet.
It consists of a 8” transducer
and a 1” high frequency
tweeter.
It o ers 90º conic
dispersion and 120 dB SPL
peak (300W program).
LF 1 x 5″ transducer / HF 1 x 1″ tweeter Components LF 1 x 8″ transducer /HF 1 x 1″ tweeter
65 Hz – 20 KHz (-10 dB) Frequency range 50 Hz – 22 KHz (-10 dB)
75 Hz – 18 KHz± 3 dB Frequency Response 60 Hz – 20 KHz± 3 dB
88 dB (1W @ 1m) Sensitivity 92 dB (1W @ 1m)
107 dB - 113 dB peak Max. SPL 114 dB - 120 dB peak
80 W (160 W program, 320 W peak) Rated Power AES 150 W (300 W program, 600 W peak)
90ºH x 90ºV Coverage angle 90ºH x 90ºV
16 Ohm Impedance 8 Ohm
2 x Neutrik Speakon NL4MP Input Connectors 2 x Neutrik Speakon NL4MP
10mm DM Material 15mm Premium birch plywood
High resistant water-based black paint. black steel grill
with acoustic fabric protection Finish High resistant water-based black paint. black steel grill with acoustic fabric protection
254 x 172 x 186 mm Dimensions 450 x 277 x 275 mm (H x W x D)
3 kg (6.6 lbs) Weight 8.5 kg (18.7 lbs)
WB-01
for QB-5
SB-02
Stand
AGR-6
Eye bolt
TU-C01
connecting pole
TU-C02
M20 pole
WB-02
Wall bracket
VSM-V1
Top hat
TV-50
Clamp truss
TV-35
35mm adaptor
WB-03
Wall bracket
Specs

Accessories
Specs
www.lynxproaudio.com
6
SUB-08 DR-N12
Extremelly compact, high power, passive sub-bass cabinet with
one 12” low frequency transducer with rubber surround in direct
radiation conguration. 130 dB SPL peak (2000W Program).
Ultra-compact double band pass, passive sub woofer with one 8”
transducer with double independent coil and rubber suspension.
122 dB SPL peak (400W program).
LF 1 x 8″ transducer (2 x 50mm voice coil) Components LF 1 x 12″ transducer
43 Hz – 160 Hz (-10 dB) Frequency range 34 Hz – 400 Hz (-10 dB)
47 Hz – 154 Hz ± 3 dB Frequency Response 39 Hz – 220 Hz± 3 dB
93 dB (1W @ 1m) Sensitivity 94 dB (1W @ 1m)
116 dB - 122 dB peak Max. SPL 124 dB - 130 dB SPL peak
200 W (400 W program, 800 W peak) Rated power AES 1000 W (2000 W program, 4000 W peak)
Omnidirectional Coverage angle Omnidirectional
2 x 8 Ohm Impedance 8 Ohm
2 x Neutrik Speakon NL4MP Input Connectors 2 x Neutrik Speakon NL4MP
15mm Premium birch plywood Material 18mm Premium birch plywood
High resistant water-based black paint Finish High resistant water-based black paint. black steel grill
with acoustic fabric protection
268 x 641 x 304 mm Dimensions (H x W x D) 415 x 590 x 370 mm
9 kg (20 lbs) Weight 28 kg (62 lbs)
TU-C01
connecting pole
TU-C02
M20 pole
VSM-V2
pole support

www.lynxproaudio.com 7

www.lynxproaudio.com 8
The technical specications described in this catalogue can vary without previous notication.
