M-Audio MiniMacman User manual

MiniMacman
™
1 IN/ 1 OUT
Macintosh MIDI Interface
1
MANUAL
GUARANTEED FOR LIFE

MiniMacman™
1x1 Macintosh MIDI Interface
The MiniMacman MIDI Interface allows your Macintosh com-
puter to send and receive MIDI.
MiniMacman draws power directly from the computer itself
and needs no external supply -- only the connection of the ser-
ial cable is required. The included serial cable should be
plugged into the Serial In connector on the MiniMacman. The
other end of the serial cable should be plugged into either the
modem or printer port of your Mac. Either port can be
used. Just make sure the MIDI program you are using is set
to use the same port you have your MiniMacman plugged
into.
MiniMacman operates in MIDI mode whenever it is plugged
into your computer AND a MIDI application is run. When the
unit is properly activated in this fashion, the red Power LED
will light, indicating it is fully functional. The MiniMacman is
now able to send and receive MIDI when addressed by a stan-
dard MIDI application.
MIDI Data In and Out indicator LEDs are operational whenev-
er the MiniMacman power LED is lit. These LEDs will flash
whenever MIDI data is received or transmitted and can be
very helpful when trouble-shooting your MIDI system. If
MiniMacman is plugged in and MIDI data is sent by the

POWER
MIDIIN
MIDI OUT
Mini
Macman
MACINTOSH MIDI INTERFACE
™
MIDI Out
MIDI In
Serial
From Mac
Modem or
Printer Port
To Synth or
Sound Module
MIDI In's
From Synth
or Sync Box
MIDI Out
MiniMacman Hook-Up Diagram
To Synthesizer
or Sound Module
MIDI In
From Synthesizer
or Sync Box
MIDI Out
computer, MiniMacman's MIDI Out LED should blink, indicat-
ing that data is being sent. If your keyboard's MIDI Out is
MIDI IN
MIDI OUT
POWER
MACINTOSH MIDI INTERFACE

MIDIMAN U.S. • 45 East Saint Joseph Street • Arcadia, CA 91006 • USA
Sales Information: 626-445-2842
Sales Information (email): [email protected]
Tech Support: 626-445-8495
Fax: [phone]
Internet Home Page: http://www.midiman.net
MIDIMAN U.K. • Unit 22, Harrogate Business Park • Freemans Way • Harrogate • N Yorks •
HG3 1DH • England
Sales Information: 01423 886692
Sales Information (email): [email protected]
Technical Support: 01309 671301
Technical Support (email): [email protected]
Fax: [phone]
MIDIMAN Deutschland (Germany) • Kuhallmand 34 • D-74613 Ohringen • Germany
Sales Information: 07941-98-7000
Sales Information (email): [email protected]
Technical Support: 07941-98-70030
Technical Support (email): [email protected]
Fax: [phone]
Internet Home Page: http://www.midiman.de
1
connected to the MiniMacman MIDI In and keys are played,
the In LED should blink, indicating that data is being received.
Typically, the MiniMacman's MIDI In should be connected to
the MIDI Out of your keyboard. The MiniMacman's MIDI Out
jack should be connected to of your instrument's MIDI In.
If you need to use the serial port into which the MiniMacman
is plugged for a printer or a modem you will need to unplug
the unit. After doing this, plug in the printer or modem and if
necessary restart your computer.
If you have any questions about MiniMacman or any of our
products please call us at: [phone].
Have fun with MIDI!
