M Design Luna Diamond Series User manual

LUNA DIAMOND GAS
700-1000-1150-1300-1600-1900H
02-2019
INSTRUCTIONS FOR INSTALLATION AND USE

VERY IMPORTANT
INSTALLATION INSTRUCTIONS
FOR THE M-DESIGNG GAS
FIREPLACES
THE SUPPLIER TAKES NO RESPONSBILITY FOR ANY
POSSIBLE DAMAGE, POOR WORKINGAPPLIANCES AND
ACCIDENT AS A RESULT OF INCORRECT
INSTALLATION
MAINTENANCE GAS FIREPLACE M-DESIGN
THE M-DESIGN GAS FIREPLACES MUST BE CHECKED EVERY 2
YEARS AND GET A MAINTENANCE. THIS IS ALSO TO MAINTAIN
YOUR WARRANTY. IF THIS WILL BE NOT OBSERVED,
THE WARRANTY FELL.
YOU CAN RELY ON M-DESIGN TO MAKE THIS CHECK FOR YOU,
OR YOU CAN DO THIS BY YOURSELF AND FOLLOW THE
METHOD BELOW.
Instructions for installation and use DIAMOND Gas

3
SUMMARY
1. GENERAL REMARKS......................................................................................................... 5
2. CONNECTION.......................................................................................................................... 5
3. INSTALLING THE FIREPLACE...................................................................................... 6
3.1. Positioning the fireplace ...................................................................................... 6
3.2. Nearbox (Gasunit)...................................................................................................... 7
3.3. The Gas connection................................................................................................. 8
3.4. Electrical connection............................................................................................... 9
3.5. Modification natural gaz to propane........................................................... 9
4. INSTALLING THE CHIMNEY ........................................................................................ 10
4.1. Roof exit (C31)........................................................................................................... 10
4.2 Roof exit via existing chimney....................................................................... 11
4.3 Wall exit (C11)............................................................................................................. 12
4.4 Roof exit with bend................................................................................................ 13
5. FLAME ADJUSTMENT SETTINGS............................................................................. 13-14
6. INSULATION AND FINISHING..................................................................................... 14
7. CONVECTION CURRENT ................................................................................................ 15-17
8. POSITIONING THE LOGS................................................................................................ 18-23
9. FIRST-TIME USE................................................................................................................... 24
10. SAFETY, ADVICE AND MAINTENANCE ............................................................ 24
11. GUARANTEE........................................................................................................................ 25
12. REMOTE CONTROL ......................................................................................................... 26-28
13. DRAWINGS............................................................................................................................ 29-34
14. IDENTIFICATION BOARDS......................................................................................... 35-36

4
OPEN EN CLOSE THE DOOR
For initial setup, you need to clean the window and clear the fireplace of any
dust and grease that is left behind. This is also the only maintenance action
that may be performed on the device by the user.
Thanks to a patented system, the door can be easily opened at an angle of 45° to allow a user-
friendly cleaning of the window
To close, push the door gently (but not to soft) against the hooks. Make sure that all
hooks are hooked
CLOSING
OPEN
Above the glass (below the upper frame) hooks are provided (left, right and center). Push
it upwards with your fingers. the window can now be opened.

5
1. General remarks
This is an appliance using the closed combustion system, designed for the atmosphere and
comfort of your living-room. It constitutes an ecient source of heat and gives the
impression of a real fire.
The balanced flue appliances are based on the principle of natural extraction from the
firebox, which eliminates flue gas outside and brings in air (oxygen) from outside the house
which is necessary for combustion of the gas. It uses to this eect two concentric pipes.
The internal pipe ensures the elimination of burned gases and the external pipe brings in
combustion air. The advantage of this principle is that the equipment works independently
of the atmosphere which predominates in the house.
2. Connection
This appliance must be connected by an approved installer in accordance with the most
recent
regulations in force. On the basis of your order specifications, this appliance is designed for
natural or propane gas.
Read the instructions before installing and using this appliance. Before installing the
appliance, please check the local regulations about this type of appliance (identification of
the type of gas, etc.) and check that the furnace is adapted to your means of installationt.
It is imperative that the installer sees to the following:
•The appliance must be subject to an air tightness test of the gas and elimination of flue
gases.
•The concentric pipe, if already available, must be working correctly.
•The running of the control valve, lighting of the pilot light, the main burner and the
thermocouple must all be checked.
This appliance has been programmed and factory sealed. The sealed parts cannot be
modified. The appliance may therefore also be installed in airtight accommodation and
accommodation equipped with mechanical ventilation. It constitutes ambient heating even
in accommodation equipped with a closed ventilation system.
The appliance must be connected to the type of gas mentioned on
the appliance. Never connect a propane burner to natural gas or vice
versa!

6
A min = 3,5 cm
B = 19 cm
C min = 22.5 cm
3. Installing the fireplace
After having checked the appliance, you are ready to install your appliance. This is done as
follows
3.1. Positioning the appliance
Place the appliance on a stable surface using the adjustable feet. Adjust the height of the
appliance turning the bolt ( pic 1 )
The appliance must not be placed directly on the floor as you
need to allow natural convection. The appertures for the air
supply (IN) is situated underneath the appliances
Regulating the height of the appliance :
This can be made in two ways.
A regulation by 5 cm ( pic. 1 ) and a fine regulation by screw ( pic.2 ).
The minimum height as from ground to the bottom of the appliance is 3,5 cm ( A min ).
The minimum height “C min” will be 22.5 cm, measured as from the ground to 4th side
frame ( pic.3 ).
The maximum height as from the ground to the 4th side frame is 45 cm for LUNA DH and
max 35cm for Luna CL/CR/DC
pic. 1 pic. 2
Pic 3

7
365
18864
For safety reasons, The gasbattery or “NEARBOX” is fixed with screws at the rear of the unit during
transport .
THE UNIT CANNOT BE INSTALLED WITH THIS NEARBOX FIXED AT THE REAR, IT IS MANDATORY
TO UNSCREW THE BATTERY FROM THE REAR PRIOR TO INSTALLATION .
unscrew 4 screws in the corners
(key 8)
gas connection1/2”
reciever
DFGT-03MC01 V09
Transmitter burner
Gas valva
VK4105ME5004
3.2. Nearbox (gasunit)
gas connection1/2”
to main burner
Electro magnet ventil 1 or 2 burners
NEARBOX FOR 1 BURNER
NEARBOX FOR 2 BURNERS
to main burner
(455 2 burners)
to second burner or side burner

GAS SUPPLY TO SIDE BURNER OR SECOND
BURNER (YELLOW)
220V
NEARBOX
Connection Gas 1/2” (provide tap)
8
Opening provided in wall
for maintenance
Cable to ionistation pin
GAS SUPPLY TO MAIN BURNER ( RED)
flexible for GAS
The appliance is provided
with a direct ignition , no
starting pilot
3.3. The Gas connection
Valve 1/2”
After the “NEARBOX” has removed from the of the back of the fire, you can place it loosely on the ground
in proximity to the opening provided in the wall of mantelpiece. The device is always connected with an
approved gas tap 1/2, and preferably with a yellow gasflexible that is reachable at all times. Provide the
mantelpiece with a door so that the valve and the electrical connection is easily accessible.
ATTENTION : DO NOT PLACE ANY DECORATION ON THE DIRECT IGNITION PIN
(be carefull to stay out of the little rectangular zone with the dcoration)

9
3.4. Electrical connection
These appliances are equipped with a radiographic remote control, making an earthened
220V socket necessary.
You should bear in mind that the appliance must be connected to all electrical supplies for
the purposes of service. It’s mandatory to connect an earth current.
3.5. Modification natural gaz to propane
Modification of the fireplace can only be done by the manufacturer or an approved
installer. A new signal plate is provided.

10
C
C
4.1. ROOF EXIT (C31)
4. Installing the chimney
Install the concentric flue duct as indicated by ONTOP - METALOTERM. The only authorised pipes are ONTOP
Metaloterm™. ONTOP-METALOTERM tested our appliances with their conduct and we only guarantee a good
working of the appliance with those. Between the external wall of the pipe and the wall or the ceiling, you
should allow for a clearance of at least 50mm and protection that is suitable against temperatures of around
130°C. The passage of the front panel cowl in the external wall must be filled in using silicone mastic.
Ø 200/130Ø 200/130
Appliance C (min) C (max) Restriction (as from 4m)
700 / 1000 H 2 m 10m Ø 60 (as from 2m : Ø 75)
1150 H 2 m 10m Ø 60 (as from 2m : Ø 75)
1300 H 2 m 10m Ø 60 (as from 2m : Ø 75)
1600 H / 1900 H 2 m 12m Ø 60 (as from 2m : Ø 75)
Ø 150/100Ø 150/100
Appliance C (min) C (max) Resctriction (as from 4m)
700H / 1000 H 3 m 18m Ø 60 (as from 2m : Ø 75)
1150 H 3 m 18m Ø 53
1300 H 3 m 18m Ø 60
1600 H / 1900 H 3 m 20m Ø 75
This is recommended with a roof exit ≥ 3m
This is recommanded with a roof exit ≤ 3 m

USDHC13 or
USDHC10
*
11
*
C
C
4.2. ROOF EXIT VIA EXISTING CHIMNEY (C91S)
It is mandatory to use the termination set USSAN with
positioning.
flex 130mm
or 100mm
This USSAN piece must be sealed at the roof!
Ø200(min) / Ø 130Ø200(min) / Ø 130
Appliance C (min) C (max) Restriction (as from 3m)
700 H / 1000 H 2 m 10m Ø 60
1150 H 2 m 10m Ø 53
1300 H 2 m 10m Ø 60
1600 H / 1900 H 2 m 12m Ø 75
Ø 150 (min) / Ø 100Ø 150 (min) / Ø 100
Appliance C (min) C (max) Restriction (as from 4m)
700 H / 1000 H 3 m 18m Ø 60
1150 H 3 m 18m Ø 53
1300 H 3 m 18m Ø 60
1600 H / 1900 H 3 m 20m Ø 75

3°
12
A
B
0,25 min. 0,75m
A min* = 0,25m
(USVK13)
+ 0,75m
4.3. WALL EXIT (C11)
IMPORTANT:Be carefull every horizontal part does not have a negative
inclination in direction of the outlet. It is even better, when possible to
have a little inclination of 2 or 3 degrees ascending to avoid rain and
condenstation in the tube.
Ø 150/100Ø 150/100
With reduction usvk13 on appliance (pic. 1 )
Appliance A (min) B (min) B (max) Restriction
700H / 1000 H 1 *m Wall Exit A+1m Ø 75
1150 H 1 *m Wall Exit A+0,5m Ø 60
1300 H 1 *m Wall Exit = A Ø 75
ø 200/130 in combination with ø 150/100ø 200/130 in combination with ø 150/100
With reduction USVK13 after 90° curve on horizontal part (pic.2)
Appliance A (min)
Ø
200/130
B (min)
Ø 150/100
B (max)
Ø 150/100
Restriction
700H / 1000 H 1m Wall Exit A+ ”USVK13” +6m Horiz.<2m : Ø 75
1150 H 1m Wall Exit A+ ”USVK13” +5m Horiz.<2m : Ø 60
1300 H 1m Wall Exit A+ ”USVK13”
+3,5m
Horiz.<2m : Ø 75
1600 H 1m Wall Exit A+ ”USVK13”
+1m
----
Picture 2
Picture 3
ø 200/130 (pic.3)ø 200/130 (pic.3)
Appliance A (min) B (min) B (max) Position air inlet
700H / 1000H 1m Wall Exit A+8m Ø 75
1150 H 1m Wall Exit A+7m Ø 60
1300 H 1m Wall Exit A+6m Ø 75
1600 H 1m Wall Exit A+4m Ø 90
1900 H 1m Wall Exit A+2m Ø 90
USVK13
reduction 200/130 to 150/100
Not for the 1900 H
Picture 1

13
A
B
C
A
B
C
4.4. ROOF EXIT WITH BEND
Ø 150/100Ø 150/100
With reduction USVKk13 on appliance
Appliance A (min) B (max) C (min) (A+B+C )max
700 H /1000 H 1,25* m A+C+0,5m B-A-0,5m 18m
1150 H 1,25* m A+C+0,5 B-A-0,5 17m
1300 H 1,25* m A+C B-A 16m
1600 H 1,25* m A+C-0,5m B-A+1m 16m
1900 H 1,25* m A+C-1m B-A+1m 14m
Ø 200/130Ø 200/130
without reduction
Appliance A (min) B (max) C (min) (A+B+C )max
700 H /1000 H 1 m (A+C) + 8m B-A-9m 20m
1150 H 1 m (A+C) + 7m B-A-8m 19m
1300 H 1 m (A+C) + 6m B-A-7m 18m
1600 H 1 m (A+C) + 3m B-A-4m 18m
1900 H 1m (A+C)+ 1m B-A-2m 16m
Appliance Ø 150/100Ø 150/100 and Ø 200/130Ø 200/130
700 H /1000 H / 1150 H
1300 H / 1600 H / 1900 H
for each 90° bend subtract 1m
horizontally or add 1m vertically
700 H / 1000 H / 1150H
1300 H / 1600 H / 1900 H
for each 45°/30°/15° bend subtract 0,5m
horizontally or add 0,5 m vertically
5. Flame adjustment settings
Caution: if the vertical part is 3 m
longer than the horizontal part, you have to
use te restriction ring Ø 75
Before initial setup, you need to clean the window (from outside and inside) and fireplace of any dust
and grease. If you do not clean the glass properly, after lightning up the fireplace it can
remained still on the glass. After installing the fireplace correctly on the concentric tube or chimney
system, you must make a flame adjustment according to the draft (see chapter 4 page9. Installing the
chimney + use restriction rings).
The air intake for flame can be adjusted in fireplaces. Setting element is situated on the left side of the
bottom plate in the combustion chamber. Adjustment of air intake may only be set out by a specialist.

14
6. Insulation and finishing
Once installation is complete, the appliance can be fitted. Before doing so, check the tightness of the gas
pipe one more time. Light the appliance and check that it is working: check the tightness of the gas pipe
and the smoke pipe. Once you have checked everything, you can perform the final insulating and finishing
operations.
The built-in part of the appliance tends to be very warm. Please check that the appliance is not too nar-
rowly fitted and that there is adequate space for the elimination of hot air. For insulation of the appliance,
we advise you to use M Design insulating plates. You are advised against using any other insulation pro-
duct. Inflammable materials as well may not be used for the finishing.
Please , follow this instruction. The appliance can overheat if you do not follow these
instructions. Errorcode F02 will appear !
Masonry must be raised around the fireplace. Due to the expansion of the fireplace
during combustion, a gap of at least 5 mm must be provided at the front of the
fireplace and 4 cm on each side of the appliance. The masonry must not rest on the
fireplace. THE FIREPLACE MUST BE FREE. Always leave 2 mm clearance between
the inner frame and the masonry.
INSTALLING –SETTING OF AIR INTAKE GAS18
Before initial setup, you need to clean the window (from outside and inside)
and fireplace of any dust and grease. If you do not clean the glass properly,
after lightning up the fireplace it can remained still on the glass.
After installing the fireplace correctly on the concentric tube or chimney
system, you must make a flame adjustment according to the draft (see
chapter 9. Installing the chimney + use restriction rings)
The air intake for flame can be adjusted in fireplaces LUNA GAS 18, GAS TRUE
VISION, VENUS GAS. Setting element is situated on the left side of the bottom
plate in the combustion chamber. Adjustment of air intake may only be set
out by a specialist.
It is needed to wait 30-60 minute until the setting is fully showen up in the
fired fireplace. . Natural gas is first burning by blue colour and it will turn
yellow in time, LPG burning become quicker yellow.
If the flame is blue, it can mean that there is too much air in the combustion
chamber but also that there is too little air. If there is too much air, the flame
move very quickly.
Attention, burner have to burn continuously evenly in the whole
length included secondary burners.
By adjusting the flame cannot remove up from burner (cannot be
separated flame from burner), it is really dangerous. Then there is
too little air in combustion, in this case, add air by moving the
regulation element to the right side.
By adjustment must be taken to account that the more yellow the flame is the
quicker glass can get dirty.
Min Max
INSTALLING –SETTING OF AIR INTAKE GAS18
Before initial setup, you need to clean the window (from outside and inside) and fireplace of any dust and grease. If you do not clean the glass properly, after lightning up the fireplace it can remained still on the glass. After installing the fireplace correctly on the concentric tube or chimney system, you must make a flame adjustment according to the draft (see chapter 9. Installing the chimney + use restriction rings)
The air intake for flame can be adjusted in fireplaces LUNA GAS 18, GAS TRUE
VISION, VENUS GAS. Setting element is situated on the left side of the bottom
plate in the combustion chamber. Adjustment of air intake may only be set out by a specialist. It is needed to wait 30-60 minute until the setting is fully showen up in the fired fireplace. . Natural gas is first burning by blue colour and it will turn
yellow in time, LPG burning become quicker yellow.
If the flame is blue, it can mean that there is too much air in the combustion chamber but also that there is too little air. If there is too much air, the flame move very quickly.
Attention, burner have to burn continuously evenly in the whole
length included secondary burners.
By adjusting the flame cannot remove up from burner (cannot be
separated flame from burner), it is really dangerous. Then there is
too little air in combustion, in this case, add air by moving the
regulation element to the right side.
By adjustment must be taken to account that the more yellow the flame is the quicker glass can get dirty.
Min Max
INSTALLING –SETTING OF AIR INTAKE GAS18
Before initial setup, you need to clean the window (from outside and inside)
and fireplace of any dust and grease. If you do not clean the glass properly,
after lightning up the fireplace it can remained still on the glass.
After installing the fireplace correctly on the concentric tube or chimney
system, you must make a flame adjustment according to the draft (see
chapter 9. Installing the chimney + use restriction rings)
The air intake for flame can be adjusted in fireplaces LUNA GAS 18, GAS TRUE
VISION, VENUS GAS. Setting element is situated on the left side of the bottom
plate in the combustion chamber. Adjustment of air intake may only be set
out by a specialist.
It is needed to wait 30-60 minute until the setting is fully showen up in the
fired fireplace. . Natural gas is first burning by blue colour and it will turn
yellow in time, LPG burning become quicker yellow.
If the flame is blue, it can mean that there is too much air in the combustion
chamber but also that there is too little air. If there is too much air, the flame
move very quickly.
Attention, burner have to burn continuously evenly in the whole
length included secondary burners.
By adjusting the flame cannot remove up from burner (cannot be
separated flame from burner), it is really dangerous. Then there is
too little air in combustion, in this case, add air by moving the
regulation element to the right side.
By adjustment must be taken to account that the more yellow the flame is the
quicker glass can get dirty.
Min Max
It is needed to wait 30-60 minute until the setting is fully showen up in the fired fireplace. . Natural gas
is first burning by blue colour and it will turn yellow in time, LPG burning become quicker yellow.
If the flame is blue, it can mean that there is too much air in the combustion chamber but also that there
is too little air. If there is too much air, the flame move very quickly.
By adjustment must be taken to account that the more yellow the flame is the quicker glass can get
dirty.
Attention, burner have to burn continuously evenly in the
whole length included secondary burners.

15
7. Convenction current
It is MANDATORY to equip the fireplace with a convection kit consisting of inlets and outlets which are
connected to stretchable hoses from 3m to 5m.
In this way is created a circualtion and evacuation of the heat by convection.
This is very important to avoid overheating in the firebox casing and also to distribute the air hot air in the
room or in another adjacent room (oce, kitchen, ...)
This system directs the heat inside the room using hoses (150mm dia.). It is necessary to open minimum
2 hot air outlets. For the installation of these ducts, limit their lengths, avoid as much as possible elbows
and changes of direction, because the losses of speed generated, decrease the eciency of the air out-
lets at the end of travel. We advise you to install the hot air grilles at the same height to have the same
heat provided. M-Design has developed hot air and ambient air outlet grilles available from your dealer (see
page 16).
Outlet grids have two or four hose connections (2/4 hoses on 1 grid!).
The air inlet grilles (not to be connected with a hose) must be placed as low as possible at the bottom of
the fireplace.
Please, follow this instructions. The appliance can overheat if you not apply those instructions.
Errorcode F02 will appear!
ATTENTION : A house is never completely 100 % dustfree, heating appliances and warmth
circulation create dust particles. During the periods where you are not using the fireplace,
dust is accumulated in the flexible pipe and and the grills
This could cause a problem with a smell, so we would certainly advise you to clear the
flexible and air inlets and outlets using a vacuum cleaner regularly. The smell caused by
these dust particles will disappear after you have used the fireplace again a few times.
(This phenomenon is very common and can be compared to the gray traces
appearing above your radiators.) Optionally you can order design metal lids to cover the
inlets and outlets during the summertime .

2xØ150 13
126
126 200
200 550
350
1223
82
64
72
268
114 44
180x180
200
200
4 dm²
2xØ150
13
82
64
114 44
72
268
102
102 200
423
100
225
77
102
250
2 dm²
16
OUTLET CONVECTION
INLET CONVECTION
OUTLET CONVENTION
INLET CONVECTION
Picture 3
Design Grill (Outlet) with 2 connections
INLET grill covection air INLET grill covection air
Design Grill ( outlet ) with 4 connections
OR OR
Design Grill (outlet) with 2 connections

17
You have to connect at least two appertures situated at the top of the appliance.
For the Luna 1600, you must connect 4 appertures. The appliance may not be placed directly on the
floor, without the feet. This is to allow natural convection. The appertures for the air supply are situated
underneath the aplliance Every opening you make must be connected with a flexible tube dia 150MM
(see pic below). This will avoid the heating of the electronic part of the appliance. In this case you will
have errorcode F02.
Good
Closed
closed
GOOD 1300H, 1150H, 1000H

18
8. Positioning the logs, diamond, sapphire and white pebbles
Put the little imitation coal pieces on the burner and here and there between the big
Put the big imitation coal pieces around the burner.
Please check that the pilot light is switched o and that the appliance has cooled
down.
• Move the window to the front by pulling it. The window tips open at 45°.
• Arrange the materials supplied. In accordance with your order you will have either
a set of logs, diamond, sapphire or white pebbles. There is an adequate supply of
materials . Our appliance is approved with these materials, so please do not use
other products. Other decorative products are prohibited in our appliances. Please
do not change the delivered quantities
Attention:
Do not put anything on the ignition pin.
To arrange the logs respect the order as follows.
One bag of liite pebbles is delivred with the set. First place de little
pebbles on the burner. Place the big pebbles around the little pebbles and
be carefull to not place big pebbles directly on the burner.
ATTENTION WHEN USING THE BIG WHITE PEBBLES

Luna 700H Gas Luna 1000H Gas
1
56
78
9
2
34
1
4
23
6
7
8
99
8
6
7
4
123
5
Remark : set for 700H and 1000H are the same.
19

20
1
56
78
9
2
34
Luna 1150H GasLuna 1150H Gas
