M-Elec Blind Snake User manual

For2.5mmcable,
removetheinsertin
thecentre,placethe
cableintothechannel
andpushitdownso
itʼscompletelyflat.
For1.5mmcable
placethecable¹into
thechanneland
pushitdownsoitʼs
completelyflat.
OPTIONAL
INSTALLATION GUIDE
Turn over for termination and unlocking guide
¹NOTE:forpolarity,ensurethe
Active/Lineconductorisaligned
withtheredmark.Thiscanbe
achievedbynickingasmallpart
oftheinsulationoffthecable
outersheath. N E L
TPS2C+E
flatcable
Placethecoverontop
ofthemainbodyand
pressthepinsfirmly
intotheguides.

Slidethecover
backuntilyou
canremoveit
completely.
Slidethecover
closeduntilyou
hearaʻclickʼ
soundforasafe
andsecure
termination.
Strip15mmofthe
outercableinsulation
exposingtheinner
insulatedwires.
Insertactive,
earthandneutral
insulatedcables
intotheslotson
theterminator
block.
Cliptheterminator
blockinthetop
endofthechannel
ensuringthecable
issittingflatinthe
channel.
Please refer to M-Elec website (melec.com.au) for information on
the warranty period of each product. Each of our product
warranties is separate and subject to the following terms and
conditions:
• M-Elec products must be properly installed by a qualified
electrician and in accordance with any relevant guidelines, codes,
and standards. This includes wiring and connection to proper
approved components and product working environments.
• This warranty is void and does not apply to products that fail as a
result of neglect, mistake misuse, alteration, or that is
improperly installed and implemented. This includes but is not
limited to: improper wiring, installation under improper and
non-approved operating environments such as temperature,
humidity, corrosion or voltage conditions; improper installation
using components that are not approved or are not M-Elec
manufactured products.
• It is the responsibility of the purchaser to obtain all necessary
approvals and to understand the products intended use and all
relevant instructions, recommendations, and guidelines for the
proper installation and use of any M-Elec products and related
‘manufactured products’ used in conjunction with same.
• M-Elec is not liable for the accuracy and completeness of any
statements, technical information and recommendations in any
form of product literature or instructions are not guaranteed,
and are not part of this warranty, and does not in any way
constitute a warranty. The purchaser is solely responsible for
determining suitability of the M-Elec products for installation
and full implementation must determine potential applications
and installations independently.
• Warranty is void if products have been altered, opened/modified
in any way that is outside the bounds of normal electrical work.
• To make a claim on any of M-Elec’s products, you must do so
within 14 days from the day of receipt (from place of purchase)
please read our returns policy for further information
(melec.com.au/returns-policy) and deliver the transformer to
M-Elec (at your cost) to Head Office. M-Elec will assess the
warranty claim by conducting electrical tests, and visual and
microscopic inspection to make sure there is no visible physical
damage. If M-Elec grants the warranty claim, we will replace the
product or refund your money, at our election.
• M-Elec is not responsible or liable for any injuries, damages, or
death caused by the use, misuse or failure of products purchased
from us.
• This warranty is in addition to any other rights the consumer may
have under the Australian Consumer Law.
To the fullest extent permied by law, no warranties other than
those described above are given in respect of M-Elec products.
M-Elec’s liability is limited, to the fullest extent permied bylaw,
to the refund or replacement of the M-Elec products. We
expressly do not warrant that an M-Elec product will last any
particular length of time nor guarantee is made as to fitness to a
particular application, since we have no control of the electrical
supply or circuits.
M-Elec goods come with guarantees that cannot be excluded
under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and compensation for
any other reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced if the goods fail to
be of acceptable quality and the failure does not amount to a
major failure.
ALL RETURNS MUST BE RETURNED TO:
M-ELEC HEAD OFFICE
10 Technology Drive, Warana Qld 4575
Please read our returns policy procedure for further information
on M-Elec website melec.com.au/returns-policy or request it via
phone [phone] from our customer care consultants.
Warranty Disclaimer
1 Year Warranty TERMINATION GUIDE - OPTIONAL
UNLOCKING GUIDE
Placethecoveron
topofthemain
bodyandpressthe
pinsfirmlyintothe
guides.
ML-BS-PB
