1Product Overview
The UPLYNX-M-RCZ24 is a Sigfox Verified modem module for the low power wide area network
(LPWAN) market. It is designed with M2COMM’s Uplynx M2C8001 SOC. The module was
designed for high performance, high quality, small form factor and a low cost. The design is fully
compliant with FCC part 15.209. The Sigfox application is ported over the Uplynx M2C8001 and
executed at high efficiency using its internal 32bit core processor. Every module is preloaded
with Sigfox application software and module specific ID/KEY/PAC as specified by the Sigfox
network system. The preloaded software also includes a bootloader which allows software
updates or future user application development.
2Product Features
Sigfox VerifiedTM RF modem (reference design fully certified)

Maximum output power: 22dBm typical

Operating Voltage: 3.4V to 5.5V (2.5V min for 20dBm+ transmission power)
Operating Temperature: -40°C to 80°C
Module enabling pin (POW_EN)
0.05µA OFF current
LGA 29 24mm x 13.5mm (RF IPEX connector) Land Grid Array
Frequency range: 902.1375-904.6625 MHz
Current consumption: 170mA continuous wave, 130mA AT$SB at [email protected]

RM-UPLYNX-E003 version 1.0
Confidential and Proprietary
10
3Functional Description
The core of the Uplynx-M-RCZ24 module is the Uplynx M2C8001 SOC. The module design is
based on the M2C8001 Sigfox VerifiedTM reference design. The Uplynx-M-RCZ24 has 6 sets of
analogue/digital multi-function pins and digital only multi-function pins. Each multi-function pin
can be configured by the user.
The Uplynx-M-RCZ24 communicates with the host MCU over a UART interface. The preloaded
UART interface firmware is configured at 9600bps baud rate, 8-bit data, no parity bit, 1 stop bit
and no flow control.
The STATUS pin indicates the activity of the Sigfox AT command interface. The module is
switched ON and OFF with the POW_EN pin. In OFF mode, the module current consumption
can be cut to its minimum (0.05µA) for longer battery operating time, an essential requirement
for Sigfox where modem activity is very low.
The RF output is a 50ΩIPEX connector and the whole module is shielded for best spurious
containment.

RM-UPLYNX-E003 version 1.0
Confidential and Proprietary
11
4Pin Assignment and Package Mechanicals
Dimension
A
B
C
D
E
F
G
mm
24
13.5
4.6
7.65
2.25
4.6
1.8
TYP.
Dimension
H
J
K
L
M
N
P
mm
1.0
TYP.
4.1
3.3
5.9
14
4.5
3.9
Pad Length: 1.68 TYP.
Maximum thickness: 3.0
Figure 4-1 Bottom view of module
PCB Layout and Gerber files are available upon request

RM-UPLYNX-E003 version 1.0
Confidential and Proprietary
12
Pad Name
IO
Description
VDD
VDD
Power
VSS
GND
GND
VLDO
O
Operating voltage monitor point
RESET_N
I
Reset: When asserted LOW sets module to INITIAL state
POW_EN
I
Enable: Logic low for Disable; Logic high for Enable
UART_TX
O
UART Tx data (9600bps)
UART_RX
I
UART Rx data (9600bps)
TX_OUT
O
50Ω antenna output
GPIO [0:5]
IO
Reserved
STATUS
O
Logic High: AT Command Interface ready
Logic Low: Module busy
JDAT
I
JTAG Interface
JCLK
I
JTAG Interface
Figure 4-2 Module Pinout

RM-UPLYNX-E003 version 1.0
Confidential and Proprietary
13
5Electrical Specifications
Parameter
Min
Max
Unit
Power (VDD)
-0.3
5.5
V
Voltage on GPIO
-0.3
3.6
V
Storage Temperature
-40
140
°C
Maximum soldering temperature
250
°C
Table 5-1 Absolute Maximum Ratings
Parameter
Min
Max
Unit
VDD
3.4
5.5
V
Operating Temperature
-40
80
°C
Table 5-2 Recommended Operating Conditions
Parameter
Min
Typ.
Max
Unit
Off mode
0.05
1
µA
Sigfox Tx mode 902MHz 22dBm @5V
170
mA
Table 5-3 DC Current Characteristics
Parameter
Min
Typ.
Max
Unit
Output power
22
23
dBm
Harmonics conducted 915MHz 22dBm
output
FCC Compatible
dBm
Output Power deviation vs Input voltage
(2.6V ~5.5V)
1
dB
Table 5-4 Transmitter RF Performance

RM-UPLYNX-E003 version 1.0
Confidential and Proprietary
14
Parameter
Min
Typ.
Max
Unit
Reference Frequency
24
MHz
Frequency Range: High band
MHz
In-Band Phase Noise Floor
-89.77
dBc/Hz
Phase Noise @ 1MHz Offset from Carrier
-104
dBc/Hz
Settling time from power on
100
µs
Lock Time
30
µs
Table 5-5 Synthesizer Specification
Parameter
Note
Min
Typ.
Max
Unit
Calibrated
frequency
±5% course calibration
32.768
kHz
Frequency accuracy
after calibration
With software offset
adjustment routine
±1
%
Supply voltage
coefficient
Frequency drift when
supply voltage changes
after calibration
+10
%/V
Initial calibration
time
2.5
ms
Table 5-6 32kHz RC Oscillator Specification
902.1375 904.6625

RM-UPLYNX-E003 version 1.0
Confidential and Proprietary
15
Parameter
Condition/Note
Min
Typ.
Max
Unit
Crystal
Frequency
24
MHz
Crystal
Frequency
accuracy
requirement
This is the total tolerance
including
a) initial tolerance
b) crystal loading
c) aging
d) temperature dependence
The acceptable crystal tolerance
depends on RF frequency and
channel spacing / bandwidth
±20
ppm
Startup time
2
ms
Table 5-7 24MHz Crystal Oscillator Specification
Parameter
Min
Typ.
Max
Unit
Input Low Voltage
-0.3
0.8
V
Input High Voltage
2
3.6
V
Threshold point
1.36
1.45
1.55
V
Output High Voltage
2.4
V
Output Low Voltage
0.4
V
Schmitt Trigger Low to High Threshold Point
1.56
1.66
1.76
V
Schmitt Trigger High to Low Threshold Point
1.1
1.19
1.27
V
Input Leakage Current
±10
µA
Pull up resistor
42k
59k
88k
Ω
Pull down resistor
34k
54k
92k
Ω
Output current drive
20
mA
Table 5-8 Pin IO Voltage

RM-UPLYNX-E003 version 1.0
Confidential and Proprietary
16
6Preloaded Software
The Uplynx-M-RCZ24 is loaded with the following software prior shipping:
1. Sigfox VerifiedTM Application
2. Bootloader
3. Device ID, KEY and Portable Access Code (PAC)
More detailed information can be found in document “RM-UPLYNX-E001: Uplynx AT Command
GUI and EasyAT User Guide”
6.1 Sigfox Verified AT command
The Uplynx-M-RCZ24 is designed to be compliant with the Sigfox uplink specification. The Sigfox
VerifiedTM AT command set is a standard deliverable and is used to access the network. For API
interface request, please contact our sales representatives.
The Uplynx-M-RCZ24 communicates with the host MCU over a UART interface. The UART
interface is configured at 9600bps baud rate, 8-bit data, no parity bit, 1 stop bit and no flow
control. When the AT command interface is running at startup, the pin STATUS will be pulled
high.
The following AT commands are supported.
Command
Description
Value
AT$302=pwr
Set Tx power
Pwr = Tx power [14 to 22]
AT$302?
Get current TX power
Return Current transmission power
setting
AT$400=v1,v2,v3,v4
Set Sigfox configuration
word for RCZ2 and RCZ4
settings
v1 = config_words_0
v2 = config_words_1
v3 = config_words_2
v4 = default FCC Channel
AT$400?
Inquire the Sigfox
configuration words
AT$410=mode
Enable Public Key for
emulator mode
Mode: 0-normal mode; 1- Public key
enabled (emulator mode)
AT$SB=bitvalue
Send a bit value of 0 or 1
Bitvalue = 0/1
AT$SF=frame
Send payload data, 1 to 12
bytes
Frame: data bytes (0,1,2,3…C,D,E,F)
to be sent, 12 byte maximum
AT$RC
SIGFOX_API_reset
AT$ID?
Get device ID
return ID
AT$PAC?
Get device PAC
return PAC
AT$IF=freq
Set transmission
frequency in Hz
e.g. 868000000
AT$IF?
Inquire current frequency
setting
Return frequency in Hz
AT$CW= freq, mode
Test mode with
continuous wave emission
Freq: 868000000
mode: 0-disable; 1-enable

RM-UPLYNX-E003 version 1.0
Confidential and Proprietary
17
AT$CM= packetlength
Test mode with random
data packet at fixed
frequency
Packet length = number of bytes to
be transmitted (1~26)
AT$V?
Read firmware
information
AT$O=mode, standard
Open Sigfox API library
Mode: 1 to load Sigfox library
Standard: 1-RCZ1; 2-RCZ2; 4-RCZ4
AT$RCZ=standard
Sigfox library regional
setting
Standard: 1-RCZ1; 2-RCZ2; 4-RCZ4
AT$RCZ?
Inquire Sigfox library
regional setting
Standard: 1-RCZ1; 2-RCZ2; 4-RCZ4
AT$O?
Inquire Sigfox API library
open or not
Mode: 1 to load Sigfox library
standard: 0(EU)/1(US)
AT$OOB?
Get operation condition
Return values:
[Battery voltage before active
transmission in mV]
[Battery voltage during active
transmission in mV]
[10x silicon temperature ]
e.g.
2650 [battery voltage 2.65V before
transmission]
2550 [battery voltage 2.55V during
transmission]
270 [27C silicon temperature]
AT$FW=mode
Firmware update mode
0: normal mode
1: update firmware with UART at
115200
After asserting the command, the
device needs to be rebooted into
XMODEM mode with UART speed of
115200bps. New binary can be
loaded via XMODEM protocol over
UART.
AT$GPIODIR=gpio, val
Set GPIO pin direction.
gpio = 1-GPIO0; 2-GPIO1; … , 6-
GPIO5
val: 0-input (weak pull high); 1-
output (input float)
AT$GPI=gpio
Return GPIO value
gpio = 1-GPIO0; 2-GPIO1; … , 6-
GPIO5
AT$GPO=gpio, val
Set GPIO output high or
output low
gpio = 1-GPIO0; 2-GPIO1; … , 6-
GPIO5
val: 0(output low)/1(output high)
AT$FEAT=page
Erase flash page
Page: 0 ~ 13 [EasyAT Commander
related]
AT$SIO=port
Scan GPIO input values
and execute relevant flash
Port: 6-bit input for GPIO0 to GPIO5.
A “1” represents the relevant GPIO

RM-UPLYNX-E003 version 1.0
Confidential and Proprietary
18
page
input will be scanned. [EasyAT
Commander related] e.g. port =
“100000”, GPIO0 value is scanned
and either GPIO0_Input(High) or
GPIO0_input(Low) flash page will be
executed [EasyAT Commander
related]
AT$IFVTH=voltage
Set battery detection
voltage threshold
Voltage supply is measured and the
AT command on page 12 or page 13
will be executed if the voltage is
lower and higher than the threshold
respectively [EasyAT Commander
related]
AT$DLY=count
No operation delay
Count: number of 100ms delays
Table 6-1 AT Command Set
6.2 Special Notes for Sigfox AT command interface
To load the Sigfox library for specific region X, one should set (AT$RCZ) and confirm
(AT$RCZ?) the value stored for RCZ then execute AT$O=1,X
The configuration set by the following AT commands will be stored on flash and the
value will be retained even after power off
oTransmitting frequency (i.e. AT$IF)
oTransmitting power (i.e. AT$302)
oSigfox configuration word (i.e. AT$400)
oThe following setting must be loaded to ensure normal Sigfox network activity:
RCZ2: AT$IF=902200000, AT$400=1,0,0,1

oSet RCZ region by AT$RCZ
6.3 Bootloader
The preloaded bootloader allows the user to reprogram the flash in the SOC. To enter the
firmware update mode, user can
I. Pull pin 16 low at startup (i.e. the STATUS pin of module)
On start up, the bootloader polls the module “STATUS” pin which is pin 16 of the SOC. If
the pin is logically low, the UART on the SOC is configured as 115200bps and the
bootloader is waiting for firmware via XMODEM. User can then upload the application
binary file to the SOC via XMODEM. Details can be found in “RM-UPLYNX-E001: Uplynx
AT Command GUI and EasyAT User Guide”. The application will be stored at the
application startup address and be uploaded after the system is rebooted. Details can
be found in the “Uplynx Software Development Kit User Guide”. Since the “STATUS” pin
is an output pin at normal operation, it is important to ensure the pin is NOT pulled
down by the application circuit during normal startup.
II. Enter AT$FW=1 when the Sigfox verified AT command interface is uploaded, the module
enters XMODEM mode after the AT$FW command is asserted. The speed of UART is

RM-UPLYNX-E003 version 1.0
Confidential and Proprietary
19
configurable to 115200bps. The new firmware is to be transmitted via XMODEM
protocol over UART and will be installed automatically. Upon successful update, the new
firmware will be uploaded on the next reboot. Details can be found in “RM-UPLYNX-
E001: Uplynx AT Command GUI and EasyAT User Guide”
6.4 Device ID, KEY and Portable access code
As part of the Sigfox operation requirements, each Sigfox device must be assigned a unique
identification number (ID), encryption key (KEY) and portable access code (PAC). This
information is preloaded in the module and only the ID and PAC can be read via AT command.
7Transmission Power and Current Consumption
7.1 Transmission Power vs. Input Voltage
902.2MHz
VDD
Power
Current
(Continuous Wave)
5
22.3
170.6
4.5
22.3
170.6
4
22.3
170.6
3.9
22.3
170.6
3.8
22.3
170.6
3.7
22.3
170.6
3.6
22.3
170.6
3.5
22.3
170.6
3.4
22.3
170.6
3.3
22.16
167.5
3.2
21.96
163.4
3.1
21.75
159.6
3
21.53
155.9
2.9
20.31
152.5
2.8
21.06
149.3
2.7
20.8
146.1
2.6
20.5
142
2.5
20.1
135.8
Table 7-1 Recommended Pin Connections
The current consumption of the Uplynx-M-RCZ24 is measured and data is presented as a
reference. The current is measured using the evaluation kit for Uplynx-M-RCZ24. Current
through J2 is measured by a Tektronix MDO3104 and a TCPA300. The module is configured for
RCZ2 and AT$SB=1 is executed to send a bit.

RM-UPLYNX-E003 version 1.0
Confidential and Proprietary
20
7.2 Current Profile and Measurement
Figure 7-1 Current Profile
VDD @ 5V, 902.2MHz
Output Power
Current
AT$302 to give
Average Current consumption AT$SB=1
14dBm
59.3mA
16dBm
70.6mA
18dBm
83mA
20dBm
124mA
22dBm
132mA
Standby Current (waiting for AT command)
2.5mA
Average current between packets (waiting
period + calibration + packet preparation)
14.5mA
