owner's manual
Window air conditioner
Read this manual completely before installing your new air conditioner
0(,95
0(,95
Model No.
MEI18VR
MEI24VR
CONTENTS
Thank you for choosing the air conditoner.Our design is based on the best eff-
iciency and the lowest noise operation and it can keep the room comfortable.
Please read this operating manual carefully before operating the unit and keep it
for consultation.
Structure mechanism and Installation
The Refrigerant 1
Function 3
Precautions 2
Power requirement 4
Installation 5
Notes for installation 8
Operation procedure
9
Air direction adjustment 9
10
Remote control panel
Remote control operation procedure
15
Operation Tips 16
Care and maintenance
Caution 17
Care and maintenance 19
Troubleshooting guide 20
After service 21
22
Please read this operating manual carefully before operating the unit.
to the material objects for reference.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory
or mental capabilities or lack of experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
- 1 -
The Refrigerant
To realize the function of the air conditioner unit, a special refrigerant circulates
r
WARNING:
.r
electric heater.)
than X
’s
instructions onl.
’
Appliance shall e installed, operated anstored in a roo ith a floor area larger
a
to explosion under certain conditions.BuD.
- 2 -
cause electric shock.
Please contact your dealer when you need to repair air conditioner.
injury or damage.
sensory or mental capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction.
Disconnect the power supply when cleaning the air conditioner. Otherwise, it may
the air conditioner by yourself. It may cause electric shock or damage.
alified professionals.Otherwise,it may cause
sons (including children) with reduced physical,
Please install the safety devices such us short-circuit protection and electrical leakage
According to the local safety regulations, u
protection during the installation of the air conditioner.
breaker.
Working temperature range
ĆOperating emperature Range
B/WB(°C)
32/23 43/-
or temperature) for cooling only unit is
18°C~ 43°C.
Precautions
ged from 8 years and above and persons
with reduced physical, sensory or mental capabilities, or lack of experience and knowledge
if they have been given supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be conducted by children without supervision.
Warning
accordance with national wiring regulation.
Air Conditioner should be properly grounded. Incorrect grounding may cause electric
shock.
hazard.
broken.
injury or damage.
damage or personal injury.
purpose socket.Otherwise, it may cause
may cause electric shock or malfunction.
inlet or air outlet. It may cause personal
It may cause
fire
the air outlet or air inlet. It may cause malfunction.
- 3 -
Function
Introduction
Room
temp.
Spring Autumn
Winter
Wind
direction
Summer
Cooling in summer Dehumidifying in rainy or
humid season
In hot summer, Air conditioner can
cool down theroom air by transferring
heat out.
Without reducing the room temp., air
conditioner can dehumidify and make
the room air dry and comfortable.
Dry
Window type room air conditioners can help
cycle the air, maintain a cool temperature and
dehumidifying your room. It is convenient for
your work, study and life. It can be widely used
in residence,shop,hotel,office,library and
laboratory, and so on.
- 4 -
Power requirement
Rated voltage :230V~ 60Hz
The electric components will be damaged when
the voltage is too high. If the voltage is too low,
the compressor will vibrate violently damaging
the refrigerant system the compressor and other
electric components.
To ensure reliable earthing, please do not connect earth
wire to the following places:
Earth wire
Water pipe
The ground must be connected.
sed. Furthermore, the
regulations. And the earthing method must be
reliable.
protection switch of enough power capacity
and air switch with enough space.
- 5 -
Installation
Installation precaution:
please engage the services of a professional
HVAC technician to install the unit and do not
attempt the work by yourself.We will not be Uesponsible
for any damages caused by self -installation.
Location:
The condensation water must be able to drain away continuously.
Install air conditioner unit far away from TV set or radio etc. to avoid inter-
bing video or voice.
Please contact four dealer if you are staying in these areas.-salt air
environment -coastal area -thermal spring area -sulphurous polluted arean
salt and coastal area or place where is near thermal springsand polluted .
Avoid other heat sources or direct sun light.
Avoid a place where is easy for children to touch.
Do not install the unit in or near laundryroombathroom shower
or a swimming pool.
version. Please contact your dealer for advices before installation.
How to install:
Choose a location where there are
no obstructions and the plug is
accessible.
htly bigger than unit size.
band on the guidelines given here.
Over
1500 mm
The distance of obstructions from
window unit inside should be upper
300mm, lower 1500mm, left 500mm,
right 500mm, front 1500mm.
500mm 500mm
300mm
300mm
- 6 -
Installation procedure:
1) Remove the sticker from the front panel.
3) Fill up space in the cabinet with sponge
or foam.
2) Put the unit into the installation hole.
The installation hole should be strong
enough to and rigid bear the weight
the unit so that the unit will not bibrate
and make noise.
Installation assistance:
The installation hole should be stro-
ng enough to support the air condit-
ioner.
If not, iron support has to
be used
outdoors. Iron support sho-
A sunshade board can protect the air
conditioner from direct sunlight and any
falling objects from hitting the WAC. If
your WAC location does not come with
a proper coverage, please contact your
dealer to install a sunshade board. Do
not block the air inlet at the side grill
after the sunshade board is installed.
Wall
Wooden
frame
Sunshade
board
Rubber
plate
Support
Horizontal line
down to the back to make sure the
condensation water can be drained
away conveniently.(Slant about 3
(Shown at right figure.)
ȾȾ
1 )
ȾȾ
13
ȾȾ
13
ȾȾ
13
Inclined about
- 7 -
Drain water :
Drain pan and drain hose need to be installed before use. Drain hose is not
provided please purchase from your local hardware short if needed.Use the
following procedure to install drain pan and drain hose.
1. Slide the chassis out from the cabinet.
2. Install the drain pan provided to the corner of the cabinet with 2 screws.
3. Insert the drain hose into the outlet on the bottom of the drain plan.
4. Slide the chassis back into the cabinet.
The air conditioner is designed to
splash the condensate on the condenser coil to improve cooling capacity and
efficiency.. If the splashing sound annoy you , please remove the rubber plug
from the chassis to lower the noise, which will reduce the performance slighly.
- 8 -
Notes for installation
Remove
Noise
Electric wiring
Before removing air conditioner to the other place, you
Then it must be done under the direction of the profe-
ssional technician. In addition, the charge of this must
be paid.
enlargement of noise and vibration.
to avoid increasing noise.
there is strange noise during operation.
y.
The exclusive circuit must be used. But removable socket
y.
and leakage current is less than 30mA.
d
necting method of each individual ele
The air conditioner should be installe
regulation.
An all-pole disconnection itch having a contact separation of at least 3mm
) should be installed in the circuit.
facturer or
All The dectrical ork must be done according to the local iring regulations.
- 9 -
Air direction adjustment
positioning the vane to discharge the air upwards,
downwards or go straight out.
Remote
control
panel
Air inlet
louver
Cabinet
Front intake
grille
(behind the
front intake
grille)
Model with remote control. There will be some slight variation verse the final
version of four unit.
- 10 -
Buttons on remote controller
Introduction for icons on display screen
1
3
5
2
4
6
7
ON/OFF button
MODE button
+/- button
FAN button
SWING button
SLEEP button
TIMER button
Timer on Timer off
Sending signal
swing operation
sleep operation
lock
set speed
Set timeSet temperature
heat operation
fan operation
dry operation
cool operation
auto operation
Remote control operation procedure
21
3
45
67
- 11 -
Introduction for buttons on remote controller
Note:
When power is connected(stand by condition), you can operate the air conditioner
through the remote controller.
When unit is on, each time you press the button on remote controller, the sending
signal icon " " on the display of remote controller will blink once. If the air con-
ditioner gives out a beep sound, it means the signal has been sent.
ff, set temperature will be displayed on the remote controller (If the
light of the unit display is turned on, the corresponding icon will be displayed);
When unit is on, it will display the icon of the on-going function.
Press this button to turn unit on/off.
ON/OFF button
1
Press this button once so that your desired mode can be circularly selected as (the
corresponding icon " " will be lit up after the mode is selected):
When the auto mode is selected, the air conditioner will operate automatically acc-
ording to the ambient temperature.The set temperature cannot be adjusted and will
not be displayed . Press FAN button to adjust the fan speed.
is selected, the
air conditioner will operate under cool mode.
Then
press + or - button to adjust the set temperature. Press FAN button to adjust
WKHfan speed.
is selected, the
air conditioner will operate at low fan speed
under dry mode. In dry mode, fan speed cannot be adjusted.
is selected, the
air conditioner will operate in fan mode only.
Then press FAN button to adjust the fan speed.
is selected, the
air conditioner will operate under heat mode.
Then
press + or - button to adjust set temperature. Press FAN button to adjust the fan
speed.
(Cooling only unit connot receive heating mode signal. If set HEAT mode by
remote
controller, press ON/OFF button connot turn on the air conditioner.)
AUTO COOL DRY FAN HEAT
MODE button
2
Pressing + or - button once will increase or decrease set temperature by 1°F(°C).
Hold + or - button for 2s, set temperature on remote controller will change quickly.
Release the button after your required set temperature is reached.
Timer On or Timer Off , press + or - button to adjust the time.(See
TIMER Button for setting details)
+ / - button
3
it could be used for AC that comes with
more functions; For some function, which the model doesn't have, if press
the corresponding button on the remote controller that the unit will keep the
original running status.
- 12 -
Introduction for buttons on remote controller
Press this button to turn on left & right air swing.
SWING button
5
Under Cool and Heat mode, press this button to turn on Sleep function. Press this button
to cancel Sleep function. Under Fan, Dry and Auto mode, this function will not be available.
SLEEP button
6
TIMER button
7
Note:
Auto speed, the air conditioner will select a proper fan speed automatically acc-
ording to the ambient temperature.
FAN button
4
Press this button so that the fan speed can be circularty selected as: AUTO,
SPEED 1( ),
SPEED 2 ( ) , SPEED 3 ( ), SPEED 4 ( ) (NA.
Speed 4 is the same as 3.).
AUTO
SPEED 1(equals to low fan speed)
SPEED 3 (equals to high fan speed) SPEED 4 (equals to high fan speed)
SPEED 2 (equals to mid fan speed)
d H icon will be
for Timer Off. Pressing
+ or - button once will increase or decrease the time by 0.5h. Hold + or - button
for 2s, will change the time rapidly. Release the button after your desired set time
is reached. Then press TIMER button to confirm it. T-OFF and H icon will stop
blinking.
H icon will be
for Timer On. Pressing
+ or - button once will increase or decrease the time by 0.5h. Hold + or - button
for 2s, will change the time rapidly. Release the button after your required set time
is reached. Then press TIMER button to confirm it. T-ON and H icon will stop
blinking.
s set , press TIMER button once to
review the remaining time. Within 5s, press TIMER button again to cancel this
function.
- 13 -
Introduction buttons on remote control
Note:
Introduction of combination buttons on rePRWH control
K
LVWKH
VHQG
Child lock function
Changing temperature unit function
Operation guide
AUTY
AT
Light function
- 14 -
Replacement of batteries in remote control
1. Turn four remote control over and remote the battery coverd along the arrow direction
as shown in the figure.
Battery
Battery cover
Remove
Reinstall
2. Replace with two #7 (AAA 1.5V) dry batteries.
Make sure positions for “+” pole and “-” pole are
correct.
3. Reinstall the battery cover.
The distance between signal sender and receiving window should be no more
than 8m, and there should be no obstacles between them.
when using the remote control
Replace batteries with the same type when replacement is required.
When you do not use the remote controller for a long time, please remove the
batteries from the comSartmHQt.
NOTICE
Possible sources of interference such as florescent light or wireless devices can
interfere with the remote control signal. So please get closer to the air conditioner
- 15 -
Note:
Remote control panel
1POWER BUTTON
Operation starts when pressing this button, and stops
w hen pr essing this button again.
2
FAN SPEED BUTTON
Select the fan speed HIGH, MID, LOW and AUTO in sequence.
3
Timer can be set by pressing / button. Timer can be
set in 0.5hour increments between 1and 10 hours, or in
1hour increments for 10 hours or above after each press
on or button.
4 TEMP/TIMER BUTTON
Press the keypad to increase the set (operating)
temperature of the unit.and Press the keypad to
decrease the set (operating) temperature of the unit.
The temperature seting range is from 16~30ć
MODE BUTTON
Select the operation mode, AUTO, COOL, FAN,
DRY (for reverse cycle model)
5SIGNAL RECEIVER
6
SWING BUTTON
Activate the automatic air swing function.
7 FILTER BUTTON
This feature is a reminder to clean the Air Filter (See
Care and Cleaning) for more efficient FRROLQJoperation
The LED (light) will illuminate after 250hoursRIRSHUDWLRQ
and the light will go off.
To reset after cleaning the filter, press the)LOWHUE WWRQ
If the remote controller is lost, open the panel cover and oerate the unit manually.
- 16 -
Operation Tips
ĆOperating Temperature Range
Indoor side DB/WB(°C)
Maximum cooling 32/23 43/-
Outdoor side DB/WB(°C)
The operating temperature range (outdoor temperature) for cooling only unit is
18°C~ 43°C.
Comfort and Economy2SHUDWLRQ
Do not overcool the room.
This is not good for health
and is a waste of electricity
Keep blind or curtains closed.
Do not let sunlight enter the
room directly when the air co-
ndition is in operation.
Keep the room temp. uniform.
Adjust the vertical and horizo-
a uniform temperature in the
room. Air cannot be discharged
to the direction of air-in.
Make sure the doors and
windows are tightly closed.
Avoid opening doors and wi-
ndows as much as possible
to keep air conditioning in the
room.
duce dehumidifying effects.
once every two weeks.
Ventilate the room occasionally.
Since windows are kept closed, it
is a good idea to open them and
ventilate the room regularly.
When starting the unit, curtains or
windows should be closed to pre-
vent the heat/cool leakage.
- 17 -
Caution
Operations for safety and health
1) The plug must be accessible after the appliance is positioned.
2) Do not use the appliance in the laundry.
3) Power cords pose series hazards to users if it is damaged. Please contact the
manufacture or its sevice aJHQW to replace the cord before using the applanceDJDLQ.
Select and adjustthe most
appropriate WHPSHUDW UH
to suit the URRPFRQGLWLRQV
Rooms occupLHGE\LQIDQWV
the elderly, or KHVLFNVKR OG
t be kept at an DSSURSULDWH
temperature.
Do not use heating apparatu-
ses in the vicinity. The air co-
nditioner’s plastic parts will
melt if exposed to excessive
heat.
Avoid exposing the body dire-
ctly to a continuous unidirect-
This is not recommended for
health reason.
cord.
result in serious electric
shocks
Do not use the air conditioner
for other purposes except for
cooling the room.
Do not use the air conditioner
for other purposes such as
dr
ying clothes, preserving
foods, or cultivating vegeta-
bles.
and outlet vents.
7his will not only interupt the
regular operation the applia-
nce buWwill also reduce the
cooling performance.
objects into these vents as it
is dangerous to touch the ele-
ctric components and the fan.
This manual suits for next models
1
Table of contents
Other mabe Air Conditioner manuals
mabe
mabe MMI12CABWCAM8 User manual
mabe
mabe MMI18CDBWCAM9 User manual
mabe
mabe MMT12HABWCAM8 User manual
mabe
mabe MMI09CDBWCCC8 User manual
mabe
mabe ASCHAM09BYT User manual
mabe
mabe MEV07VV User manual
mabe
mabe MMI12CABWCCE8 User manual
mabe
mabe MMI12CABWCAM9 User manual
mabe
mabe MMT12CABWCAM1 User manual
mabe
mabe MMI12CABWCA6M8 User manual
mabe
mabe MEV05VQ User manual
mabe
mabe MMT09CABWCCC8 User manual
mabe
mabe MMI09CDBWCCCHI8 User manual
mabe
mabe N Series Operating instructions
mabe
mabe MEV07VQ User manual
mabe
mabe MEV12VQ User manual
mabe
mabe MMT12CDBSCCE8 User manual
mabe
mabe MEE09VV User manual
mabe
mabe MEV05VV User manual
mabe
mabe MMT09CABWCCCHI8 User manual
Popular Air Conditioner manuals by other brands
Mitsubishi Electric
Mitsubishi Electric Mr.SLIM MS24WN Service manual
Mitsubishi Electric
Mitsubishi Electric MS-GK36VAT operating instructions
Tycoon
Tycoon TS2MVI32-09 Service manual
Carrier
Carrier 42TOVG010 owner's manual
Carrier
Carrier RAV180 installation instructions
Ravanson
Ravanson KR-8000 user manual
