Mace MaceView MVC-DM-4 User manual

Thank you for purchasing a MaceView™ MVC-DM-4 Camera. Please read
the instrucons completely before installaon. Please consult a legal expert
on the proper use of this equipment in accordance with the law.
User Guide
MaceView™ Indoor Color
Dome Camera
96.6 mm
65.0 mm
MVC-DM-4

2
SAFETY PRECAUTIONS
Please read before using
The lightning ash with arrowhead symbol, within an equilateral triangle, is intended
to alert the user to the presence of insulated dangerous voltage within the product’s
enclosure that may be sucient magnitude to constute risk of electrical shock.
The exclamaon point within an equilateral triangle is intended to alert the user to
the presence of important operaon and maintenance (servicing) instrucons in the
literature accompanying the appliance.
FCC STATEMENT
WARNING
This device complies with Part 15 of the FCC Rules. Operaon is subject to the following
two condions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received including interference
that may cause undesired operaon.
* Federal Communicaons Commission (FCC) Statement
WARNING
This Equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protecon
against harmful interference in a residenal installaon. This equipment generates uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instrucons,
may cause harmful interference to radio communicaons. However, there is no guarantee that
interference will not occur in a parcular installaon. If this equipment does cause harmful
interference to radio or television recepon, which can be determined by turning the equipment
o and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
— Reorient or relocate the receiving antenna.
— Increase the separaon between the equipment and receiver.
— Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
— Consult the dealer or an experienced radio/TV technician for help.
* You are cauoned that changes or modicaons not expressly approved by the party
responsible for compliance could void your authority to operate the equipment.
• Users should not aempt to disassemble the camera. There are no user serviceable parts
inside. Ask qualied service personnel for servicing.
• Do not use strong solvents or detergents. Use a dry cloth on the camera when it is dirty.
• Before operang, please check proper temperature, humidity and power source rangs.
• Do not aim the camera at bright objects or place it in direct sunlight. This may result in
blooming or smearing.
• Do not expose the camera to rain or moisture. This product is designed for indoor use or
a locaon where it is protected from rain and moisture. When exposed to moisture, turn
the power o immediately and ask a qualied service personnel for servicing. Moisture can
damage the camera and also create the danger of electric shock.

3
POWER AND VIDEO OUTPUT JACK
DC JACK is for power in. 12vdc required. (not supplied)
INSTALLATION
1. Secure the camera on the bracket.
2. Connect the 75Ω coaxial cable to device video input.
3. Connect the power cable.
4. Adjust the camera posion and angle to cover the desired eld of view.
Note: The camera is supplied with the focus pre-set, however, lens focus
may be adjusted if needed.
DIMENSIONS
96.6 mm
65.0 mm
96.6 mm
65.0 mm

5101 NW 21st Ave, Suite 210 • Fort Lauderdale, FL 33309
www.mace.com • [phone]
SPECIFICATIONS | MVC-DM-4
Image Sensor 1/3" SONY CCD
Eecve Pixels NTSC: 510(H) x 492(V) ; PAL: 500(H) x 582(V)
Resoluon 420 TV lines (Color)
S/N Rao More than 48 dB (AGC OFF)
Electronic Shuer Auto 1/60 (1/50) ~ 1/100,000 sec.
Minimum Illuminaon 0.3 lux / f2.0
Video Output 1.0Vp-p / 75� Composite, BNC
White Balance Auto / 2400°K ~ 9400°K
Lens Board Lens: 4.3 mm
Power Source DC12V ± 10%, 2.1 mm DC Jack Input
Power Consumpon 1.2W / 100mA (max)
Weight 0.32 kg (NW) / 0.38 kg (GW)
Operang Temperature 14ºF to 122ºF (-10ºC to 50ºC)
Storage Temperature -4ºF to 158ºF (-20ºC to 70ºC)
Regulatory Compliance CE, FCC
Dimensions 65 (H) x 96.6 (Diameter) mm
0710A
