1About
This document describes the use of the 100BASE-T1 Media Converter.
P/N: 100BASET1-MC-ETH
Web: https://www.machsystems.cz/en/products/embedded-networking/gateways-and-bus-
converters/100base-t1-media-converter
2Introduction
The Media Converter realizes a bi-directional network connection between 100BASE-T1 (BroadR-
Reach) and 100BASE-TX (Fast Ethernet) physical layer. The converter easily connects devices with a
standard OPEN Alliance BroadR-Reach (OABR) port, such as automotive cameras or ECUs, to a standard
computer network.
The device establishes a point-to-point link between an unshielded twisted-pair OABR port and
a Fast Ethernet port. The converter features one DSUB9 (BroadR-Reach, CAN bus), one Fast Ethernet
Figure 2 Block Diagram
Figure 1 100BASE-T1 Media Converter

100BASE-T1 Media Converter - User Manual
MACH SYSTEMS s.r.o.
www.machsystems.cz
Page 5of 15
[e-mail]
port with RJ-45 connector, and a Micro-USB connector (Chapter 4.1). The OABR channel is configurable
as either Master or Slave by a switch button or programmatically, and the device can be powered
either via DSUB connector or via USB. (Chapter 4.2)
The converter offers a possibility to access SMI registers of both transceivers (PHYs) via a CAN bus or a
USB’s virtual serial port. (Chapter 4.3) This enables the user to evaluate signal strength, detect polarity
of the T1 port, carry out a BroadR-Reach media test to diagnose cable errors, fine-tune the PHYs
parameters, and generally to read and write the registers.
2.1 Features
•Physical Layer conversion between 100BASE-T1 and 100BASE-TX
•Master / Slave configuration for OABR
•Automatic polarity detection for Slave
•6 Status LEDs
•Powered via DSUB9 or Micro-USB connector
•PHY SMI registers accessible via CAN bus or USB virtual serial port
•Table or DIN-rail mount
3Technical Specification
Electrical
Ports
1x 100BASE-T1 (BroadR-Reach / OABR)
1x 100BASE-TX (Fast Ethernet)
1x CAN bus
1x Virtual COM Port (USB CDC)
Power
9 - 30 V DC with polarity protection
either via DSUB or Micro-USB
Consumption
150mA @ 12 V
approx. 2 W
LEDs
5x Status Indicator
1x Power
Button and Switches
2x DIP switch (Master/Slave, User)
1x Tactile switch (Reset factory defaults)
Transreceivers
100BASE-T1: TJA1102
100BASE-TX: KSZ8041
Firmware
Upgradable via USB
Microcontroller
32-bit
Mechanical
Connectors
1x D-SUB9M
1x RJ-45
1x Micro-USB
Dimensions (L x W x H)
108 x 54 x 30 mm
Weight
83 g
Operating Temperature
0 to 70 °C
Protection
IP20
Placement
Table (adhesive pads included)
DIN-rail mount (clip sold separately)
Table 1 Technical Specification

100BASE-T1 Media Converter - User Manual
MACH SYSTEMS s.r.o.
www.machsystems.cz
Page 6of 15
[e-mail]
4Device Description
4.1 Overview
The converter has three connectors, six LEDs (4 on top, 2 on RJ-45 connector), two DIP
switches and a reset button.
4.2 Power
The device can be powered over CON 1: pins 3 and 9 or over CON 2: USB Type –B. See Chapter
4.8 for information on galvanic isolation.
Figure 4 Power Options
4.3 Media Conversion
Connect 100BASE-T1 network over CON1 (DSUB9M) pins 4 (BP - Positive) and 5 (BM -
Negative). Connect 100BASE-TX (Fast Ethernet) network over CON2 (RJ-45). Do not forget to select
the select T1 Master/Slave configuration depending on your use case (Chapter 4.4.2), and to power
the device (Chapter 4.2).
Figure 5 Power Options
Figure 3 Top View

100BASE-T1 Media Converter - User Manual
MACH SYSTEMS s.r.o.
www.machsystems.cz
Page 7of 15
[e-mail]
4.4 Pinout
4.4.1 CON 1
DSUB 9 Male
Pin
Name
Front view
1
2
CAN_L
3
GND / Power-
4
T1-BP (OABR)
5
T1-BM (OABR)
6
7
CAN_H
8
9
Power+ (or via Micro-
USB)
Table 2 Connector 1 - Pin Assignment
4.4.2 DIP Switches
DIP switches
Pin
Name
T1 Master
Master/Slave configuration
User
N/A; Currently unused
Table 3 DIP Switch - Pin Assignment
Note: To set the T1 mode to Master, switch T1 Master dip switch to „ON“ (up) position.
4.4.3 CON 2 & 3
Both RJ-45 and Micro-USB connectors use the standard pinouts. From left on RJ-45 port is
yellow and green LED. RJ-45 connector is galvanically isolated (Chapter 4.8). USB can be used for
diagnostic purposes (Chapter 5.2). The 100BASE-T1 Media Converter forwards Ethernet
communication packets between 100BASE-T1 and 100BASE-TX ports only.
Figure 6 Connector 2 and 3 - Pin Assignment

100BASE-T1 Media Converter - User Manual
MACH SYSTEMS s.r.o.
www.machsystems.cz
Page 8of 15
[e-mail]
4.5 LED Status Information
The six LEDs provide the following status information:
LED
Colour
State
Meaning
Power
Green
Off
The device is not powered
On
The device is powered
T1 Link / Act
Green
Off
Link is not established
On
Link is established
Blinking
Link activity
T1 Master
Green
Off
Slave
On
Master
Communication
CAN/USB
Green
Flash
Request received
On
USB enumerated
Off
USB connection is not active
Communication
RJ-45
Yellow
Blinking
Communication packet received
Off
Data transfer is not active
Green
On
Transmission is active
Off
Transmission is not active
Table 4 LED Function Description
4.6 CAN Bus Termination
Status information of the 100BASE-T1 Media Converter can be obtained over USB or CAN bus.
In case of a CAN bus connection, there is no internal termination resistor inside the device. Therefore,
a proper termination of the CAN bus is needed. The user needs to make sure the CAN bus is properly
terminated at both ends.
Figure 7 CAN Bus Termination
4.7 Factory Reset
The reset button is located on the side of the device (see Figure 3). For resetting to factory
defaults, power the device, wait a few seconds and then press and hold the button for 10 seconds. The
button can be pressed by tweezers or a pencil.
4.8 Galvanic Isolation
The Fast Ethernet (RJ-45) port is the only port of the device with galvanic isolation. Please be ware
that if you for example connect the device to a PC over USB, the ground signal of T1 link will be
connected to the USB port’s ground.

100BASE-T1 Media Converter - User Manual
MACH SYSTEMS s.r.o.
www.machsystems.cz
Page 9of 15
[e-mail]
5Usage
The Media Converter offers a plug&play bi-directional connection between 100BASE-T1 and
100BASE-TX port. USB and CAN bus can be used for diagnostic purposes.
5.1 100BASE-T1 to 100BASE-TX Conversion
Purpose of the device is to inter-connect 100BASE-T1 (BroadR –Reach) and 100BASE-TX (Fast
Ethernet) physical layers.
Power up the Media Converter as described in Chapter 4.2. The green Power LED will light up.
Select T1 Master/Slave mode as desired - either by hardware (set the Master/Slave DIP switch
to ON or OFF) or by software (Chapter 5.2).
Connect your Fast Ethernet network to the RJ-45 connector. Yellow and green LED on RJ-45 is now in
state “On”. Yellow LED on RJ-45 port and green LED on T1 Link Act flashes, when is a communication
packet received.
When USB is connected to the computer, the Green LED on CAN/USB is enabled.
5.2 Diagnostic over USB
When connect the media converter to PC over USB, it will be enumerated as a virtual COM port.
Windows 10 operating system and newer is supported.
The 100BASE-T1 Media Converter Utility PC application allows to read the status of the device.
The utility can be downloaded from www.machsystems.cz/en/support .
Run “100BASE-T1 Media Converter.exe”. Now you see window of Windows application as
shown below. To start monitoring, click once on button „Connect“.

100BASE-T1 Media Converter - User Manual
MACH SYSTEMS s.r.o.
www.machsystems.cz
Page 10 of 15
[e-mail]
(1) COM port number of the device
(2) Device’s serial number
(3) T1 signal quality
(4) current T1 mode
(5) T1 link status
(6), (7), (8) T1 link errors
(9), (10) T1 port cable test
(11) T1 Master / Slave forcing
Note: Mode of the Media Converter can be changed by software (11) or by hardware (set DIP switch
T1 Master to position „ON“for User mode „Master“).
Figure 8 Media Converter Utility

100BASE-T1 Media Converter - User Manual
MACH SYSTEMS s.r.o.
www.machsystems.cz
Page 11 of 15
[e-mail]
6Firmware Update
For updating the device’s firmware, you will need a .MSF firmware file, MsFirmwareUpdater
application, a Micro-USB cable, and a PC.
6.1 Preparations
The device’s firmware can be updated over USB. To do so, connect your Media Converter to the
PC over USB. If you are connecting your product to the computer for the first time, it takes a little bit
more time than usual. Please download the MsFirmwareUpdater application and the MSF firmware
file from our support page www.machsystems.cz/en/support and extract all files into a new folder.
Run “MsFirmwareUpdater.exe”. Now you can see window of the Windows application. Click on
button “Load from File” and select the .msf file which you downloaded previously. Details of the .msf
file will be shown. Make sure both “Variant Id check” and “New Protocol” checkboxes are checked.
Select RS-232 interface and the correct COM port. It is recommended to use baud rate of 115200.
6.2 Updating Process
Steps:
1. Make sure “New Protocol” checkbox is checked.
2. Click “Reset to Bootloader”.
Wait until the device is enumerated (usually 5 - 15 seconds).
3. The device will switch into bootloader mode and a new COM port will be added.
4. Click on “Refresh” button so that the new port is available in drop-down.
5. Select a different COM port than you found in default settings from the dropdown.
6. Click “Connect”.
7. Click “Update Firmware” and wait until the flashing is finished.
Progress bar in the bottom shows flashing progress.
8. Once finished, a pop-up windows will be shown. Click “OK”.
Figure 9 MsFirmwareUpdater - Main Window

100BASE-T1 Media Converter - User Manual
MACH SYSTEMS s.r.o.
www.machsystems.cz
Page 12 of 15
[e-mail]
Figure 11 MsFirmwareUpdater - Device Connected
Figure 10 MsFirmwareUpdater - Firmware Update Succedded

100BASE-T1 Media Converter - User Manual
MACH SYSTEMS s.r.o.
www.machsystems.cz
Page 13 of 15
[e-mail]
7Legal Information
7.1 Usage Warning
WARNING FOR ALL USERS
WARNING! - YOUR USE OF THIS DEVICE MUST BE DONE WITH CAUTION AND A FULL UNDERSTANDING OF THE RISKS!
THIS WARNING IS PRESENTED TO INFORM YOU THAT THE OPERATION OF THIS DEVICE MAY BE DANGEROUS. YOUR ACTIONS
CAN INFLUENCE THE BEHAVIOR OF A DISTRIBUTED EMBEDDED SYSTEM, AND DEPENDING ON THE APPLICATION, THE
CONSEQUENCES OF YOUR IMPROPER ACTIONS COULD CAUSE SERIOUS OPERATIONAL MALFUNCTION, LOSS OF
INFORMATION, DAMAGE TO EQUIPMENT, AND PHYSICAL INJURY TO YOURSELF AND OTHERS. A POTENTIALLY HAZARDOUS
OPERATING CONDITION IS PRESENT WHEN THE FOLLOWING TWO CONDITIONS ARE CONCURRENTLY TRUE: THE PRODUCT IS
PHYSICALLY INTERCONNECTED TO A REAL DISTRIBUTED EMBEDDED SYSTEM; AND THE FUNCTIONS AND OPERATIONS OF THE
REAL DISTRIBUTED EMBEDDED SYSTEM ARE CONTROLLABLE OR INFLUENCED BY THE USE OF THE CAN NETWORK. A
POTENTIALLY HAZARDOUS OPERATING CONDITION MAY RESULT FROM THE ACTIVITY OR NON-ACTIVITY OF SOME
DISTRIBUTED EMBEDDED SYSTEM FUNCTIONS AND OPERATIONS, WHICH MAY RESULT IN SERIOUS PHYSICAL HARM OR
DEATH OR CAUSE DAMAGE TO EQUIPMENT, DEVICES, OR THE SURROUNDING ENVIRONMENT.
WITH THIS DEVICE, YOU MAY POTENTIALLY:
•CAUSE A CHANGE IN THE OPERATION OF THE SYSTEM, MODULE, DEVICE, CIRCUIT, OR OUTPUT.
•TURN ON OR ACTIVATE A MODULE, DEVICE, CIRCUIT, OUTPUT, OR FUNCTION.
•TURN OFF OR DEACTIVATE A MODULE, DEVICE, CIRCUIT, OUTPUT, OR FUNCTION.
•INHIBIT, TURN OFF, OR DEACTIVATE NORMAL OPERATION.
•MODIFY THE BEHAVIOR OF A DISTRIBUTED PRODUCT.
•ACTIVATE AN UNINTENDED OPERATION.
•PLACE THE SYSTEM, MODULE, DEVICE, CIRCUIT, OR OUTPUT INTO AN UNINTENDED MODE.
ONLY THOSE PERSONS WHO:
(A) ARE PROPERLY TRAINED AND QUALIFIED WITH RESPECT TO THE USE OF THE DEVICE,
(B) UNDERSTAND THE WARNINGS ABOVE, AND
(C) UNDERSTAND HOW THIS DEVICE INTERACTS WITH AND IMPACTS THE FUNCTION
AND SAFETY OF OTHER PRODUCTS IN A DISTRIBUTED SYSTEM AND THE APPLICATION FOR WHICH THIS DEVICE WILL BE
APPLIED, MAY USE THE DEVICE.
PLEASE NOTE THAT YOU CAN INTEGRATE THIS PRODUCT AS A SUBSYSTEM INTO HIGHER-LEVEL SYSTEMS. IN CASE YOU DO
SO, MACH SYSTEMS s.r.o. HEREBY DECLARES THAT MACH SYSTEMS s.r.o.’s WARRANTY SHALL BE LIMITED TO THE
CORRECTION OF DEFECTS, AND MACH SYSTEMS s.r.o. HEREBY EXPRESSLY DISCLAIMS ANY LIABILITY OVER AND ABOVE THE
REFUNDING OF THE PRICE PAID FOR THIS DEVICE, SINCE MACH SYSTEMS s.r.o. DOES NOT HAVE ANY INFLUENCE ON THE
IMPLEMENTATIONS OF THE HIGHER-LEVEL SYSTEM, WHICH MAY BE DEFECTIVE.
7.2 Disposal and Recycling Information
When this product reaches its end of life, please dispose of it according to your local
environmental laws and guidelines.

100BASE-T1 Media Converter - User Manual
MACH SYSTEMS s.r.o.
www.machsystems.cz
Page 14 of 15
[e-mail]
7.3 Declaration of Conformity

100BASE-T1 Media Converter - User Manual
MACH SYSTEMS s.r.o.
www.machsystems.cz
Page 15 of 15
[e-mail]
7.4 Patents, Copyrights and Trademarks
All trademarks are the property of their respective owner. Windows is a registered trademark of
Microsoft Corporation in the United States and other countries.
Adobe, the Adobe logo, and Reader are either registered trademarks or trademarks of Adobe Systems
Incorporated in the United States and/or other countries.
Kvaser is a registered trademark of Kvaser AB in Sweden and other countries.
8Ordering Information
Product Number
Description
100BASET1-MC-ETH
Media Converter
DIN-CLIP
Clip for mounting on a DIN rail
Table 5 Ordering numbers
9Contact
MACH SYSTEMS s.r.o.
www.machsystems.cz
[email protected]
Czech Republic
Company registration: 29413893
EU VAT number: CZ29413893
