MAG WASP Series User manual

WASP Line Array User Manual rev 2.00
1
[e-mail] Tel./Fax: [phone] www.mag-audio.com
User Manual
Руководство пользователя
WASP
Systems / Системы:
WASP
WASP-S12
WASP-S18

WASP Line Array User Manual rev 2.00
2
[e-mail] Tel./Fax: [phone] www.mag-audio.com
Contents
Contents............................................................................................................................................................................................2
Panel A. Dimensions ....................................................................................................................................................................4
1. Safety instructions ...................................................................................................................................................................5
2. Regulatory information.........................................................................................................................................................6
3. WASP series................................................................................................................................................................................7
3.1. Introduction.........................................................................................................................................................................7
3.2. WASP series speaker models......................................................................................................................................7
4. Specifications............................................................................................................................................................................ 8
5. System operation.....................................................................................................................................................................9
5.1. Rigging...................................................................................................................................................................................9
5.1.1. Connecting WASP modules to WASP-S12 or WASP-S18 subwoofers ...........................................9
5.1.2. Connecting two WASP modules ..................................................................................................................... 10
5.1.3. Connecting a flying frame on the top of a WASP module ...................................................................11
5.1.4. Connecting a flying frame on the bottom of a WASP module .........................................................12
5.1.5. Connecting a flying frame on the top of a WASP-S12 or WASP-S18 ............................................13
5.1.6. Connecting a flying frame on the bottom of a WASP-S12 or WASP-S18....................................13
5.1.7. Connecting castor wheels to WSF-02 frame.............................................................................................14
5.1.8. Using WSC-34 (WSC-34A) transportation cart .......................................................................................15
5.2. Passive speakers.............................................................................................................................................................17
5.2.1. Connection plate......................................................................................................................................................17
5.2.2. Passive connections .............................................................................................................................................. 17
5.2.3. Connection details..................................................................................................................................................17
6. Standard contents................................................................................................................................................................ 18
7. Accessories ............................................................................................................................................................................... 18
8. Warranty and assistance ....................................................................................................................................................19
8.1. Product warranty............................................................................................................................................................19
8.2. Assistance..........................................................................................................................................................................19

WASP Line Array User Manual rev 2.00
3
[e-mail] Tel./Fax: [phone] www.mag-audio.com

WASP Line Array User Manual rev 2.00
4
[e-mail] Tel./Fax: [phone] www.mag-audio.com
Panel A. Dimensions
WASP
WASP-S12
WASP-S18
422
279
622
765
493
622
765
567
622

WASP Line Array User Manual rev 2.00
5
[e-mail] Tel./Fax: [phone] www.mag-audio.com
1. Safety instructions
1. Read these instructions carefully.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this equipment near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
8. Do not use near heat sources such as stoves, heat registers,
radiatiors or other equipment (including amplifiers) that
produces heat.
9. Do not use the unit near open fire sources.
10. Connect the unit only to the electric network with grounding.
Use only electic plugs that provide grounding.
11. Protect the power cord from being walked on, pinched, or
otherwise damaged.
12. Use only accessories specified by the manufacturer.
13. Unplug this unit during lightning storms or when unused for
long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is
required when the system has been damaged in any way, such
as power supply cord or plug is damaged, liquid has been spilled
or objects have fallen into the unit, the unit has been exposed
to rain or moisture, does not operate normally, or has been
dropped.
15. WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS SYSTEM UNIT TO RAIN OR
MOISTURE.
THIS UNIT CONTAINS POTENTIALLY LETHAL VOLTAGES.
TO PREVENT ELECTRIC SHOCK OR HAZARD, DO NOT
REMOVE THE AMPLIFIER MODULE. NO USER SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL. 1
INSTALLING OF THIS UNIT MUST BE PERFORMED ONLY BY
QUALIFIED TRAINED PERSONNEL FOLLOWING APPLICABLE
SAFETY RULES. DO NOT ALLOW INSTALLATION OF THIS UNIT
IF INSTALLATION HARDWARE IS BROKEN, BENT, PARTS ARE
MISSING OR IS OTHERWISE DAMAGED.
1 - for powered speakers only
The triangle with the lightning bolt is used to alert the
user to the risk of electric shock.
The triangle with the exclamation point is used to
alert the user to important operating or maintenance
instructions.
The CE-mark indicates the compliance with the low
voltage and electromagnetic compatibility.
Symbol for earth/ground connection.
Symbol indicating that the equipment is for indoor use
only.
Symbol for conformity with Directive 2002/96/EC and
Directive 2003/108/EC of the European Parliament on
waste electrical and electronic equipment (WEEE).
WARNING:TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT ATTEMPT TO OPEN ANY PART OF THE
UNIT. NO USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
TO COMPLETELY DISCONNECT THIS APPARATUS
FROM THE AC MAINS, DISCONNECT THE POWER
SUPPLY CORD PLUG FROM THE AC RECEPTACLE.
THE MAINS PLUG OF THE POWER SUPPLY CORD
MUST REMAIN READILY ACCESSIBLE.
DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR
MOISTURE, DRIPPING OR SPLASHING LIQUIDS.
OBJECTS FILLED WITH LIQUIDES, SUCH AS VASES,
SHOULD NOT BE PLACED ON THIS APPARATUS.
CONNECTIONS TO THE MAINS SHALL BE DONE ONLY
BY AN ELECTROTECHNICALLY SKILLED PERSON
ACCORDING TO THE NATIONAL REQUIREMENTS OF
THE COUNTRIES WHERE THE UNIT IS SOLD.
EXPLANATIONS OF GRAPHICAL SYMBOLS IMPORTANT SAFETY INSTRUCTIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN

WASP Line Array User Manual rev 2.00
6
[e-mail] Tel./Fax: [phone] www.mag-audio.com
2. Regulatory information
FCC COMPLIANCE NOTICE
This device complies with part 15 of the FCC
rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation.
CAUTION: Changes or modifications not expressly
approved by the party responsible for compliance
could void the user’s authority to operate the
equipment.
NOTE: This equipment has been tested and found
to comply with the limits for a Class B digital device,
pursuant to part 15 ofthe FCC Rules.These limits are
designed to provide reasonable protection against
harmful interference in aresidential installation. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instruction manual, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to radio
or television reception, which can be determined
by turning the equipment o and on, the user is
encouraged to try to correct the interference by
one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment
and receiver.
- Connect the equipment into an outlet on a
circuit dierent from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV
technician for help.
EC DECLARATION OF CONFORMITY
Manufacturer:
MAG Audio LLC
Merezhna 2
Bila Tserkva, Kyiv region
09112 Ukraine
We declare under our sole responsibility that
products:
WASP, WASP-S12, WASP-S18
Intended use: Professional Speaker System
Are in conformity with the provisions of the
following EC Directives, including all amendments,
and with national legislation implementing these
directives:
- 2006/95/EC Low Voltage Directive
- 2004/108/EC Electromagnetic Compatibility Directive
- 2002/95/CE RoHs Directive
The following harmonized standards are applied:
EN 55103-1:2009 /A1:2012
EN 55014-1:2006 /A1:2009 /A2:2011
EN 55022:2010 /AC:2011
EN 61000-3-2:2006 /A1:2009 /A2: 2009
EN 61000-3-3:2013
EN 61000-3-11:2000
EN 61000-3-12:2011
EN 55103-2:2009 /IS:2012
EN 61000-4-2:2009
EN 61000-4-3:2006 /A1:2008 /IS1:2009 /A2:2010
EN 61000-4-4:2012
EN 61000-4-5:2006
EN 61000-4-6:2014
EN 61000-4-11:2004
EN 60065:2002 /A1:2006 /A11:2008 /A2:2010 /A12:2011
Bila Tserkva,
22 January 2019
Alexey Asanov
CEO
For compliance questions: inf[email protected]
Models:

WASP Line Array User Manual rev 2.00
7
[e-mail] Tel./Fax: [phone] www.mag-audio.com
3. WASP series
3.1. Introduction
WASPline arrayis aversatile arrayforanyinstallation
size, as small as restaurant or a bar, and as big as
concert hall or a staduim.
Dual 8-inch system with 1,5-inch throat HF driver,
WASPhas receivedthe most advanced components
to assist with task of creating the ultimate compact
line-array solution. Thoroughly designed cabinets,
most advanced proprietary mounting system,
and wide selection of mounting and connectivity
accessories was called in to provide the fast
mounting\dismounting times, as well as ease of
transportation and storage.
Complete amplification solution is available for
WASP as well. Ready-to-go touring racks are
fitted with signal and power distribution, and are
based on state-of-the-art touring amplifiers from
Powersoft®. WASP system usability is further
extended with available presets as well as GLL files
for fast system performance prediction.
WASP modules and backed with WASP-S12 and
WASP-S18 flown or stacked subwoofers, and
additionally compatible with several models from
Subwoofer series.
3.2. WASP series speaker models
WASP user manual covers usage of following
models:
WASP part number 00-0003869
WASP-S12 part number 00-0008340
WASP-S18 part number 00-0007201

WASP Line Array User Manual rev 2.00
8
[e-mail] Tel./Fax: [phone] www.mag-audio.com
4. Specifications
System WASP
Passive line array module
WASP-S12
Arrayable passive sub-
woofer
WASP-S18
Arrayable passive sub-
woofer
Frequency Response (−10dB) 70 - 20000 Hz 42 - 140 Hz 32 - 200 Hz
Max SPL 1141 dB (single cabinet) 140 dB 141 dB
Sensitivity (1W/1m) 98 dB Low / 110 dB High 101 dB 98 dB
LF Driver 2x 8”, 2,5" VC 12”, 4” VC 18”, 4” VC
HF Driver 1,5”, 2,8” VC - -
Impedance 16 Ohm Low / 16 Ohm High 8 Ohm 8 Ohm
Horizontal coverage 100° - -
Vertical coverage Depends on the number of
cabinets - -
Nominal power 2600 W Low / 100 W High 950 W 1300 W
Connectors 2x Neutrik Speakon 4x Neutrik Speakon 4x Neutrik Speakon
Dimensions (W×H×D), mm 622x279x422 mm 622x493x765 mm 622x567x765 mm
Net weight, kg 22 kg 44,6 kg 47,8 kg
Shipping weight, kg 25 kg 47,6 kg 50,8 kg
Mounting Integrated flying hardware;
0° - 10° splay angle Integrated flying hardware Integrated flying hardware, M20 distance pole adapter
Enclosure material Plywood; wear-resistant
paint
Plywood; wear-resistant
paint
Plywood; wear-resistant
paint
Grill Steel grill, synthetic
acoustically transparent cloth
Steel grill, synthetic
acoustically transparent cloth
Steel grill, synthetic
acoustically transparent cloth
1 - peak value, calculated according to AES 2 - 2012
2- based on transducer power measured according to AES 2 - 2012

WASP Line Array User Manual rev 2.00
9
[e-mail] Tel./Fax: [phone] www.mag-audio.com
5. System operation
5.1. Rigging
WASP line array comes with built-in mounting
hardware for ground stack and flying cluster
installation options.
Rigging must be performed only by trained
personnel following the established safety rules.
MAXIMUM WEIGHT RESTRICTIONS MUST BE
FOLLOWED AT ALL TIMES!
MAKE SURE THE SUPPORT STRUCTURE IS
CAPABLE OF HOLDING THE APPLIED WEIGHT
WHILE SUSPENDING THE SYSTEM!
5.1.1. Connecting WASP modules to WASP-S12 or
WASP-S18 subwoofers
WASP line array is a versatile product allowing
creation of ground stack as well as flying cluster
configurations.
In both cases, connection of WASP modules and
WASP-S12 (WASP-S18) subwoofers must be
performed using an intermediate WSF-02 frame.
1
2

WASP Line Array User Manual rev 2.00
10
[e-mail] Tel./Fax: [phone] www.mag-audio.com
5.1.2. Connecting two WASP modules
- Release two VA-0018 10 mm pins on the rear
link and two VA-0010 8 mm pins on the front link.
(Pic. 1)
- Bring together two cabinets, then insert two
VA-0010 8 mm pins into front link from the sides
of the cabinets. (Pic. 2, 3)
- For each cabinet, insert one VA-0018 10 mm pin
into a slot for required splay angle. (Pic. 4, 5)
- Bring together, and then extend rears of all
cabinets to allow rear link to hook. Secure rear
connection with one VA-0018 10 mm pin. (Pic. 6, 7) 1
3
67
2
54

WASP Line Array User Manual rev 2.00
11
[e-mail] Tel./Fax: [phone] www.mag-audio.com
1
5.1.3. Connecting a flying frame on the top of a
WASP module
- Release two VA-0018 10 mm pins on the rear
link and two VA-0010 8 mm pins on the front link.
(Pic. 1)
- Attach WSF-02 flying frame on the top of the
cabinet and insert two VA-0010 pins in the front.
(Pic. 2, 3)
- Insert a VA-0018 10 mm pin into cabinet’s rear
link. Choose the angle of the tilt. (Pic. 4, 5)
- Hook the link of frame onto the cabinet’s rear
hardware, and secure with second VA-0018 10 mm
pin. (Pic. 6, 7)
43
5 6
2

WASP Line Array User Manual rev 2.00
12
[e-mail] Tel./Fax: [phone] www.mag-audio.com
5.1.4. Connecting a flying frame on the bottom of
a WASP module
- Release two VA-0018 10 mm pins on the rear
link and two VA-0010 8 mm pins on the front link.
(Pic. 1)
- Place the cabinet on the top of the WSF-02
frame, and insert two VA-0010 8 mm pin into the
front links. (Pic. 2).
- Use a VA-0018 10 mm pin to secure frame’s link
into hidden position. Use another VA-0018 10 mm
pin to attach cabinet’s link to the frame. (Pic. 3, 4, 5).
3
4 5
2
1
VA-0018 pin
VA-0018 pin

WASP Line Array User Manual rev 2.00
13
[e-mail] Tel./Fax: [phone] www.mag-audio.com
5.1.5. Connecting a flying frame on the top of a
WASP-S12 or WASP-S18
- Place the WSF-02 flying frame on the top of a
WASP-S12 (WASP-S18), align so front and rear links
of a WASP-S12 (WASP-S18) fit into receptacles of
the frame (Pic. 1).
- Insert four VA-0010 8 mm pins into front and rear
links of the WASP-S12 (WASP-S18).
5.1.6. Connecting a flying frame on the bottom of
a WASP-S12 or WASP-S18
- Place the WSF-02 flying frame on the bottom of a
WASP-S12 (WASP-S18), align so front and rear links
of a WASP-S12 (WASP-S18) fit into receptacles of
the frame (Pic. 1).
- Insert four VA-0010 8 mm pins into front and rear
links of the WASP-S12 (WASP-S18).
1
3
4
2

WASP Line Array User Manual rev 2.00
14
[e-mail] Tel./Fax: [phone] www.mag-audio.com
5.1.7. Connecting castor wheels to WSF-02 frame
WSF-02 flying frame can fitted with four 100 mm
castor wheels to easily transportation of WASP,
WASP-S12 or WASP-S18 stacks.
1
3
2
4
- In order to remove the castor wheel from the
frame, press the lock on the frame, and pull the
wheel to the center of the frame.

WASP Line Array User Manual rev 2.00
15
[e-mail] Tel./Fax: [phone] www.mag-audio.com
5.1.8. Using WSC-34 (WSC-34A) transportation
cart
WSC-34 (WSC-34A) is a covered cart that can be
usedforconvenientstorageandeasytransportation
of WASP line array stacks. (Pic. 1)
WASP-TB3 and WASP-TB4 transportation covers
are available for 3 and 4 unit WASP stacks to be
transported with WSC-34 (WSC-34A). (Pic. 2)
1
2
5
3
6
4
- Attach the lower WASP module to the WSC-34
(WSC-34A) by inserting two VA-0010 8 mm pins
to the front links and securing the rear link with one
VA-0018 10 mm pin. (Pic. 3, 4)
- Attach the upper WASP module to the WSC-34
(WSC-34A) wooden cover by inserting two VA-
0010 8 mm pins to the front links and securing the
rear link with one VA-0018 10 mm pin. (Pic. 5, 6)

WASP Line Array User Manual rev 2.00
16
[e-mail] Tel./Fax: [phone] www.mag-audio.com
6
8
9
7
- For 3 module WASP stacks, choose 10° angle
between cabinets. (Pic. 6)
- For 4 module WASP stacks, choose 10° angle
between cabinets. (Pic. 7)
- For storage of WSC-34 (WSC-34A), link wooden
cover with steel cart using two VA-0010 pins. (Pic.
8)
- For compact storage, WSC-34 (WSC-34A) can be
stacked on one another using sockets for castor
wheels for positioning. (Pic. 9)

WASP Line Array User Manual rev 2.00
17
[e-mail] Tel./Fax: [phone] www.mag-audio.com
5.2.1. Connection plate
1. SERIAL NUMBER FIELD. Sticker with the systems
serial number is located here. NEVER REMOVE
THE SERIAL FROM THE SYSTEM, AS IT IS AN
IMMEDIATE WARRANTY VOID.
2. PARALLEL INPUTS. The pair of parallel Neutrik®
Speakon connectors. Use this connectors to
connect power amplifier and to feed the signal to
the parallel systems.
5.2.2. Passive connections
Suggested accessories:
CN-0021 (part No. 00-00004268)
CN-0031 (part No. 00-00004271)
CN-0032 (part No. 00-00004272)
Use power amplifier with DSP or power amplifiers
with external speaker processor with WASP line
array.
MAKE SURE TO USE HIGH PASS FILTER FORWASP
TO PREVENT EXCESSIVE CONE MOVEMENT,
RESULTING IN TRANSDUCER DAMAGE OR FAST
DETERIORATION.
Recommended HPF settings, suggested power
amplifier ratings, and connection pins are found in
the table below.
System Amplifier power Amplifier impedance Connection pins Recommended HPF
WASP LF 600 - 1200 W 16 Ohm +1 -1 Specified by preset
WASP HF 100 - 200 W 16 Ohm +2 -2 Specified by preset
WASP-S12 950 - 1900 W 8 Ohm Rear +1 -1 Specified by preset
WASP-S12 Link Rear +2 -2
WASP-S12 Link Front +1 -1
WASP-S12 950 - 1900 W 8 Ohm Front +2 -2 Specified by preset
WASP-S18 1300 - 2600 W 8 Ohm Rear +1 -1 Specified by preset
WASP-S18 Link Rear +2 -2
WASP-S18 Link Front +1 -1
WASP-S18 1300 - 2600 W 8 Ohm Front +2 -2 Specified by preset
WASP connection plate
1
2
2
5.2. Passive speakers
1+1- LO 16 Ohm
2+ 2- HI 16 Ohm
Made in Ukraine www.mag-audio.com
WASP line array passive connections
DSP AMPLIFIER
WASP module
WASP module
WASP module
WASP module
5.2.3. Connection details

WASP Line Array User Manual rev 2.00
18
[e-mail] Tel./Fax: [phone] www.mag-audio.com
6. Standard contents
Please check complete complement of your WASP
system upon receiving the package.
Standard contents of a WASP line array module:
7. Accessories
WSF-02
Versatile frame
Part No. 00-0004068
VA-0018
10 mm pin
Part No. 00-00002877
VA-0010
8 mm pin
Part No. 00-00002878
WASP-FC4
WASP 4x Flying case
Part No. 00-0003967
WSC-34
Transportation cart
Part No. 00-0008633
WSC-34A
Transportation cart w/ auto wheels
Part No. 00-0008634
WASP-FC3
WASP 3x Flying case
Part No. 00-0006207
WASP-S12-TB3 - Transportation cover for 3x WASP-S12 - Part No. 00-0008347
WASP-S12-TB2 - Transportation cover for 2x WASP-S12 - Part No. 00-0008348
WASP-S18-TB3 - Transportation cover for 3x WASP-S18 - Part No. 00-0008349
WASP-S18-TB2 - Transportation cover for 2x WASP-S18 - Part No. 00-0008350
WASP-TB3 - Transportation cover for 3x WASP - Part No. 00-0008351
WASP-TB4 - Transportation cover for 4x WASP - Part No. 00-0008352
System WASP user manual Mounting pins Plastic bag Carton box
WASP +VA-0010 8 mm pin - 4 pcs.
VA-0018 10 mm pin - 2 pcs. + +
WASP-S12 + VA-0010 8 mm pin - 4 pcs. + +
WASP-S18 + VA-0010 8 mm pin - 4 pcs. + +

WASP Line Array User Manual rev 2.00
19
[e-mail] Tel./Fax: [phone] www.mag-audio.com
8. Warranty and assistance
8.2. Assistance
There are no user-serviceable parts in your
device. Refer servicing to qualified technical
personnel. In addition to in-house service
department, MAG Audio supports the chain of
distributors, authorized in repairs and service. If
your device needs repair contact your MAG Audio
dealer or distributor.
Occasionally, due to the nature of the failure, it
might be necessary to return defective products to
MAG Audio for repair. In this case, before shipping,
please kindly contact your MAG Audio distributor or
dealer, or MAG Audio directly. You will be provided
the RMA number code and detailed instructions
regarding your particular case. Please do not send
products without a prior authorization.
Thank you for your understanding, cooperation and
choice of MAG Audio products.
8.1. Product warranty
1. By this warranty MAG Audio grants that all
equipment manufactured under the MAG Audio
trademark is free from defects in material,
components and factory workmanship under
the normal use and maintenance for the time as
specified below.
2. All warranty repairs and maintenance of MAG
Audio products shall be carried out at MAG Audio
production sites or by MAG Audio authorized
personnel at no cost for the product purchaser.
3. Warranty period for cone transducers, high
frequency drivers and crossovers, whether sold
separately or as a component of a speaker system,
is 60 months from the production date.
4. Warranty period for enclosures, grills, connection
plates and accessories, whether sold separately or
as a component of a speaker system, is 60 months
from the production date.
5. Warranty period for built-in power amplifiers,
whether sold separately or as a component of a
speaker system, is 36 months from the production
date.
6. Warranty repairs or maintenance will be
performed only if a) MAG Audio product was
purchased from an ocial MAG Audio distributor
/ dealer and b) warranty card with specified serial
number, production date, realization date, vendor’s
signature and stamp is presented.
7. Warranty shall not cover following: damage
caused by accident, misuse or failure to follow
exploitation rules stated in technical manual;
repairs performed by non-authorized personnel;
mechanical damage caused by shipping accidents
and normal tear and wear.
8. Warranty shall not be applicable to any product
with defaced, removed, or modified serial number.
9. If your MAG Audio product needs repairs or
maintenance, contact your ocial MAG Audio
distributor / dealer. Please do not ship your MAG
Audio product without prior authorization.

WASP Line Array User Manual rev 2.00
20
[e-mail] Tel./Fax: [phone] www.mag-audio.com
2 Merezhna str., Bila Tserkva,
Kyiv region, 09100, Ukraine
Tel./Fax.: [phone]
e-mail: [e-mail]
www.mag-audio.com
