Magicshine MAGENE SEEMEE 508 User manual

PRODUCT DESCRIPTION
As a device that can monitor approaching vehicles behind within a certain range, the SEEMEE
508 Radar Tail Light contains a micro radar and a multi-mode controllable tail light. It can be
used together with the display terminal to help improve your perception of the surroundings
during riding.
This device can enhance the detection of the environment but is not a substitute for the rider's
attention and judgment. Please always pay attention to the road conditions and take a safe
ride.
INSTALL THE UNIVERSAL FIXED SEAT
WORKING INDICATOR
TAIL LIGHT MODE
DEVICE INSTALLATION TIPS
List of devices
INSTALLATION PRECAUTIONS
Select a suitable position to install the device to ensure that it will not
affect your riding safety.
Install the device at the appropriate height of the seat rod to acquire
the optimal detection range.
The fixed seat shall be installed vertically, and the matched installing
seat can adapt to most seat rod types and angles.
Correct installation, with the device facing back and perpendicular to
the road surface.
Make sure there is no obstruction in front of the device.
Note: In order to prevent the device from being lost due to the aging and fracture of a rubber
band, the suspending rope that the product is equipped with can be installed together.
SEEMEE 508 USER MANUAL
Scan to check
multi-language
manuals.
①
②
③
④
Button
Tail light
Working indicator
Radar module (built-in)
Power-on/power-off,
switch working mode
Rear warning light,
with multiple flashing
modes
Working indicator, based on indicators such as
power status, charging status, working mode, etc
Radar transmitter module, used to monitor
moving objects behind
Press and hold for 2s to
power on
Click the button to switch
the mode:
Solid mode → Flash mode
→ Pulse mode → Peloton
mode → Single Radar
mode, cyclic switching
①Button
②Tail light
③Working
indicator
④Radar
module
(built-in)
Fixed seat*1
Host*1 Rubber band*3 Charging cable*1
Rubber pad*1
70*63*3.549*42*3.536*29*3.5
15°
Pulling
Round
tube
Square
tube
1. Select an appropriate position of
the rubber pad according to the shape
of your seat rod, and place the rubber
pad on the back of the fixed seat.
3. Fix it with a rubber band.
2. Place the fixed seat and rubber pad
on the seat rod.
4. Align the card tray on the back of
the device with the card slot of the
fixed seat and turn it clockwise until
the device is locked.
Working indicator
The indicator flashes quickly
The indicator flashes slowly
The indicator flickers
The indicator goes out in
the working status
Description
Low battery
Charging, it goes out after
being fully charged
Firmware update in process
Radar function off
Radar failureThe indicator is always on
Indicator
luminance
Mode Runtime
Solid mode
Flash mode
Pulse mode
Peloton mode
Single Radar mode
Brake
On
On
On
Soft
On
None
Highlight
Default flash
setting
None 6H
10H
10H
16H
/
12H
8H
Slow
Slow
None
Rotating
None
On for 3
seconds
Rotation mode

MATCHED WITH BIKE COMPUTER
MAINTENANCE AND CLEANING OF THE DEVICE
RADAR DETECTION
FAQS
SAFETY WARNINGS AND PRODUCT NOTICE
DEVICE CHARGING
APP SETTINGS AND UPDATES
PRODUCT SPECIFICATIONS
Notes:
Please keep the USB interface dry before charging to prevent metal corrosion.
Tighten the USB cover after charging to prevent water ingress or interface damage.
This device can be matched with other display devices that support the standard ANT+
protocol of radar. You can judge the situation of vehicles coming from behind through the
information prompted on the display device for the purpose of a safe ride. Matching
operations are as follows:
1. Keep the display device 3 meters away from this device and turn both on.
2. Select "Add sensors" ("Search sensors") on the sensor page of the display device or the
corresponding APP interface.
3. Select this device in the search results to connect.
Warnings:
If the radar device does not send radar detection information to the display equipment, you
are recommended to stop riding and check the equipment at a safe position to ensure your
safety; you can turn off these two devices, restart them, and then try to connect again.
The interface of the display device is for illustration only, and the specific display form shall
be subject to the marks on the display device.
Warnings
Failure to notice the potential dangers listed below may lead to severe harm or even fatal
accidents.
Distraction warnings
The device can improve your riding experience if used properly; you may be distracted by the
screen and suffer from severe injury or death if the device is used improperly.
Just check the information quickly and keep your attention on the surroundings at all times.
Do not keep staring at the display or be distracted by it.
Paying excessive attention to the screen display may lead to your neglect of obstacles or
dangers. You will take risks for all the serious consequences arising therefrom, therefore,
please use this device in an appropriate and careful manner.
Battery-related warnings
The product has a rechargeable lithium battery.
Failure to follow the instructions listed below may shorten the battery's shelf life, damage the
device, or cause fire, chemical burns, electrolyte leakage, or the risk of injury.
Do not disassemble, modify, puncture, or damage the device or the battery violently.
Notes:
Do not store the device in an environment with an extreme temperature for a long time
because it may cause permanent damage.
Avoid using organic solvents, chemicals, or repellents, because it may cause damage to parts
of the device.
Try to avoid violent impact or rough use because it may shorten the life of the product.
Do not use any cloth or other materials that may scratch the optical lenses. Scratches may
give rise to a decline in the performance of radar detection.
Regular cleaning of mud or dirt on the device can prolong its service life.
This device can enhance the inspection of the environment but is not a substitute for the
rider's attention and judgment. Please always pay attention to the road conditions and take
a safe ride. Failure to follow relevant instructions may result in death or severe injury.
Radar can detect approaching vehicles within a distance of about 140 meters.
The relative speed of approaching vehicles that can be detected by radar must be within 10km/h -
120km/h (6 - 75mph).
Note: radar will not detect vehicles traveling at the same speed as you or away from you.
The radar beam width is 40°(-20°- +20°).
Radar can detect eight approaching vehicles at most.
SEEMEE 508 can be connected to Magene Utility with
Bluetooth. You can upgrade the firmware of the device,
set the mode preference, etc. in the APP.
Model SEEMEE 508
Battery type Built-in rechargeable lithium battery/1500mAh
Application temperature range -10°C-50°C (14°F-122°F)
Charging temperature range 0℃-45℃ (32℉-113℉)
Suitable voltage DC 5V, 750mA
Communication protocol ANT+, Bluetooth
Transmission frequency 24.050GHz-24.250GHz (Radar)
2.402GHz-2.480GHz (Bluetooth)
Transmission power consumption
(maximum transmission power)
10mW (Radar)
2.5mW (Bluetooth)
Waterproof rating IPX7
Luminous flux 20lm (Solid mode, Flash mode)
3-20lm (Pulse mode)
6lm (Peloton mode)
Note: Product parameters for laboratory test results,the actual use of
environmental factors interference, the actual results prevail.
Question Solutions
Indoor power-on
and alarm of
radar detection
No response after
power-on/
incapable of
power-on
The device cannot
be charged
The O-shaped
rubber ring is
damaged
Unable to connect
to APP or Bike
Computer
The radar tail light
does not work
during charging
The device can detect vehicles in an outdoor
environment. If it is started indoors, a
saturation alarm may occur, therefore, please
use it outdoors;
Please ensure that the device is within the
permissible range of operating temperature;
Please check the power and try to charge the
device to ensure that it is fully charged up
before use;
Please check the USB charging cable,
connector or port for damage;
Please ensure that the device is within the
permissible range of charging temperature;
The product is equipped with an O-shaped
rubber ring, please keep it properly on
standby. The O-ring is a consumable
product, therefore, please buy it yourself if it
is lost or damaged;
Please ensure that the device is within the
permissible range of operating temperature;
Please try to connect again after restarting
the device;
Avoid multiple sources of radar interference;
The device is off by default during charging;

The following situations are not covered by the warranty:
The warranty period has expired.
Any damage caused by improper use, maintenance, or storage.
The product is damaged because the user did not use or install the product as instructed in
the user manual.
The failure is caused by unauthorized repair, misuse, collision, negligence, abuse, liquid
ingress, accident, alteration, or improper use of accessories not matched with the product.
No electronic warranty card or valid invoice.
The product serial number or code stated on the electronic warranty card is inconsistent with
that on the product.
Failures and damages caused by other non-product design, manufacture, and quality
problems.
The damage is caused by wear or dirt due to the normal use, including human factors such
as scratches, exposure to chemical reagents or sharp objects, falling, or pressure.
Any damage caused by force majeure.
After-sales service period:
The company provides permanent after-sales service for the product.
When the warranty period has expired, only a cost price will be charged for repairs due to
product failures, and only the labor and accessory costs will be charged for repairs due to
human factors.
Please leave your exact name and contact number when sending for repair, so that the
maintenance center can inform you to pick up the device promptly.
FCC STATEMENTS
LEGAL RESTRICTIONS
CE DECLARATION OF CONFORMITY
WARRANTY TERMS
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions :
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
NOTE: The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modifications or changes to this equipment. Such modifications or changes
could void the user’s authority to operate the equipment.
NOTE:This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
‐ Reorient or relocate the receiving antenna.
‐ Increase the separation between the equipment and receiver.
‐Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
‐Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement, The device can be
used in portable exposure condition without restriction.
Federal Communication Commission
(FCC) Radiation Exposure Statement Power is so low that no RF exposure calculation is needed.
Users must comply with all relevant laws and regulations when installing and operating the
equipment. MAGICSHINE is not responsible for fines or losses incurred by you in violation of
any national or local regulations or ordinances while using MAGICSHINE equipment.
The company reserves the right to change and interpret the above content.
Hereby, MAGICSHINE & MAGENE declares that this product is in compliance with the Directive
2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet address:
https://magenefitness.com/certificate.html
UK DECLARATION OF CONFORMITY
Hereby, MAGICSHINE & MAGENE declares that this product is in compliance with The Radio
Equipment Regulations 2017.
The full text of the declaration of conformity is available at the following internet address:
https://magenefitness.com/certificate.html
Thank you for purchasing the product of MAGICSHINE. Please read the following terms
carefully.
Repair, Replacement, and Return:
This product has been strictly tested for quality. According to this Warranty, during the
warranty period, if this product suffers from quality-related failures when being properly used,
free warranty service will be provided.
The user can return or replace the product without any reason within 7 days as from the day
of purchase (included) if the product suffers from any quality issues.
The warranty period of the product host is 12 months from the purchase date, and that of
other accessories is three months, subject to the warranty period on the [Electronic Warranty
Card].
For repairs covered by the Warranty, the product must be packed in the original package and
transported by the specified carrier. Otherwise, the user shall bear the freight or any loss
caused by the transportation.
Do not expose the device or the battery to fire, explosion, or other hazards.
Do not place or store the device near a dryer, in a car under direct sunlight, or in other high-
temperature environments.
Do not immerse the battery in water or other liquids.
Riding warnings
Be sure to keep your best sense of attention and judgment and ride in the safest way.
Please make sure that your bike and all components are well maintained and all parts are
installed correctly.
SEEMEE 508 Radar Tail Light
SEEMEE 508
3.7V
1500mAh
65g
MAGENE
Model
Nominal Voltage
Nominal Capacity
Ref.Weight
Manufacturer
No.2 AWS, Road, Licang District,
Qingdao Shandong China
WSJ Product LTD(for authorities only)
Eschborner Landstraße 42-50
60489 Frankfurt am Main, Hessen,
Germany
Address
WSJ Product LTD.
UK Authorised Representative:
Unit 1 Alsop Arcade, brownlow hill,
Liverpool, L3 5TX, GB
