Magicshine MONTEER 8000S V2.0 User manual

HOW TO INSTALL BATTERY PACK
High capacity battery pack with 4*21700 Li-ion battery cells 7.2V 10 Ah.
Multiple circuit protections for safety use.
High quality fireproof PC material for shell.
Type-C charging & discharging integrated interface for 10w/18w fast output.
BATTERY FEATURES
HOW TO RECHARGE
Charging Fully charged
≤30%
≤70%
100%
Standard charging time
Approx.9.5hrs (5V 2A)
USB-C
LUMENS/RUN TIME
0-900
16 00
0-1400
11 30
0-2400
07 00
FLASHBRIGHTNESS
MODE
900
15 00
1400
11 00
2400
06 30
LOW
400
32 00
600
22 00
1000
12 00
ECO
1700
09 00
2600
05 30
4400
03 25
MID
3200
04 00
4800
02 10
8000
01 30
HIGH
ACCESSORY/STRUCTURE
3mm Hex
Battery pack
USB-C Cable
MONTEER 8000S V2.0
Nylon strap
Handlebar mount
M-REMOTE
5
Input/Output
1 2
43
BATTERY INDICATOR
GREEN
31%-100%
RED
11%-30%
FLASH RED
0%-10%
When the light is off, press the power button to display the remaining power.
Long press power button to turn on/off
When you turn the light on, it lights up in the last lighting mode you used.
(Mode memory function)
SWITCHING THE LIGHTING MODE
Click
Double click
Double clickDouble click
Click
Click
Click
Click
Long press to turn on
Long press to turn off
Battery Indicator
Click
Click Click Click Click
Click
Click Click
Click Click
Click
HOW TO INSTALL
1 2
43
MONTEER 8000S V2.0 USER MANUAL

*The M-REMOTE can only be paired with one device. To pair a new device,
please repeat the operation steps above.
Disconnect the lighthead from the battery
Press the two buttons at the same time until the indicator light flashes
OR
Reconnect the lighthead to the battery
Pairing is successful: the lighthead flashes once or the
indicator light stops flashing
HOW TO PAIR
HOW TO USE THE M-REMOTE
-Press and hold to turn on/off
-Press to change the brightness
-Double press to active flash mode
Brightness selection button
-Press and hold to turn on/off
-Press to active max.output
-Double press to change the mode
Mode selection button
OPTIONAL PARTS
*Adaptable accessories (sold separately)
Helmet mount TTA front mount
ANSI FL 1 STANDARD
315m
BEAM DISTANCE
25000cd
PEAK BEAM INTENSITY
WATER RESISTANT
IMPACT RESISTANCE
1m
8000
LIGHT OUTPUT
The Magicshine lighting system is warrantied for 24 months from the
date of purchase.
If you register the lighting system on the Magicshine website you will
receive a bonus 6 month warranty.
Battery packs and AC adapters have a 6 month warranty, however,
there is no bonus warranty available.
The warranty is limited to defects in material and workmanship on the
lighting system itself, the battery pack and the AC adapter.
The warranty is only valid if the affected parts have not been tampered
with and there is no intentional damage. Please keep your proof of
purchase in a safe place. Proof of purchase must be presented in the
event of any claim. Please contact the specialist retailer from whom
you purchased the device for complaint or warranty claim.
Alternatively, you can send your complaint or claim directly to
Magicshine at
Tel: [phone]
Fax: [phone]
E-mail: [email protected] (order from Magicshine.com
online store)
ser[email protected] (order from other sales channels)
In the event of a justified warranty claim and delivery of a replacement
device, you will only be entitled to a model available when replacing.
The manufacturer retains the right to make technical modifications.
WARRANTYEN
2
1
4
3
WARNING
