MAGIMIX Juice Expert Series User manual

INSTRUCTIONS FOR USE

Safety instructions ............................................ 2
Description ....................................................... 4
Maximum processing capacities ......................... 6
Assembly/Disassembly...................................... 7
Using the Citrus Press ........................................ 8
Using the Juice Filter........................................ 10
Using the Extra Press®...................................... 11
Using the Veg Cutter........................................ 12
Cleaning ........................................................ 14
Tips and advice .............................................. 15
CONTENT
Why not visit our website juice-expert.com or download our free Magimix
app to access recipes, demonstrations, advice from nutritionists and tips
for getting the very best out of your appliance.
1

2
SAFETY INSTRUCTIONS
WARNING: these safety instructions are an integral part of this product.
For your own safety, make sure you read them through carefully before
using your new appliance.
• This appliance can be used by persons with reduced physical, sensory
or mental capabilities, or lack of experience or knowledge, providing
they are given supervision or have received full instructions regarding
the use of the appliance in a safe way and understand the hazards
involved.
• This appliance is intended solely for use in the home.
• The following usages are not covered by the warranty: use in kitchen
areas reserved for staff in shops, offices and other workplace
environments, on farms, by the patrons of hotels, motels and other
commercial environments of a residential nature, and in bed and
breakfast-type environments.
• This appliance can be used by children aged 8 years and over,
providing they are given supervision, or have received full instructions
regarding use of the appliance in a safe way, and understand the
hazards in volved. Cleaning and aftercare should not be undertaken
by children unless they are at least 8 years old and are supervised by
an adult. This appliance and its power cord should be stored out of the
reach of children under 8 years.
• Never immerse your appliance in water or any other liquid, to avoid
the risk of electrocution.
• Never use your appliance outdoors.
• This appliance should not be used by children under 8 years. This
appliance and its power cord should be stored out of children’s reach.
• Children should not use this appliance like a toy.
• This appliance should never be left running unattended, even though it
can function without the user having to keep the button pressed.
RISKS LINKED TO USAGE
• Never insert your hands or a utensil in the feed tube while the appliance
is running. To prevent serious injury and avoid damaging the machine,
always use the pusher.
• Never use this appliance if the rotating filter or protective lid is damaged
or visibly cracked.

3
SAFETY INSTRUCTIONS
• Check that the lid is horizontal and locked into place before switching
your appliance on.
• Never attempt to override the safety mechanism.
• Press 0 and wait for the parts to stop moving completely before turning
the lid.
• The appliance is fitted with a thermal failsafe that automatically stops
the motor if it has been running for too long or is overloaded. If it
is triggered, switch the appliance off and wait for it to cool down
completely before switching it back on.
MAINS CONNECTION
• Chrome models must always be connected to an earthed socket with
the original power cord.
• Before plugging your machine in, check that the voltage indicated on
its identification plate corresponds to the voltage of your mains supply.
• Never allow the power cord to dangle over the edge of your worktop
or counter, and make sure that it does not come into contact with hot
surfaces.
• Always unplug your appliance if you are going to leave it unattended,
clean it, remove parts or put them back.
SERVICE AGENT
• If the power cord has been damaged, it must be replaced by the
manufacturer, a Magimix-approved service agent or a similarly
qualified person, in order to avoid all risks.
KEEP THESE SAFETY INSTRUCTIONS
FOR FUTURE REFERENCE
This symbol indicates that this product must not be treated
as regular household waste. It should be taken to a waste
electrical and electronic equipment (WEEE) collection point.
For more details about collection points, please contact your local council
or your household waste recycling centre.
ENVIRONMENTAL PROTECTION

DESCRIPTION
4
Citrus Press / Pulp System®
Ideal for juicing oranges, lemons, grapefruit
and other citrus fruit.
Result: instant, pip-free juice, with or without
pulp
Veg Cutter*
Ideal for making fruit or vegetable carpaccio,
salads, tarts, and much more.
Result: sliced, grated or shredded fruit and
vegetables
Juice Filter
Ideal for juicing greens (e.g. spinach,
cabbage) and hard-fleshed fruit and
vegetables (e.g. apples, carrots and fennel).
Result: a clear, pure juice with no pulp or
pips
Extra Press®*
Exclusive to Magimix, the patented Extra
Press®* turns your appliance into a cold
press juicer.
Ideal for juicing soft or cooked fruit and
vegetables (e.g. raspberries, strawberries,
tomatoes, bananas) and for making plant-
based milks (e.g. almonds, cashew nuts).
Result: a thicker, fibre-rich juice with an
exceptional yield: + antioxidants, + vitamins,
+ juice.
For more information about these analyses,
please go to juice-expert.com
For some fruit (e.g. pineapple, pear), you can either use the Juice Filter or the
Extra Press®, depending on how you like your juice:
- Juice Filter : a clear, pure juice with a lower yield.
- Extra Press®: a thicker, fibre-rich juice with a higher yield.
Never insert hard fruit or vegetables
(e.g. carrots, coconuts) when using this
function, as you risk damaging your
appliance.
* depending on the model
S G
ANTI
O XIDANTS
EXTRA PRESS
95
l
a
b
.
t
e
s
t
I
S
H
A
VITAMINS
EXTRA PRESS
85
l
a
b
.
t
e
s
t
I
S
H
A
JUICES
EXTRA PRESS
96
l
a
b
.
t
e
s
t
I
S
H
A
up to up to up to

Citrus Press Juice Filter Extra Press®* Veg Cutter*
Lever arm
Cone for
large citrus
Pusher
and lid
Pusher
and lid
Extra Press®
Pusher
and lid
Slicing, grating
and julienne discs
Disc supportDetachable rimDetachable rimCone for
small citrus
Citrus press
Pulp System®
Juice filter Juice filter
*depending on the model
All the removable parts are dishwasher safe.
Midi bowl
5
DESCRIPTION
* depending on the model
Spatula for cleaning
Bowl
Spout
Spindle
Motor base

MAXIMUM PROCESSING CAPACITIES
6
TIPS & ADVICE
When processing larger amounts, make sure you empty the bowl regularly.
The maximum capacities below are for average-sized fruit and vegetables.
Results may vary according to the size of the fruit and vegetables you choose,
as well as their variety, degree of ripeness, quality and freshness.
2 kg
1.5 kg
1 kg
1 kg
900 g
600 g
4 kg
3 kg
1.5 kg
1.2 kg
1.2 kg
1 kg
600 g sliced, grated or shredded fruit or vegetables
= = =
= = =
JUICE FILTER
VEG CUTTER
EXTRA PRESS®
It is important not to exceed these maximum capacities.
J
SG

Before using your appliance for the first time, make sure you wash all the parts
thoroughly (see p. 14).
Lower the bowl (spout facing left) onto
the spindle.
Unlock the lid or citrus press.
Double failsafe
Your appliance will only work if both the bowl AND the lid (or citrus press) are
locked into place.
Turn the bowl to the right to lock it into
place. Fit the attachments (p. 8-12).
Turn the bowl to the left. Lift it off the
spindle.
Assembly
Disassembly
Unwind the length of power cord you need.
Thread the power cord through the notches
on the underside of the appliance to avoid
vibrations.
1
1
2
2
3
3
ASSEMBLY/DISASSEMBLY
7

8
USING THE CITRUS PRESS
Slot the citrus press onto the bowl and
turn until it locks into place.
Insert the lever arm tab into the
corresponding slots.
Position the citrus half on the cone,
pressing down gently.
The large cone should always be clipped
onto the small one.
There are two cones:
Yellow cone for small citrus fruit.
Grey cone for large citrus fruit.
Fit the selected cone on the spindle.
Place a glass under the spout.
13
10
2
6 7
4
8
5
9

9
USING THE CITRUS PRESS
Lower the lever arm. Press 1, then exert
gentle pressure on the arm until all the
juice has been extracted.
After juicing, make sure you stop the
machine before you raise the arm, to
avoid splashing.
TIPS & ADVICE
Make sure you wash the citrus press, cones and Pulp System®thoroughly to avoid
white marks.
10 1011 12 1413
Using the Pulp System®(pulp-free juice)
Fit the citrus press on the bowl and turn
to lock into place.
2 3
For pulp-free juice, slot the Pulp System®
onto the spindle in the bowl.
1
Insert the lever arm tab into the
corresponding notches.
Place the cone on the spindle.
4
Position the citrus half on the cone.
Lower the arm, press 1, then exert gentle
pressure on the arm until all the juice has
been extracted.
5 6

10
USING THE JUICE FILTER
WARNING
Assembly: place the rim flat on the Juice
Filter and press down all round until it
is completely horizontal (the two ends
should meet).
Position the lid on the bowl and turn to
lock into place.
Insert the fruit or vegetables into the feed
tube. Gently help them down using the
pusher. Leave your machine on until all
the juicing is finished. Then switch it off.
• Never insert your fingers or an object
into the feed tube. Always use the
pusher supplied for that purpose.
• Wait until the Juice Filter has come to
a standstill before unlocking the lid.
• Turn to page 6 to find out the
maximum capacities.
Slot the Juice Filter onto the spindle (for
removal and cleaning, see p. 14).
Place a glass under the spout. Press 1.
1
4
8
2
9
3
65 7
7
Stop and empty the Juice Filter regularly (or if it starts vibrating). To maximize
your appliance’s lifespan and ensure optimum yield, exert a gentle pressure
on the pusher to keep the fruit or vegetables in contact with the grater.
When all the fruit or vegetables have gone through, leave your appliance
running for a few more seconds to extract every last drop of juice.

11
USING THE EXTRA PRESS®
Insert the Extra Press®into the Juice Filter.
Insert the fruit and vegetables into the
feed tube. Gently help them down using
the pusher. Leave your machine on until
all the juicing is finished. Then switch it
off.
Assembly: place the rim flat on the Juice
Filter and press down all round until it
is completely horizontal (the two ends
should meet).
Slot the Juice Filter onto the spindle
(for removal and cleaning, see p. 14).
Stop and empty the Juice Filter regularly (or if it starts vibrating). To maximize your
appliance’s lifespan and ensure optimum yield, exert a gentle pressure on the
pusher to keep the fruit or vegetables in contact with the grater. When all the fruit
or vegetables have gone through, leave your appliance running for a few more
seconds to extract every last drop of juice.
Place the lid on the bowl and turn to lock
into place. Press 1.
WARNING
• Never insert your fingers or an object
into the feed tube. Always use the
pusher supplied for that purpose.
• Wait until the Juice Filter has come to
a standstill before unlocking the lid.
• Never insert hard fruit or vegetables
(e.g. carrots).
• Turn to page 6 to find out the
maximum capacities.
1
4
8
2
5
9
3
6 7

USING THE VEG CUTTER
12
The function is engraved on the disc.
R/G = grater, E/S = slicer, J = julienne.
The number corresponds to the thickness of the cut (e.g. 2 = 2 mm).
WARNING
Fit the midi bowl onto the spindle.
Position the selected disc so that the side
indicating the function and thickness is
uppermost.
Position the lid and lock into place.
• Always handle the discs with care, as
the blades are extremely sharp.
• Never insert an object or your fingers
into the feed tube. Always use the
pusher supplied for that purpose.
Slot the disc support onto the spindle.
First lower the disc onto the disc support,
then turn to lock into place.
1
3
5 6
2
4
Turn to page 6 to find out the maximum capacities.

13
Insert the fruit or vegetables.
Slicing: stand long fruit or vegetables
(e.g. leeks, carrots) upright in the feed
tube until it is full.
Grating: for longer shreds, lay the fruit or vegetables flat in the feed tube.
Julienne: lay the fruit or vegetables
flat.
Switch your appliance on and press
down on the pusher.
If necessary, cut round fruit or vegetables
(e.g. apples, tomatoes) in half.
7 8
USING THE VEG CUTTER
OPTIONAL DISCS:
6-mm grater • 6-mm slicer • Parmesan
• Ripple cut•
Narrow
ribbon cut Broad ribbon cut

14
CLEANING
TIPS & ADVICE
To avoid damaging the removable parts:
• Detergents: make sure they are compatible with plastic parts.
• Dishwasher: select the minimum temperature.
• Handwashing: avoid leaving the parts immersed in detergent.
Bowl: push the spout down.
Citrus press: pull the tab to release
the lever arm.
Using the narrow side of the spatula,
scrape the inside of the Juice Filter to
remove the bulk of the pulp.
If necessary (e.g. after juicing
berries), use a washing-up brush to
clean the grater.
Make sure you always unplug your appliance before cleaning.
Immediately after use, detach (see p. 7) and wash the parts (water + washing-up
liquid).
Motor base: wipe with a soft damp
cloth. Avoid using abrasive products.
Juice Filter: remove the rim. Press
PUSH inwards then lift out.
Rinse the Juice Filter under a slowly
running tap, scrubbing the outside first,
then the inside.

15
With your Juice Expert®, you can follow the seasons and harness your desires and
imagination to create an endless array of juices, smoothies, coulis and sorbets.
Our tips and advice will ensure that each of your creations is a success.
For delicious juices packed with vitamins and nutrients, make sure you choose
and use your fruit and vegetables carefully. It is best to buy organic fruit and
vegetables. Here are a few simple rules to follow:
Fruit and vegetables with thin, “edible” skins: no need to peel them – just wash
them thoroughly before juicing in your Juice Expert®.
Fruit and vegetables with thick, “nonedible” skins: peel before using.
Stone fruit and vegetables: make sure you remove the stone before juicing.
Fibrous fruit and vegetables or dried fruit: soak in cold water for 30 minutes
(fibrous greens) or 8 hours (dried fruit).
You will find more than 100 recipes for making juices, smoothies, plant-based
milks, coulis, salads and sorbets in the book supplied with your appliance.
Even more recipes are available, along with tips, advice and recipe variations,
on our website and the Magimix app:
1. Log onto magimix.uk.com/recipes
2. Download the "Magimix" app onto your mobile phone or tablet (Apple
or Android ).
TIPS & ADVICE

TIPS & ADVICE
16
• Insert the fruit and vegetables into the feed tube one at a time, taking care not
overload the machine.
• The amount of juice contained in fruit and vegetables can vary according to
their variety, freshness, ripeness and season.
• We recommend using fresh fruit and vegetables, as they are juicier. Out of
season, however, you can use frozen fruit. Make sure they are completely
thawed before pressing. You can also use canned fruit in syrup (e.g. pears,
litchis).
• Some hard or fibrous vegetables may cause your appliance to vibrate. Add a
juice-rich fruit or vegetable (e.g. apple or cucumber) to balance the Juice Filter.
• Do not throw away the pulp some of it can be used in cakes and soups, and
the rest can go on your compost heap.
Yield
• We recommend alternating between juice-poor (e.g. spinach, cabbage leaves)
and juice-rich (e.g. apple, cucumber, carrot) fruit and vegetables.
• More generally, to maximize the amount of juice you obtain, add juice-rich
fruit and vegetables such as apples, carrots and cucumber.
• Soak fibrous vegetables for at least 30 minutes and dried fruit for 8 hours in
cold water to optimize their yield.
• Depending on whether you use the Juice Filter or Extra Press®attachment,
you will not obtain the same amount of juice.
With the Extra Press®, a patented system that crushes the fruit and vegetables
to extract the maximum amount of juice, you will always have more juice than
with the Juice Filter.
• After juicing, remember to recover any juice that is still in the bowl, to maximize
yield.
Texture
• If you have the Juice Expert®3 or Juice Expert®4, you can make two types of
juice. When juicing pineapples, for instance, the Juice Filter will yield a clear,
pure juice, whereas the Extra Press®attachment will deliver a creamy smoothie
that is richer in fibres and other nutrients.
• Some juices such as apple juice can quickly go brown. To slow this process
down, add a dash of lemon juice.
• Depending on the type of fruit and vegetables you use, the juice may settle into
separate layers. This does not affect either the taste or the health benefits of the
juice. Just stir with a spoon.

Ref. 460 265 - 011/2020
