MAGINON MPP 5200-LI User manual

POWER BANK 5200 mAh
BATERÍA EXTERNA DE 5200 mAh
English ........05
Español .......25
User Manual
Manual del usuario

Dok./Rev.-Nr. IM_Cover_MPP5200-LI-USA-A6-240816
Contents
Overview ......................................................................... 3
Use.................................................................................... 4
Product contents/device parts...................................... 5
Preface..............................................................................7
General ............................................................................ 8
Read and keep instructions............................................. 8
Explanation of symbols .................................................... 8
Safety............................................................................ 10
Correct use.........................................................................10
Safety information............................................................10
Start ................................................................................15
Check contents of box......................................................15
Preparing the Power Bank .............................................15
Charging the Power Bank ..............................................16
Charging mobile devices.................................................18
Cleaning..........................................................................19
Storing ............................................................................21
Fault Finding ..................................................................21
Technical Specification ..................................................22
Declaration of Conformity.............................................23
Disposal ......................................................................... 24
Dispose of packaging.......................................................24
Disposing of old appliances............................................24

3
A
IN:5V 1.0A
OUT:5V 1.0A
OUT:5V 2.1A
1
2

4
B
C
OUT:5V 2.1A OUT:5V 1.0A
IN:5V 1.0A
34
5
6
7
8
9

5
Product contents⁄device parts
1Maginon MPP 5200-Li
2Micro USB cable
3Micro USB plug (Output 5 V, 1 A)
4USB charging plug (Intput 5 V, 1 A)
5On/Off button
6Micro USB charging connection (Intput 5 V, 1 A)
7USB connection (Output 5 V, 1 A)
8Charging display LED
9USB connection (Output 5 V, 2.1 A)

Preface
7
Preface
Dear customer,
Congratulations on purchasing a high-quality MAGINON
product.
You have chosen a modern Power Bank with excellent
technical equipment , which is particularly easy to operate.
The device comes with a 3-year warranty. In case of a defect
in the Power Bank, you will need the enclosed warranty card
and proof of purchase. Please keep these in a safe place.
Imprint
Issued by:
supra
Foto-Elektronik-Vertriebs-GmbH
Denisstr. 28A
67663 Kaiserslautern
Germany
VI.1.0.us

General
8
General
Read and keep instructions
These operating instructions belong to this Power
Bank (hereinafter referred to as Power Bank). They
contain important information about the start-up
and handling.
Study these operating instructions and, in particular the
safety information in detail prior to using the Power Bank.
Non-observance of these operating instructions can lead to
damage to the Power Bank.
These operating instructions are based on valid standards
and regulations of the EU. Also observe specific guidelines
and laws in other countries!
Keep operating instructions for further use. When passing
on the Power Bank to third parties please also include these
operating instructions.
Explanation of symbols
The following symbols and signal words are used in these
operating instructions, on the device or on the packaging.
DANGER!
This signal symbol/word indicates a high-risk hazard, which
when not avoided can cause death or serious injury.

General
9
WARNING!
This signal symbol/word indicates a medium-risk hazard,
which when not avoided can cause death or serious injury.
CAUTION!
This signal symbol/word indicates a low-risk hazard, which
when not avoided can cause minor or medium levels of
injury.
NOTE!
This signal word warns against potential material damage.
This symbol provides useful additional
information about the assembly or operation.
Declaration of conformity (see chapter
“Declaration Of Conformity”): Products containing
this symbol comply with all Community
legislation of the European Economic Area.

Safety
10
Safety
Correct use
The Power Bank is designed to be only used as a Power Bank.
It is only suitable for private and not or commercial use.
Only use Power Bank as described in the operating
instructions. Any other use is deemed to be incorrect and can
cause material damage.
The manufacturers or dealers do not accept any liability for
damage resulting from improper or incorrect use.
Safety information
WARNING!
Danger of electrocution!
Excessive mains voltage can cause electrocution.
− When using a USB power supply, only connect the Power
Bank to an easily accessible socket allowing quick
disconnection of the Power Bank from the power supply
in case of a fault.
− Do not operate Power Bank in case of visible damage or if
the main cable or connector is defective.
− In case of the Power Bank or housing being damaged,
it must be replaced by the manufacturer or customer
service or a similar qualified person in order to prevent
any danger.

Safety
11
− Do not open housing, and have all repairs carried out by
an expert.
− For repairs only use parts corresponding to the original
devices. This Power Bank contains electrical and
mechanical parts required for protection against hazards.
− The Power Bank may not be operated with an external
timer or separate remote control system
− Never immerse Power Bank or accessories in water or
other fluids.
− Never touch Power Bank with wet hands.
− Never use the cables as a carrying handle.
− Keep Power Bank away from open flames and hot
surfaces.
− Only use Power Bank inside. Never operate Power Bank in
wet rooms or in the rain.
− Never store the Power Bank in such a way that it can fall.
− Never touch the electric device that has fallen into water.
− Ensure that children do not push objects into the Power
Bank.
− When not using or cleaning the Power Bank, switch off the
Power Bank and pull the USB power supply (not included)
out of the socket. All connected devices should also be
disconnected from the USB port.
− Do not expose Power Bank to spray or dripping water and
do not place any objects filled with liquid, such as vases
or open drinks on or next to the device.

Safety
12
− Switch off Power Bank immediately and pull the
connected charging cable out of the Power Bank, if you
detect a burning smell or smoke and stop using Power
Bank.
WARNING!
Hazard for children and persons with reduced physical,
sensory or mental abilities (such as partially disabled,
older persons with limited physical and mental abilities)
or lack of experience and know-how (such as older
children).
− This Power Bank may be used by children 8 years or older
and persons with reduced physical, sensory or mental
abilities or lack of experience or know-how provided they
are supervised or have been instructed on how to safely
use the Power Bank and understand hazards resulting
therefrom. Children may not play with the Power Bank.
The WLAN repeater may not be cleaned or maintained by
children without supervision.
− Do not leave Power Bank unintended during operation.
− Keep packaging foil away from children. Children could
get caught in it during play and could suffocate.
NOTE!
Danger of damage!
Incorrect use of the Power Bank can damage the Power Bank .
− Place Power Bank on an easily accessible, level, dry, heat-
resistant and sufficiently sturdy work surface. Do not place
Power Bank at the edge or periphery of the work surface.

Safety
13
− Prevent heat build-up by not covering the Power Bank.
The Power Bank could be damaged by the generated
heat.
− Do not expose Power Bank to direct sun light or high
temperatures. Otherwise the Power Bank can overheat
and can be damaged.
− Never expose Power Bank to extreme heat. This applies
in particular when stored in a vehicle. During longer
storage times extreme temperatures are generated
inside the passenger compartment and glove
compartment.
− Ensure that Power Bank does not come into contact with
hot parts.
− When cleaning, never immerse Power Bank in water
and do not use steam cleaner. The Power Bank could
otherwise be damaged.
− Handle Power Bank with care. The Power Bank can be
damaged by impact, shocks or dropping from low heights.
− Do not use Power Bank if plastic parts of the Power Bank
show cracks or tears or are deformed. Replace damaged
parts only with original spare parts.
− Do not open, change or modify the Power Bank and do
not insert any metal objects or wires into Power Bank.
− Do not charge Power Bank while charging another device.

Safety
14
WARNING!
Danger of explosion!
The battery may not be exposed to excessive heat, fire or
similar, due to danger of explosion.
− Do not swallow battery - danger of chemical burns.
− Keep battery away from children.
− Do not short-circuit Power Bank.
− Do not impact or puncture the Power Bank as the battery
acid could leak and could cause serious burns.
− Never use Power Bank in areas housing explosive or
flammable materials. Danger of fire and explosion.
− Seek immediate medical attention if you believe that your
child or you yourself have come into contact with the acid.
− Observe restrictions of use or prohibited use for battery-
operated devices at special hazard locations, such as fuel
stations, aircraft, hospitals, etc.
The Power Bank may only be used inside.

Start
15
Start
Check contents of box
WARNING!
Danger of suffocation!
Keep plastic foil and bags away from babies and small children
as danger of suffocation.
− Dispose of packaging material immediately so that babies
and small children cannot be injured.
NOTE!
Danger of damage!
If the packaging is carelessly opened with a sharp knife or
other pointed objects, the Power Bank can be easily damaged.
− Please open packaging carefully.
1. Remove Power Bank from packaging.
2. Check that delivery is complete (see Fig.A).
3. Check Power Bank and parts for damage. If there is
damage, do not use Power Bank. Contact the service
address of the manufacturer listed on the warranty card.
Preparing the Power Bank
− Remove packaging material and all protective foil.

Start
16
Charging the Power Bank
Charge integral battery fully prior to using the Power Bank.
Charging time of the battery depends on the selected
charging source and its output.
− For charging the Power Bank only use power
supplies with an output voltage of 5 V and
an output current of at least 1 A or a USB 3.0
connection of your computer.
− When using a USB connection for charging,
ensure that at least one further USB connection
remains unassigned in order to ensure that
sufficient Amps are available for charging. This
also applies when using USB 3.0 connections.
Charging using the USB charging plug
Connect USB charging plug 4of Power Bank to a
switched-on PC or a USB-power supply (not supplied).
During charging, the current charging status is shown by the
charging LEDs 8.
LEDs Charging status
One LED flashes <25%
One LED is lit, the second LED flashes. 25 - 49%
Two LEDs are lit, the third LED flashes 50 - 74%
Three LEDs are lit, the fourth LED flashes 75 - 99%
All LEDs are lit 100 %

Start
17
Charging using the Micro USB cable
Connect the Micro USB cable 2to the Micro USB charging
connection 6of the Power Bank.
Connect the other end of the Micro USB cable to a switched-
on USB connection of a computer or a USB-power supply (not
supplied). During charging, the current charging status is
shown by the charging LEDs 8.
To prevent damaging the Power Bank, power
supply or computer, never use both charging
options simultaneously.
Checking the charging level of Power Bank
You can also check the charging status of the Power Bank if it
is not charged or used for charging other devices.
Briefly depress the On/Off button 5. The charging indicator
LEDs 8show the current charging status of the Power Bank
for approx. 20 seconds.
LEDs Charging status
All LEDs are lit 100 %
Three LEDs are lit 75 - 99%
Two LEDs are lit 50 - 74%
One LED is lit 20 - 49%
One LED flashes <20%
All LEDs are dark 0 %

Start
18
Charging mobile devices
The Power Bank can be used to charge up to three devices
simultaneously. When using all outputs simultaneously the
total output voltage must not exceed 2.1A.
1. Connect a USB charging lead suitable for the device to be
charged to the respective USB connection 7/ 9or use
the Micro USB plug 3of the Power Bank.
2. Next, connect the USB charging lead to the device to be
charged. The charging process starts automatically.
3. If the charging process does not start automatically,
briefly depress the On/Off button 5to start the charging
operation.
• If the device to be charged contains a Micro USB
charging lead, you can also use the Micro USB charging
lead 2of the Power Bank.
• During charging, the current charging status is shown
by the charging LEDs 8.
4. To stop charging, disconnect charging lead from mobile
device. The charging indication LEDs then extinguish after
approx. 20 seconds.

Cleaning
19
Cleaning
WARNING!
Burn hazard!
The Power Bank becomes hot during operation!
− Let Power Bank cool down completely prior to any
cleaning!
NOTE!
Danger of short circuit!
Any water that has entered the housing can cause a short
circuit.
− Never immerse Power Bank in water.
− Ensure that no water enters the housing.

Cleaning
20
NOTE!
Danger of damage!
Incorrect use of the Power Bank can damage the Power Bank.
− Do not use any aggressive cleaners, brushes with metal or
nylon bristles or sharp or metallic cleaning objects, such as
knives, hard spatulas and similar. These can damage the
surface.
− Never place Power Bank in dishwasher. This would
destroy the device.
− Do not use corrosive, abrasive or solvent-based cleaning
agent. These can damage the surface of the device.
1. Pull out mains connector prior to cleaning.
2. Let Power Bank cool down completely prior to any
cleaning.
3. Wipe Power Bank with a slightly damp cloth. Let all parts
dry completely.

Storing
21
Storing
− When not in use please disconnect the Power Bank from
the power supply and store it in a clean and dry place
outside of the reach of children.
− When storing for longer periods, charge integral battery
fully, to extend service life. When not using the device for
longer periods of time, charge integral battery regularly.
Fault Finding
The Power Bank is not charged
• Check that Power Bank is correctly connected.
• It can happen that a USB 2.0 connection can not charge
the Power Bank. In this case use a USB 3.0 connection or a
separate power supply.
• Some computers switch off the power supply of the USB
connections when the computer is switched off. Ensure
that computer is switched on.
The Power Bank is not charged
• Check whether the integrated battery is full.
• Check that the connection to the Power Bank is correctly
connected.
• Briefly depress the On/Off button 5to start the charging
operation.
• If the charging process is disrupted after 20 seconds, the
charging current of the device is less than 45mA. The
device cannot be charged using the Power Bank.
