Magnasonic FS51 User manual

FS51 User Manual v1.0
23MP All-In-One Film Scanner
Thank you for your purchase of this Magnasonic product. Please read
this user manual carefully before using product to ensure proper use.
Keep this manual in a safe place for future reference.
magnasonic.com/support

Since 1954, Magnasonic has been a leader in developing innovative
and unique products. We are dedicated to empowering people using
six key fundamentals: superior quality, performance, simplicity, style,
value and a fanatical obsession with outstanding customer service.
At Magnasonic, our mission is a simple one – create people-driven
products that make life’s daily adventures easier and more fun.
We believe everyday experiences should be extraordinary.

Table Of Contents
What’s Included.................................................................................................4
Product Information ........................................................................................5
Operating Instructions ........................................................................7
Using an SD Card...................................................................................8
Selecting Your Film/Slide Type..........................................................9
Capturing an Image .............................................................................10
Adjusting Image Brightness and Color .........................................10
Deleting Saved Images .......................................................................11
Formatting SD Card ..............................................................................11
Watching Saved Images From a TV Screen .................................12
Downloading Images To Your Computer .....................................12
FAQ / Troubleshooting....................................................................................13
Specications ....................................................................................................16
Magnasonic® Warranty ...................................................................................18
Important Safety Instructions ......................................................................20
FCC Information ................................................................................................22

4
What’s Included
• 23MP All-In-One Film Scanner
• 135 slide/main lm tray
• 135 lm adaptor
• 110 lm adaptor
• 126 lm adaptor
• USB to micro USB cable (59.1")
• USB wall adapter
• TV out cable (59.1")
• Cleaning brush
We reserve the right to change models, congurations, or specication without notice or liability.
Product may not be exactly as shown. © MAGNASONIC®, MAGNASONIC®, the MAGNASONIC®
marks may be registered. All other trademarks are property of their respective owners

5
Product Information
TV Out
LED Light
Power On/O
Delete
Playback
LCD Screen
Film Type/Left
EV/RGB/Right
OK/Copy
SD Card Slot
USB Connector/
Power Input
Film/Slide Holder Slot

6
135 Slide Holder/Main Holder
135 Film Adaptor
126 Film Adaptor 110 Film Adaptor

7
Operating Instructions
1. Using the included micro USB to USB cable, connect the micro USB
plug to the micro USB port on the lm scanner.
2. Connect the other end of the USB cable into the included USB
wall adapter.
3. Press the power button on the scanner to turn it on. A blue LED
will turn on indicating the scanner is on.
4. On the LCD screen, a pop up will appear asking if you’d like to link
the lm scanner to your PC. If you do not want to connect to your
PC, select “No”by pressing the button. If you would like to
connect to your PC, see “Downloading Images To Your Computer”
on page 12.
5. You are now ready to scan.
NOTE: This scanner has 64MB of built-in memory available to store scanned images. You may also
use an SD card (up to 32GB) to save even more scanned images. See “Using an SD Card” on page 8
for more details.

8
Using an SD Card
Insert the SD card, face down, into the SD card slot located at the back
of the lm scanner. The SD card will click in automatically if inserted
properly. Remove the SD card by pressing it in until it clicks and pops
out, then remove it from the slot.
NOTE: This lm scanner will only accept SD and SDHC cards with a maximum of 32GB of storage.
XDHC SD cards are not compatible.

9
Selecting Your Film/Slide Type
1. On the bottom left corner of the screen you will see the
symbol. This logo represents the lm type being scanned. It is
automatically defaulted to 135 lm. To change the lm type to
match what you are scanning, press the button until you
see the icon that represents your lm/slide type.
2. Select the appropriate lm/slide adaptor for your lm/slide type
as shown on page 6.
3. Open the main holder, select the appropriate lm adapter for the
lm you are scanning, place it in the main tray making sure the
4 pins of the lm adaptor are properly inserted into the 4 holes
of the main tray until it is lying at. Close the main tray, ensure it
locks with a “click”.
Film/Slide Type Icon
135 Positive Slide
135 Negative
135 Black & White
110 Negative
126 Negative
B/W
110
126
135 Film Adaptor
135 Slide Holder/Main Holder

10
4. Insert the main tray (with selected lm adapter) into the scanner
as shown below. Insert the main tray from the right side of the lm
scanner. The tray is inserted with the arrow side rst.
5. You can now insert the appropriate lm into the main tray. The
image should now be showing on the LCD screen.
Capturing an Image
To capture that image, press the button. The image will be saved
on the lm scanner’s internal memory automatically.
Adjusting Image Brightness and Color
1. The brightness and color are preset automatically. If you would
like to adjust these, press the button. You will then see the
following icons on the screen:
NOTE: Any lm/slides that have already been scanned and saved before adjusting the
brightness or color, will not be aected. Only lm/slides that are scanned after brightness
and color changes are made will be aected.
Insert 135 Slide
