Magnasonic FS71 User manual

FS71 User Manual v1.0
All-In-One 22MP Film Scanner with HDMI
Thank you for your purchase of this Magnasonic product. Please read
this user manual carefully before using product to ensure proper use.
Keep this manual in a safe place for future reference.
magnasonic.com/support
We reserve the right to change models, congurations, or specication without notice or liability. Product may not
be exactly as shown. © MAGNASONIC®, MAGNASONIC®, the MAGNASONIC® marks may be registered. All other
trademarks are property of their respective owners

Since 1954, Magnasonic has been a leader in developing innovative and unique products. We
are dedicated to empowering people using six key fundamentals: superior quality, performance,
simplicity, style, value and a fanatical obsession with outstanding customer service.
At Magnasonic, our mission is a simple one – create people-driven products that make life’s daily
adventures easier and more fun. We believe everyday experiences should be extraordinary.
Thank you for your purchase of this Magnasonic® product.
We hope you enjoy your experience.
Questions?
Give us a chance to help, we’re just a click away.
www.youtube.com/magnasonic
Magnasonic.com/support
Magnasonic.com/contact
Don’t forget to register your product with us!
Magnasonic.com/registration

3
Table Of Contents
What’s Included.....................................................................................................................3
Product Information............................................................................................................4
Operating Instructions .......................................................................................................6
Main Menu Icons.........................................................................................................6
Cleaning and Care.......................................................................................................7
Powering On Your Film Scanner ............................................................................7
Changing The Language ..........................................................................................8
Prepping Your Film/Slides........................................................................................8
Using an SD Card.........................................................................................................9
Scanning Your Images...............................................................................................9
Viewing Your Scanned Images...............................................................................10
Watching Saved Images From a TV Screen........................................................11
Downloading Images To Your Computer ...........................................................11
Formatting Your SD Card..........................................................................................12
FAQ / Troubleshooting........................................................................................................13
Specifications.........................................................................................................................14
Magnasonic® Warranty.......................................................................................................15
Important Safety Instructions..........................................................................................17
Safety Alerts ..................................................................................................................17
Best Practices for Safe Use .......................................................................................17
Cleaning and Care.......................................................................................................18
FCC/HDMI Information.......................................................................................................19
What’s Included
• 22MP All-In-One HDMI Film Scanner
• Slide Adapter
• Negative Film Adapter
• 110 Slide Insert
• 110 Film Insert
• Super 8/8mm Insert
• Mini USB-to-USB Cable
• USB Wall Power Adapter
• Cleaning Brush

4
Product Information
Slide Adapter
Negative Adapter
110 Slide Insert
Super 8/8mm Insert
110 Film Insert

5
Product Information
Home Button
OK/Image Settings
Button
Forward/Flip Button
Film/Slide Adapter Slot
Capture Button
Power Button
Back/Mirror
Button
HDMI PortMini USB Port
LCD Screen
SD Card Slot
Front
Back

6
Main Menu Icons
Format SD Card
Connect to PC
Language Setting
Resolution Setting
Capture Images
Gallery
Film Type Setting

7
Operating Instructions
Cleaning and Care
Use the included cleaning brush to
ensure there is no dust or debris on the
lens. Insert the soft end of the brush,
face down, into the film/slide holder
slot. Carefully push the brush around
inside to get rid of any dust or debris
that may be on the lens
Powering On Your Film Scanner
1. Using the included mini USB to USB cable, connect the mini USB plug to the
mini USB port on the film scanner.
2. Connect the other end of the USB cable into the included USB wall adapter.
Plug the wall adapter into a power outlet.
3. Press the power button on the scanner to turn it on.

8
Changing The Language
1. On the main menu, go to Language.
2. You may now select the language of your choice by using the < and >
buttons to scroll between the available selections.
3. Press the OK button to select the language.
Prepping Your Film/Slides
1. Insert your slide or film into the appropriate slide or film adapter. If you are
unsure what adapter to use, on the film scanner menu go to Film Type then
choose the film or slide type you are going to scan. There will be images of
the corresponding film or slide adapter you can reference.
2. Ensure the slide/film is facing the correct way and is not bent.
3. Close the slide or film adapter and press the edges so that it locks into place.
Note: This scanner has 128MB of built-in memory available to store approximately 50 scanned
images. This lm scanner will also accept SD, SDHC, and SDXC cards with a maximum of 128GB for
extra memory.

9
Using an SD Card
Insert the SD card, face down, into the
SD card slot located at the back of the
film scanner. The SD card will click in
automatically if inserted properly.
Remove the SD card by pressing on it
until it clicks and pops out, then remove
it from the slot.
Scanning Your Images
1. Press and hold the power button for 3 seconds on the scanner to turn
it on.
2. Insert the prepared film or slide adapter into the slot on the right side of the
film scanner.
3. Select your film/slide type that you
are scanning by going into Film
Type on the scanner’s menu, go to
your corresponding film/slide and
press the OK button.
4. Once you have selected your film or
slide type, hit the button to
go back to the main menu.
5. Go to Capture to begin scanning your images. Press the OK button.
6. You should now see your film or slide image on the screen.
Note: If you are using a 128GB SD card, it may need to be formatted before using for the rst time.
Please see page 12 for formatting instructions.

10
Viewing Your Scanned Images
1. To view your scanned images, go
to Gallery and press the OK button.
2. Your images will play
automatically.
3. To manually review your saved
images and stop the auto-play,
press the OK button again.
4. Use the left and right buttons to scroll through each saved image.
7. To adjust brightness or color, press the OK button. Use the left and right
arrow buttons to move between brightness, red, green, or blue. Press the
OK button to adjust them up or down.
8. When ready, press the button to return to your image.
9. You can also mirror or flip your image prior to scanning and saving your
image by pressing the left (mirror) or right (flip) buttons.
10. To capture and save your image, press the button again.
11. You can press the button to return back to the main menu when
your scanning is done.
