Magnetrol Echotel 961 User manual

Model 961/962
Model 961
Model 962
Installation and Operating Manual
Ultrasonic
Single and
Dual Point
Level Switches

51-646 Echotel®Model 961 & 962 Ultrasonic Level Switches
Read this Manual Before Installing
This manual provi es information on the Echotel®
Mo els 961 an 962 Ultrasonic Liqui Level Switches.
It is important that all instructions are rea carefully an
followe in sequence. Detaile instructions are inclu e
in the Installation section of this manual.
Conventions Used in this Manual
Certain conventions are use in this manual to convey
specific types of information. General technical material,
support ata, an safety information are presente in
narrative form. The following styles are use for notes,
cautions, an warnings.
Notes
Notes contain information that augments or clarifies
an operating step. Notes o not normally contain
actions, they follow the proce ural steps to which
they refer.
Cautions
Cautions alert the technician to special con itions
that coul injure personnel, amage equipment, or
re uce a component’s mechanical integrity. Cautions
are also use to alert the technician to unsafe prac-
tices or the nee for special protective equipment or
specific materials. In this manual, a caution box in i-
cates a potentially hazar ous situation which, if not
avoi e , may result in minor or mo erate injury.
Warnings
Warnings i entify potentially angerous situations or
serious hazar s. In this manual, a warning in icates
an imminently hazar ous situation which, if not
avoi e , coul result in serious injury or eath.
Safety Messages
ECHOTEL Mo els 961 & 962 are esigne for use in
Category II, Pollution Degree 2 installations. Follow all
stan ar in ustry proce ures for servicing electrical an
computer equipment when working with or aroun high
voltage. Always shut off the power supply before touch-
ing any components.
Electrical components are sensitive to electrostatic is-
charge. To prevent equipment amage, observe safety
proce ures when working with electrostatic sensitive
components.
This evice complies with Part 15 of the FCC rules.
Operation is subject to the following two con itions:
(1) This evice may not cause harmful interference,
an (2) This evice must accept any interference
receive , inclu ing interference that may cause
un esire operation.
WARNING! Explosion hazar . Do not connect or is-
connect equipment unless power has been switche off
or the area is known to be non-hazar ous.
Low Voltage Directive
For use in Category II installations. If equipment is use
in a manner not specifie by manufacturer, protection
provi e by equipment may be impaire .
Notice of Trade ark, Copyright, and Li itations
Magnetrol®, Magnetrol®logotype an Echotel®are
registere tra emarks of Magnetrol International,
Incorporate .®
Copyright © 2018 Magnetrol International,
Incorporate . All rights reserve .
Performance specifications are effective with ate of issue
an are subject to change without notice. MAGNETROL
reserves the right to make changes to the pro uct
escribe in this manual at any time without notice.
MAGNETROL makes no warranty with respect to the
accuracy of the information in this manual.
Warranty
All MAGNETROL electronic level an flow pro ucts
are warrante free of efects in materials or workman-
ship for eighteen months from the ate of original
factory shipment.
If returne within the warranty perio ; an , upon factory
inspection of the control, the cause of the claim is
etermine to be covere un er the warranty; then,
MAGNETROL will repair or replace the control at no
cost to the purchaser (or owner) other than transportation.
MAGNETROL shall not be liable for misapplication,
labor claims, irect or consequential amage or expense
arising from the installation or use of equipment. There
are no other warranties expresse or implie , except spe-
cial written warranties covering some MAGNETROL
pro ucts.
Quality Assurance
The quality assurance system in place at MAGNETROL
guarantees the highest level of quality throughout the
company. MAGNETROL is committe to provi ing
full customer satisfaction both in quality pro ucts an
quality service.
The MAGNETROL quality assurance
system is registere to ISO 9001
affirming its commitment to known
international quality stan ar s
provi ing the strongest assurance of
pro uct/service quality available.

51-646 Echotel®Model 961 & 962 Ultrasonic Level Switches
Table of Contents
1.0 Introduction ...................................................................4
1.1 Principle of Operation ..............................................4
2.0 Installation .....................................................................4
2.1 Unpacking ................................................................4
2.2 ESD Han ling Proce ure..........................................5
2.3 Mounting..................................................................5
2.4 Wiring ......................................................................6
2.4.1 Mo el 961 Line-powere Wiring ...................6
2.4.1.1 Mo el 961 Remote Trans ucer
Housing Wiring......................................7
2.4.2 Mo el 961 Loop-powere Wiring..................8
2.4.2.1 Mo el 961 Remote Trans ucer
Housing Wiring......................................8
2.4.3 Mo el 962 Line-powere Wiring ...................9
2.4.3.1 Mo el 962 Remote Trans ucer
Housing Wiring....................................10
2.4.4 Mo el 962 Loop-powere Wiring................11
2.4.4.1 Mo el 962 Remote Trans ucer
Housing Wiring....................................11
2.5 Configuration .........................................................12
2.5.1 Mo el 961 Line-powere Configuration ......12
2.5.1.1 Time Delay Potentiometer ....................13
2.5.1.2 Level Test Push Button..........................13
2.5.1.3 Malfunction Test Push Button ..............13
2.5.1.4 High/Low DIP Switch ..........................14
2.5.1.5 In epen ent/Joint DIP Switch..............14
2.5.2 Mo el 961 Loop-powere Configuration.....15
2.5.2.1 Time Delay Potentiometer ....................15
2.5.2.2 Loop Test Push Button..........................15
2.5.2.3 Fault Test Push Button..........................15
2.5.2.4 High/Low DIP Switch ..........................16
2.5.2.5 22/3.6 DIP Switch................................16
2.5.3 Mo el 962 Line-powere Configuration ......17
2.5.3.1 Time Delay Potentiometer ....................17
2.5.3.2 Level Test Push Button..........................17
2.5.3.3 Malfunction Test Push Button ..............17
2.5.3.4 High/Low DIP Switch ..........................18
2.5.3.5 PC/LC DIP Switch...............................18
2.5.3.6 LC an Hi/Lo DIP Switch Configuration 18
2.5.3.7 PC an Hi/Lo DIP Switch Configuration 19
2.5.4 Mo el 962 Loop-powere Configuration.....20
2.5.4.1 Time Delay Potentiometer ....................20
2.5.4.2 Loop Test Push Button..........................20
2.5.4.3 Fault Test Push Button..........................20
2.5.4.4 High/Low DIP Switch ..........................21
2.5.4.5 22/3.6 DIP Switch................................21
3.0 Reference Infor ation..................................................22
3.1 Electronics Specifications ........................................22
3.1.1 Mo el 961/962 with Relay Output..............22
3.1.2 Mo el 961/962 with Current Shift Output .22
3.2 Performance Specifications......................................22
3.3 Physical Specifications.............................................23
3.4 Trans ucer Specifications ........................................23
3.4.1 Mo el 9A1/9M1 Single Point ......................23
3.4.2 Mo el 9A2/9M2 Dual Point........................23
3.5 Dimensional Specifications .....................................24
3.6 Agency Approvals....................................................26
3.6.1 Agency (FM/CSA) Drawing an
Entity Parameters .........................................27
3.7 Troubleshooting ......................................................28
3.8 Replacement Parts...................................................30
3.9 Mo el Number .......................................................32
3.9.1 Mo el 961/962 Electronics ..........................32
3.9.2 Mo el 961 Single Point Trans ucer..............33
3.9.3 Mo el 962 Dual Point Trans ucer ...............34
3.9.4 Connecting Cable ........................................35
Echotel®Model 961 & 962
Ultrasonic Single and Dual Point
Liquid Level Switches

451-646 Echotel®Model 961 & 962 Ultrasonic Level Switches
1.0 Introduction
ECHOTEL Mo el 961 an 962 ultrasonic level switches
utilize pulse signal technology to etect high, low, or ual
point level in a broa range of liqui me ia applications.
Mo el 961 is a single point level switch. Mo el 962 is a
ual point switch use as a level controller or to control
pumps in an auto-fill or auto-empty mo e.
1.1 Principle of Operation
Mo el 961/962 switches utilize ultrasonic energy to etect
the presence or absence of liqui in a single or ual point
trans ucer. Ultrasonic contact level technology uses high-
frequency soun waves that are easily transmitte across a
trans ucer gap (see Figure 1) in the presence of a liqui
me ia, but are attenuate when the gap is ry. Mo el
961/962 switches use an ultrasonic frequency of 2 MHz to
perform this liqui level measurement in a wi e variety of
process me ia an application con itions.
The trans ucer uses a pair of piezoelectric crystals that are
encapsulate in epoxy at the tip of the trans ucer. The
crystals are ma e of a ceramic material that vibrates at a
given frequency when subjecte to an applie voltage. The
transmit crystal converts the applie voltage from the elec-
tronics into an ultrasonic signal. When liqui is present in
the gap, the receive crystal senses the ultrasonic signal from
the transmit crystal an converts it back to an electrical
signal. This signal is sent to the electronics to in icate the
presence of liqui in the trans ucer gap. When there is no
liqui present, the ultrasonic signal is attenuate an is not
etecte by the receive crystal.
2.0 Installation
2.1 Unpacking
Unpack the instrument carefully. Inspect all units for
amage. Report any conceale amage to carrier within
24 hours. Check the contents of the packing slip an
purchase or er. Check an recor the serial number for
future reference when or ering parts.
serial number
Ultrasonic
transducer
Transmit
crystal
Receive
crystal
Figure 1
Ultrasonic Signal Transmission
Across Transducer Gap

5
51-646 Echotel®Model 961 & 962 Ultrasonic Level Switches
Figure 2
Typical Mounting Orientations
2.2 Electrostatic Discharge (ESD) Handling
Procedure
MAGNETROL electronic instruments are manufacture to
the highest quality stan ar s. These instruments use
electronic components that may be amage by static
electricity present in most work environments.
The following steps are recommen e to re uce the risk of
component failure ue to electrostatic ischarge.
• Ship an store circuit boar s in anti-static bags. If an anti-
static bag is not available, wrap the boar in aluminum
foil. Do not place boar s on foam packing materials.
• Use a groun ing wrist strap when installing an removing
circuit boar s. A groun e workstation is recommen e .
• Han le circuit boar s only by the e ges. Do not touch
components or connector pins.
• Make sure that all electrical connections are completely
ma e an none are partial or floating. Groun all equip-
ment to a goo , earth groun .
2.3 Mounting
The Mo el 961 level switch may be mounte in a variety
of positions as shown in Figures 2 through 5. Mo el 962
is always mounte vertically.
Proper orientation of the trans ucer gap will facilitate
maximum performance in ifficult applications. When the
Mo el 961 is mounte horizontally, the trans ucer gap
must be turne vertically to allow proper rainage of liqui
out of the gap. The wrench flats on the mounting nut are
aligne with the trans ucer gap; therefore, proper trans-
ucer mounting can be achieve by aligning the mounting
nut flats in a vertical orientation. See Figure 4. For flange
trans ucers, a vertical gap orientation shoul be confirme
prior to installing unit to the mating flange.
When installing a Mo el 961 switch in a nozzle or pipe,
the trans ucer gap must exten into the tank at least one
inch beyon the insi e tank wall. Refer to Figure 5.
Screw trans ucer into the opening using a wrench on the
trans ucer mounting nut flats. If flange , bolt unit to mat-
ing flange with proper gasket. Use threa tape or suitable
pipe compoun on the threa s. Do not over-tighten.
Pump
Protection
Fill Line Dual Point Alarm
High Alarm
Low Alarm
Figure 3
Vertical Mounting
Use wrench on flats
Process
connection
Bottom View
Bottom View
Figure 4
Horizontal Mounting
Figure 5
Nozzle Mounting

651-646 Echotel®Model 961 & 962 Ultrasonic Level Switches
2.4 Wiring
Wiring for Mo el 961/962 level switches is ifferent for all
four versions. These switches are available as 4-wire, line-
powere units with 5-amp relays, or as 2-wire loop-pow-
ere units with mA current shift output. Determine which
version you have from the table below an procee to the
proper wiring section.
2.4.1 Model 961 Line-powered Wiring
Power an relay wiring connections are suitable for
12–24 AWG wire.
Caution: OBSERVE ALL APPLICABLE ELECTRICAL CODES
AND PROPER WIRING PROCEDURES.
1. Make sure the power source is turne off.
2. Unscrew an remove housing cover.
3. Pull power supply an relay wires through the con uit
connection.
4. Refer to Figure 6. Connect power lea s to proper terminals.
Mo el 961 is available for AC power (102 to 265 VAC) or
for DC power (18–32 VDC)
a. AC Power – Connect “hot” wire to terminal marke L1
an the “neutral” wire to the terminal marke L2. The
green hea screw shoul be use for groun ing.
b. DC Power – Connect wires to terminals (+) an (-) on
the terminal block. The green hea screw shoul be
use for groun ing.
5. Connect esire relay wiring as shown in Figure 6.
6. Prevent moisture seepage into housing by installing an
approve seal rain fitting in the con uit run lea ing to
the unit.
7. Wiring is complete. Replace housing cover.
Caution: In hazardous areas, do not power the unit until the
conduit is sealed and enclosure cover is screwed
down securely.
NOTE: Housing must be grounded via green head ground screw in
the base of the housing.
TIME
DELAY
LEVEL
TEST
MALF
TEST
MALF RELAY
FAULT
WET
LEVEL
MALF
MODEL 961
NC C NONC C NO NC C NO L2L1
Malfunction
SPDT Relay
Input
Power
Ground
Level DPDT
Relay
Hi I
Lo J
Model Input Output Wiring Information
961 Line-powered 5 amp relays Proceed to section 2.4.1
961 Loop-powered Current shift Proceed to section 2.4.2
962 Line-powered 5 amp relays Proceed to section 2.4.3
962 Loop-powered Current shift Proceed to section 2.4.4
Figure 6
Model 961 Line-Powered Wiring

7
51-646 Echotel®Model 961 & 962 Ultrasonic Level Switches
2.4.1.1 Model 961 Remote Transducer Housing Wiring
Remote mount Mo el 961 units have a “1” as the 8th
igit (961-XXXX-1XX) of the mo el number. The
037-3316-XXX cabling is connecte at the factory on the
electronics en , an secure with a cable tie. The other
en of the cabling is connecte by the user insi e the
remote trans ucer housing at a terminal block marke as
1 2 3 4 on a blue label. See Figure 7.
NOTE: The 037-3316-XXX cabling is connected at the factory on the
electronics end. TB1 and TB2 connections are shown below
in Figure 7 in the event the cable needs to be reattached.
NOTE: The Signal wires are 30 AWG RG Type 178/U coax with the white jacket stripped
off. The Shield wires are prepared with solid tinned copper 22 AWG bus wire.
Ground
037-3316-xxx Cabling
Shield: 1, 3
Signal: 2, 4
030-3591-001
P2
R29
TB1
TB1
TB2
TB2
RECVXMIT
Figure 7
Model 961 Line-Powered Remote Transducer Wiring
Remote Transducer Housing
Electronics Module
Transducer Housing
Terminal Position Wire Electronics Terminal Block & Terminal Position
1 Receive Shield
TB1
2 Receive Signal RECV
3 Transmit Shield
TB2
4 Transmit Signal XMIT
Model 961 Line-powered Remote Mount Wiring

851-646 Echotel®Model 961 & 962 Ultrasonic Level Switches
2.4.2 Model 961 Loop-powered Wiring
For intrinsically safe installations, refer to the Agency
Drawing in Section 3.6.1. Loop wiring connections are
suitable for 12–24 AWG wire.
Caution: OBSERVE ALL APPLICABLE ELECTRICAL CODES
AND PROPER WIRING PROCEDURES.
1. Make sure the power source is turne off.
2. Unscrew an remove housing cover.
3. Pull twiste pair wire through the con uit connection.
4. Refer to Figure 8. Connect wires to terminals (+) an (-)
on the terminal block. Unshiel e cable may be use . If
shiel e cable is use , attach shiel to green hea screw.
5. Prevent moisture seepage into housing by installing an
approve seal rain fitting in the con uit run lea ing to
the unit.
6. Wiring is complete. Replace housing cover.
Caution: In hazardous areas, do not power the unit until the
conduit is sealed and enclosure cover is screwed
down securely.
2.4.2.1 Model 961 Remote Transducer Housing Wiring
Remote mount Mo el 961 units have a “1” in the 8th
igit (961-XXXX-1XX) of the mo el number. The
037-3316-XXX cabling is connecte at the factory on the
electronics en , an secure with a cable tie. The other
en of the cabling is connecte by the user insi e the
remote trans ucer housing at a terminal block marke as
1 2 3 4 on a blue label. See Figure 9.
NOTE: The 037-3316-XXX cabling is connected at the factory on the
electronics end. TB2 and TB3 connections are shown in
Figure 9 in the event the cable needs to be reattached.
TIME
DELAY
FAULT
TEST
MODEL 961
–+
Hi 22
Lo 3.6
LOOP
TEST 8 16
+–
F
A
U
L
T
Ground
Figure 8
Model 961 Loop-Powered Wiring
Transducer Housing
Terminal Position Wire
1 Receive Shield
2 Receive Signal
3 Transmit Shield
4 Transmit Signal
Electronics Terminal Block
& Terminal Position Wire
TB3
RECV Receive Signal
Receive Shield
TB2
XMIT Transmit Signal
Transmit Shield
Model 961 Loop-powered Remote Mount Wiring
NOTE: The Signal wires are 30 AWG RG Type 178/U coax with the white jacket stripped off. The Shield wires
are prepared with solid tinned copper 22 AWG bus wire.

51-646 Echotel®Model 961 & 962 Ultrasonic Level Switches
2.4.3 Model 962 Line-powered Wiring
Power an relay wiring connections are suitable for 12–
24 AWG wire.
Caution: OBSERVE ALL APPLICABLE ELECTRICAL CODES
AND PROPER WIRING PROCEDURES.
1. Make sure the power source is turne off.
2. Unscrew an remove housing cover.
3. Pull power supply an relay wires through the con uit
connection.
4. Refer to Figure 10. Connect power lea s to proper terminals.
Mo el 962 is available for AC power (102 to 265 VAC) or
for DC power (18–32 VDC)
a. AC Power – Connect “hot” wire to terminal marke L1
an the “neutral” wire to the terminal marke L2. The
green hea screw shoul be use for groun ing.
b. DC Power – Connect wires to terminals (+) an (-) on
the terminal block. The green hea screw shoul be
use for groun ing.
5. Connect esire relay wiring as shown in Figure 10.
6. Prevent moisture seepage into housing by installing an
approve seal rain fitting in the con uit run lea ing to
the unit.
7. Wiring is complete. Replace housing cover.
Caution: In hazardous areas, do not power the unit until the
conduit is sealed and enclosure cover is screwed
down securely.
TIME
DELAY
LEVEL
TEST
MALF
TEST
MALF RELAY
FAULT
MALF
LOWER
UPPER
MODEL 962
NC C NONC C NO NC C NO L2L1
Malfunction
SPDT Relay
Input
Power
Ground
Lower Gap
SPDT Relay
Upper Gap
SPDT Relay
Hi PC
Lo LC
LOWER UPPER
Figure 10
Model 962 Line-Powered Wiring
Ground
Shield: 1, 3
Signal: 2, 4
TB3
DELAY
FAULT
16ma
8ma
FORCE
CHANGE
FORCE
FAULT
TB2
XMIT
TB2
TB3
RECV
037-3316-xxx Cabling
Figure 9
Model 961 Loop-Powered Remote Transducer Wiring
Remote Transducer Housing
Electronics Module

10 51-646 Echotel®Model 961 & 962 Ultrasonic Level Switches
2.4.3.1 Model 962 Remote Transducer Housing Wiring
Remote mount Mo el 962 units have a “1” in the 8th
igit (962-XXXX-1XX) of the mo el number. The
037-3317-XXX cabling is connecte at the factory on the
electronics en , an secure with a cable tie. The other
en of the cabling is connecte by the user insi e the
remote trans ucer housing at terminal blocks marke as
12345678on a blue label. See Figure 11 for proper
terminations.
NOTE: The 037-3317-XXX cabling is connected at the factory on the
electronics end. TB1, TB2, TB3, and TB4 connections are
shown below in Figure 11 in the event the cable needs to be
reattached.
P2
TB1
TB1
TB4
TB4
RCV1XMIT1
TB3
TB3
TB2
TB2
RCV2XMIT2
037-3317-xxx Cabling
Ground
Shield: 1, 3, 5, 7
Signal: 2, 4, 6, 8
Model 962 Remote Transducer Wiring
Figure 11
Model 962 Line-Powered Remote Transducer Wiring
Transducer
Gap
Cable
Marker
Wire
Marker
Transducer
Housing TB
Position Wire
Electronics
Housing TB &
Terminal Position
Upper High 1 1 Transmit Shield TB4
Upper High 1 2 Transmit Signal XMT1
Upper High (none) 3 Receive Shield TB1
Upper High (none) 4 Receive Signal RCV1
Lower Low 1 5 Transmit Shield TB2
Lower Low 1 6 Transmit Signal XMT2
Lower Low (none) 7 Receive Shield TB3
Lower Low (none) 8 Receive Signal RCV2
Model 962 Line-powered Remote Mount Wiring
NOTE: The Signal wires are 30 AWG RG Type 178/U coax with the white jacket stripped off. The Shield wires
are prepared with solid tinned copper 22 AWG bus wire.

11
51-646 Echotel®Model 961 & 962 Ultrasonic Level Switches
TIME
DELAY
FAULT
TEST
MODEL 962
–+
Hi 22
Lo 3.6
LOOP
TEST 812 16
+–
Ground
Figure 12
Model 962 Loop Power Wiring
2.4.4 Model 962 Loop-powered Wiring
For intrinsically safe installations, refer to the Agency
Drawing in Section 3.6.1. Loop wiring connections are
suitable for 12–24 AWG wire.
Caution: OBSERVE ALL APPLICABLE ELECTRICAL CODES
AND PROPER WIRING PROCEDURES.
1. Make sure the power source is turne off.
2. Unscrew an remove housing cover.
3. Pull twiste pair wire through the con uit connection.
4. Refer to Figure 12. Connect wires to terminals (+) an (-)
on the terminal block. Unshiel e cable may be use . If
shiel e cable is use , attach shiel to green hea screw.
5. Prevent moisture seepage into housing by installing an
approve seal rain fitting in the con uit run lea ing to
the unit.
6. Wiring is complete. Replace housing cover.
Caution: In hazardous areas, do not power the unit until the
conduit is sealed and enclosure cover is screwed
down securely.
2.4.4.1 Model 962 Remote Transducer Housing Wiring
Remote mount Mo el 962 units have a “1” in the 8th
igit (962-XXXX-1XX) of the mo el number. The
037-3317-XXX cabling is connecte at the factory on the
electronics en an secure with a cable tie. The other en
of the cabling is connecte by the user insi e the remote
trans ucer housing at terminal blocks marke as
12345678on a blue label. See Figure 13 for proper
terminations.

12 51-646 Echotel®Model 961 & 962 Ultrasonic Level Switches
TB1
TB1
TB4
TB4TB3
TB3
TB2
TB2
RECV1
XMIT1
RECV2
XMIT2
037-3317-xxx Cabling
Ground
Shield: 1, 3, 5, 7
Signal: 2, 4, 6, 8
Model 962 Remote Transducer Wiring
Figure 13
Model 962 Loop-Powered Remote Transducer Wiring
Transducer
Gap
Cable
Marker
Wire
Marker
Transducer
Housing TB
Position Wire
Electronics
Housing TB &
Terminal Position
Upper High 1 1 Transmit Shield TB2
Upper High 1 2 Transmit Signal XMT1
Upper High (none) 3 Receive Shield TB3
Upper High (none) 4 Receive Signal RCV1
Lower Low 1 5 Transmit Shield TB4
Lower Low 1 6 Transmit Signal XMT2
Lower Low (none) 7 Receive Shield TB1
Lower Low (none) 8 Receive Signal RCV2
Model 962 Loop-powered Remote Mount Wiring
2.5 Configuration
2.5.1 Model 961 Line-powered Configuration
Mo el 961 line-powere units have the following
configuration options:
• TIME DELAY potentiometer for 0.5 to 10 secon
signal averaging
• LEVEL TEST push button for testing of the DPDT
process level alarm
• MALF TEST push button for testing of the SPDT
malfunction alarm
• Hi/Lo DIP switch for fail-safe high or low level selection
• I/J DIP switch for in epen ent or joint operation of
the relays
NOTE: The Signal wires are 30 AWG RG Type 178/U coax with the white jacket stripped off. The Shield wires are
prepared with solid tinned copper 22 AWG bus wire.

13
51-646 Echotel®Model 961 & 962 Ultrasonic Level Switches
TIME
DELAY
LEVEL
TEST
MALF
TEST
MALF RELAY
FAULT
WET
LEVEL
MALF
MODEL 961
NC C NONC C NO NC C NO L2L1
High/Low
DIP Switch
Independent/Joint
DIP Switch
Level Test
Pushbutton
Malfunction Test
Pushbutton
Hi I
Lo J
Time Delay Pot
to decrease delay
to increase delay
Turn
Turn
Figure 14
Model 961 Line Power Configuration
2.5.1.1 Time Delay Potentiometer
The time elay potentiometer is typically use in applica-
tions where turbulence or splashing may cause false level
alarms. This is a 25-turn pot with a factory efault setting
of 0.5 secon s. If esire , this pot may be turne clockwise
to increase the response time from the stan ar 0.5 secon s
to a maximum of 10 secon s. Turning the pot counter-
clockwise ecreases the time elay.
The WET LED is not influence by the time elay pot.
As an example, turning the pot clockwise several turns will
put a time elay into the 961. Immersing the tip of the
trans ucer in water with the Hi/Lo switch in the Hi posi-
tion, will pro uce the following results:
• WET LED will imme iately turn on
• After the time elay the LEVEL LED will turn off an the
DPDT process level relay will e-energize
When removing the tip of the trans ucer from the water
the WET LED will imme iately turn off. After the time
elay the LEVEL LED will turn on an DPDT process
level relay will energize.
2.5.1.2 Level Test Push Button
The level test push button is use to manually test the
DPDT process level relay. Pressing this push button reverses
the state of the DPDT relay, from energize to e-ener-
gize or vice-versa. This can be use to manually test the
relay, an whatever is connecte to this relay. The time
elay pot oes not affect the operation of the level test
push button.
2.5.1.3 Malfunction Test Push Button
The malfunction test push button is use to manually test
the SPDT malfunction relay. Pressing an hol ing this
push button for 2 secon s will cause the SPDT relay to
e-energize in icating a fault con ition. This can be use
to manually test the relay, an whatever is connecte to
this relay. The time elay pot oes not affect the operation
of the malfunction push button.
NOTE: Under normal operating conditions the green MALF (malfunc-
tion) LED is on to indicate that the malfunction relay is ener-
gized, and the red FAULT LED is off to indicate that there are
no faults. Should a fault condition occur, the red FAULT LED
turns on and the green MALF LED turns off, indicating that the
malfunction relay is de-energized.
Operating
Condition
Red
Fault LED
Green
Malfunction LED
Normal Off On
Fault On Off
Fault and Malfunction LED Indication

14 51-646 Echotel®Model 961 & 962 Ultrasonic Level Switches
2.5.1.4 High/Low DIP Switch
The Hi/Lo Dip Switch is use to select whether the
Mo el 961 will be use as a high level fail-safe (HLFS)
switch or a low level fail-safe (LLFS) switch.
In the Hi position the DPDT process level relay will
e-energize (alarm con ition) when the gap becomes wet.
In the Lo position the DPDT process level relay will
e-energize (alarm con ition) when the gap becomes ry.
The table below provi es assistance in configuring the
Hi/Lo DIP switch.
Hi/Lo DIP
Switch
Gap
Condition
Level
Condition
Relay
Contacts WET LED
LEVEL
LED
Hi
(HLFS) Dry
NC
C
NO
Off On
Hi
(HLFS) Wet
NC
C
NO
On Off
Lo
(LLFS) Wet
NC
C
NO
On On
Lo
(LLFS) Dry
NC
C
NO
Off Off
High/Low DIP Switch Configuration (Model 961 Line-powered)
Normal
Alarm
Normal
Alarm
Energized
De-energized
Energized
De-energized
2.5.1.5 Independent/Joint DIP Switch
The I/J DIP switch is use to configure whether the SPDT
malfunction relay acts in epen ently or jointly with the
DPDT process level relay. The factory efault is for this
switch to be in the “I” position, where the relays act totally
in epen ent of each other. If this DIP switch is in the “J”
position, both the SPDT malfunction relay an the DPDT
process relay will e-energize when a fault is etecte .

15
51-646 Echotel®Model 961 & 962 Ultrasonic Level Switches
TIME
DELAY
FAULT
TEST
MODEL 961
Hi 22
Lo 3.6
LOOP
TEST
+–
8 16
F
A
U
L
T
High/Low
DIP Switch
22/3.6 mA
DIP Switch
Fault Test
Push Button
Loop Test
Push Button
Time Delay Pot
to decrease delay
to increase delay
Turn
Turn
Figure 15
Model 961 Loop Power Configuration
2.5.2 Model 961 Loop-powered Configuration
Mo el 961 loop-powere units have the following config-
uration options:
• TIME DELAY potentiometer for 0.5 to 10 secon signal
averaging
• LOOP TEST push button for testing the 8/16 mA loop
output
• FAULT TEST push button for testing the 3.6 or 22 mA
fault output
• Hi/Lo DIP switch for fail-safe high or low level selection
• 22/3.6 DIP switch to select the fault mA current output
2.5.2.1 Time Delay Potentiometer
The time elay potentiometer is typically use in applica-
tions where turbulence or splashing may cause false level
alarms. This is a 25-turn pot with a factory efault setting
of 0.5 secon s. If esire , this pot may be turne clockwise
to increase the response time from the stan ar 0.5 secon s
to a maximum of 10 secon s. Turning the pot counter-
clockwise ecreases the time elay.
2.5.2.2 Loop Test Push Button
The loop test push button is use to manually test the loop
current output. Pressing the LOOP TEST push button
reverses the output from 8 mA to 16 mA or from 16 mA
to 8 mA. This can be use to manually test the loop out-
put an whatever is connecte to the 961. The time elay
pot oes not affect the operation of the loop test push button.
2.5.2.3 Fault Test Push Button
The FAULT TEST push button is use to manually force
the 961 to the mA value that is selecte at the 22/3.6 DIP
switch. Pressing this push button for 2 secon s will simu-
late a circuit test failure. This causes the output to go to
the selecte fault current of either 22 or 3.6 mA, an the
re FAULT LED will light. The time elay pot oes not
affect the operation of the FAULT TEST push button.
NOTE: Fault current will be greater than 21 mA, or less than 3.6 mA.

16 51-646 Echotel®Model 961 & 962 Ultrasonic Level Switches
2.5.2.4 High/Low DIP Switch
The Hi/Lo DIP switch is use to select whether the 961
will be use as high level fail-safe switch or low level fail-safe
switch. Normal process level operation pro uces an 8 mA
value, an 16 mA is pro uce when the unit is in a level
alarm state. The table can be use to assist in configuring
the Hi/Lo DIP switch.
2.5.2.5 22/3.6 DIP Switch
The 22/3.6 DIP switch is use to select whether the 961
will pro uce a 22 mA or a 3.6 mA output when the unit
etects a fault con ition.
NOTE: Fault current will be greater than 21 mA, or less than 3.6 mA.
Hi/Lo DIP
Switch
Gap
Condition
Level
Condition
Output
Signal
8 mA
LED
16 mA
LED
FAULT
LED
Hi
(HLFS)
Dry 8 mA
(±1 mA) On Off Off
Wet 16 mA
(±1 mA) Off On Off
Lo
(LLFS)
Wet 8 mA
(±1 mA) On Off Off
Dry 16 mA
(±1 mA) Off On Off
High/Low DIP Switch Configuration (Model 961 Loop-powered)
NOTE: The FAULT LED only turns on during a fault condition.
Normal
Alarm
Normal
Alarm

17
51-646 Echotel®Model 961 & 962 Ultrasonic Level Switches
2.5.3 Model 962 Line-powered Configuration
Mo el 962 line-powere units have the following configu-
ration options:
• TIME DELAY potentiometer for 0.5 to 10 secon signal
averaging
• LEVEL TEST push button for testing of the SPDT
process level relays
• MALF TEST push button for testing of the SPDT mal-
function relay
• Hi/Lo DIP switch for fail-safe high or low level selection
• PC/LC DIP switch for level control or pump control
operation
2.5.3.1 Time Delay Potentiometer
The time elay potentiometer is typically use in applica-
tions where turbulence or splashing may cause false level
alarms. This is a 25-turn pot with a factory efault setting
of 0.5 secon s. If esire , this pot may be turne clock-
wise to increase the response time from the stan ar 0.5
secon s to a maximum of 10 secon s. Turning the pot
counterclockwise ecreases the time elay.
2.5.3.2 Level Test Push Button
The LEVEL TEST push button is use to manually test
both of the SPDT process level relays. Pressing this push
button reverses the state of both SPDT process level relays,
from energize to e-energize or vice-versa. This can be
use to manually test these relays, an whatever is con-
necte to them. The time elay pot oes not affect the
operation of the LEVEL TEST push button.
2.5.3.3 Malfunction Test Push Button
The MALF TEST push button is use to manually test
the SPDT malfunction relay. Pressing an hol ing this
push button for 2 secon s will cause all three relays to
e-energize, in icating a fault con ition. This can be use
to manually test the relay, an whatever is connecte to
this relay. The time elay pot oes not affect the operation
of the malfunction push button.
NOTE: Under normal operating conditions the red fault LED is off and
the green malfunction LED is on, indicating that the
malfunction relay is energized. Should a fault condition occur,
the red fault LED turns on and the green malfunction LED
turns off, indicating that the malfunction relay is de-energized.
TIME
DELAY
LEVEL
TEST
MALF
TEST
MALF RELAY
FAULT
MALF
LOWER
UPPER
MODEL 962
NC C NONC C NO NC C NO L2L1
Hi PC
Lo LC
LOWER UPPER
High/Low
DIP Switch
Pump Control/Level Control
DIP Switch
Level Test
Push Button
Malfunction Test
Push Button Time Delay Pot
to decrease delay
to increase delay
Turn
Turn
Figure 16
Model 962 Line Power Configuration
Operating
Condition
Red
Fault LED
Green
Malfunction LED
Normal Off On
Fault On Off
Fault and Malfunction LED Indication

18 51-646 Echotel®Model 961 & 962 Ultrasonic Level Switches
2.5.3.4 High/Low DIP Switch
The Hi/Lo DIP switch is use to select whether the 962
will be use as a high level fail-safe (HLFS) switch or low
level fail-safe (LLFS) switch. The setting of the Hi/Lo DIP
also affects how the PC/LC DIP switch configures the
unit. Rea Section 2.5.3.5 below an then procee to the
appropriate table in Section 2.5.3.6 or 2.5.3.7 for proper
setting of the DIP switches.
2.5.3.5 PC/LC DIP Switch
The PC/LC DIP switch is use to select whether the 962
will operate in a pump control or a level control mo e.
Select LC to use the 962 as a level controller where the
relays operate in epen ently of each other. Select PC to
operate the 962 as a pump controller where the relays
latch to enable an auto fill or auto empty mo e.
The configuration tables (Section 2.5.3.6 & 2.5.3.7) are
use for proper setting of the Hi/Lo an PC/LC DIP
switches. They also in icate the status of the yellow
LOWER an UPPER LEDs. The green MALF (malfunc-
tion) LED an the re FAULT LEDs are not inclu e in
these tables.
2.5.3.6 LC and Hi/Lo DIP Switch Configuration Table
Level
Condition
Hi/Lo DIP
Switch
Lower Gap Upper Gap
Relay LED Relay LED
Hi energized On energized On
Lo de-energized Off de-energized Off
Hi de-energized Off energized On
Lo energized On de-energized Off
Hi de-energized Off de-energized Off
Lo energized On energized On
Level Control (DIP switch set to LC)
NOTE: During a fault condition all three relays de-energize

1
51-646 Echotel®Model 961 & 962 Ultrasonic Level Switches
2.5.3.7 PC and Hi/Lo DIP Switch Configuration Tables
Level
Condition
Hi/Lo DIP
Switch
Lower Gap Upper Gap
Relay LED Relay LED
Hi energized On energized On
Hi energized On energized On
Hi de-energized Off de-energized Off
Hi de-energized Off de-energized Off
Hi energized On energized On
Pump Control (DIP switch set to PC)
Auto-empty Pump Control Sequence
NOTE: During a fault condition all three relays de-energize
Level
Condition
Hi/Lo DIP
Switch
Lower Gap Upper Gap
Relay LED Relay LED
Lo de-energized Off de-energized Off
Lo de-energized Off de-energized Off
Lo energized On energized On
Lo energized On energized On
Lo de-energized Off de-energized Off
Pump Control (DIP switch set to PC)
Auto-fill Pump Control Sequence
NOTE: During a fault condition all three relays de-energize

20 51-646 Echotel®Model 961 & 962 Ultrasonic Level Switches
2.5.4 Model 962 Loop-powered Configuration
Mo el 962 loop-powere units have the following config-
uration options:
• TIME DELAY potentiometer for 0.5 to 10 secon signal
averaging
• LOOP TEST push button for testing the 8/12/16 mA
loop output
• FAULT TEST push button for testing the 3.6 or 22 mA
fault output
• Hi/Lo DIP switch for fail-safe high or low level selection
• 22/3.6 DIP switch to select the fault mA current output
2.5.4.1 Time Delay Potentiometer
The time elay potentiometer is typically use in applica-
tions where turbulence or splashing may cause false level
alarms. This is a 25-turn pot with a factory efault setting
of 0.5 secon s. If esire , this pot may be turne clock-
wise to increase the response time from the stan ar 0.5
secon s to a maximum of 10 secon s. Turning the pot
counterclockwise ecreases the time elay.
2.5.4.2 Loop Test Push Button
The loop test push button is use to manually test the
loop current output. Pressing the LOOP TEST push but-
ton will force the output from 8 mA to 12 mA, 12 mA to
16 mA, or 16 mA to 8 mA. This can be use to manually
test the loop output an whatever is connecte to the 962.
The time elay pot oes not affect the operation of the
loop test push button.
2.5.4.3 Fault Test Push Button
The FAULT TEST push button is use to manually force
the 962 to the mA value that is selecte at the 22/3.6 DIP
switch. Pressing this push button for 2 secon s will simu-
late a circuit test failure. This causes the output to go to
the selecte fault current of either 22 or 3.6 mA, an all 3
LEDs will go ark. The time elay pot oes not affect the
operation of the FAULT TEST push button.
NOTE: Fault current will be greater than 21 mA, or less than 3.6 mA.
TIME
DELAY
FAULT
TEST
MODEL 962
Hi 22
Lo 3.6
LOOP
TEST 812 16
+
–
High/Low
DIP Switch
22/3.6 mA
DIP Switch
Fault Test
Push Button
Loop Test
Push Button
Time Delay Pot
to decrease delay
to increase delay
Turn
Turn
Figure 17
Model 962 Loop Power Configuration
