Maipu MP2600C Series User manual

MP2600D, MP2600C & MP1700E Series Installation Manual V1.4
Maipu Confidential & Proprietary Information Page 1 of 52
MP2600D&MP2600C&MP1700E
Series Routers
Installation Manual V1.4
Maipu Communication Technology Co., Ltd
No. 16, Jiuxing Avenue
Hi-tech Park
Chengdu, Sichuan Province
People’s Republic of China - 610041
Tel: [phone]
Fax: [phone]
URL: http:// www.maipu.com
Email: [email protected]

MP2600D, MP2600C & MP1700E Series Installation Manual V1.4
Maipu Confidential & Proprietary Information Page 2 of 52
All rights reserved. Printed in the People’s Republic of China.
No part of this document may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any
language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual
or otherwise without the prior written consent of Maipu Communication Technology Co., Ltd.
Maipu makes no representations or warranties with respect to this document contents and specifically disclaims any implied
warranties of merchantability or fitness for any specific purpose. Further, Maipu reserves the right to revise this document
and to make changes from time to time in its content without being obligated to notify any person of such revisions or
changes.
Maipu values and appreciates comments you may have concerning our products or this document. Please address comments
to:
Maipu Communication Technology Co., Ltd
No. 16, Jiuxing Avenue
Hi-tech Park
Chengdu, Sichuan Province
People’s Republic of China - 610041
Tel: [phone]
Fax: [phone]
URL: http:// www.maipu.com
Email: [email protected]
All other products or services mentioned herein may be registered trademarks, trademarks, or service marks of their
respective manufacturers, companies, or organizations.
Document History
Date Revision No. Description
20/09/2007 R1.0 The MP2600D, MP2600C & MP1700E Series Installation Manual V1.4 provides
information about the installation of routers designed and developed by Maipu
Communication Technology Co., Ltd

MP2600D, MP2600C & MP1700E Series Installation Manual V1.4
Maipu Confidential & Proprietary Information Page 3 of 52
Maipu Feedback Form
Your opinion helps us improve the quality of our product documentation
and offer better services. Please fax your comments and suggestions to
(86) 28-85148948, 85148139 or email to [email protected].
Document Title MP2600D, MP2600C & MP1700E SERIES INSTALLATION MANUAL V1.4
Product
Version Document
Revision
Number
1.0
Evaluate this
document Presentation:
(Introductions, procedures, illustrations, completeness, arrangement, appearance)
Good Fair Average Poor
Accessibility:
(Contents, index, headings, numbering)
Good Fair Average Poor
Editorial:
(Language, vocabulary, readability, clarity, technical accuracy, content)
Good Fair Average Poor
Your
suggestions to
improve the
document
Please check suggestions to improve this document:
Improve introduction Make more concise
Improve Contents Add more step-by-step procedures/tutorials
Improve arrangement Add more technical information
Include images Make it less technical
Add more detail Improve index
If you wish to be contacted, complete the following:
Name Company
Postcode Address
Telephone Email

MP2600D, MP2600C & MP1700E Series Installation Manual V1.4
Maipu Confidential & Proprietary Information Page 4 of 52
Contents
Installation Manual ....................................................................................7
Purpose .................................................................................................................7
How to Get in Touch ...............................................................................................7
Customer Support...................................................................................................................7
Documentation Support...........................................................................................................7
Overview.....................................................................................................8
Product Features........................................................................................9
Hardware Features.................................................................................. 11
MP2600D, MP2600C & MP1700E Router Appearance...............................................11
MP2600D, MP2600C & MP1700E Front Panel ..........................................................12
MP2600D, MP2600C & MP1700E Back Panel...........................................................14
MP2600D, MP2600C & MP1700E System................................................................15
Product Functions.................................................................................................16
MP2600D, MP2600C & MP1700E Main Board ..........................................................17
Modules.................................................................................................... 22
Sync/Async Serial Interface Module (SAE) Series.....................................................22
1-port High-speed V.24/V.35 Serial Module (1SAE).................................................................22
1SAE Interface Module ..........................................................................................................23
1SAE interface module connected cable..................................................................................23
1SAE Interface Attributes.......................................................................................................23
Channelized E1 Module (CE1) Series ......................................................................24
1-port channelized E1 Module (1CE1).....................................................................................24
1CE1 Interface & Indicator.....................................................................................................24
1CE1 Interface Module Connected Cable ................................................................................24

MP2600D, MP2600C & MP1700E Series Installation Manual V1.4
Maipu Confidential & Proprietary Information Page 5 of 52
Non-channelized E1 Series ....................................................................................25
1-port Non-channelized E1 (1E1) ...........................................................................................25
Frequency-band MODEM M336 Series....................................................................26
1-port 33.6K Frequency-band MODEM (1M336) .....................................................................26
Base-band MODEM (M128) Series..........................................................................28
1-port 128K Base-band MODEM (1M128)...............................................................................28
ISDN (U) Series....................................................................................................29
1-port ISDN U Module (1U)....................................................................................................29
IP Module (VOP/VOS) Series..................................................................................30
1-port VoIP Module (1VOP)....................................................................................................30
2-port VoIP Module (2VOP)....................................................................................................32
1-port Switch VoIP Module (1VOS).........................................................................................33
2-port Switch VoIP Module (2VOS).........................................................................................34
Ethernet Module (ETE) Series ................................................................................35
1-port Ethernet Module (1ETE) ..............................................................................................35
ISDN S/T Module (ST) Series.................................................................................36
1-port ISDN S/T Module (1ST)...............................................................................................36
System Installation................................................................................. 37
Preparation ..........................................................................................................37
Environment Requirements....................................................................................................38
Check Router & Accessories...................................................................................................39
Chassis Installation...............................................................................................40
Tools & Equipment ................................................................................................................40
Machine Installation...............................................................................................................41
Connecting Power Supply ......................................................................................................41
Main Control Board Cable Connection.....................................................................................42
Console Port Connection........................................................................................................42
Grounding Wire Connection ...................................................................................................42
Module Installation ................................................................................................................43
Rack/Desk ............................................................................................................................43
Panel Wire Connection...........................................................................................................43

MP2600D, MP2600C & MP1700E Series Installation Manual V1.4
Maipu Confidential & Proprietary Information Page 6 of 52
Hardware Installation ............................................................................................................44
Module Interface Cable Connection ........................................................................45
1SA Module Cable Connection................................................................................................45
1CE1/1E1 Module Cable Connection.......................................................................................47
1M336 Module Cable Connection............................................................................................47
1M128 Module Interface Cable Connection .............................................................................48
1U Module Interface Cable Connection ...................................................................................48
1VOP/2VOP Module Cable Connection....................................................................................48
1VOS/2VOS Module Cable Connection....................................................................................48
1ETE Module Cable Connection ..............................................................................................49
1ST Module Cable Connection................................................................................................49
Interface Cable Signal............................................................................. 50
Ethernet Interface Cable........................................................................................50
Console Port Cable................................................................................................51
RM2-1E1 & RM2-1CE1 Uses RJ45-RJ45 Cross-cable.................................................52

MP2600D, MP2600C & MP1700E Series Installation Manual V1.4
Maipu Confidential & Proprietary Information Page 7 of 52
Installation Manual
Purpose
The MP2600D, MP2600C & MP1700E Series Installation Manual V1.4
provides technical information to understand the installation issues of the
routers. The document provides right answers to your technical queries.
How to Get in Touch
The following sections provide information on how to obtain support for
the Maipu English documentation and products.
Customer Support
If you have problems or questions regarding your product, please contact
us by e-mail at [email protected]. You can also call our International
Business Department over [phone], 85148041, 85148050,
85148750, and 85148997.
Documentation Support
Maipu Communication Technology Co., Ltd welcomes comments and
suggestions on the document usefulness. For further queries or
suggestions, contact us by e-mail [email protected] or fax comments
to [phone]. You can visit our website at http://www.maipu.com,
which comprises interesting subjects such as product knowledge base,
sales & support, and the Maipu news.

MP2600D, MP2600C & MP1700E Series Installation Manual V1.4
Maipu Confidential & Proprietary Information Page 8 of 52
Overview
MP2600D, MP2600C and MP1700E series routers are highly beneficial for
finance, telecom, tax, and public security industries and large & medium
enterprises. The routers provide a series of highly efficient and low cost
network interconnection solution for integration and powerful functions.
The routers support:
Internet connection
Multi-service data integration
Branch dialup & backup service
Internet & Extranet access

MP2600D, MP2600C & MP1700E Series Installation Manual V1.4
Maipu Confidential & Proprietary Information Page 9 of 52
Product Features
High performance & reliability – The MP2600D, MP2600C and
MP1700E series routers’ CPU provides high performance and RISC
communication processor. The software adapts high performance and
reliable RTOS and network program design.
High port integration - The MP2600D, MP2600C and MP1700E series
routers have two fixed 10/100M fast Ethernet ports, one high-speed
asynchronous interface (1SAE), eight asynchronous interfaces
(MP2600D supports only 8A) and voice card and MIM slots. It has
powerful multi-port access performance, which provides high price-
performance ratio network solution.
Modular system structure - The MP2600D, MP2600C and MP1700E
series routers adapt modular system, which provides different interface
configuration. They support various optional interface modules and
interface cards, and customers choose different extending interfaces
and modules such as Ethernet interface, sync/async interface,
asynchronous interface, E1/CE1 interface, ISDN-U IST interface,
baseband MODEM, frequency band MODEM and VOP/VOS interface.
They also support the site upgrade of all core software and modular
components.
Routing/transmission integration - The MP2600D, MP2600C and
MP1700E series routers integrate CSU/DSU, sync 33.6K MODEM,
asynchronous 33.6K MODEM, ISDN NT1 and ISDN TE into router to
provide required solutions.
Universality - The MP2600D, MP2600C and MP1700E series routers
support a series of Internet protocol standard (RFC) and international
communication network standard.

MP2600D, MP2600C & MP1700E Series Installation Manual V1.4
Maipu Confidential & Proprietary Information Page 10 of 52
Structure - The hardware design adapts lower power consumption
design and integrated structure design, which has powerful
performance on radiation and EMC.

MP2600D, MP2600C & MP1700E Series Installation Manual V1.4
Maipu Confidential & Proprietary Information Page 11 of 52
Hardware Features
MP2600D, MP2600C &
MP1700E Router Appearance
MP2600C router
MP2600D router

MP2600D, MP2600C & MP1700E Series Installation Manual V1.4
Maipu Confidential & Proprietary Information Page 12 of 52
MP1700E router
MP2600D, MP2600C &
MP1700E Front Panel
MP2600D front panel
MP2600C front panel
MP1700E front panel

MP2600D, MP2600C & MP1700E Series Installation Manual V1.4
Maipu Confidential & Proprietary Information Page 13 of 52
Indicators from left to right:
SYS & PWR (system and power supply indicator)
SYS - System status indicator. It shines fast when system is loading, and
after that it shines slowly
PWR - System power supply indicator, and it is on after power on.
SLOT1 (slot 1 status indicator)
ACT - voice card module data indicator
RDY - voice card module link status indicator
SLOT 0 (slot 0 status indicator)
ACT - inserted module data indicator
RDY - inserted module link status indicator
SA (fixed sync/async serial status indicator)
ACT - sync/async serial data indicator
LINK - sync/async serial link status indicator
CONSOLE (console port)
TXD - console port data sending indicator
RXD - console port data receiving indicator
ETHERNET1 (Ethernet interface1)
100M - 10/100M Ethernet interface data rate indicator. On: 100M，off:
10M
ACT - Ethernet interface data indicator
ETHERNET0 (Ethernet interface 0)
100M - 10/100M Ethernet interface data rate indicator. On: 100M/off: 10M
ACT - Ethernet interface data indicator

MP2600D, MP2600C & MP1700E Series Installation Manual V1.4
Maipu Confidential & Proprietary Information Page 14 of 52
ASYN 0-7 (8 async interface) (MP2600D supports)
LINK - asynchronous interface link status indicator
ACT - asynchronous interface data indicator
MP2600D, MP2600C &
MP1700E Back Panel
MP2600D, MP2600C & MP1700E back panel interface configuration
MP2600D, MP2600C & MP1700E back panel interface:
Interface Form Description Application
ON/OFF Power supply switch,
right is OFF; left is ON
INPUT AC 100-240V 1A input
SLOT1 Bus slot VOP/VOS module
SLOT0 Decided by
interface
module
High-speed serial, bus
slot MIM module
S/A DB25 pin High-speed serial High-speed fixed
sync/async
interface
SLOT1 is voice card module slot for VOP/VOS series module; SLOT0 is MIM
slot, adopting modularization design, and its function can be realized
according to different interface card and relevant software modules.

MP2600D, MP2600C & MP1700E Series Installation Manual V1.4
Maipu Confidential & Proprietary Information Page 15 of 52
MP2600D, MP2600C &
MP1700E System
MP2600D, MP2600C & MP1700E router basic configuration and working
environment:
Item Description
Console port One fixed, async DTE working mode (RJ45)
Ethernet interface Two fixed 10/100Mbps fast Ethernet (RJ45)
Async interface Eight fixed async interface (RJ45) - only MP2600D supports
SA interface One fixed high-speed async/sync interface (DB25)
Voice card slot One voice card SLOT1
MIM slot MIM SLOT0, supports various modules
Processor High performance PowerPC processor
FLASH 8MB
SDRAM 64MB
Dimension
(W×D×H) 340×230×44 (mm)
Power supply
input voltage AC: 100 – 240V 50/60HzDC: －40～－57V - only MP1700E
supports.
AC/DC.
Environment
Temperature 0-40℃
Environment
humidity 10-90%. Non-condensing
Power supply
rating power 45W
Maximum power
consumption 15W
MP2600D router has eight fixed asynchronous interfaces with modular and
clip design. MP2600C/MP1700E router doesn’t have this interface.

MP2600D, MP2600C & MP1700E Series Installation Manual V1.4
Maipu Confidential & Proprietary Information Page 16 of 52
Product Functions
MP2600D, MP2600C & MP1700E functions, supported protocols & services:
Supported protocols &
Services Description
Network protocol WAN supports:
PPP
PPP compression
SLIP
CSLIP
Frame relay
Frame relay switching
X.25
X.25 switching
HDLC
LAPB
ISDN
LAN is Ethernet network, and it supports two kinds of
link layer frame format:
Ethernet-II
Ethernet-SNAP
Dialup network MODEM dialup（call in/call out）
CALLBACK
Dialup on demand
Dialup backup
Routing protocol Static routing
Dynamic routing:
RIPv1
RIPv2
OSPF
BGP
IRMP (compatible with CISCO EIGRP protocol)
SNSP (compatible with CISCO ODR protocol)
Dial-on-demand routing (DDR)
Policy routing
Multicast:
IGMP
PIM-SM
PIM－DM
DVMRP
Hot backup:
VRRP
VBRP (compatible with CISCO HSRP protocol)

MP2600D, MP2600C & MP1700E Series Installation Manual V1.4
Maipu Confidential & Proprietary Information Page 17 of 52
Network service ARP
Proxy ARP
L2TP
Configuration command protection
IP packet filtering firewall
IP UNNUMBERED
IP policy routing
DHCP relay
PAP/CHAP check
EASY IP
NAT network concealing
RADIUS check
IPSEC data encryption
IKE
GRE
Load balance
MPLS
QoS service PQ
CQ
WFQ
CBWFQ
LLQ
WRED
CAR
Network management SNMPv1, SNMPv2, SNMPv3
Supporting standard network management (fully
compatible with CISCO)
Configuration via Console port
Local or remote login via local Telnet
Configuration command security isolation function
Chinese/English prompting and help information
Debugging information, for troubleshooting.
Login and managing other products via Telnet
Download and upload configuration file and application
program by FTP
Download and upload configuration file and application
program by TFTP
Colorful distributing debugging information
Log function
Security IP packet filtering firewall, PAP/CHAP, MD5, NAT,
RADIUS, TACACS, IPsec data encryption
MP2600D, MP2600C &
MP1700E Main Board

MP2600D, MP2600C & MP1700E Series Installation Manual V1.4
Maipu Confidential & Proprietary Information Page 18 of 52
The MP2600D, MP2600C & MP1700E main board includes 12/4/4 fixed
interface, one voice card slot, one MIM slot, eight indicators and power
supply slots.
Fixed interface
The MP2600D, MP2600C and MP1700E provide fixed console port, Ethernet
interface, high-speed sync/async interface and asynchronous serial, which
is totally 12/4/4 fixed interfaces.
Console port
Console port attributes:
Attributes Description
Converter type RJ45
Interface standard RS232
BR 9600bps - 115200bps
Supported service Connect to character terminal
Connect to local PC serial, and operate
terminal emulation program command line
interface on PC
Ethernet interface
Ethernet interface attributes:
Attributes Description
Converter type RJ45
Interface number 2
Supported frame format Ethernet_II
Ethernet_SNAP
IEEE 802.2
IEEE 802.3
Working mode 10M/100M adaptive
Full/half-duplex
Auto across
Supported network protocol IP
Novell IPX

MP2600D, MP2600C & MP1700E Series Installation Manual V1.4
Maipu Confidential & Proprietary Information Page 19 of 52
Fixed high-speed sync/async interface
Fixed high-speed sync/async interface attributes:
Attributes Description
Synchronous Asynchronous
Converter type DB25 DB25
Interface standard
and working mode V.24 V.35 EIA/TIA-232
DTE
DCE DTE DCE
Minimum (bps) 1200 1200 300
Maximum (bps) 128K 8M 115.2K
Supported protocols
& Services X25
HDLC
PPP
SLIP
FR
LAPB
Dialup
Backup
HDLC
PPP
SLIP
Fixed 8 asynchronous serial:
Fixed 8 async serial attributes
Attributes Description
Converter type RJ45
Interface standard RS232
Isolation type Supports advanced optical/electric isolation interface
protection technology
BR 9600bps - 115200bps
Supported service MODEM dialup
Async terminal access

MP2600D, MP2600C & MP1700E Series Installation Manual V1.4
Maipu Confidential & Proprietary Information Page 20 of 52
The MP2600D router has eight fixed async interfaces. MP2600D router
interface has the following features:
High port density - It adapts unique 8×1 RJ45 jack converter, which
guarantees highest port density.
Low access cost - Special access cable is not needed for the connection of
eight async interface and terminal or MODEM. From your side, we adapt
normal connected Ethernet cable combing with DB25-RJ45.
Eight asynchronous interfaces connect to DTE or MODEM.
Fixed 8 asynchronous interface connection & connecting mode:
