MAKELSAN 1K User manual

-1-
MAKELSANUPS
1 BRIEF INTRODUCTION
1.1Prolegomenon
The product is designed specially aiming at the requirement of MINI and MICRO
level computer with exquisite quality and excellent function, easy to operate. With the
development of customer office automatism and computerism, considering the bulk and
the position of positing space, the noise disturbance to personnel in office, the light,
thin, short and small product is our design direction, and we stress low noise. So this
product is optimum supply power partner for office and makes you can attain optimal
clean power quality.
1.2 Five design points
1. Small bulk and no occupation space
2. Light weight and convenience to transit
3. Beauty and nature, easy to install
4. Convenient to maintain and easy to operate
5. Package material with environment protection and no pollution to environment
1.3 Note
The manual makes you can operate and maintain the system easily. To normally exert
all functions of the system, please note the following:
1. Read the manual carefully before use
2. Perform the operation strictly according to operating process
3. Place the equipment carefully and lightly when moving the equipment
4. Install the power according to illumination in the manual
5. Please do not open the cover to avoid injury caused by electrical shock
6. Please charge batteries once every a period if no used for long time
7. Do not use UPS on the condition of overload to avoid UPS fault
8. Please carefully keep the manual for the future reference
9. Please handle the system according to "ABNORMITY HANDLING PROCESS" if
there presents any abnormal phenomenon in machine.
10. Please keep UPS neatness and cleanness
BRIEFINTRODUCTION

-2-
MAKELSANUPS
2 CONFIGURATION AND FUNCTION
2.1 Frontpanel
CONFIGURATIONANDFUNCTION
1) Welcome screen
WELCOME TO
2) Display of system status
_Pro
AC: IN BAT: OK
Note: AC indicates utility; BAT indicates battery;
AC: IN indicates utility power is normal;
AC: LOSS indicates utility power is abnormal;
BAT: OK indicates battery is normal;
BAT: LOW indicates battery capacity isn't enough.

-3-
MAKELSANUPS
3) Display of input voltage value
INPUT VOLTAGE
220V 2/8
4) Display of output voltage value
OUTPUT VOLTAGE
220V 3/8
5) Display of input frequency value
INPUT FREQUENCY
50HZ 4/8
6) Display of output frequency value
OUTPUT FREQUENCY
50HZ 5/8
7) Display of battery voltage value
BATTERY VOLTAGE
220V 6/8
8) Display of output power percent
CURRENT LOAD
100% 7/8
9) Temperature display in machine
TEMPERATURE
33 8/8
*These parameters vary with machine model.
CONFIGURATIONANDFUNCTION

-4-
MAKELSANUPS
2.2 Appearance
8 LCD cycle display switch button: digital signal display items switch button.
9 UPS switch button: UPS general switch button.
(1) Turn on UPS inverter by pressing the "ON" key. UPS convert to UPS inverter
power output 20s later, UPS pure AC output power is supplied by UPS internal
power supply equipment.
(2) Turn off UPS inverter by pressing the "OFF" button. UPS convert to utility
bypass.
The button acts as general switch mainly.
10 Emission heat ventilation hole:
The ventilation hole and other small long elliptic ventilation holes should be kept
good ventilation.
CONFIGURATIONANDFUNCTION

-5-
MAKELSANUPS
11 Wiring inlet/outlet hole:
Wiring inlet/outlet hole of input, output and battery pack.
12 DB-9 communication interface receptacle
Standard communication interface between UPS and computer.
13 Power switch:
Power switch controls input, output and battery power switch at the same time.
14 Wiring terminal support
Power wiring terminal support of input, output and battery.
15 Active wheel:
There are four hidden movement wheel, in favor to move.

-6-
MAKELSANUPS
MOVEMENTHANDLING
3 PLACEMENT NOTES
3.1Transit or move
1. Please dismantle all barge connection firstly. (First turn off before performing)
2. Place lightly and carefully, forbid to hit.
3. Please do not move UPS inverted.
3.2 Placement
1. Do not place the UPS on the slope or scraggy land. (Figure 4)
2. Please place the UPS in the place where keeps good ventilation, rear panel of UPS
and two side faces should keep more than 10cm away from the wall. (Figure 5)

-7-
MAKELSANUPS
3. Do not install UPS under sunlight, drain and damp place. (Figure 6, 7)
4. Please keep away from fire source and high temperature to avoid over-high
temperature. (Figure 8)
5. Do not lay goods on the UPS. (Figure 9)
6. Do not install UPS in the place where contains caustic gas. (Figure 10)
PLACEMENTNOTES

-8-
MAKELSANUPS
7. Running environment temperature:
INSTALLATION
4 INSTALLATION
4.1 Input
1. Prohibit using general household socket, because the Max. current of general
socket is 15A, the socket may be burned down because of overload.

-9-
MAKELSANUPS
2. Please connect UPS input terminal to utility power in nearby switchboard. Figure
11.
3. Position and way of connect
(1) Remove two screws with "+" screw-driver (Figure 12)
(2) Open the back panel and inspect the wiring terminal below the power switch.
(Figure13)
4. Relock the special cover after completing connection.
5. Please first fetch in the power cables of input, output and batteries pack through
inlet/outlet hole of distribution electricity and then barge connect to terminal
plate.
INSTALLATION

-10-
MAKELSANUPS
INSTALLATION

-11-
MAKELSANUPS INSTALLATION

-12-
MAKELSANUPS
INSTALLATION
6. Please connect power correctly
Simple identification way to power polarity:
(1) Live (L): There is 220V relative to other two holes.
(2) Neutral (N): there is 220V relative to the Live, there is 0.5-2V relative to the
ground.
(Load current circulate through neutral)
(3) Ground (G): Please find out correct connecting point to the ground in the
switchboard.
7. If the difference between the neutral and the ground is more than 5V or it can't
meet the requirement of system, please reinstall good grounding system to keep
safety of system operation.
8. The comparison list of input current rating and input cable size is as follows:
9. The power cable and the impaction terminal must be first grade product manu-
factured by authentic manufacturer. Prohibit use spent and inferior product.
10.The power cable must be impacted by impaction terminal of authentic
manufacturer, prohibit directly wrapping power cable to the terminal plate.
11.After fastening input cable, please see if the input cable contacts with protection
cover and avoid short-circuit.
12.Please turn off power when connecting cable, prohibit operation on live and keep
safety.
Model Max. input current Input wire Terminal specification
1KVA 8A 3.5mm2(soft wire) 5.5~6
2KVA 12A 5.5mm2(soft wire) 5.5~6
3KVA 18A 5.5mm2(soft wire) 5.5~6
5KVA 24A 5.5mm2(soft wire) 5.5~6
6.25KVA 34A 5.5mm2(soft wire) 5.5~6
10KVA 45A 5.5mm2(soft wire) 8.5~9
12.50KVA 56A 5.5mm2(soft wire) 8.5~9
Table 1

-13-
MAKELSANUPS INSTALLATION
13.Please follow the electrician law when installation.
14.Avoid using the same switch with other equipment when connect to switchboard,
try to connect cable to utility terminal. Figure 14.
15. In 3 4Wsystem, pleaserespectively
measure the voltage between R/N, S/
N, T/N with ammeter firstly and see if
they are close to 220V, then connect
L cable of UPS to the cable whose
voltage measured is the highest
(means supply power of this phase
is lighter than that of other two
phase), the N cable of UPS is con-
nected to utility neutral cable N, the
UPS-GND is connected to grounding
club.
16. If the model of the unit you purchase
is input voltage of 110V, please con-
nect UPS-L cable into live, connect N
cable into neutral cable, and connect
UPS-GND cable to grounding club.
Please note that this equipment is a system of 220V or 110V, do not connect 380V,
andavoidcausinganyfault.

-14-
MAKELSANUPS
INSTALLATION
4.2 Output
1. Please refer to output installation principle when installation.
2. Position and way of connection, refer to figure 15.
3. Output power cable is designed according to load current, do not use over-thin
cable. Please refer to Table 2
4. Avoid short-circuit and overload.
5. The comparison between output current rating and output cable size is listed in
Table 2.
Model Max. input current Input wire Terminal specification
1KVA 6A 3.5mm25.5 6
2KVA 10A 5.5mm25.5 6
3KVA 14A 5.5mm25.5 6
5KVA 17A 5.5mm25.5 6
6.25KVA 22A 5.5mm25.5 6
10KVA 29A 8.5mm28.5 9
12.5KVA 36A 8.5mm28.5 9
Table 2

-15-
MAKELSANUPS INSTALLATION
6. The ground to this unit only acts as reference point, if the ground isn't good, that
may cause disturbance and false datum management, and affect UPS and computer,
please ask professional personnel for handling immediately.
7. User offers a good grounding system.
8. Try to make the ground close to connecting point of grounding club or origination
point in switch- board. Please refer to figure 16.
* Please install wiring according to input voltage system purchased *
Please contact professional personnel or our service department if there is problem
ininstallation.

-16-
MAKELSANUPS
OPERATIONPROCESS
5 OPERATION PROCESS
5.1Preparebeforestart-up.
To make UPS normally and correctly run, please confirm the following items. (Refer
to figure 2)
1. Verify power switch on back panel is on the "OFF" position.
2. Verify the installation position again. (Figure 4 to 10)
3. Rock power cable by hand and see if there is any looseness, retighten them if
looseness.
4. Do not connect load.
5. Inspect if input voltage meet the demand of UPS (220V 10%) with ammeter.
5.2 Operation process for first start-up
After verify the above items are correct, please turn on UPS according to the following
ways:
(Please refer to figure 1, figure 2, figure 3)
1. Please switch power switch
"NON- FUSEBREAKER"(NFB)
on the back panel to the "ON"
position. Input indicator light
and bypass indicator light on
the front panel are lit on at the
same time. As right figure.

-17-
MAKELSANUPS
2. Press the "ON" button on front
panel. As right figure. The input
indicator and the bypass indi-
cator are solid on. LCD display
is lit on. Output is utility pow-
ered via bypass.
3. After 20s, input indicator light on
front panel is lit on, bypass indi-
cator is off, and output indicator
is lit on. The welcome information
is displayed on LCD, output
is UPS inverter powered.
4. Shutdown input power of UPS,
utility indicator light is off, the
welcome information is displayed
on LCD, and output is UPS
inverter powered, as following
drawing. UPS sounds every
four seconds, which indicates
UPS runs on battery mode at
present. The sound will auto-
OPERATIONPROCESS

-18-
MAKELSANUPS
matically stop 90s later. UPS will sound alarm every 1s again when battery power
is to be exhausted.
5. Utility indicator will be lit on when UPS input power source is resumed. Press the
LCD display cycle switch button to switch items displayed, inspect if the display
value is normal, thus first startup procedure has been completed. Please measure
output voltage and see if it meets the requirement, then connect load to UPS
output terminal. Use pure power provided by UPS.
6. After connect load, press LCD display cycle switch button to switch items dis-
played till display the output power display percent %. If the value displayed is
more than 100%, please dismantle the unimportant load till the value displayed is
less than 100%.
5.3Operationprocess for routine turn-off
If you want to switch on/off UPS when daily using, please operate UPS according to
the following ways:
1. You can switch off UPS by pressing the "OFF"button on front panel. At the time
UPS is on bypass mode, output is utility powered and the batteries are charged.
2. Always turn on UPS by pressing down the "ON" button when daily operation.
5.4 Operationprocessforlong-timenoswitchon/off
1. If UPS is not used above ten days, please first turn off UPS by pressing the "OFF"
button on front panel, then switch the power switch NFB on back panel to the
position of "OFF".
2. If UPS is not used above three months, please run UPS for above 24 hours refer to
the first start-up process and keep the battery the full voltage level to extend
battery life.
OPERATIONPROCESS

-19-
MAKELSANUPS STATUSHANDLING
6 STATUS HANDLING
6.1 symbol signification
Note: If indicator light flash, the flash period is synchronal with that of buzzer sounds
1. Panel indicator status is as the right
figure:
(1) UPS running status:
Utility is normal, UPS runs normally
and UPS is used under full-load.
(2) Handling way: needn't handling.
6.2UPSrun status indicationandhandlingwayswhennormal
Please refer to indicator on UPS panel, LCD indicator value and buzzer sound, you
can know if UPS running is normal, if abnormal, please refer to the handling way accord-
ing to panel indicator status.

-20-
MAKELSANUPS
2. panel indicator status is as the right
figure
(1) UPS running status:
Utility is normal, UPS runs normally
and battery capacity is above 90%.
(2) Handling way: needn't handling.
3. panel indicator status is as the right
figure:
(1) UPS running status:
Utilitysuppliespowerof220Vacnor-
mally and UPS runs normally.
(2) Handling way: needn't handling.
4. panel indicator status is as the right
figure:
(1) UPS running status:
Utilityisnormal,UPSrunsnormally
and battery voltage is low.
(2) Handling way: The charger is
fault, please replace charging board.
STATUSHANDLING
